NEC LT40 Quick Connect Manual

Quick Connect Guide
Step1
Connect the supplied power cable.
Step2 Connect the supplied 15pin-15pin signal cable.
Always power down
before you hook up.
PC CARD
ACCESS
USB
PC CONTROL MOUSE OUT RGB INPUT S-VIDEO
Step3 Turn on the projector.
For Mac, use the supplied
pin adapter to connect to the
computer 's video port.
VIDEO AUDIO
L ( MONO ) R
Power button
NOTE: To turn off the projector, press and
hold the POWER button for a minimum
of two seconds.
MultiSync LT84/LT140
Step4 Set up the Projector
To adjust the projector' s focus or to zoom in and out, use
the Focus/Zoom ring on the lens.
Zoom ring
Focus ring
If necessary, adjust the front or rear feet to
properly position the projected image on the
screen.
If the projected image does not appear
square to the screen then use keystone cor-
rection for proper adjustment.
