Page 1 Multimedia Projector Network Supported PLC-WL2503 MODEL Owner’s Manual...
Page 2: Features And Design
Features and Design Large Screen in Limited Space Digital Zoom (for Computer) Security Features Blackboard Function Logo Function Colorboard Function Closed caption Multilanguage Menu Display Simple Computer System Setting Helpful Maintenance Functions Switchable Interface Terminal LAN Network Function Power Management Direct OFF Function Auto Setup Function Interactive function...
Page 3: Table Of Contents
Table of Contents Features and Design ....2 Table of Contents ..... .3 To the Owner.
Page 4: To The Owner
To the Owner Safety Precaution WARNING: THIS APPARATUS MUST BE EARTHED. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
Page 5: Safety Instructions
Safety Instructions NOTE FOR CUSTOMERS IN THE US...
Page 6 Safety Instructions Air Circulation CAUTION CAUTION CAUTION ON CEILING MOUNTING Moving the Projector CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR Installing the Projector in Proper Position...
Page 7: Compliance
Compliance Federal Communications Commission Notice AC Power Cord Requirement AC Power Cord for the United States and Canada: GROUND AC Power Cord for the United Kingdom: WARNING : A PLUG WITH BARED FLEXIBLE CORD IS HAZARDOUS IF ENGAGED IN A LIVE SOCKET OUTLET.
Page 8: Part Names And Functions
Part Names and Functions Front ① Lamp Cover ② Top controls ① ② ③ Adjustable feet ④ Infrared Remote Receiver ⑤ Projection Lens ⑥ Speaker ⑦ Lens Cover CAUTION ⑥ ③ ⑤ ④ ③ ⑧ Interactive Camera ⑧ ⑦ ⑨ Exhaust vent Side ⑩...
Page 9: Side Terminal
Part Names and Functions Side Terminal ① ② ③ ④ ⑤ ⑥ ⑦ ⑩ ⑨ ⑧ ① LAN Connection Terminal ⑥ AUDIO OUT (VARIABLE) ⑧ ⑨ ② ② HDMI ⑦ CONTROL PORT ③ COMPUTER IN 1 / COMPONENT IN ⑧ COMPUTER / COMPONENT AUDIO IN ②...
Page 10: Top Panel
Part Names and Functions Top Panel ① POWER indicator ① ② ③ ② WARNING indicator ③ LAMP REPLACE indicator ① ON/STAND-BY button ② Point ( VOLUME – / + ) buttons ① ② ③ ④ ③ SELECT button ④ MENU button ⑤...
Page 11: Remote Control
Part Names and Functions Remote Control ① ④ VIDEO button ⑤ S-VIDEO button ② HDMI ③ ⑥ Point ④ ⑳ ⑤ ⑦ SCREEN button ⑥ ⑲ ⑧ MENU button ⑦ ⑱ ⑧ ⑰ ⑨ FREEZE button ⑯ ⑨ ASPECT ⑩ NO SHOW button ⑩...
Page 12 Part Names and Functions Remote Control Battery Installation Two AAA size batteries Remote Control Operating Range Remote Control Code Code 1 Code 2 Code 1 Code HDMI Code 1 MENU button ASPECT IMAGE button...
Page 13: Installation
Installation Positioning the Projector Note: 3.93' (119.7 cm) (Inch Diagonal) 2.83’ (86.1 cm) 2.09’ (63.6 cm) Screen Size 60” 80” 110” (W x H) mm 16:10aspect ratio 1292 x 808 1723 x 1077 2369 x 1481 Throw distance 2.09’ (63.6 cm) 2.83’...
Page 14 Installation Connecting to a Computer Cables used for connection Note:...
Page 15 Installation Connecting to Video Equipment Cables used for connection...
Page 16 Installation Connecting to Component Video Equipment Cables used for connection...
Page 17: Connecting The Ac Power Cord
Installation Connecting the AC Power Cord CAUTION Note: NOTE ON THE POWER CORD Projector side AC outlet side For the U.S.A. and Canada For Continental Europe For the U.K. (120 V AC) (200 - 240 V AC) (200 - 240 V AC)
Page 18: Basic Operation
Basic Operation Turning On the Projector Selected Input Source and Lamp Control Video Note: Video / PC selection window Input signal guidance window Video / PC selection window Note: Countdown off Input signal guidance window On 2...
Page 19 Basic Operation Enter a PIN code PIN Code Input Dialog Box PIN code What is PIN code? CAUTION ON HANDLING PIN CODE Note:...
