PC Control Command Reference

Command Codes
No. Function Code Data Description
01 Video 03H
02 RGB 04H
03 S-Video C6H No
04 PC CARD 27H
05 Power On 08H
06 Power Off 14H
07 Picture Mute 47H
08 Audio Mute 45H
09 Onscreen Mute 11H
10 Reset 43H
11 D Up DEH No
12 D Down DFH No
13 D Right DCH No
14 D Left DDH No
15 D Right Up 21H
16 D Left Up 22H
17 D Right Down 23H
18 D Left Down 24H
19 Freeze 4CH No
20 Slide + 4BH No
21 Slide – 20H
22 Front Floor 33H
23 Front Ceiling 34H
24 Rear Floor 35H
25 Rear Ceiling 36H
26 Auto Start On 19H
27 Auto Start Off 1AH No
28 Auto Picture On 1BH No
29 Auto Picture Off 1CH No
30 Input Mode Select 1DH Yes
31 Gamma Select 1EH Yes
No Same as remote
No Same as remote
Same as remote
No Same as remote (available only when Viewer kit is connected to)
No Same as remote
No Same as remote
No Same as remote
No
No
No
Same as remote
Same as remote
Same as remote
Same as remote
No Same as remote
No Same as remote
No Same as remote
No Same as remote
Same as remote
Same as remote (available only when PC CARD is selected)
No Same as remote (available only when PC CARD is selected)
No
No
No
No
No
0 Standard VIDEO (available only when VIDEO/S-VIDEO is selected)
1 Doc Camera
0 Normal
1 Natural 1
2 Natural 2
103
