Installation, Start-up, Operating, and
Service and Maintenance Instructions
Catalog No: 5331-105
Deluxe Induced-Combustion
-Series A
The 311AAV/JAV Deluxe 4-Way Multipoise Gas Furnace offers
outstanding features in an 80% AFUE furnace. Deluxe features include:
third fan relay for discrete continuous fan speed, the ability to change
continuous fan speeds from the thermostat, dehumidify mode, standard
Media Filter Cabinet, fault code storage, and more. The Plus 80 is very
quiet thanks to a new combustion design that eliminates noise, not just
muffle or box it in. Applications are easy with 4-way multipoise design,
through-the-furnace downflow venting, 13 different venting options, and a
door designed for easy service access. An inner blower door is provided for
tighter sealing in sensitive applications.
approved for use with natural or propane gas, and the 311JAV is also
approved for use in Low NOx Air Quality Management Districts.
STANDARD FEATURES
• Noise elimination combustion system
• Media Filter Cabinet included
• Microprocessor based "smart" control center
Fan On Plus -Continuous Fan speed adjustable from thermostat
Dehumidify mode
Adjustable heating air temperature rise
LED diagnostics and self test feature
Non-volatile fault code storage
• Patented blocked vent safeguard to ensure proper furnace venting
• All models are Chimney Friendly when used with accessory vent
kit
• Insulated blower compartment
• Four-position furnace: upflow, horizontal right, horizontal left,
downflow
Thirteen different vent options
• Heat pump compatible
• Hot surface ignition (HSI)
• Residential installations eligible for consumer financing through
the Comfort Credit Program
LIMITED WARRANTY
• 20-year warranty on "Super S™" heat exchanger
• 3-year parts warranty on microprocessor and hot surface ignition
• 1-year parts warranty on all other components
Form No. II 311A-45-2
4-Way Multipoise Furnace
The Plus 80 Gas Furnace
The 311AAV/JAV furnace is
311AAV/JAV
6-02

Advertisement

Table of Contents
loading

Related Manuals for Bryant 311AAV

Summary of Contents for Bryant 311AAV

  • Page 1 Service and Maintenance Instructions -Series A The Plus 80 Gas Furnace The 311AAV/JAV Deluxe 4-Way Multipoise Gas Furnace offers outstanding features in an 80% AFUE furnace. Deluxe features include: third fan relay for discrete continuous fan speed, the ability to change continuous fan speeds from the thermostat, dehumidify mode, standard Media Filter Cabinet, fault code storage, and more.

  • Page 2: Table Of Contents

    Single-Stage Deluxe Induced-Combustion 4-Way Multipoise Furnace Cancels: II 311A-45-1 II 311A-45-2 Installation, Start-up, Operating, and Service and Maintenance Instructions Series 100/A NOTE: Read the entire instruction manual before starting the EFFICIENCY installation. RATING CERTIFIED TABLE OF CONTENTS SAFETY CONSIDERATIONS .............1 INTRODUCTION ................2 CODES AND STANDARDS............3 CERTIFIED...

  • Page 3: Introduction

    A02096 NOTES: 1. Two additional 7/8-in. diameter holes are located in the top plate. 2. Minimum return-air openings at furnace, based on metal duct. If flex duct is used, see flex duct manufacturer’s recommendations for equivalent diameters. a. For 800 CFM-16-in. round or 14 1/2 x 12-in. rectangle. b.