Page 20 Basic Operation Turning Off the Projector Power off? Power off? Direct OFF Function Note: Note:...
Page 21 Basic Operation How to Operate the On-Screen Menu Remote Control POINT buttons (arrowhead) SELECT button MENU button Top Control MENU button SELECT button POINT buttons (arrowhead) On-Screen Menu Point or SELECT button...
Page 22: Mode
Basic Operation Menu Bar ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① Input Computer 1 Computer 2 HDMI Video S-video ② PC adjust Auto PC adj. Fine sync Total dots Horizontal Vertical Current mode Clamp Display area H Display area V ③...
Page 23: Focus Adjustment
Basic Operation Focus Adjustment Auto Setup Function Remote Control AUTO SET button HDMI Note: Fine sync Total dots Horizontal Vertical Keystone Correction Remote Control POINT buttons KEYSTONE button Top Control POINT buttons KEYSTONE button...
Page 24: Sound Adjustment
Basic Operation Sound Adjustment Direct Operation Remote Control Volume ASPECT VOLUME + button MUTE button VOLUME - button Mute Top Control VOLUME +/- buttons Menu Operation Volume Dialog Box Sound Volume Sound Menu Mute...
Page 25: Remote Control Operation
Basic Operation Remote Control Operation Remote Control COMPUTER 1/2, HDMI, VIDEO, S-VIDEO and COMPUTER 1/2 buttons COMPONENT buttons HDMI button S-VIDEO HDMI button COMPONENT VIDEO button button FREEZE button INFO. button FREEZE button LAMP ASPECT button D.ZOOM Fig.1 buttons ASPECT button Note: Note:...
Page 26 Basic Operation NO SHOW button User No show Note: P-TIMER button Remote Control SCREEN button P-TIMER button ASPECT NO SHOW button IMAGE button IMAGE button Note: SCREEN button...
Page 27: Computer Input
Computer Input Input Source Selection (Computer 1: RGB) Direct Operation Remote Control Computer 1(RGB) HDMI COMPUTER 1 button Computer 1(RGB) Top Control Computer 1 Computer 1(Scart) Computer 2 * HDMI Input Menu INPUT button Video S-video Menu Operation Input Computer 1 Computer 1 Computer Note:...
Page 28 Computer Input Input Source Selection (Computer 2: RGB) Direct Operation Remote Control Computer 2 (RGB) HDMI COMPUTER 2 button Computer 2 (RGB) Top Control Computer 1 Computer 2 * HDMI INPUT button Video S-video Menu Operation Input Menu Input Computer 2 Computer 2 Note: On 1...
Page 29: Computer System Selection
Computer Input Computer System Selection PC System Menu Auto Auto ----- Mode 1 Mode 1-10 SVGA 1 * Mode 1 SVGA 1 Selecting Computer System Manually Mode (1–10) PC System Menu Input System...
Page 30: Auto Pc Adjustment
Computer Input Auto PC adjustment Fine sync Total dots Horizontal Vertical Clamp Menu Operation Auto PC adj. PC adjust Menu PC adjust Auto PC adj. To store adjustment parameters Auto PC Mode (1-10) adj. Please wait... Note: Fine sync Total dots Horizontal Vertical 480i 575i 480p 575p 720p 1035i 1080i...
Page 31: Manual Pc Adjustment
Computer Input Manual PC adjustment PC adjust Menu PC adjust Fine sync Total dots Horizontal Vertical Current mode H-sync freq. V-sync freq. Clamp Display area H Display area V...
Page 32 Computer Input Reset Reset Mode free Menu Mode free Mode free Store Store Total dots Horizontal Note: Vertical Display area H Display area V Display area (H/V) 480i 575i 480p 575p 720p 1035i 1080i PC adjust Store Menu...
Page 33 Computer Input Image Mode Selection Remote Control Direct Operation IMAGE button Dynamic Standard Dynamic Real Blackboard (Green) Colorboard Image 1 Image 2 ASPECT Image 3 Image 4 Standard Real Blackboard (Green) IMAGE button Colorboard Image 1 Menu Operation Image 2 Image Image 3 select...
Page 34 Computer Input Image Adjustment Image adjust Menu Image adjust Contrast Brightness Color temp. (XLow Low Mid High White balance (Red) White balance (Green) White balance (Blue) Note: Sharpness Red Green Blue Color temp. User Blackboard(Green) Colorboard Color temp. Blackboard Colorboard Gamma Reset Reset...
