Instruction Manual
Service Manual
Color Television
CHASSIS : CP-185M
Model : KR14E5/DTV-14V3
KR20E5/DTV-20V3
KR21E5/DTV-21V3
14V3/20V3/21V3
Specification
Version
PAL-SECAM B/G-D/K
TV Standard
MONO
Sound system
Power Consumption
14": 39W; 20": 42W; 21": 45W
2.5W(at 60% mod, 10% THD)
Sound Output Power
Speaker
3W
NONE
Teletext system
75ohm unbalanced
Aerial Input
Channel coverage
Off-air cannels, S-cable channels and hyperband
Tuning System
Frequency synthesiser tuning system
14" : 34cm
Visual screen size
20" : 48cm
21" : 51cm
On screen Display
Channel indication
Program selection
100 programmes
EURO-SCART:Audio /Video and Out, R/G/B in,
Auxiliary Output Terminal
slow and fast wtching, SVHS in.
Audio-Video jack on front of cabinet in common
connection with EURO-SCART.
Headphone jack(3.5mm)on front of cabinet
Remote Control
R-40A10
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : TCP185MEF1
TK
8 ohm
Feb. 2001
Advertisement
Related Manuals for Daewoo KR14E5
Summary of Contents for Daewoo KR14E5
-
Page 1: Service Manual
S/M No. : TCP185MEF1 Service Manual Color Television CHASSIS : CP-185M Model : KR14E5/DTV-14V3 KR20E5/DTV-20V3 KR21E5/DTV-21V3 14V3/20V3/21V3 Specification Version PAL-SECAM B/G-D/K TV Standard MONO Sound system Power Consumption 14": 39W; 20": 42W; 21": 45W 2.5W(at 60% mod, 10% THD) Sound Output Power... - Page 2 SPECIFICATIONS EUROP GB(IRE- EAST EUROP GB(IRE- EAST FRANCE FRANCE E CCIR LAND) OIRT E CCIR LAND) OIRT 311.25 311.25 311.25 311.25 112.25 116.75 111.25 112.25 119.25 128.75 119.25 119.25 319.25 319.25 319.25 319.25 327.25 327.25 327.25 327.25 126.25 140.75 127.25 126.25 133.25 152.75...
-
