Quick Start

To attach the MultiSync monitor to your system,
follow these instruction:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information, refer to the
display card manual.
3. For the PC: Connect the 15-pin mini D-SUB of the captive signal
cable to the connector of the display card in your system (Figure A.1)
Tighten all screws.
For the Mac: Connect the MultiSync 75F or 95F Macintosh Cable
Adapter (not included) to the monitor connector on the Macintosh
(Figure B.1). Attach the 15-pin mini D-SUB end of the captive signal
cable to the Macintosh cable adapter on the computer (Figure B.1).
Tighten all screws.
4. Connect one end of the power cord to the MultiSync monitor and the
other end to the power outlet (Figure C.1).
5. Turn on the monitor (Figure D.1) and the computer.
6. This completes the installation.
NOTE: If you have any problems, please refer to the
Troubleshooting section of this User's Manual.
15-pin-mini-D-SUB
Figure A.1
English-8
Captive Signal Cable
