Owner's Manual & Safety Instructions
Save This Manual
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and
the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright
2012 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly, operating,
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SaVE thiS manual.
ITEM 69033

Advertisement

Table of Contents
loading

Related Manuals for Central Machinery 69033

Summary of Contents for Central Machinery 69033

  • Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Visit our website at: http://www.harborfreight.com ITEM 69033 Email our technical support at: tech@harborfreight.com When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Table Of Contents

    8. USE RIGHT TOOL. Don’t force tool or attachment Don’t use power tools in damp or wet locations, to do a job for which it was not designed. or expose them to rain. Keep work area well lighted. Page 2 For technical questions, please call 1-800-444-3353. Item 69033...
  • Page 3 It’s safer than using your 21. NEVER LEAVE TOOL RUNNING UNATTENDED. hand and it frees both hands to operate tool. TURN POWER OFF. Don’t leave tool until it comes to a complete stop. Item 69033 For technical questions, please call 1-800-444-3353. Page 3...

  • Page 4: Sander Safety Warnings

    DamaGED, OR REmOVED. moving guards pulled into the machine. For safety, it must be must move freely and close instantly. adjusted very close to the sanding surface. Page 4 For technical questions, please call 1-800-444-3353. Item 69033...

  • Page 5: Vibration Safety

    If you feel any medical or vibration occurs, stop use immediately. physical symptoms related to vibration (such as tingling, numbness, and white or blue fingers), seek medical advice as soon as possible. SaVE thESE inStRuCtiOnS. Item 69033 For technical questions, please call 1-800-444-3353. Page 5...

  • Page 6: Specifications

    5. Secure in place with the hardware (sold separately) as shown at left. note: Hardware must be strong enough to withstand the weight and pressure of the Sander. Page 6 For technical questions, please call 1-800-444-3353. Item 69033...
  • Page 7 Belt 8. Tighten the Tension Knob, turning clockwise. 9. Replace the Guards, Belt Cover and the Belt Table (see page 8). Proceed to Adjusting Belt Tracking. Driving Wheel Figure D Item 69033 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 3. To tilt the Belt Table for bevel sanding. Loosen the Table Lock Handle and tilt the Belt Table Figure G: adjusting the Belt table forward then tighten the Table Lock Handle. Page 8 For technical questions, please call 1-800-444-3353. Item 69033...
  • Page 9 Disc, then tighten the Disc Guard Adjustment Bolts. 3. Clean any saw dust or debris from around the Disc Plate. Tighten all handles and screws. 4. Press a new PSA Sanding Disc onto the Disc Plate. Item 69033 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10 Tension Knob Sanding Belt ON/OFF Switch Disc Guard Belt Table Sanding Disc Disc Table Lower Belt Guard Base Miter Guide Belt Table Lock Handle Disc Table Lock Handle Figure l Page 10 For technical questions, please call 1-800-444-3353. Item 69033...

  • Page 11: Operation

    6. To prevent accidents, turn off the tool and disconnect its power supply after use. Clean, then store the tool indoors out of children’s reach. Item 69033 For technical questions, please call 1-800-444-3353. Page 11...

  • Page 12: Sanding Tips

    Belt will have some give, and will light contact until the bevel is sharpened. better contact the curved edges of the workpiece. Page 12 For technical questions, please call 1-800-444-3353. Item 69033...

  • Page 13: Maintenance

    See table a on page 3. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. Item 69033 For technical questions, please call 1-800-444-3353. Page 13...

  • Page 14: Parts List And Diagram

    Belt Table Clip Lower Belt Guard Belt Tension Knob Bolt M8×25 Belt Tracking Bolt M10×30 Pulley Axle Dust Chute Sanding Belt 1" x 30" Screw Side Cover Spring Cover Knob Handle Page 14 For technical questions, please call 1-800-444-3353. Item 69033...

  • Page 15: Assembly Diagram

    Diagram Item 69033 For technical questions, please call 1-800-444-3353. Page 15...

  • Page 16: Warranty

    limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
