Philips HR7629 User Manual

Register your product and get support at
www.philips.com/welcome
EN User manual
NL Gebruiksaanwijzing
DA Brugervejledning
NO Brukerhåndbok
Benutzerhandbuch
DE
PT Manual do utilizador
EL Εγχειρίδιο χρήσης
SV Användarhandbok
ES Manual del usuario
TR Kullanım kılavuzu
Käyttöopas
FI
FR Mode d'emploi
IT Manuale utente
Specifications are subject to change without notice
© 2014 Koninklijke Philips N.V.
All rights reserved. 3140 035 30412
English
1 Important
Congratulations on your purchase and welcome to Philips! To fully benefit from the support
that Philips offers, register your product at www.philips.com/welcome.
Read this user manual carefully before you use the appliance, and save the user manual for
future reference.
Danger
Do not immerse the motor unit in water nor rinse
•
it under the tap.

Warning

Never use your fingers or an object to push
•
ingredients into the feeding tube while the appliance
is running. Only use the pusher.
Before you connect the appliance to the power,
•
make sure that the voltage indicated on the bottom
of the appliance corresponds to the local power
voltage.
Never connect this appliance to a timer switch, to
•
avoid a hazardous situation.
Do not use the appliance if the power cord, the
•
plug, protecting cover, rotating sieve or any other
parts are damaged or has visible cracks.
If the power cord is damaged, you must have it
•
replaced by Philips, a service center authorized
by Philips, or similarly qualified persons to avoid a
hazard.
This appliance shall not be used by children. Keep
•
the appliance and its cord out of reach of children.
This appliance can be used by persons with reduced
•
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved.
For their safety, do not allow children to play with
•
the appliance.
Never let the appliance run unattended.
•
If food sticks to the wall of the blender jar or bowl,
•
switch off the appliance and unplug it. Then use a
spatula to remove the food from the wall.
Be careful when you are emptying the bowl, handle
•
or clean the discs, the blade units and the juicer
sieve. The cutting edges are very sharp.
Do not touch the blades, especially when the
•
appliance is plugged in. The blades are very sharp.
If the blades get stuck, unplug the appliance before
•
you remove the ingredients that block the blades.
Be careful if hot liquid is poured into the food
•
processor or blender as it can be ejected out of the
appliance due to a sudden steaming.
This appliance is intended for household use only.
•
1
HR7629
(MAX)
(MAX)
5 x 1 sec
5 x 1 sec
30 sec
60 sec
45 sec
30 sec
2-3 min
60-180 sec
60-180 sec
30 sec
30 sec
30 sec
(HR7627, HR7628)
30 sec
AR
30 sec
FA
30 sec
(HR7629)
30 sec
30 sec
4 min
20 sec
(HR7629)
1 min
1 min
1 min
P x 9
(HR7628, HR7629)
3 min

Caution

Never switch off the appliance by turning the
•
blender jar, the bowl, or their lids. Always switch off
the appliance by turning the speed selector to 0 or
OFF.
Unplug the appliance immediately after use.
•
Always wait until the moving parts stop running,
•
then switch off and unplug the appliance before
opening the lid and reaching into any of the parts
that move in use.
Always switch off and unplug the appliance if it is left
•
unattended, and before assembling, disassembling,
cleaning and changing accessories, or approaching
parts that move in use.
Thoroughly clean the parts that come into contact
•
with food before you use the appliance for the first
time. Refer to the instructions and table for cleaning
given in this manual.
Never use any accessories or parts from other
•
manufacturers that Philips does not specifically
recommend. If you use such accessories or parts,
your guarantee becomes invalid.
Do not exceed the maximum level indication on
•
the bowl or the jar. Follow the quantities, processing
time and speed as indicated in the user manual.
Let hot ingredients cool down (< 80ºC) before
•
processing them.
Always let the appliance cool down to room
•
temperature after each batch that you process.
Certain ingredients such as carrots may cause
•
discolorations on the surface of the parts. This
does not have a negative effect on the parts. The
discolorations usually disappear after some time.
Noise level: Lc = 85 dB [A]
•
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations regarding
exposure to electromagnetic fields (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use based on scientific evidence
available today.
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means
the product is covered by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform yourself
about the local rules on the separate collection of electrical and electronic products.
The correct disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
2 Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit from the support
that Philips offers, register your product at www.philips.com/welcome.
This appliance is equipped with a built-in safety lock. You can only switch on the appliance
after you correctly assemble the following parts on the motor unit:
• the food processor bowl and its lid, or
• the blender jar and its lid (HR7628, HR7629 only), or
• the citrus press (HR7629 only)
If these parts are assembled correctly, the built-in safety lock is unlocked.
For recipes to use with your food processor, go to www.philips.com/kitchen
2 3
P 1
(MAX)
(MAX)
500 g P
500 g P/2
50 g P
250 g 2
250 g 2
200 g 2
500 g
1
360 ml
1
350 ml
5
4 pcs 1
500 g 1
500 g 1
2 pcs 1
300 g 1
1
500 g
200 g 1
1
2 pcs
500 g 1
1 kg 1
7
500 g 1
1 L 2
1 L 2
1 L 2
6 x P
400 g
2
600 ml