Page 35 Computer Input Store Menu Store Store Image 1 Image (1-4) Screen Size Adjustment Yes. Screen Menu Screen Normal True Full Custom True Digital zoom +/- True Full Digital zoom +/– 480i 575i 480p 575p...
Page 36 Computer Input Custom adj. Custom adj. Menu Custom adj. Scale H/V H&V Scale V Scale H Position H/V Common Note: Normal Common Custom adj. Custom Scale H/V Position H/V Reset Reset Remote Control For zooming in and out the images POINT buttons Digital zoom +...
Page 37: Video Input
Video Input Input Source Selection (Video, S-video) Direct Operation Remote Control Video S-video VIDEO button Video S-VIDEO button S-video Top Control Computer 1 Computer 2 * HDMI INPUT button Video S-video Input Menu Menu Operation Input Video S-video Video S-video Note: On 1 On 2...
Page 38 Video Input Input Source Selection (Component, RGB Scart 21-pin, HDMI) Remote Control Direct Operation COMPUTER 1 button Computer 1(Component) Computer 1(Scart) Computer 1 (RGB) HDMI Computer 1 (Scart) HDMI HDMI button HDMI COMPONENT button Computer 1 (Component) Top Control Computer 1 Computer 2 * HDMI Input Menu...
Page 39: Video System Selection
Video Input Video System Selection AV System Menu (Video or S-video) Input Video S-video Computer 1(Component) System Video or S-video Auto PAL-M PAL-N PAL/SECAM/NTSC/NTSC4.43/PAL-M/PAL-N SECAM NTSC NTSC 4.43 PAL-M PAL-N Component AV System Menu (Component) Auto COMPONENT VIDEO SIGNAL FORMAT 480i 575i 480p 575p 720p 1035i 1080i...
Page 40 Video Input Image Mode Selection IMAGE button Direct Operation Remote Control Dynamic Dynamic ASPECT Standard Cinema Blackboard (Green) Colorboard Standard Image 1 Image 2 Image 3 Image 4 Cinema Blackboard (Green) IMAGE button Colorboard Menu Operation Image 1 Image select Image 2 Image 3 Image 4...
Page 41 Video Input Image Adjustment Image adjust Menu Image adjust Contrast Brightness Color Tint Color temp. White balance (Red) White balance (Green) White balance (Blue) Note: White balance Red Green Blue User PAL SECAM PAL-M PAL-N Blackboard (Green) Colorboard Color temp. Blackboard Colorboard...
Page 42 Video Input Sharpness Gamma Noise reduction Progressive Film Reset Reset Store Menu Store Store Note: Noise reduction Progressive 480p 575p 720p 1035i 1080i Yes.
Page 43 Video Input Screen Size Adjustment Screen Menu Screen Normal Full Zoom Wide Natural wide Custom Custom adj. Custom adj. Scale H/V H&V Scale V Scale H Note: Position H/V Normal Common Scale H/V Position H/V Zoom Natural wide Wide 720p 1035i 1080i Zoom Natural wide Wide...
Page 44: Setting
Setting Setting Setting Menu Setting Language Language Menu Menu position Menu position...
Page 45 Setting Auto setup Auto setup Input search On 1 On 2 Auto PC adj. Note: On 1 On 2 Fine sync Total dots Horizontal Vertical...
Page 46 Setting Keystone Keystone Keystone Store or Reset Store Reset Background Blue User Black Display Countdown off Power off? No signal Please wait ... P-Timer...
Page 47 Setting Logo (Logo and Logo PIN code lock settings) Logo select Note: Logo select Default User...
Page 48 Setting Capture Capture Capture User Note: Standard 720p 1035i 1080i On Logo select Capture User Default Logo PIN code lock Logo PIN code lock Note: On Logo select Capture...
Page 49 Setting Enter a Logo PIN code Enter a Logo PIN code Logo PIN code Change the Logo PIN code lock setting Logo PIN code change Logo PIN code change Logo PIN code change CAUTION: WHEN YOU HAVE CHANGED THE LOGO PIN CODE, WRITE DOWN THE NEW PIN CODE IN COLUMN OF THE LOGO PIN CODE NO.
Page 50 Setting Ceiling Ceiling Rear Rear Screen aspect 16:9 True Digital zoom +/ 16:9 16:10 16:9 Zoom Natural wide Wide HDMI setup Image HDMI setup Normal Enhanced Sound HDMI HDMI Computer Computer Normal Enhanced Terminal Computer 2 Monitor Out Computer 2 Computer 1 Video HDMI...
Page 51 Setting Standby mode Network Power management Note: Network Power management Ready Shut down Timer signal Note: Ready: 5 Min...
