BUCKSTOVE
MODEL 74 ROOM HEATER
NON-CATALYST
FIREPLACE INSERT & FREESTANDING
FEATURES
PREPARATIONS
INSTALLATION
OPERATION
MAINTENANCE
SAFETY

SAFETY NOTICE

IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
FOR YOUR SAFETY, FOLLOW THE
INSTALLATION
INSTRUCTIONS.
CONTACT
LOCAL
BUILDING
OR
FIRE
OFFICIALS
CONCERNING
RESTRICTIONS AND INSTALLATION INSPECTIONS IN YOUR AREA.
TESTED AND LISTED BY: ITS/WARNOCK HERSEY, MIDDLETON, WI
MANUFACTURED BY
NEW BUCK CORPORATION - SPRUCE PINE, NC 28777
5/2007