3 Food processor

Warning
• Never use your fingers or an object to push ingredients into the feeding tube while the appliance is
running. Only use the pusher.
Blade unit
Before you start, make sure you assemble according to Fig. 2.
You can use the blade unit to chop, mix, blend, or puree ingredients. You can also use it to
mix and blend cake batters.
Caution
•
Do not use the blade unit to chop hard ingredients, like coffee beans, turmeric, nutmeg, and ice
cubes, as this may cause the blade to get blunt.
Note
• Do not let the appliance run too long when you chop (hard) cheese or chocolate. Otherwise these
ingredients become too hot, start to melt, and turn lumpy.
• Precut large pieces of food into pieces of approx. 3 x 3 x 3 cm.
1
Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder in
the bowl.
» When the bowl is fixed correctly, you hear a click.
2
Put the blade unit on the tool holder.
3
Put the ingredients in the bowl.
4
Put the lid on the bowl, and then turn the lid clockwise to fix it.
» When the lid is assembled correctly, you hear a click and the lid is fixed to the bowl
handle.
5
Put the pusher into the feeding tube.
6
Connect the power plug to the power supply.
7
Check the preparation time, the maximum amount and the speed setting required for
the ingredients in Table 1. Turn the knob to the desired speed setting.
8
After use, turn the knob to 0, and then unplug the appliance.
Tip
• When you chop onions, turn the knob to P a few times to prevent the onions from becoming too
finely chopped.
• How to remove food that sticks to the blade or to the inside of the bowl? 1. Switch off the appliance,
and then unplug it. 2. Remove the lid from the bowl. 3. Remove the ingredients from the blade or
from the side of the bowl with a spatula.

Kneading accessory

Before you start, make sure you assemble according to Fig. 3.
You can use the kneading accessory to knead yeast dough for bread and pizzas. You need to adjust
the amount of liquid to form the dough according to the humidity and temperature condition.
Note
• Do not use the kneading accessory to blend cake batters. Use the blade unit for this job.
• Always put the kneading accessory in the bowl before you add the ingredients.
1
Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder in
the bowl.
» When the bowl is fixed correctly, you hear a click.
2
Put the kneading accessory on the tool holder.
3
Put the ingredients in the bowl.
4
Put the lid on the bowl, and then turn the lid clockwise to fix it.
» When the lid is assembled correctly, you hear a click and the lid is fixed to the bowl
handle.
5
Put the pusher into the feeding tube.
6
Connect the power plug to the power supply.
7
Turn the knob to the 1 position.
8
Check the preparation time, the maximum amount and the speed setting required for
the ingredients in Table 1.
9
After use, turn the knob to 0, and then unplug the appliance.
4 9
6
10
8
Discs and Inserts
Before you start, make sure you pick your desired disc from following and assemble
according to Fig. 4 and Fig. 5.
• Emulsifying disc
• Insert for fine (HR7627 and HR7628 only)
• Insert for granulating (HR7627 and HR7628 only)
• Reversible slicing / shredding disc (coarse) (HR7629 only)
Caution
•
Be careful when you handle the slicing blade of disc. It has a very sharp cutting edge.
• Never use the disc to process hard ingredients, like ice cubes.
•
Do not exert too much pressure on the pusher when you press ingredients into the feed tube.
Note
•
Precut large ingredients into chunks that fit in the feeding tube.
1
Turn the bowl clockwise to fix it on the motor unit, and then put the tool holder in the
bowl.
» When the bowl is fixed correctly, you hear a click.
2
Put the disc on the shaft. For inserts (HR7627 and HR7628 only), place an insert in the
insert holder as indicated below, then place the insert holder with insert on the shaft.
Place the opening of the insert over the shaft of the insert holder.
Push the opening of the insert over the projection on the shaft.
Press the insert onto the insert holder until it locks in position with a click.
3
Put the lid on the bowl, and then turn the lid clockwise to fix it.
» When the lid is assembled correctly, you hear a click and the lid is fixed to the bowl
handle.
4
Put the ingredients into the feeding tube with the pusher. Fill the feeding tube evenly for
the best results. When you have to process a large amount of ingredients, process small
batches and empty the bowl between batches.
5
Connect the power plug to the power supply.
6
Check the preparation time, the maximum amount and the speed setting required for
the ingredients in Table 1. Select the speed that matches the color of the accessory.
7
After use, turn the speed selector to 0, and then unplug the appliance.
Citrus press (HR7629 only)
Before you start, make sure you assemble according to Fig. 6.
You can use the citrus press to squeeze citrus fruits.
1
Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder in
the bowl.
» When the bowl is fixed correctly, you can hear a click .
2
Put the sieve for citrus press on the tool holder in the bowl. Make sure that the
projection on the sieve is locked in the slot of the bowl handle.
» When the sieve is fixed correctly, you can hear a click .
3
Put the cone on the sieve.
4
Connect the power plug to the power supply.
5
Check the maximum amount required for the ingredients in Table 1. Turn the knob to
speed 1.
» The cone starts rotating.
6
Press the citrus fruit onto the cone.
7
Stop pressing from time to time to remove the pulp from the sieve. When you finish
pressing or when you want to remove the pulp, turn the knob to 0 and remove the bowl
from the appliance with the sieve and cone on it.
Blender (HR7628 and HR7629 only)
Before you start, make sure you assemble according to Fig. 7.
The blender is intended for:
• Blending fluids, like dairy products, sauces, fruit juices, soups, mixed drinks, and shakes.
• Mixing soft ingredients, like pancake batter.
• Pureeing cooked ingredients, like baby food.
• Crushing ice.
11 12
P
1
1/5