  • Page 4: Codes And Standards

    Table 1—Dimensions (IN.) VENT UNIT SIZE SHIP WT (LB) CONN* 045-08/024045 14-3/16 12-9/16 12-11/16 045-12/036045 14-3/16 12-9/16 12-11/16 070-08/024070 14-3/16 12-9/16 12-11/16 070-12/036070 14-3/16 12-9/16 12-11/16 070-16/048070 17-1/2 15-7/8 090-14/042090 17-1/2 15-7/8 090-16/048090 19-3/8 19-1/2 090-20/060090 19-3/8 19-1/2 110-12/036110 17-1/2 15-7/8 110-16/048110 19-3/8...
  • Page 5 INSTALLATION MINIMUM INCHES CLEARANCE TO COMBUSTIBLE CONSTRUCTION DISTANCE MINIMALE EN POUCES AUX CONSTRUCTIONS COMBUSTIBLES This furnace is approved for UPFLOW, DOWNFLOW, and This forced air furnace is equipped for use with HORIZONTAL installations. natural gas at altitudes 0-10,000 ft (0-3,050m). Cette fournaise est approuvée pour l´installation HORIZONTALE accessory kit,...

  • Page 6: Location

    Do not install furnace in a corrosive or contaminated atmo- sphere. Make sure all combustion and circulating air require- ments are met, in addition to all local codes and ordinances. → This gas furnace may be used for construction heat provided that: -The furnace is permanently installed with all electrical wiring, piping, venting and ducting installed according to...

  • Page 7: Unconfined Space

    THE BLOWER IS LOCATED BELOW THE BURNER SECTION, AND CONDITIONED AIR IS DISCHARGED UPWARD. THE BLOWER IS LOCATED TO THE RIGHT OF THE BURNER SECTION, AND AIR CONDITIONED AIR IS DISCHARGED TO THE LEFT. THE BLOWER IS THE BLOWER IS LOCATED TO THE LEFT LOCATED ABOVE THE BURNER SECTION, AND...

  • Page 8: Confined Space

    ventilation openings must be equivalent to those used for a 1 SQ IN. PER 4000 DUCTS confined space (defined below). Return air must not be taken from BTUH * the room unless an equal or greater amount of air is supplied to the OUTDOORS room.

  • Page 9: Installation

    free area per 4000 Btuh of total input for all equipment within the confined space. (See Fig. 8 and Table 2.) b. If combustion air is taken from outdoors through 2 hori- zontal ducts, the openings and ducts must have at least 1 sq in.

  • Page 10: Horizontal Installation

    → Table 3—Opening Dimensions (In.) FURNACE PLENUM OPENING FLOOR OPENING CASING APPLICATION WIDTH Upflow Applications on Combustible or Noncombustible 12-11/16 21-5/8 13-5/16 22-1/4 Flooring (KGASB subbase not required) Downflow Applications on Noncombustible Flooring 12-9/16 13-3/16 19-5/8 (KGASB subbase not required) 14–3/16 Downflow applications on combustible flooring (KGASB 11-13/16...

  • Page 11: Air Ducts

    PLENUM OPENING FLOOR FURNACE OPENING CD5 OR CK5 COIL ASSEMBLY OR KCAKC COIL BOX COMBUSTIBLE FLOORING A96283 Fig. 11—Floor and Plenum Opening Dimensions SHEET METAL PLENUM FURNACE FLOOR (OR COIL CASING OPENING WHEN USED) COMBUSTIBLE FLOORING DOWNFLOW SUBBASE SHEET METAL PLENUM FLOOR A96284...

  • Page 12: Ductwork Acoustical Treatment

    Air Conditioning Contractors National Association (SMACNA) or horizontal furnaces. (See Fig. 19.) Bypass humidifier connections American Society of Heating, Refrigerating and Air Conditioning should be made at ductwork or coil casing sides exterior to Engineers (ASHRAE). Or consult The Air Systems Design Guide- furnace.
  • Page 13 UPFLOW DOWNFLOW HORIZONTAL 90° 90° 120° 120° 120° A02020 Fig. 14—Duct Flanges A02013 → Fig. 15—Horizontal Unit Suspension should extend below level of gas controls. Place a ground joint union between gas control manifold and manual gas shutoff valve.

