SE060914083E Ver.pptx14E

CONTENTS

● DISASSEMBLING PROCEDURES ............................. 2~18
● PARTS LIST ................................................................. 19,20
● ELECTRICAL PARTS LIST ........................................ 21~36
* Refer to the Service Manual for DY-5MU4R69-T,-2
(34U277, 34W894) unless otherwise stated in this.
MITSUBISHI MOTORS
SERVICE MANUAL
AM / FM-ST ELECTRONIC TUNING RADIO,
CD PLAYER
MITSUBISHI ELECTRIC CORP. SANDA WORKS
Model :
DY-5MU4R69-T-4
MELCO Code : 34U587, 34W936
PART No. : 8701A587, 8701A587
Copyright (C) Mitsubishi Electric Corporation.
DY-5MU4R69-T-3,4
2014 Oct.
(For MMC)
(For MMNA)
Your company internal use only.

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi DY-5MU4R69-T-3

Summary of Contents for Mitsubishi DY-5MU4R69-T-3

  • Page 1 (34U277, 34W894) unless otherwise stated in this. DY-5MU4R69-T-3 Model : (For MMC) DY-5MU4R69-T-4 (For MMNA) MELCO Code : 34U587, 34W936 PART No. : 8701A587, 8701A587 MITSUBISHI ELECTRIC CORP. SANDA WORKS Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 2 DY-5MU4R69-T-3,4 DISASSEMBLING PROCEDURES *It is assembling procedure. Disassembling procedure is in reverse. M019(1)/M030(2) : LABEL M020(1) : NAME-CARD(DY-5MU4R69-T-3) M031(2) : NAME-CARD(DY-5MU4R69-T-4) Model (1) DY-5MU4R69-T-3 (2) DY-5MU4R69-T-4 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 3: Disassembling Procedures

    DY-5MU4R69-T-3,4 DISASSEMBLING PROCEDURES ● Disassembling procedures In reverse of assembling procedures. ● Assembling procedures 1. Attach M025 to S2-CHASSIS. S2-CHASSIS M025 : ASSY-KNOB Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 4 And fit tab D of M012. (4 places) 2. Screw S2-CHASSIS and M012 with Ⓔ. (3 places) M012 : COVER Ⓔ x 3 S2-CHASSIS S2-CHASSIS Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 5: Dy-5Mu4R69-T

    3. Screw S2-CHASSIS and S2-DECK with Ⓔ. (4 places) S2-DECK Ⓔ x 4 S2-DECK M003 : FLAT-CABLE 18P S2-CHASSIS M003 S2-DECK S2-CHASSIS M003 S2-DECK M003 Screw Tighten torque(N・m) S2-DECK Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 6 3. Insert M002 to the connector of S2-CHASSIS. (Connector E) *Lock connector after inserting M002. Ⓐ x 2 S2-PANEL M002 : FLAT-CABLE 30P Ⓐ x 2 S2-CHASSIS Screw Tighten torque(N・m) Ⓐ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 7 ● Disassembling procedures In reverse of assembling procedures. ● Assembling procedures 1. Insert M004 to the connector A and B. *Lock connector after inserting M004. M004 : FLAT-CABLE 60P S2-CHASSIS S2-CHASSIS Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 8 4. Screw M009 and S3-CHASSIS with Ⓔ. (9 places) M009 : CHASSIS-REAR Ⓔ x 11 M014 : HOLDER-FAN M005 : MOTOR-FAN M009 M014,M005 Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 9 1. After inserting the convex position of S3-CHASSIS into the locating hole of M008, screw M008 and S3-CHASSIS with Ⓔ. (4 places) S3-CHASSIS Ⓔ x 4 M008 : CHASSIS-F Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 10 4. Screw S4-CHASSIS and CHASSIS-M with Ⓕ. (1 place) CHASSIS-M Ⓔ x 2 S4-CHASSIS Ⓔ x 4 Ⓕ Ⓕ Ⓕ M016 : HEAT-SINK Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Ⓕ 2.6X12 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 11 1. Insert the locating convex of M007 into the locating hole of M027. (2 places) And fit M027 to M007. 2. Screw M027 with Ⓔ. (7 places) Ⓔ x 7 M027 : ASSY-PCB-MEDIA-T M007 : CHASSIS-M Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 12 2. After inserting locating hole on M021 into locating convex on M006, screw with Ⓔ. (4 places) Ⓔ x 4 M021 : S5-PCB-MAIN-T M029 M006 : CHASSIS-B Screw Tighten torque(N・m) Ⓔ 0.4 ± 0.1 2.6X6 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 13 1. After inserting the locating convex of M013 into the locating hole of M026, screw M026 and M013 with Ⓓ. (2 places) 2. Note that M026 handling prohibited area. Ⓓ x 2 M013 : HOLDER-CD8 M026 Screw Tighten torque(N・m) Ⓓ 0.8 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 14 (The right side of the bottom center.) M022 : ASSY-PANE Detail of M022 assembly work M022 M022. S3-LCD Rearranging point of M022 Screw Tighten torque(N・m) ASSY-PANEL Ⓒ 0.4 ± 0.1 2.6X6 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 15 2. After inserting locating hole on PCB-SW-L into locating pin on M024, and screw with Ⓑ. (3 places) Ⓑ x 4 PCB-SW-R Ⓑ x 3 PCB-SW-L M024 : ASSY-PANEL Screw Tighten torque(N・m) Ⓑ 0.2 +0.15/-0.04 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 16 3. Insert FPC-1 into connector on M028 and certainly fasten connector of M028. 4. Insert FPC-2 into connector on M028 and certainly fasten connector of M028. Ⓔ x 6 M028 : ASSY-PCB-MONI-T HOLDER-LCD-RE Screw Tighten torque(N・m) Ⓔ 2.6X6 0.5 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 17 Ⓖ x 2 M010 M015 : HOLDER-LCD-R M015 Ⓖ x 2 M011 : HOLDER-LCD-L ASSY-LCD M010 M010 : HOLDER-LCD-RE M011 ASSY-LCD M010 ASSY-LCD Screw Tighten torque(N・m) Ⓖ M2X2 0.2 +0.15/-0.04 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 18 4. After attach, remove the release paper of M017 and M018. M023 : ASSY-LCD Bending point of the FPC. M017 : SHEET-TP TAPE- M023 : POLYESTER ASSY-LCD M018 : SHEET-TP TAPE-POLYESTER M023 M017 : SHEET-TP M023 M023 M023 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 19: Parts List

