Page 1: Installation Instructions
Installation Instructions for Topload Washers Original Instructions Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 202955R1 www.speedqueen.com September 2014... -
Page 3: Table Of Contents
Table of Contents Dimensions and Specifications ............... 4 Installation..................... 5 Before You Start.....................5 Supplies..................... 5 Parts Included..................... 5 Order of Installation Steps................5 Remove the Shipping Brace and Shipping Plug..........5 Wipe Out Inside of Washtub................6 Connect Fill Hoses..................6 Water Supply Requirements................. 6 Connecting Hoses.................. -
Page 4: Dimensions And Specifications
Dimensions and Specifications Dimensions and Specifications TLW2162N_SVG 28 in. [711 mm] 22.13 in. [562 mm] *40.77 in. [1036 mm] *53 in. [1346 mm] 26 in. [660 mm] 0.4 in. [10 mm] 25.63 in. [651 mm] *29 in. [737 mm] *43 in. [1092 mm] *36 in. -
Page 5: Installation
Installation Installation Before You Start • User’s Guide • Warranty Bond Supplies Order of Installation Steps For most installations, the basic supplies you will need are: The proper order of steps must be followed to ensure correct in- stallation. Refer to the list below when installing your unit. 1. -
Page 6: Wipe Out Inside Of Washtub
Installation Connect Fill Hoses WARNING Under certain conditions, hydrogen gas may be pro- duced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLO- SIVE. If the hot water system has not been used for such a period and before using the washer, turn on all hot water faucets and let the water flow from each for several minutes. -
Page 7: Connecting Hoses
Installation NOTE: Water pressure under 20 pounds per square inch [138 kPa] will cause an extended fill time in the washer. COLD Turn on the water supply faucets and flush the lines for approxi- mately two minutes to remove any foreign materials that could clog the screens in the water mixing valve. -
Page 8: Low Standpipe Installation
Installation 4. Tighten strap to hold hose to standpipe. This will prevent the drain hose from dislodging from drain receptacle during use. W329I_SVG 1. Beaded Strap (tape if necessary) TLW2220N_SVG 2. Standpipe Adapter 1. Ribbed Portion of Drain Hose 2. Standpipe Adapter Figure 7 3. -
Page 9: Plug In The Washer
Installation Do not slide washer across floor once the leveling legs have been extended, as legs and base could become damaged. 9. Verify that unit does not rock. Plug In the Washer Electrical Requirements 120 Volt, 60 Hertz with 3-Prong Earth/Ground Plug NOTE: The wiring diagram is located in the control hood. -
Page 10: Earth/Ground Instructions
Installation Standard 120 Volt, 60 Hertz 3-Wire Effective Earth/ WARNING Ground Circuit Improper connection of the equipment earth/ground conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the unit is properly connected to a protective earth/ground. -
Page 11: Check Lid Switch
Installation Check Lid Switch Washer should stop filling, agitating, and spinning when lid is opened. W376I_SVG Figure 13 Check Installation 1. Refer to Installer Checklist on the back cover of this manual and make sure that washer is installed correctly. 2. -
Page 12: Installer Checklist
Installer Checklist Installer Checklist Fast Track for Installing the Washer Remove the Shipping Position and Level the Brace and Shipping Washer. Plug. CHECK CHECK TLW2201N_SVG TLW1975N_SVG1 Wipe Out Inside of Plug In the Washer. Washtub. CHECK CHECK TLW2009N_SVG D254I_SVG Connect Fill Hoses. Add Water to the Washer.