  • Page 14: Electrical Connections

    A02014 Fig. 16—Horizontal Suspension with Straps A 1/8-in. NPT plugged tapping, accessible for test gage connec- Step 7—Electrical Connections tion, MUST be installed immediately upstream of gas supply See Fig. 24 for field wiring diagram showing typical field 115-v connection to furnace and downstream of manual shutoff valve. wiring.
  • Page 15 A02075 Fig. 18—Upflow Return Air Configurations and Restrictions → A02163 Fig. 19—Downflow Return Air Configurations and Restrictions A02162 → Fig. 20—Horizontal Return Air Configurations and Restrictions...

  • Page 16: 115-V Wiring

    → NOTE: On 14″ wide casing models, the J-Box cannot be relo- cated to other side of furnace casing when the vent pipe is routed SUPPLY within the casing . MANUAL SHUTOFF 1. Remove screws holding auxiliary J-box. (See Fig. 22.) VALVE (REQUIRED 2.

  • Page 17: 24-V Wiring

    Table 5—Electrical Data OPERATING VOLTS- MAXIMUM MAXIMUM MAXIMUM MINIMUM VOLTAGE RANGE UNIT SIZE HERTZ- FUSE OR CKT BKR UNIT AMPS WIRE LENGTH (FT)‡ WIRE GAGE PHASE AMPS† Maximum* Minimum* 045-08/024045 115-60-1 045-12/036045 115-60-1 070-08/024070 115-60-1 070-12/036070 115-60-1 070-16/048070** 115-60-1 090-14/042090 115-60-1 090-16/048090 115-60-1...
  • Page 18 TWINNING AND/OR COMPONENT TEST BLOWER OFF-DELAY TERMINAL BLOWER OFF-DELAY HUMIDIFIER TERMINAL (24-VAC 0.5 AMP MAX.) 24-V THERMOSTAT TERMINALS TRANSFORMER 24-VAC CONNECTIONS TEST/TWIN 0.5 AMP@24VAC 3-AMP FUSE FUSE 3-AMP SEC-2 SEC-1 LED OPERATION & EAC-2 DIAGNOSTIC LIGHT PL1-LOW VOLTAGE MAIN HARNESS CONNECTOR 115-VAC(L2)NEUTRAL CONNECTIONS COOL...
  • Page 19 A00268 Fig. 25–Single-Stage Furnace with Single-Speed A00270 Air Conditioner Fig. 27–Single-Stage Furnace with Single-Speed Heat Pump (Dual Fuel) A00271 Fig. 28–Single-Stage Furnace with Two-Speed Heat Pump (Dual Fuel) A00269 Fig. 26–Single Stage Furnace with Two-Speed Air Conditioner...
  • Page 20 HUMIDFIER HUMIDFIER (24VAC) (24VAC) A02103 A02102 → Fig. 30–Dual Fuel Thermostat with Single-Stage Fig. 29–Dual Fuel Thermostat with Single-Stage Furnace and Two-Speed Heat Pump Furnace and Single-Speed Heat Pump HUMIDFIER (24VAC) → A02161 Fig. 31–Two-Stage Thermostat with Single-Stage Furnace and Two-Speed Air Conditioner...
  • Page 21 Notes For Figure 25-31 1. Heat pump MUST have a high pressure switch for dual fuel applications. 2. Refer to outdoor equipment Installation Instructions for additional information and setup procedure. 3. Select the “ZONE” position on the two-speed heat pump control. 4.

  • Page 22: General Venting Requirements

    CARBON MONOXIDE POISONING HAZARD Do not bypass the draft safeguard switch, as an unsafe Failure to follow the steps outlined below for each appliance condition could exist which must be corrected. Failure to connected to the venting system being placed into operation follow this warning could result in a build-up of carbon could result in carbon monoxide poisoning or death.