Page 52 Setting Direct on Note: P-timer P-timer Count up 000:00 000:00-180:00 Count down Timer (1-180 Min Count down Timer 10 Min Start Start Stop Count up Count down Stop Restart Reset Reset Count up Count down Exit Stop or Cancel the P-timer via Remote Control...
Page 53 Setting Closed caption Closed caption Off CC1 CC2 CC3 Color White Note: NTSC Auto NTSC Auto Closed caption Off CC1 CC2 CC3...
Page 54 Setting Lamp control Normal Remote control Remote control Code 1 (Code 2 Code 2 Code 2 To change the code for the projector: Code 1 Code 2 To change the code for the remote control: Note:...
Page 55 Setting Security (Key lock and PIN code lock) On 1 On 2...
Page 56 Setting PIN code Off On 1 On 2 PIN code change CAUTION: WHEN YOU HAVE CHANGED THE PIN CODE, WRITE DOWN THE NEW PIN CODE IN COLUMN OF THE PIN CODE NO. MEMO ON PAGE 76, AND KEEP IT SECURELY. IF YOU FORGET YOUR PIN CODE, THE PROJECTOR CAN NO LONGER BE STARTED.
Page 57 Setting Fan control Note: On 1 On 2 On 1 On 2 Video delay control Note: Noise reduction Progressive Lamp counter Fig.1 Note: Note: Freeze No show...
Page 58 Setting Filter counter Filter counter RESET Fig.1 Off 2000H 3000H 4000H Note: Note: Freeze Factory default No show Warning log Note: Factory default User logo PIN code lock Logo PIN code lock Lamp counter Filter counter...
Page 59: Information
Information Input Source Information Display Direct Operation Remote Control INFO. button Menu Operation ASPECT Input Information Menu H-sync freq. - - - -KHz V-sync freq. - - - - Hz Screen Language Lamp status Lamp counter Power management Off Ready Shut down Timer Key lock PIN code lock...
Page 60: Maintenance And Cleaning
Maintenance and Cleaning WARNING indicator The projector is shut down and the WARNING indicator is blinking red. Top Panel Note: Then check the matters below: The projector is shut down and the WARNING indicator lights red. Top Panel CAUTION...
Page 61: Replacing The Filter
Maintenance and Cleaning Replacing the Filter CAUTION Filter counter RECOMMENDATION We recommend avoiding dusty/smoky environments when you operate the projector. Usage in these environments may cause poor image quality. Resetting the Filter Counter Filter counter Reset? Setting Filter counter Filter counter reset Filter counter Reset?
Page 62 Maintenance and Cleaning Attaching the Lens Cover Cleaning the Projection Lens Cleaning the Projector Cabinet CAUTION...
Page 63 Maintenance and Cleaning Lamp Replacement Top Panel WARNING: Note: Freeze No show CAUTION CAUTION CAUTION Reset the lamp counter. ORDER REPLACEMENT LAMP Model No. of your projector : PLC-WL2503 Replacement Lamp Type No. : POA-LMP141...
Page 64: Resetting The Lamp Counter
Maintenance and Cleaning Resetting the Lamp Counter Setting Lamp counter Lamp counter reset Lamp replacement counter Reset? Lamp replacement counter Lamp replacement counter Reset? Reset? Note: Lamp replacement counter Reset? LAMP HANDLING PRECAUTIONS IF A LAMP EXPLODES, THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE TAKEN.
Page 65: Appendix
Appendix Troubleshooting Problem: No power The initial display is not shown. Countdown off The initial display is not same User as the default set. Input signal switches automatically. (or does not switch automatically) An icon other than Input mode or Lamp mode icon appears.
Page 66 Appendix No image No Show No sound The color is strange. Blackboard Some displays are not seen during the operation. Auto PC adjustment function does not work. 480p 575p 720p 480i 575i 1035i 1080i The setting does not remain Store after turning off power.
Page 67 Appendix The image is distorted or runs off. PC adjustment Screen PIN code dialog box appears at start-up. The Remote Control does not work. Indicator blinks or lights. The exclamation mark appears on the screen. Top control does not work. Unable to unlock the Logo PIN code lock or Security PIN code lock.
Page 68: Menu Tree
Appendix Menu Tree Computer Input/HDMI Input/Video Input Input Sound Sound Computer Input System Image adjust PC adjust Screen Image select...
Page 69 Appendix Computer Input/HDMI Input/Video Input Video Input Setting System System HDMI Input/Video Input Image select Image adjust Screen Information...