    SCREW-D-PAN 3X6 M016 635L09111 HEAT-SINK P.10 655P03028 SCREW-D-BIND 2.6X6 M017 644L19010 SHEET-TP P.18 655P03033 SCREW-D-BIND 2.6X12 M018 644L19011 SHEET-TP P.18 653P01556 SCREW-MC-PAN-PR1B M2X2 * Marked part is the ASSY replacement. Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 20: Parts List

    SCREW-D-PAN 3X6 M016 635L09111 HEAT-SINK P.10 655P03028 SCREW-D-BIND 2.6X6 M017 644L19010 SHEET-TP P.18 655P03033 SCREW-D-BIND 2.6X12 M018 644L19011 SHEET-TP P.18 653P01556 SCREW-MC-PAN-PR1B M2X2 * Marked part is the ASSY replacement. Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 21 GRM155B31C104KA87D B 16V 104K 1005 N931L65519 C300 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N931L65419 C205 141P154O6 C-CERAMIC-CHIP GRM155B31C104KA87D B 16V 104K 1005 N931L65519 C300A 141L063O2 C-CERAMIC-CHIP GRM21BB11H104KA11L B 50V 104K2125 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 22: Electrical Parts List

    C3D2 181P80123 C-ELECTROLYTIC-CHIP UWX1C100MCL1GB 16V 100M N931L65519 C408 141P154O2 C-CERAMIC-CHIP EMK105BJ223KV-F B 16V 223K1005 N931L65519 C3D3 181P80123 C-ELECTROLYTIC-CHIP UWX1C100MCL1GB 16V 100M N931L65519 C409 141P159O0 C-CERAMIC-CHIP GRM155B11A104KA01D B 10V 104K1005 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 23 GRM1552C1H102JA01D CH 50V 102J1005 N931L65519 C73E 141P161O5 C-CERAMIC-CHIP GRM1552C1H150JA01D CH 50V 150J1005 N937L56118 C5C3 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N931L65519 C73F 141P161O5 C-CERAMIC-CHIP GRM1552C1H150JA01D CH 50V 150J1005 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 24 CM05W5R471K50AH B 50V 471K1005 N937L56118 C79E 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N937L56118 C769 141P159O0 C-CERAMIC-CHIP GRM155B11A104KA01D B 10V 104K1005 N937L56118 C79F 141P161O3 C-CERAMIC-CHIP GRM1552C1H120JA01D CH 50V 120J1005 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 25 C893 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N937L56118 D560 264P560O3 DIODE-ZENER-CHIP UDZS-TE-17 6.2B N931L65519 C894 141P170O2 C-CERAMIC-CHIP GRM32RB11H105KA01L B 50V 105K 3225 N937L56118 D5A1 264P59629 DIODE-ZENER-CHIP UDZS-TE-17 22B N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 26 COIL-CHOKE BLM15BA100SN1D 1005 N931L65519 IC301 262P07711 IC-TAPE SM6451AT-G-E2 N931L65519 L125 351P031O6 COIL-CHIP FSLM2520-2R2J=P2 2R2M 2520 N931L65519 IC302 266P511O3 IC-TAPE NJM4580M-D DMP 8P N931L65519 L126 351P031O6 COIL-CHIP FSLM2520-2R2J=P2 2R2M 2520 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 27 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N937L56118 L4C7 351P12322 COIL-CHIP BK1005HS601 N931L65519 L705 351P093O5 COIL-CHIP BK1608HM102-T HM102 1608 N937L56118 L4D4 351P086O1 COIL-CHOKE-CHIP LB2016T2R2M 2R2M 2125 