USER MANUAL
TABLE OF CONTENTS
FOR YOUR SAFETY............................................................
SAFETY PRECAUTIONS............................................
CUSTOMER SERVICE................................................
CLEANING...................................................................
BEFORE YOU OPERATE THE MONITOR..........................
FEATURES..................................................................
ACCESSORIES...........................................................
FOR WINDOWS 95/98/ME/2000 USERS.......................
LOCATION OF CONTROLS........................................
CONNECTING YOUR MONITOR..................................
OPERATING THE MONITOR................................................
ADJUSTMENT MENU CONTENTS..............................
POWER MANAGEMENT FEATURE.............................
SELF DIAGNOSIS FUNCTION........................................
TROUBLE SHOOTING........................................................
APPENDIX............................................................................
SPECIFICATIONS.......................................................
PRESET MODES.........................................................
CONNECTOR PIN ASSIGNMENT.................................
Thank you very much for choosing the iiyama Vision Master color monitor.
We recommend that you take a few minutes to read carefully through this brief but comprehensive
manual before installing and switching on the monitor. Please keep this manual in a safe place
for your future reference.
HM903DT
A902MT-v
ENGLISH
DEUTSCH
FRANCAIS
1
1
NEDERLANDS
3
3
SVENSKA
4
4
ITALIANO
4
4
5
6
7
8
13
13
14
16
16
17
17
Advertisement
Table of Contents
Related Manuals for Iiyama HM903DT
Summary of Contents for Iiyama HM903DT
-
Page 1: Table Of Contents
PRESET MODES............CONNECTOR PIN ASSIGNMENT......... Thank you very much for choosing the iiyama Vision Master color monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place... -
Page 2: Why Do We Have Environmentally Labelled Computers
Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. -
Page 3: Environmental Requirements
Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. -
Page 4: Fcc Declaration Of Conformity
To meet the FCC requirements, the specified signal cables below should be used. Signal Cable MB30 (Enclosed): 242Z013-01 Signal Cable MB31 (Optional): 242Z017-01 CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the equipment under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE STATEMENT This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulation of the Canadian department of communications. -
Page 5: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 6 CAUTION MAINTAIN GOOD VENTILATION Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause fire. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls. Do not remove the tilt stand when operating the monitor. Ventilation slots on the cabinet bottom will be blocked and the monitor may overheat if the stand is removed.
-
Page 7: Customer Service
To reduce fatigue use the Text mode or take a short break. CUSTOMER SERVICE NOTE If you have to return your unit for service and the original packaging has been discarded, please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING WARNING... -
Page 8: Before You Operate The Monitor
10A / 250V must be used. FOR WINDOWS 95/98/ME/2000 USERS Windows 95/98/Me/2000 Monitor Information File for iiyama monitors may be obtained via the Internet, using the address: http://www.iiyama.com (U.S.A.) http://www.iiyama.co.uk (U.K.) -
Page 9: Location Of Controls
LOCATION OF CONTROLS A Speakers Front The volume control is performed with the On Screen Display. Press the Buttons and then the Menu Button continuously when the Menu is not displayed. B Power Indicator C Input Select Button (VIDEO 1/2) Select either VIDEO IN 1 or 2 for the signal input when both of the signal inputs are connected to a signal source. -
Page 10: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 11: Operating The Monitor
OPERATING THE MONITOR The iiyama Vision Master has been preset at the factory with the signal timings listed on page 17 in PRESET MODES to create the best picture. If an incorrect picture appears during the operation, adjust the image by following the procedure below to get the desired picture. -
Page 12: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Direct You can skip the Menu pages and display an adjustment scale directly by using the following button operations. l Volume Control: Press the Buttons and then the Menu Button continuously when the Menu is not displayed. l Contrast/Brightness: Press the Buttons when the Menu is not displayed. - Page 13 Main Menu Sub-Menu Problem / Option Button to Press Too small Zoom Too large Screen Too small Control H-Size Too large Too small V-Size Too large Too far to the left H-Position Too far to the right Too low V-Position Too high Return to Menu Return to Main Menu.
- Page 14 Main Menu Sub-Menu Problem / Option Button to Press To correct misconvergence H-Convergence for vertical lines Picture To correct misconvergence Quality V-Convergence for horizontal lines To correct vertical H-Moire wavy lines Moiré is the result of interference between the phosphor layout and the NOTE video signal.
- Page 15 Main Menu Sub-Menu Problem / Option Button to Press Top-Left To correct discoloration Landing To correct discoloration Top-Right Bottom-Left To correct discoloration Bottom-Right To correct discoloration Return to Menu Return to Main Menu. Too far to the left OSD H-Position Too far to the right Function Too low...
- Page 16 Main Menu Sub-Menu Option Any changes are automatically saved in Auto Save Recall the memory when the On Screen Display disappears. Function Turning off the power should be avoided while NOTE using the Menu. Reset Factory-preset data is restored. Performing this operation resets any adjustment NOTE data made by the user to the factory-preset frequencies.
-
Page 17: Power Management Feature
B Turn ON the monitor. Diagnosis A A color bar picture is displayed: The monitor is working normally. Check the computer. B A color bar picture is not displayed: The monitor may be damaged. Contact your dealer or iiyama service center. OPERATING THE MONITOR... -
Page 18: Trouble Shooting
THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... - Page 19 Normal phenomenon on ‘Diamondtron M /NF-CRT’ monitors Misalignment of Aperture Grille Due to the nature of the Diamondtron M /NF-CRT, in rare cases, a misalignment of the aperture grille may happen by the shock or vibration caused during transportation. If a black vertical line appears on the screen, apply a light shock to the side of the monitor with your hand.
-
Page 20: Appendix
APPENDIX SPECIFICATIONS 19" (18.0" / 46cm viewable), Aperture Grille pitch Center: 0.25mm, Edges: 0.27mm, 90 degree deflection, Short persistence phosphor, Anti-reflection & Anti-static coating HM903DT: Diamondtron M -CRT A902MT-v: Diamondtron NF-CRT Sync Frequency Horizontal: 30.0-130.0kHz, Vertical: 50-200Hz Video Bandwidth 345MHz dot clock Recommended Resolution 1280 ×... -
Page 21: Preset Modes
PRESET MODES The following chart indicates the Factory Preset Modes. Sync Polarity Horizontal Vertical VESA Timing Name Frequency Frequency 640×480 @60Hz 31.47kHz 59.9Hz Negative Negative 640×480 @85Hz Negative 43.27kHz 85.0Hz Negative 800×600 @85Hz 53.67kHz 85.1Hz Positive Positive 1024×768 @85Hz 68.68kHz 85.0Hz Positive Positive...