  • Page 23: Appliance Application Requirements

    these furnaces, which are listed for use with the kit, a listed Local 99% Winter Design chimney-lining system, or a Type-B common vent. Temperature: -11 degrees F or lower* Not recommended for any vent Exterior Masonry Chimney configuration FAN + NAT Installations with Type-B Double-Wall Vent Connectors →...
  • Page 24 CHIMNEY INSPECTION CHART For additional requirements refer to the National Fuel Gas Code NFPA 54/ANSI Z223.1 and ANSI/NFPA 211 Chimneys, Fireplaces, Vents, and Solid Fuel Burning Appliances in the U.S.A. or to the Canadian installation Codes CSA-B149.1 in Canada. Crown Rebuild condition: crown.
  • Page 25 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,7,8,9 A02061 Fig. 36—Downflow Application-Vent Elbow Up A02058 Fig. 33—Upflow Application-Vent Elbow Up SEE NOTES: 1,2,4,5,6,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 A02062 Fig. 37—Downflow Application-Vent Elbow A02059 Fig. 34—Upflow Application-Vent Elbow Right Left then Up SEE NOTES:1,2,3,4,5,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 A02060 A02063...
  • Page 26 SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 A02064 A02066 Fig. 39—Horizontal Left Application-Vent Elbow Left Fig. 41—Horizontal Left Application-Vent Elbow Up SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 A02065 A02067 Fig. 40—Horizontal Left Application-Vent Elbow Right Fig. 42—Horizontal Left Application-Vent Elbow Right then Up SEE NOTES: 1,2,4,5,7,8,9 A02068...
  • Page 27 CONNECTION DIAGRAM TO 115VAC FIELD DISCONNECT SWITCH SCHEMATIC DIAGRAM BLOWER OFF-DELAY FRS2 (NATURAL & PROPANE GASES) JUMPER SELECT OR NEUTRAL EQUIPMENT GROUND DHUM (WHEN USED) MED LO HEAT MED HI GRN/YEL NOTE #10 NOTE #5 START SPARE-1 FRS1 NOTE #15 COOL EAC-2 Y/Y2...

  • Page 28: Additional Venting Requirements

    as detergent, paint, glue, aerosol spray, bleach, cleaning solvent, An accessory Vent Guard Kit, KGAVG0101DFG is REQUIRED salt, and air freshener, and can cause corrosion of furnaces and for downflow applications for use where the vent exits through the vents. Avoid using such products in the combustion-air supply. lower portion of the furnace casing door.

  • Page 29: Adjustments

    must use Table 11 (21,000 Btuh/Burner). See input listed on EXAMPLE 1: rating plate. 88,000 BTUH INPUT FURNACE INSTALLED AT 4300 FT. a. Obtain average yearly gas heat value (at installed altitude) Derate Furnace Input Rate from local gas supplier. Furnace Input Rate Multiplier at Installation...
  • Page 30 b. Run furnace for 3 minutes in heating operation. ON AND OFF SWITCH c. Measure time (in sec) for gas meter to complete 1 revolu- tion and note reading. The 2 cubic feet dial provides a more accurate measurement of gas flow. GAS PRESSURE d.

  • Page 31: Check Safety Controls

    g. When correct input rate and temperature rise is achieved, a. Non-electric thermostat—Set thermostat heat anticipator to turn gas valve ON/OFF switch to OFF. match the amp draw of the electrical components in the R-W circuit. Accurate amp draw readings can be obtained h.

  • Page 32: Checklist

    d. Burners will re-light when furnace cools down. 2. Check draft safeguard switch. Label all wires prior to disconnection when servicing con- The purpose of this control is to permit the safe shutdown of trols. Wiring errors can cause improper and dangerous the furnace during certain blocked vent conditions.

  • Page 33: Care And Maintenance

    SERVICE If status code recall is needed, briefly remove then reconnect one main limit wire to display stored status code. On RED LED boards do not remove power or blower door before initiating status code recall. After status code recall is completed component test will occur. LED CODE STATUS CONTINUOUS OFF - Check for 115VAC at L1 and L2, and 24VAC at SEC-1 and SEC-2.

  • Page 34: Cleaning And/Or Replacing Air Filter

    is not recommended. See Table 9 for size information. 5. If equipped with factory-specified disposable media filter, Turn off the gas and electrical supplies to the unit before replace only with media filter having the same part number performing any maintenance or service. Follow the operating and size.

