MP3 Player (C670) User' s Manual
Copyright Protection
This manual contains information protected by copyright law. All rights are
reserved. No part of this files may be used or reproduced in any form or by
any means, or stored in a database/retrieval system without prior written
permission from Netac Technology Co., Ltd.
Overview
Thank you for purchasing Netac MP3 Player (C670), which is a unique
designed device combining MP3 player, recorder, FM receiver, SD/MMC
Card reader and Flash Drive.
Features
High definition array LCD with indigo backlight
Playback MP3/WMA music files
Stereo output
Lyric shows while music is playing back
Support English, Traditional & Simplified Chinese Fonts
Start from where it was shut down
With multiple Playback Mode & Sound Mode
Support A-B repeat
Support SD/MMC Card hot plug and play
With FM receiver & support recording FM programs to MP3 files
Support VOICE and LINE-IN recording
With button lock
Playing time is approximately 10 hours with an AAA alkaline battery
Built-in 32M ~ 512MB flash memory
No driver installation required (except on Windows 98)
Easy to transfer files: just copy and paste
Built-in Mini USB port, compatible USB Specifications 2.0/1.1/1.0
System Requirements
IBM Compatible PC, Notebook, Mac with USB port
Windows 98/Me/2000/XP/Server 2003, Mac OS 10.2 or above
Getting Started
Unpacking
The full package inculdes:
MP3 Player Earphone
USB Cable LINE-IN Cable
Installation CD User' s Manual
Neck Strap Size AAA alkaline battery
Parts and Controls
LCD
Battery Cover
: Power on/Play/Pause/Stop/Power off/FM Preset channel select/FM Mode select
: Record/Stop record/A-B repeat/Play Mode short switch
: Mode switch/Mode select/FM Mode select
: REW/Previous track/FM channel down/Submenu-scroll-down select
: FF/Next track/FM channel up/Submenu-scroll-up select
: Volume up
: Volume down
: Lock
Connecting MP3 Player to the PC
Driver Installation on Windows 98
MP3 Player requires driver installation on Windows 98. Double click the file
" setup.exe" under the directory " \C670V2" of the installation CD, and driver
for Windows 98 will be installed automatically.
Transferring Files from the PC to MP3 Player
1) Power on MP3 Player and connect it to your computer through the USB
Cable when MP3 Player is under MUSIC MODE.
2) When successfully connected, " READY" will display on the LCD.
3) Double click " My Computer" , and you would find two new icons representing
MP3 Player and SD/MMC Card. A new icon
taskbar on Windows Me/2000/XP/Server 2003 representing MP3 Player.
Double click " My Computer" , and you would find two new icons " NO_NAME"
representing MP3 Player and SD/MMC Card on Mac OS 10.2 or above.
Note: Only one disk letter will appear if the card is not pluged into the MP3
Player.
4) Now you can copy, delete or save files on MP3 Player or SD/MMC
Card, just as you would do on a traditional hard disk.
5) During file transferring, don' t remove MP3 Player from computer.
Safely Remove MP3 Player
To remove MP3 Player from your computer, please choose one of the
following methods according to your operating system:
Windows 98: Unplug MP3 Player from the USB port directly when " READY"
appears on the LCD.
Windows Me/2000/XP/Server 2003: Click the icon
and " Stop USB Mass Storage Device-Drive" message appears. Click the
message, and a window indicating " The USB Mass Storage device can
now be safely removed from the system" shows. Then click " OK" to un-
plug MP3 Player safely.
Mac os 10.2 or above: Click " push NO_NAME" or " push" (the card pluged
into MP3 Player) of " Files" in the menu, then you can unplug MP3 Player
safely.
Skill: Taking disk letter into recycle bin before unpluging MP3 Player.
Basic Operations
Power On & Power Off
To power on/off MP3 Player, please hold
mode is MUSIC MODE and MP3 Player is in stop status.
