Shark ABC Killer Manual

ABC Killer Shark
FEATURES:
• 30 meters H2O
• Day/date/calendar
• Compass with degrees and direction
• Barometer with pressure trend
• Altimeter with cumulative ascent and
descent
• 99 lap memory chronograph
• Countdown timer
• 5 Alarms
• EL backlight
CONTROL BUTTONS
S1 – Start/split Button
S2 – Stop/reset Button
S3 – Mode Button
S4 – Light/adjust Button
S4
S3
DISPLAY MODES
The watch has eight display modes: TIME,
COMPASS (COMP), ALTIMETER (ALTI),
BAROMETER (BARO), CHRONOGRAPH
(CHRO), TIMER, ALARM and TEMPERA-
TURE (TEMP).
OPENING SCREEN FOR EACH MODE
To change from one display mode to
another, press S3 button once. The mode
description will appear for approximately
2 seconds before the selected mode is
activated.
TO USE THE BACKLIGHT
Press S4 button to turn on the backlight
for 3-5 seconds.
OTHERS
In any setting/viewing mode, if there is
no key manipulation for approximately
1-2 minutes, the watch will automatically
save the entered data and exit the setting/
viewing mode.
TO SET THE TIME AND CALENDAR
Day
1. Press S3 button to select TIME
mode.
2. Press S4 button for approximately 3
seconds.The message "Set-Time"
will be displayed.
3. Press S3 button once, the hour
S1 digits will blink.
4. Press S1/S2 button to set the hour
digits. Holding down the button will
speed up the process.
5. Press S3 button once, the minute
S2
digits will blink.
6. Press S1/S2 button to set the
minute digits.
7. Follow the same pattern to set the
second, year, month, date and hour
format.
8. To set the second digits, press S1/S2
button to reset the second digits to
00.
9. To set the hour format, press S1/S2
button to toggle between 12-hour
and 24-hour format. The P.M.
indicator may be displayed to
indicate the time period 12:00 A.M.
– 11:59 P.M. in 12-hour format.
10.When finished making all the settings,
press S4 button to confirm.
TO SET NIGHT, CHIME AND BEEP
1. In TIME mode, press S4 button for
approximately 3 seconds. The message
"Set-Time" will be displayed.
2. Press S1/S2 button to select option
mode. The message "OPTION" will
be displayed.
3. Press S3 button continuously to
select among NIGHT, CHIME or
BEEP mode.
4. Press S1/S2 button to activate or
deactivate each mode.
5. When finished making all the settings,
press S4 button to confirm.
NOTE: When NIGHT mode is activated,
the NIGHT mode icon will appear. The
backlight will turn on for 3-5 seconds
when any button is pressed. NIGHT mode
will turn off automatically after 8 hours.
TO SHOW DUALTIME (T1 OR T2)
1. In TIME mode, press and hold S2 but-
ton to view T1 or T2 time zone.
2. Press and hold S2 button for approxi-
mately 4 seconds to switch to display
T1 or T2 time zone.
3. Follow the same pattern to toggle
between displaying T1 and T2 time
zones.
TO SHOW CALENDAR OR TEMPERATURE
1. In TIME mode, press and hold S1
button to view calendar or
temperature.
2. Press and hold S1 button for 4
seconds to switch to display
calendar or temperature.
3. Follow the same pattern to toggle
between temperature and calendar
displays.
TO USE THE COMPASS
This moving dot represents the direction
of North (N).
1. Press S3 button to select COMPASS
Sea level
mode. The direction, degree and
pressure trend
time will be displayed.
Time
NOTE: In COMPASS mode, if there is no
key manipulation for approximately 30
Month
seconds, the compass sensor will be de-
Date & Year
activated for power saving. Press S1/S2/
S4 button to re-activate the compass sen-
sor. If the compass sensor is deactivated
for approximately 10 minutes, the watch
will automatically return to TIME mode.
NOTE: If the compass does not seem to
work well, for example: when it displays
the wrong compass direction or it displays
"DISTORT" on the screen, then you have
to calibrate the compass. You should also
calibrate it after replacing the battery. If
your watch has been exposed to strong
electromagnetic fields, such as electric
lines, magnets or loudspeakers, then you
have to calibrate it again.
Calibrate the compass before using it for
the first time and before a long trip.
Because of the difference between true
north and magnetic north, you have to
compensate it by adjusting the compass
declination. The declination angle for your
local area may be found below:
City
Anchorage
Atlanta
Bombay
Boston
Calgary
Chicago
Denver
Jerusalem
London
Little Rock
Livingston, MT 14 E
Munich
New York City
Orlando
Oslo
Paris
Rio De Janeiro 21 W
San Francisco 15 E
Seattle
Shanghai
Toronto
Vancouver
Washington DC 10 W
Waterbury, CT 14 W
TO SET THE DECLINATION ANGLE
1. In COMPASS mode, press and hold S4
button for approximately 3 sec-
onds. The message "CALIB" will be
displayed.
2. Press S1/S2 button to select declina-
tion angle setting mode. The message
"DECLIN" will be displayed.
3. Press S3 button, E will blink.
4. Press S1/S2 button to toggle between
E (East) & W (West).
5. Press S3 button. The declination
angle will blink.
6. Press S1/S2 to set the degree from
0˚ to 90˚.
7. When finished making all the settings,
press S4 button to return to COMPASS
mode.
TO CALIBRATE THE COMPASS
1. In COMPASS mode, press and hold
S4 button for approximately 3 seconds.
The message "CALIB" will be dis-
played.
ENGLISH
Direction
Degree (0º to 360º)
Time
Declination
Angle
22 E
4 W
1 W
16 W
18 E
3 W
10 E
3 E
4 W
3 E
1 E
14 W
5 W
2 W
2 W
19 E
5 W
11 W
20 E