  • Page 35: Cleaning Heat Exchanger

    b. Remove screws securing cutoff plate and remove cutoff shown in “Adjustments” Section. If outdoor temperature is plate from housing. below 70° F, turn off circuit breaker to outdoor unit before running furnace in the cooling cycle. Turn outdoor circuit c.

  • Page 36: Sequence Of Operation

    11. Spray releasing agent on the heat exchanger cell panel where collector box assembly contacts cell panel. NOTE: A releasing agent such as cooking spray or equivalent (must not contain corn or canola oil, aromatic or halogenated 7/8” hydrocarbons or inadequate seal may occur) and RTV sealant (G.E.
  • Page 37 circuit. The furnace control performs a self-check, verifies the blower motor BLWM will continue operating on the pressure switch contacts PRS is open, and starts the inducer COOL speed for an additional 90 seconds. Jumper Y/Y2 to motor IDM. DHUM to reduce the cooling off-delay to 5 seconds. (See Fig.

  • Page 38: Wiring Diagrams

    blower-ON delay (25 seconds), allowing the furnace heat prepurge period, then shut off for 24 seconds then come back exchangers to heat up more quickly, then restarts at the end of on at HEAT speed. When the W input signal disappears, the the blower-ON delay period at HEAT speed.
  • Page 39 TABLE 10—Orifice Size* and Manifold Pressure For Gas Input Rate (Tabulated Data Based On 22,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS ALTITUDE AVG GAS 0.58 0.60 0.62 0.64 RANGE HEAT VALUE Orifice...
  • Page 40 Table 10—Orifice Size* And Manifold Pressure For Gas Input Rate (Continued) (Tabulated Data Based On 22,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS AVG GAS ALTITUDE HEAT VALUE 0.58 0.60 0.62 0.64...
  • Page 41 Table 10—Orifice Size* And Manifold Pressure For Gas Input Rate (Continued) (Tabulated Data Based On 22,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS AVG GAS ALTITUDE HEAT VALUE 0.58 0.60 0.62 0.64...
  • Page 42 TABLE 11—Orifice Size* and Manifold Pressure For Gas Input Rate (Tabulated Data Based On 21,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS ALTITUDE AVG GAS 0.58 0.60 0.62 0.64 RANGE HEAT VALUE Orifice...
  • Page 43 Table 11—Orifice Size* And Manifold Pressure For Gas Input Rate (Continued) (Tabulated Data Based On 21,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS AVG GAS ALTITUDE HEAT VALUE 0.58 0.60 0.62 0.64...
  • Page 44 Table 11—Orifice Size* And Manifold Pressure For Gas Input Rate (Continued) (Tabulated Data Based On 21,000 Btuh Per Burner, Derated 4 Percent For Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS AVG GAS ALTITUDE HEAT VALUE 0.58 0.60 0.62 0.64...

  • Page 45: Troubleshooting Guide

    TROUBLESHOOTING GUIDE START Is LED status light on? Is there 115V at L1 and L2? Is door switch closed? Is door switch closed? Is there 24V at SEC-1 and SEC-2? Is there 115V going to switch? Is circuit breaker closed? Replace furnace control.
  • Page 46 11 NO PREVIOUS CODE – Stored codes 31 PRESSURE SWITCH DID NOT CLOSE 45 CONTROL CIRCUITRY LOCKOUT OR REOPENED – If open longer than 5 are erased after 72 hours. On RED LED Auto-reset after 1 hour lockout due to: minutes, inducer shuts off for 15 minutes boards stored status codes can also be Flame circuit failure.
  • Page 47 Copyright 2002 Carrier Corporation 58dl2si Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book 1 4 PC 101 Catalog No. See Cover Printed in U.S.A. Form 58DL-2SI Pg 46 6-02 Replaces: 58DL-1SI Tab 6a 8a...