N931L65519 L707 351P12430 COIL-CHIP FBMH3216HM501NT HM501 3216 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 28 COIL-CHIP BK1005HS241 N937L56118 L8P4 351P12321 COIL-CHIP BK1005HS241 N937L56118 L77L 351P12321 COIL-CHIP BK1005HS241 N937L56118 L8P5 351P096O2 COIL-CHIP BK1608TS601-T TS601 1608 N937L56118 L77M 351P12321 COIL-CHIP BK1005HS241 N937L56118 L8P6 351P12321 COIL-CHIP BK1005HS241 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 29 1/10W 331J 1608 N931L65519 Q572 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N931L65519 R014 103L291O6 R-CHIP RMC1/16181JTP 1/10W 181J 1608 N931L65519 Q575 260M06214 TRANSISTOR-CHIP DTA114EUA T106 N931L65519 R014S 103L291O6 R-CHIP RMC1/16181JTP 1/10W 181J 1608 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 30 R-CHIP RMC1/16SJPTH 1/16W 0 1005 N931L65519 R2A2 103P151O1 R-CHIP RMC1/16S680JTH 1/16W 680J 1005 N931L65519 R205 103P159O9 R-CHIP RMC1/16SJPTH 1/16W 0 1005 N931L65519 R2A3 103P151O1 R-CHIP RMC1/16S680JTH 1/16W 680J 1005 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 31 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N931L65519 R405 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N931L65519 R3A5 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N931L65519 R406 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 32 R-CHIP RPC03T154F 1/16W 154F 1005 N937L56118 R557 103P504O3 R-CHIP RMC1/16333FTP 1/10W 333F 1608 N931L65519 R4V9C 103P164O6 R-CHIP RPC03T563F 1/16W 563F 1005 N937L56118 R558 103P505O3 R-CHIP RMC1/16224FTP 1/10W 224F 1608 N931L65519 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 33 R-CHIP RMC1/16S473JTH 1/16W 473J 1005 N931L65519 R72E 103P115O3 R-CHIP RGC1/16SC224DTH 1/16W 224D 1005 N937L56118 R5G5 103P154O5 R-CHIP RMC1/16S473JTH 1/16W 473J 1005 N931L65519 R72F 103P152O5 R-CHIP RMC1/16S102JTH 1/16W 102J 1005 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 34 R-CHIP RMC1/16S472JTH 1/16W 472J 1005 N937L56118 R791 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N937L56118 R75C 103P153O3 R-CHIP RMC1/16S472JTH 1/16W 472J 1005 N937L56118 R792 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 35 R-CHIP RGC1/16SC202DTH 1/16W 202D 1005 N937L56118 R8AJ 103P111O6 R-CHIP RGC1/16SC181DTH 1/16W 181D 1005 N937L56118 R83S 103P154O1 R-CHIP RMC1/16S223JTH 1/16W 223J 1005 N937L56118 R8AK 103P120O4 R-CHIP HPC03KT200D 1/16W 200D 1005 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
  • Page 36 R-NETWORK-CHIP RAC104D220JCTH 1/16W 220J 2010 N937L56118 RA761 109P020O9 R-NETWORK-CHIP RPB03T4470J 1/16W 470J 2010 N937L56118 RA762 109P020O9 R-NETWORK-CHIP RPB03T4470J 1/16W 470J 2010 N937L56118 RA763 109P020O9 R-NETWORK-CHIP RPB03T4470J 1/16W 470J 2010 N937L56118 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