MP3 Player will automatically power off in pause/stop status when there is
no operation on it if the setting of " Auto poert off" is able.
On the LCD
1) Playback: Indicates the playback status with different logos.
USB Port
2) Repeat mode: NORMAL/REPEAT TRACK/REPEAT ALL/SHUFFLE.
3) A-B repeating: Indicates if A-B repeating is selected.
4) Sound Mode: Indicates the EQ, such as NORMAL, ROCK, JAZZ, CLAS-
SICAL and POP.
LINE-IN Port
5) Card: Indicates SD/MMC Card status.
SD/MMC Card Slot
Earphone Port
has been inserted in.
6) Lock: Indicates whether the HOLD switch has been enabled.
7) Battery: Indicates the battery status.
8) Volume: Indicates volume status.
9) Elapsed Time: Indicates play time of current track.
10) Track number: Area for track number/total number of all tracks.
11) Track Information & Lyric: Area for track information & Lyric display
during playing status.
Locking the Buttons
This function is used to prevent the buttons from being accidentally operated
when you carry MP3 Player. To lock all buttons please simply push the " Hold"
switch to the direction of the arrow marked above it, an icon appears in the
" Lock" area of the LCD and no buttons will be able to operate. To release the
hold function, please push the " Hold" switch to the opposite direction.
SD/MMC Card
MP3 Player supports SD/MMC Card hot plug and play.
After the Card has been successfully inserted in MP3 Player, an icon would
display in " Card" area of the LCD. You can store more files.
You can also set to store LINE-IN/MIC/FM recorded files in SD/MMC Card.
Note: After the Card has been inserted, the order of MP3 Player playing
back is: play back music in MP3 Player before in SD/MMC Card.
would display at the
Mode Switch
There are eight modes in MP3 Player system: MUSIC, FM, VOICE, LINE-IN, SETUP,
REC-SETUP, INFO and EXIT. Please press
press
MUSIC
Play / Pause / Stop
Please press
Please press
Please hold
Fast Forward & Rewind track
Please hold
Track select
on the taskbar,
Please press
Volume adjust
Please press
status.
A-B repeat
Please press
status, MP3 Player will start A-B repeat.
Please press
Lyric Shows
MP3 Player can find lyric with the same name of the song under the directory
automatic (LRC form, you can make it by yourself, or download from Internet
and other channel).
1) Copy lyric and song (LRC form) to the same directory of MP3 Player.
. After power on, the default
2) Make sure that the name of lyric and song must be the same, if not the
lyric will not be shown.
3) Lyric will be shown in the LCD " ID3 AND LYRIC" during the music playing
back.
FM
Under FM MODE MP3 Player can receive FM programs and record programs.
F M
Press /
You can press
on receiving.
SCAN
Press
Auto search channel: Under SCAN status, press
status, then press
store it to the relevant number automatically after searching each channel.
indicates that SD/MMC Card
Search channel by hand: You can search a channel by hand which has
been stored. Under the SCAN status, press
press will increase or decrease 0.1 MHz.
Note: MP3 Player support 30 preset channels most.
SAVE
After auto search channel or by hand, press
status, then press
" Station Saved" , MP3 Player go back to FM status.
Exit
Press
MUSIC mode.
/ to choose each menu, then
repeatedly to select the mode you want.
to playback a file while in pause/stop status.
to have a pause while in playing status.
to stop playing while in playing/pause status.
/ to fast forward or rewind the track while in playing status.
/ to select a track while in playing/pause/stop status.
/ to adjust the volume while in playing/pause/stop
twice to decide the start and the end while in playing
to have a pause or press again to exit A-B repeat.
to change the preset channel.
to stop receiving at any moment, press
to switch the SCAN status.
to go to auto search
or / to start auto search, MP3 Player will
/ to search channel. Each
to switch to SAVE
to save searched channel. After LCD displayed
to switch to the EXIT status, press to exit and go back to
