Seiko W861 User Manual

CONTENTS

FEATURES .................................................................................................................

MODE CHANGE ........................................................................................................

ILLUMINATING LIGHT (LED panel) ...........................................................................

TIME/CALENDAR MODE ..........................................................................................

STOPWATCH MODE (CHRONO) ..............................................................................

TIMER MODE............................................................................................................

ALARM MODE ..........................................................................................................

WORLD TIME MODE................................................................................................

SCHEDULE ALARM MODE ......................................................................................

SETTING MODE ........................................................................................................

NOTES ON USING THE WATCH ...............................................................................

BATTERY CHANGE ...................................................................................................

TO PRESERVE THE QUALITY OF YOUR WATCH .....................................................

SPECIFICATIONS ......................................................................................................

Page

Table of Contents

Summary of Contents for Seiko W861

Page 1: Table Of Contents
CONTENTS Page FEATURES ......................... MODE CHANGE ......................ILLUMINATING LIGHT (LED panel) ................TIME/CALENDAR MODE ..................STOPWATCH MODE (CHRONO) ................TIMER MODE......................ALARM MODE ......................WORLD TIME MODE....................SCHEDULE ALARM MODE ..................SETTING MODE ......................NOTES ON USING THE WATCH ................BATTERY CHANGE ....................
Page 2: Features
MODE CHANGE CAL. W861 l Selection of a desired mode can be made by pressing buttons C or D in the MENU FEATURES display. FULL-pANEL DOT-MATRIx LIqUID CRySTAL pANEL TIME/CALENDAR STOpWATCH WITH MEMORy RECALL FUNCTION COUNTDOWN TIMER 5-CHANNEL REGULAR ALARM...
Page 3: Illuminating Light (Led Panel)
TIME/CALENDAR MODE l Once the time/calendar of your area is set in the TIME/CALENDAR mode, the Select the desired mode. times of the 39 cities covered in the WORLD TIME mode will be set automatically. When button B is pressed, the opening animation display is shown before the selected mode appears.
Page 4 CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME TIME/CALENDAR SETTING If the daylight saving time is effective in the selected city, press Press for 2 seconds to show TIME/CALENDAR SETTING display. to show the daylight saving time. With each press of button C, the standard time and daylight saving time of the city are alternatively shown.
Page 5: Stopwatch Mode (Chrono)
STOpWATCH MODE (CHRONO) MEMORY RECALL FUNCTION l The stopwatch measures up to 99 hours, 59 minutes and 59.99 seconds l The first 100 lap and split times are automatically stored in memory. in 1/100 second increments. l The stored data can be recalled either during or after the measurement. Press in MENU display to show STOPWATCH mode.
Page 6: Timer Mode
TIMER MODE TIMER SETTING l The timer can be set from 10 seconds up to 99 hours, 59 minutes 59 seconds in one- second increments. Press for 2 seconds to show TIMER SETTING display. l The number of times the countdown is repeated can be set from 1 to 99 times. Press to select the digits to be adjusted (hour / minute / second Press in MENU display to show TIMER mode.
Page 7: Alarm Mode
ALARM MODE TIMER OPERATION l The alarm can be set to ring daily at five different times per day. l The alarms can be engaged and disengaged independently of one another. No. of times the countdown is repeated Press in MENU display to show ALARM mode. Start/Stop/Restart Alarm channel Time measured...
Page 8 ALARM ENGAGEMENT/DISENGAGEMENT ALARM TIME SETTING l The alarms can be engaged and disengaged independently of one another. Press to select the desired alarm channel (from AL-1 to AL-5). Press to select the desired alarm channel (from AL-1 to AL-5). Press for 2 seconds to show ALARM SETTING display. With each press, the selected alarm is engaged and disengaged alternately.
Page 9: World Time Mode
WORLD TIME MODE CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME l The time of 39 cities in different time zones throughout the world can be displayed If the daylight saving time is effective in the selected city, press together with their respective country code for overseas telephone call. for 2 seconds to show the daylight saving time.
Page 10 GMT± (hours) City name GMT± (hours) City mark City name Country name Country code City mark Country name Country code D X B Dubai United Arab Emirates C H I Chicago* U.S.A. Kabul Afghanistan + 4.5 K B L N Y C New York* U.S.A.
Page 11: Schedule Alarm Mode
SCHEDULE ALARM MODE SCHEDULE ALARM SETTING l The schedule alarm can be set to ring at 30 different times. Year, month, date, hour, and minute can be set for each schedule. Press to select the desired schedule alarm channel (from l A message up to 14 characters can also be set.
Page 12 Return to SCHEDULE ALARM mode. Return to SCHEDULE ALARM mode. [When editing MESSAGE:] Press to show MESSAGE SETTING display when MESSAGE Press buttons C and D simultaneously to erase the message when advancing or moving back the flashing cursor. is flashing. If no message is set, “NO MESSAGE”...
Page 13: Setting Mode
SETTING MODE ADJUSTING EACH ITEM l The setting of the following functions can be adjusted: Opening animation display, [ANIMATION] time display, eco mode, LCD contrast, LED color, key sound (confirmation sound for l The opening animation display can be engaged (ON) or disengaged (OFF). button operation), alarm sound, schedule alarm sound, and preset messages.
Page 14 [LCD CONTRAST] [ALARM SOUND] l The contrast on the liquid crystal display can be adjusted in 7 steps from level “ -3” l The alarm sounds can be selected between three types of sounds. to “+3”. The contrast becomes higher as the digits indicating the contrast level in- [SCHEDULE ALARM SOUND] l The schedule alarm sounds can be selected between three types of sounds.
Page 15: Notes On Using The Watch
NOTES ON USING THE WATCH The lap time and split time measured remain displayed for 5 seconds together with the flashing lap and split numbers. Then, the display automatically returns to the measurement in progress. TIME/CALENDAR MODE Even if the digits are reset to “00” in the stopwatch measurement, the stored data is not erased and The calendar automatically adjusts for odd and even months including February of leap years from can be recalled unless a new measurement is started.
Page 16: Battery Change
When the battery expires, be sure to replace it as soon as possible to prevent any The time differences and use of daylight saving time may change in some areas or countries. malfunction. l We recommend that you contact an AUTHORIZED SEIKO DEALER and request SCHEDULE ALARM MODE SEIKO CR2025 battery.
Page 17: To Preserve The Quality Of Your Watch
TO pRESERvE THE qUALITy OF yOUR WATCH l Necessary procedure after battery change After the battery is replaced with a new one or if an abnormal display (broken WATER RESISTANCE ■ digits, etc.) appears, follow the procedure below to reset the IC. Condition Press and hold buttons A, B, C and D at the same time for 2 to 3 seconds.
Page 18 ■ TEMPERATURES checked by an AUTHORIZED • When taking a shower with a wa- SEIKO DEALER or SER VICE CENTER to ter resistant 5 bar watch, or tak- 10/15/20 O p e r a t i o n a l t e m p e r a t u r e ■...
Page 19: Specifications
Please contact your AUTHORIZED such as TV screens which emit strong static SEIKO DEALER or SERVICE CENTER if you TIMER mode ........Up to 99 hours and 59 minutes can be set in minute electricity. wish to have a new panel fitted (guaran-...
Page 20 10 preset messages A message up to 14 characters can also be set. SETTING MODE ........Engagement/disengagement of the opening animation display and key sound Changeover between normal and enlarged displays Setting of Eco mode and LCD contrast Selection of LCD color, alarm sound and schedule alarm sound Adjustment of preset messages Others…………………………………….
