Page 1: Table Of Contents
GSM TELEPHONE GT-S3600L GSM TELEPHONE CONTENTS 1. Safety Precautions 2. Specification 3. Product Function 4. Array course control 5. Exploded View and Parts list 6. MAIN Electrical Parts List 7. Block Diagrams 8. PCB Diagrams 9. Chart of Troubleshooting 10. Reference data 11. - Page 2 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. ⓒ Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2009. 01. Rev.1.0...
-
Page 3: Safety Precautions
― Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 4 ― You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 5: Specification
0pcl ~ 15pcl 0pcl ~ 15pcl 0pcl ~ 15pcl Sen sitivity - 102dBm - 102dBm - 100dBm - 100dBm TDMA Mux Cell Radiu s 35Km 35 Km SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 6: Gsm Tx Power Class
8±4dBm 8±4dBm 11±3 dBm 6±4 dBm 6±4 dBm 9±3dBm 4±4 dBm 4±4 dBm 7±3 dBm 2±5 dBm 2±5 dBm 5±3 dBm 0±5 dBm 0±5 dBm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 7: Product Function
3) UART1,2(920Kbps) & IIC(400Kbps) &SPI(13MHz,26MHz)1/2/3 & IIS support 4) Multimedia support(64 poly General MIDI & WMA,MP3,AAC,AAC+) 5) USB2.0 Full Speed Interface support 6) Burst mode Memory support SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 8: Array Course Control
4. Array course control 4-1. Software Adjustments Test Cable (GH39-01160A) Test Jig (GH99-36900A) RF Test Cable (GH39-00985A) Adapter (GH99-38251A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 9 - if the tfs file wanted, check only 'TFS' - if all the files wanted, check 'BIN+TFS' 3/4. Select the file(s) what you want to download SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 10 Array course control 5/6. Choose the binary/tfs file then click open button. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 11 7. After you select the binary/tfs file you want to download, then click 'START' button. Then connect a phone with test cable. If connection has no problem, the downloader will start pre-downloading. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 12 Array course control 8. Finished the pre-downloading, click 'confirm'(8) button. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 13: Exploded View And Parts List
5. Exploded View and Parts List 5-1. Cellular phone Exploded View SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 14 - This Document can not be used without Samsung's authorization - 5-2. Cellular phone Parts list : GT-S3600RKAXEB Design LOC Description SEC CODE QAN01 INTENNA-GT_S3600 GH42-01768A QAN03 INTENNA-BT(GT_S3600) GH42-01770A QBA00 PMO COVER-BATTERY GH72-49614B QBA01 INNER BATTERY PACK-880MAH,BLK,UNI,MAIN GH43-03248A QBR04 ASSY BRACKET-KEYPAD...
- Page 15 - This Document can not be used without Samsung's authorization - 5-2. Cellular phone Parts list : GT-S3600TIISER Design LOC Description SEC CODE QAN01 INTENNA-GT_S3600 GH42-01768A QAN03 INTENNA-BT(GT_S3600) GH42-01770A QBA00 PMO COVER-BATTERY GH72-49614C QBA01 INNER BATTERY PACK-880MAH,BLK,UNI,MAIN GH43-03248A QBA01 ADAPTOR-SGHC275L,BLK,EU...
- Page 16 - This Document can not be used without Samsung's authorization - 5-2. Cellular phone Parts list : GT-S3600TIISER Design LOC Description SEC CODE QBR04 C-CER,CHIP 2203-005057 QBR04 C-CER,CHIP 2203-005234 QBR04 C-CER,CHIP 2203-005281 QBR04 C-CER,CHIP 2203-005395 QBR04 C-CER,CHIP 2203-005446 QBR04 C-CER,CHIP...
- Page 17 - This Document can not be used without Samsung's authorization - 5-2. Cellular phone Parts list : GT-S3600TIISER Design LOC Description SEC CODE QFU01 INA-TEST JIG COMM GH99-36900A QFU01 INA-XPLUG ADAPTER GH99-38251A QHI01 ASSY MEC-HINGE GH75-07144A QIF01 PMO COVER-IF GH72-49615C...
-
Page 18: Main Electrical Parts List
R-CHIP R403,R404,R413,R414 2007-000242 R-CHIP R307,R316,R421 R-CHIP 2007-000758 R405,R408,R409,R410 2007-001291 R-CHIP R411 2007-001291 R-CHIP R210,R211 2007-001319 R-CHIP R317,R400,R401,R432 2007-001333 R-CHIP R402 2007-001339 R-CHIP R206,R412 2007-002796 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 19 C-CERAMIC,CHIP C215,C322,C324,C327 2203-006048 C-CERAMIC,CHIP C332,C401,C404,C409 C-CERAMIC,CHIP 2203-006048 C412,C414,C415,C416 2203-006048 C-CERAMIC,CHIP C307,C311,C313 2203-006208 C-CERAMIC,CHIP C136,C138,C301,C308 2203-006257 C-CERAMIC,CHIP C310,C312,C314,C316 2203-006257 C-CERAMIC,CHIP C325,C329,C330,C331 2203-006257 C-CERAMIC,CHIP C139,C141,C300,C418 2203-006260 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 20 3711-006256 CONNECTOR-HEADER HDC400 3711-006483 CONNECTOR-HEADER BAT300 4302-001177 BATTERY Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 21: Pcb Diagrams
8. PCB Diagrams BH202 R300 C412 R404 R431 C401 C402 ZD406 C427 C216 ZD400 C415 C416 C403 OSC300 C209 C300 C316 C211 R306 R313 C320 C318 L115 R305 L300 R205 UME200 C309 R202 C321 R312 BTC300 BH200 BH201 R315 C207... - Page 22 PCB Diagrams Bottom ANT102 ANT101 F400 F401 F402 F403 F404 C117 C133 C140 F100 HDC400 R107 L109 C429 U102 L104 TP_RXD2 C204 C203 C200 C106 L100 TP_VC1 C304 TP_VC2 C305 L101 R102 C113 C143 C119 TP_RTS2 D100 C335 R317 TP_TXD2 TP_CTS2 RFS100 C110...
