Setting the gray level for the sides of the screen

Use this procedure to set the gray level for the parts on the
screen on which nothing is displayed when the screen is
set to the 4:3 size.
Example: Setting "GRAY LEVEL" to "5"
Set "ADVANCED OSM" to "ON" in the FUNCTION menu.
On "GRAY LEVEL" of "SET UP" menu, select "5".
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
SEL. ADJ.
Information
GRAY LEVEL settings
This adjusts the brightness of the black (the gray level)
for the sides of the screen.
The standard is 0 (black). The level can be adjusted
from 0 to 15. The factory setting is 3 (dark gray).

Setting the screen size for S1/S2 video input

If the S-video signal contains screen size information, the
image will be automatically adjusted to fit the screen when
this S1/S2 is set to AUTO.
This feature is available only when an S-video signal is
input via the VIDEO2 terminal.
Example: Setting "S1/S2" to "AUTO"
Set "ADVANCED OSM" to "ON" in the FUNCTION menu.
On "S1/S2" of "SET UP" menu, select "AUTO".
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
SEL. ADJ.
Information
S1/S2 settings
AUTO: Adjusts the screen size automatically according
to the S1/S2 video signal.
OFF: Turns the S1/S2 function off.

Turning on/off the menu display

When this is set to OFF, the menu will not displayed even
if you press the MENU/ENTER button.
Example: Turning the DISPLAY OSM off
Set "ADVANCED OSM" to "ON" in the FUNCTION menu.
On "DISPLAY OSM" of "SET UP" menu, select "OFF".
: ENGLISH
: COMPONENT
: RGB
: 1080 I
: AUTO
: HIGH
: AUTO
: GRAY
: 5
: OFF
: ON
: TOP LEFT
: ALL
: OFF
EXIT RETURN
: ENGLISH
: COMPONENT
: RGB
: 1080 I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: AUTO
: ON
: TOP LEFT
: ALL
: OFF
EXIT RETURN
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
SEL.
Information
DISPLAY OSM settings
ON: The informations on screen size, volume control,
etc. will be shown.
OFF: The informations on screen size, volume control,
etc. will not be shown.
The DISPLAY button on the remote control will not
function either.

Setting the position of the menu

Adjusts the position of the menu when it appears on the
screen.
Example: Set the position to "TOP CENTER"
Set "ADVANCED OSM" to "ON" in the FUNCTION menu.
On "OSM ADJ." of "SET UP" menu, select "TOP CENTER".
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
SEL.
Information
OSM ADJ. settings
TOP
LEFT
BTM
LEFT
En-26
SET UP
: ENGLISH
: COMPONENT
: RGB
: 1080 I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: OFF
: TOP LEFT
: ALL
: OFF
ADJ. RETURN
EXIT
SET UP
: ENGLISH
: COMPONENT
: RGB
: 1080 I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP CENTER
: ALL
: OFF
ADJ. RETURN
EXIT
TOP TOP
RIGHT
CENTER
BTM BTM
RIGHT
CENTER