Page 70 Appendix Indicators and Projector Condition Indicators Projector Condition red/green yellow...
Page 71: Compatible Computer Specifications
Appendix Compatible Computer Specifications ON-SCREEN RESOLUTION H-Freq. V-Freq. ON-SCREEN RESOLUTION H-Freq. V-Freq. DISPLAY (KHz) (Hz) DISPLAY (KHz) (Hz) Note:...
Page 72 Appendix ON-SCREEN H-Freq. V-Freq. ON-SCREEN H-Freq. V-Freq. RESOLUTION RESOLUTION DISPLAY (KHz) (Hz) DISPLAY (KHz) (Hz) Note:...
Page 73: Technical Specifications
Appendix Technical Specifications Mechanical Information Panel Resolution Signal Compatibility Optical Information Interface Audio Power Operating Environment Remote Control Accessories...
Page 74: Optional Parts
Appendix Optional Parts SCART-VGA Cable COMPONENT-VGA Cable VGA-Cable (10 m) TERMINAL COVER The Terminal Panel Replacement Fig. 1 Terminal Panel Five(5) screws Fig. 2 Terminal Cover Attachment Terminal Cover Note: Two(2) screws CAUTION Fig. 3...
Page 75: Configurations Of Terminals
Appendix Configurations of Terminals COMPUTER IN 1 /COMPONENT IN LAN TERMINAL Terminal: Analog RGB (Mini D-sub 15 pin) 87654321 COMPUTER IN 2/MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) CONTROL PORT CONNECTOR (D-sub 9 pin) HDMI (19 PIN Type A) TMDS Data 2+ Input Ground (TMDS Clock) 1 3 5 7 9 11 13 15 17 19...
Page 76 Appendix PIN Code Number Memo PIN Code Lock No. Logo PIN Code Lock No. Attatching the Cable Holder...
Page 77: Pj Link Notice
Appendix Dimensions 6.56(166.7) 6.29(159.8) 7.53(191.3) 4.33(110) 0.56(14.2) 0.72(18.3) 4.53(115) 3.54(90) 5.60(142.2) 3.94(100) 6.77(172) 15.11(383.8) PJ Link Notice...
Page 79 Owner’s Manual Network Set-up and Operation Wired Setting Projector Set-up and Operation This is the manual for the Network function. Read this manual thoroughly to operate the Network function. First, read the owner's manual of the projector to understand the basic operation of the projector and the safety instructions.
Page 80: Federal Communications Commission Notice
If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Numbers : PLC-WL2503 Trade Name : Sanyo Responsible party : SANYO NORTH AMERICA CORPORATION Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818)998-7322...
Page 81 Safety instructions CAUTION IN USING THE PROJECTOR VIA NETWORKS When you find a problem with the projector, remove the power cable immediately and inspect the unit. Using the projector with failure may cause fire or other accidents. If you remotely use the projector via networks, carry out a safety check regularly and take particular care to its environment.
Page 82 Table of contents Compliance ..................................2 Safety instructions ................................3 Table of contents ................................4 Chapter 1 Preparation ....................5 Features....................................6 Required operating environment for computers ..................7 Network specifications of the projector......................7 Flow of installation................................9 Chapter 2 Setup Procedures.................. 11 Connecting to the LAN line............................ 12 Network configuration...............................
Page 83: Chapter 1 Preparation
Chapter 1 Preparation Describes features and operating environment of this projector.
Page 84: Features
Chapter 1 Preparation Features Web Management function ( p.31) With this func tion, you can monitor projector functions such as power status, lamp s t at us , inp u t m o d e, si gnal condition, lamp-use time, etc. through the network by using the web browser installed on Turn ON PJ2...
Page 85: Required Operating Environment For Computers
Features Required operating environment for computers When operating the projector via networks, computers should meet the operating envi- ronment below. Windows 2000, Windows XP (32bit version), Windows Vista (32bit version), Windows 7 (32bit version) Operating System Mac OS X v 10.4 or 10.5 Windows: Higher than Pentium III 900MHz Recommended CPU Macintosh : 800 MHz PowerPC G4 or faster,or 1.8 GHz Intel Core...
Page 86 Chapter 1 Preparation The limitation of connection between the projector and hub or computer Suitable LAN cables are limited by length and type as follows; Connection Type of usable LAN cable Maximum length Projector - Hub UTP Straight Cable with category 3 or 5 * 100m Projector - Computer UTP Cross Cable with category 3 or 5*...