-
Page 23: Chart Of Troubleshooting
Check the +VDD_GSM_CORE circuit = 1.9V? Check for the clock at C141 Check the clock generation circuit = 26MHz (related to OSC100) Check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 24 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 25 Flow Chart of Troubleshooting 9-2. Initial Initial Failure PMU300 pin 7 (RSTON) ="H"? Check the circuit related to reset Check the 16bit data signal & memory CE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 26 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 27: Charging Part
Check the circuit related to PMU300 pin 34 = "L"? AUX_ON signal Check the circuit related to Check the PMU300 pin 46 ≒ 4.2V MES_BATT signal SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 28 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 29: Sim Part
Check the Clock pin3 of SIM300 in a few second After SIM card insert, Replace PBA SIM300 pin 2 = "H(SIM_RST)"? Check the SIM Card SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 30 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 31: Microphone Part
Check the path around MIC bias circuit Check the circuit Check the path from MainIC to MIC from UCP200 to MIC Check the MIC Replace the MIC SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 32 Flow Chart of Troubleshooting 9-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 33 Pin Resolder or replace C417,C419 A4,B4 of U400>1.3V Check the signal at Resolder or replace U400 E4,E5 U400 Is Speaker working? Change the Speaker 9-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 34 Flow Chart of Troubleshooting 9-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 35: Key Data Input
Check the Dome sheet & Key Pad pushed, is it displayed on LCD? When one of the keys is Replace the PBA pushed, KBIO signal is OK? 9-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 36: Receiver Part
Flow Chart of Troubleshooting 9-8. Receiver Part Receiver does not work Resolder UCP200 or change PBA Is Receiver working? Replace the Receiver Is Receiver working? 9-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 37 Backlight does not work Is LCD Contrast set on high Set LCD Contrast on high level level in the Menu? Replace the LCD Module 9-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 38: Key Back Light
Flow Chart of Troubleshooting 9-10. Key Back Light Main key LED does not work PMU300 pin23(D6VDD)C329= Check the VDD_MAIN_KEY_3.3V line 9-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 39: Gsm850 Transmitter
>= 20dBm pin15=H(2.6V) Check ANT Switch control circuit RFS100 Pin1 Resolder L101, C107 >= 20dBm Check U200 Ant100 Pin17 Resolder L103, R104 >= 20dBm 9-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 40: Gsm900 Receiver
24 >= -70dBm Check U100 pin 4,5,6,7 U100 pin 11,12,32,33 U101, OSC100 >= 1V >=2.8V RF26MHz, RF PSU Part Resolder U100 Check UCP200 9-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 41: Gsm900 Transmitter
>= 20dBm pin15=H(2.6V) Check ANT Switch control circuit RFS100 Pin1 Resolder L101, C107 >= 20dBm Check U200 Ant100 Pin17 Resolder L103, R104 >= 20dBm 9-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 42: Dcs Receiver
22 >= -70dBm Check U100 pin 4,5,6,7 U100 pin 11,12,32,33 U101, OSC100 >= 1V >=2.8V RF26MHz, RF PSU Part Resolder U100 Check UCP200 9-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 43: Dcs Transmitter
>= 20dBm pin15=H(2.6V) Check ANT Switch control circuit RFS100 Pin1 Resolder L101, C107 >= 20dBm Check U200 Ant100 Pin17 Resolder L103, R104 >= 20dBm 9-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 44: Pcs Receiver
20 >= -70dBm Check U100 pin 4,5,6,7 U100 pin 11,12,32,33 U101, OSC100 >= 1V >=2.8V RF26MHz, RF PSU Part Resolder U100 Check UCP200 9-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 45: Pcs Transmitter
>= 20dBm pin15=H(2.6V) Check ANT Switch control circuit RFS100 Pin1 Resolder L101, C107 >= 20dBm Check U200 Ant100 Pin17 Resolder L103, R104 >= 20dBm 9-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 46 Flow Chart of Troubleshooting 9-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 47 Flow Chart of Troubleshooting 9-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 48: Reference Data
― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 49: Disassembly And Assembly Instructions
2) Disjoint HOOK on the side of the REAR BRACKET, lift REAR. - Be careful Locker damage when you Disjoint a REAR - Be careful not to damage LCD FPCB and molding. 11-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 50 - Be careful not to make scratch and molding damage. - Be careful not to make scratch and molding damage. - Be careful not to damage LCD FPCB, When separating FRONT and LOWER. 11-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 51 2) Disjoint HOOK on the side of the LOWER - Be careful not to make scratch and molding damage. - Be careful not to make scratch and molding damage. 11-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 52 - Be careful not to damage LCD FPCB - Be careful not to damage CAMERA FPCB - Be careful not to damage Motor & Speaker wire 11-4 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 53 - Check GAP is exist after finish assembly. - Be careful not to make scratch and molding damage. - Be careful not to damage LCD FPCB 11-5 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 54 3) Joint LCD CONNECTOR, KEY CONNECTOR, INTENNA CONNETOR. - Be careful not to damage LCD FPCB - Be careful not to make scratch and molding damage 11-6 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 55 - Be careful not to make scratch and molding - Be careful not to make scratch and molding damage damage - Check GAP is exist after finish assembly. 11-7 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
