Interlogix IFS NS4802-24P-4S-2X Quick Start Manual

IFS NS4802-24P-4S-2X Quick Start Guide
Content
Package Contents 1
Requirements 1
Terminal Setup 2
Logon to Console 2
Configuring IP Address 2
Starting Web Management 3
Saving Configuration 4
Recovering Back to Default Configuration 5
Contact information 5
This is the IFS NS4802-24P-4S-2X Quick Start Guide. This
document provides basic instructions for installing and using
the IFS NS4802-24P-4S-2X.

Package Contents

Thank you is for purchasing IFS NS4802 - L2+ 24-Port
10/100/1000T 802.3at PoE + 2-Port 10G SFP+ Managed
Stackable Switch. The description of this model is shown
below:
NS4802-24P- L2+ 24-Port 10/100/1000T 802.3at PoE + 2-
4S-2X Port 10G SFP+ Managed Stackable Switch
Open the box of the Managed Switch and carefully unpack it.
"Stackable PoE Managed Switch" is used as an alternative
name in this Quick Start Guide The box should contain the
following items:
• The Stacking Managed Switch x 1
• Installation Guide x 1
• Quick Installation Guide x 1
• RJ45 to RS232 Cable x 1
• Rubber Feet x 4
• Two Rack-mounting Brackets with Attachment Screws x 1
• Power Cord x 1
P/N 1073041 • REV A • 10SEP15
• SFP Dust-proof Cap x 8
If any item is found missing or damaged, please contact your
local reseller for replacement.

Requirements

•
Workstations running Windows XP/2003/Vista/7/8/2008, or
other platforms are compatible with TCP/IP protocols.
•
Workstations are installed with Ethernet NIC (Network
Interface Card)
•
Serial Port Connection (Terminal)
• The above Workstations come with COM Port (DB9) or
USB-to-RS232 converter.
• The above Workstations have been installed with
terminal emulator, such as Hyper Terminal included in
Windows XP/2003.
• Serial cable -- one end is attached to the RS232 serial
port, while the others end to the console port of the
Managed Switch.
• Ethernet Port Connection
• Network cables -- Use standard network (UTP) cables
with RJ45 connectors.
• The above PC is installed with Web Browser and JAVA
runtime environment plug-in.
It is recommended to use Internet Explore 8.0 or above
to access the Web Smart PoE Switch. If the Web
interface of the Web Smart PoE Switch is not accessible,
please turn off the anti-virus software or firewall and then
try it again.
1