Page 87: Flow Of Installation
Flow of installation Flow of installation To use the projector via the networks, follow the setup procedures below. STEP 1 Connect the LAN and set the configuration. Decide depending on the LAN environment. “2. Setup Procedures” (pp.11–16). Detailed LAN configurations need to be done with a browser later. First, complete the Wired LAN connection between computers and projec- tors, then start browser configurations.
Page 88 Chapter 1 Preparation...
Page 89: Chapter 2 Setup Procedures
Chapter 2 Setup Procedures Describes how to configure the network.
Page 90: Connecting To The Lan Line
Chapter 2 Setup Procedures Setting procedures and contents differ depending on the LAN installation location. When installing, consult your system administrator to set up the LAN appropriately. Connecting to the LAN line Connect the LAN cable to the LAN connection terminal of the projector. LAN Connection ACT Lamp (Orange) Terminal...
Page 91 Network configuration 3. Select "Network setting" in the Network menu and press SELECT button, and then the LAN setting screen will appear and selected LAN settings will be displayed. Adjust each item to the setting environment. Consult your system administrator about the detailed settings.
Page 92: Network Pin Code
Chapter 2 Setup Procedures Network PIN code The Network PIN code is to restrict the access to the projector through the network. After setting the Network PIN code, you need to enter it to operate the projector via the networks. 1.
Page 93: Network Factory Default
Network factory default Network factory default 1. Select “Network factory default” in the Network menu and press SELECT button. 2. A confirmation box appears and select "Yes" and then press SELECT button. 3. Another confirmation box appears and select "Yes" and then press SELECT button. 4.
Page 94: Wired Lan Factory Default Settings
Chapter 2 Setup Procedures Wired LAN factory default settings SELECTED LAN Parameter LAN 1 LAN 2 LAN 3 DHCP IP ADDRESS 169.254.100.100 192.168.100.100 192.168.100.100 SUBNET MASK 255.255.0.0 255.255.255.0 255.255.255.0 GATEWAY ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255 DNS ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255...
Page 95: Chapter 3 Basic Setting And Operation
Chapter 3 Basic Setting and Operation Describes basic operations and settings for controlling the projec- tor by using the web browser. It is required that computer and projector is connected to the network and the network address is properly configured.
Page 96: Login The Setting Page Of The Projector
Chapter 3 Basic Setting and Operation Login the setting page of the projector [1] Enter the IP address Launch the web browser installed in your computer, enter the IP address into the "Address" on the browser and then press "Enter" key. Enter the address that you configured in item "Network configuration"...
Page 97: Display Of Main Setting Page
Login the setting page of the projector [3] Display of main setting page The following main setting page will be displayed according to your display mode selection. Perform various kinds of settings through this page. Click on the menus to dis- play the control and setting pages.
Page 98: How To Use The Setting Page
Chapter 3 Basic Setting and Operation How to use the setting page To control and set up the projector, use the setting menus on the web browser. Describes the basic operation and procedures commonly used on this manual. Example of the setting page The setting menu appears when clicking the sub menu tab.
Page 99 How to use the setting page Radio button setting Select an item by selecting a radio button. Check box setting Select items by ticking on check boxes.
Page 100: Initial Setting
Chapter 3 Basic Setting and Operation Initial setting After installing the projector, perform the following basic initial setting. Click Initial Setting on the main menu to display the initial setting page. Item Description Language....Switches display language on the setting page. (Japanese, English) Model name ..Indicates the model name of the projector Network PIN code ..Sets the Network PIN code to login the setting page ( p.23) PJLink.......Switches PJLink password authentication.
Page 101: Network Pin Code Setting
Initial setting Network PIN code setting This is to set the Network PIN code to restrict the access from an unauthorized person through the network. Enter a 4-digit number as the Network PIN code onto the text box and click Set button. The projector begins restarting and it takes about 10 seconds.
Page 102: Network Configuration
Chapter 3 Basic Setting and Operation Network configuration Click Network on the main menu. The following setting page is displayed. The IP Address, Subnet Mask, Default Gateway, DNS (Domain Name Server) and projector name are set up on this menu. The IP address and Subnet Mask have been configured already in chapter "Installation".
Page 103: E-Mail Setting
E-mail setting E-mail setting This projector has an E-mail function which can send an alert message to users or an administrator if it detects an abnormality on the projector or run out of the life span of the lamp. Click E-mail Setting on the main menu and follow the below steps.
Page 104 Chapter 3 Basic Setting and Operation Setting SMTP server and administrator address Enter the server name or IP address of the SMTP server* , the port number of the SMTP server and administrator address and click Set button. The administrator address is set to "Reply-To"...
Page 105 E-mail setting Setting SMTP authentication Set the SMTP authentication concerned and click Set button. Please contact your network administrator in details. Setting POP server When "POP before SMTP" is selected at "Auth" of "SMTP Authentication setting", enter "POP server* " and "POP server port" and click Set button.
Page 106: Examples: Type And Contents Of Alert Mail
Chapter 3 Basic Setting and Operation Examples: Type and contents of alert mail When the projector has an abnormality, the following alert messages are sent to the regis- tered E-mail address according to your selected condition. Administrator or user can take an efficient action quickly by receiving this message.
Page 107: Snmp Setting
SNMP setting SNMP setting This projector provides a SNMP (Simple Network Management Protocol) agent function. The SNMP consists of a manager and agents. The group which communicates information each other with SNMP is called "Community". There are two access modes in a community, Refer (read only) and Set (read- write).
Page 108 Chapter 3 Basic Setting and Operation Trap check/delete Check and delete the trap address Checking the registered trap address and deleting the address. To delete the address, tick check box in front of the IP address and click Delete button. Up to 10 trap addresses can be registered.
Page 109: Chapter 4 Controlling The Projector
Chapter 4 Controlling the Projector Describes controlling and setting of the projector by using the web browser.
Page 110: Power Control And Status Check
Chapter 4 Controlling the Projector Power control and status check Click Power & Status on the main menu. The control page will be dis- played. By clicking ON or Standby button on the page, the power of the projector can be con- trolled.
Page 111 Power control and status check About projector condition Status Description Normal............... Projector is operating normally. Power management in operation... Power management is operating Lamp failure........... Lamp failure is occurring Abnormal Temperature......The temperature of the projector became too high Standby after Abnormal Temp..Projector detects abnormal temp. and sets into standby mode. Power failure ..........
Page 112: Control
Chapter 4 Controlling the Projector Control Click Control on the main menu. The setting method differs depending on the contents of the page. Click on the page number to change pages and select desired setting items. Please see the owner's manual of the projector to have the further information of each control item.
Page 113: System
Control System This function is to select the system of signal input to the projector. The available system mode are listed on the pull-down menu but- ton according to the input signal. Select a system and then click Set button. Available selection at the RGB input Item Description...
Page 114: Sound
Chapter 4 Controlling the Projector Sound This function is to adjust the sound of the projector. The values in the text box represent the current control value or status. Item Description Volume ....Adjusts the sound volume from the speaker. (0 ~ 63) Mute......Suppresses the sound.
Page 115: Image Adjustment
Control Image adjustment This function is to adjust the projected picture image and save the image mode. To store the adjusted value, click Store button, and to load the adjusted value, click Load button. Item Description Contrast ......Adjusts picture con- trast (0~ 63) Brightness ......
Page 116: Pc Adjustment
Chapter 4 Controlling the Projector PC adjustment Click PC Adj. on the main menu. This function is to adjust the signal from the computer connected to the projector to obtain the proper picture image on the screen. Item Description Current mode..Displays a current mode like VGA, SVGA, XGA. SXGA, UXGA, WXGA, etc. or Mode1 - Mode10 which are the customized mode created by using the "Mode Store"...
Page 117: Setting Up The Projector
Setting up the projector Setting up the projector Click Setting on the main menu. This function is to set up the projector. Select the sub menu [Screen setting] or [Setting] and then set up each set- ting. Screen setting This function is to adjust the screen mode of the projector.
Page 118: Setting 1
Chapter 4 Controlling the Projector Setting 1 Item Description Language....Sets the language display of projector's on-screen display menu. Auto setup ...Executes the Auto PC Adj, and Input Search function below according to the Start each setting after clicking button. Auto PC Adj..Sets Auto PC Adjustment mode. (ON, OFF) Input search ..Sets the auto-input signal detection mode.
Page 119: Setting 3
Setting up the projector Setting 3 Item Description Key lock....Sets the prohibition of controls either Projector or Remote control. (OFF, Projector keys, Remote control) Fan control Sets the fan control speed....Normal mode Highland mode 1 Highland mode 2 Lamp Corres.
Page 120: Information
Chapter 4 Controlling the Projector Information This page is to display the basic information of the projector status. Click Information on the main menu. Click this button to update the information. Items Description Input Displays selected input and source. System Displays selected signal system.
Page 121: Chapter 5 Appendix
Chapter 5 Appendix Connection examples Use of telnet Web browser setting Q & A...
Page 122: Examples Of Connection
Chapter 5 Appendix Examples of connection Peer-To-Peer connection Connecting the projector (PJ01) to the control computer (PC05) directly. * UTP cross cable Computer Name: PC05 Projector Name: PJ01 IP Address : 192.168.0.5 IP Address : 192.168.0.2 Subnet Mask : 255.255.255.0 Subnet Mask : 255.255.255.0 Default Gateway :...
Page 123 Examples of connection The gateway (Router) installed in the network Connecting the projector (PJ01) to the control computer (PC05) via the gateway. Entrance hall Computer Name : PC205 IP Address : 192.168.200.5 Subnet Mask : 255.255.255.0 Default Gateway : 192.168.200.1 : 192.168.201.1 Projector Name: PJ01 IP Address...
Page 124: Use Of Telnet
Chapter 5 Appendix Use of telnet You can control the projector by using the telnet application installed on your computer. Normally, the telnet application is available on your computer. * The telnet 10000 port is used to control the projector. Control (For example, in case of using the telnet (For example, in case of using the telnet...
Page 125 Use of telnet 3. When communication is established correctly, the word "PASSWORD:" appears on the window. Type the login password (Network PIN code ) for the projector and then press "Enter" key on the keyboard. If you do not set up the Network PIN code, just press "Enter" key.
Page 126: Web Browser Setting
Chapter 5 Appendix Web browser setting This projector is designed to be set up and controlled from an Internet web browser. Depending on the preference settings of the web browser, some control functions may not be available. Please make sure that the following functions are set up properly in the web browser.
Page 127: Examples: Os/Browsers
Web browser setting Examples: OS/Browsers Windows XP Professional Internet Explorer v.6.0 ActiveScript setting Select Internet Options from Tools menu on the web browser and then select Security tab and click Customize Level… button. On the security setting window, scroll down and find the Scripting item, make sure that "Enable"...
Page 128 Chapter 5 Appendix Proxy setting Select Internet Options from Tools menu on the web browser and then select Connection tab and click LAN Settings button. Properly set up your web browser's the proxy server settings according to the local area network environment to which the pro- jector is connected.
Page 129 Web browser setting Netscape Navigator v.7.1 JavaScript Setting Select Preference from Edit menu on the web browser a n d t h e n s e l e c t t h e i t e m Advanced/Scripts & Plugins in the Category column.
Page 130 Chapter 5 Appendix MAC OS X v 10.4 Safari v.3.2.1 JavaScript enable setting Selec t Preferences... from Safari on the web browser and then select S e c u r i t y t a b a n d c h e c k E n a b l e JavaScript.
Page 131: Q&A
Q&A Q&A Installation/Access Why doesn’t the setting page appear in my web browser? Following causes are possible. Please check them. 1. The projector does not connect to the network. Check LED indicators status ( p.12). - Check the connection of LAN cable if the LINK Lamp does not light green. - Check the network configuration of the projector if the ACT Lamp does not blink orange.
Page 132 Chapter 5 Appendix We use the DHCP/BOOTP server to assign the IP address. Is it possible to use the projector in this network environment? Possible. This projector supports the DHCP/BOOTP server. To use this projector in this network environment, set it up so that the DHCP/BOOTP server does not assign the IP address configured to this projector for another device on the network.
Page 133 Q&A Operation Why can't be turned on/off with web browser? Please make sure the settings of the projector are correct to use the projector. Please set the Standby mode of the projector's Setting menu to "Network". Refer to "4. Controlling the Projector" "Power control and status check"...
Page 134 Chapter 5 Appendix Others What are the rules for IP address assignment? If the network is constructed with TCP/IP protocol, a unique IP address is required for each piece of network equipment. The following are basic rules of the assign- ment.
Page 135 Q&A Can I update the firmware of the projector. It is possible to update the firmware through the network. It is required to have a special tool for the updating. For further information please consult your local deal- er. The version number of the firmware is indicated on the lower part of the "Initial setting"...
Page 136 NETWORK OWNER'S MANUAL SO-KJ8AE SANYO Electric Co., Ltd.

Sanyo plc-wl2503 Owner's Manual

Table of Contents

Table of Contents

Chapter 1 Preparation

Chapter 2 Setup Procedures

Chapter 3 Basic Setting and Operation

Chapter 4 Controlling the Projector

Chapter 5 Appendix

Quick Links

Chapters

Related Manuals for Sanyo plc-wl2503

Summary of Contents for Sanyo plc-wl2503

Table of Contents
