Page 1: Service Manual
FILE NO. SERVICE MANUAL Multimedia Projector Model No. PLC-XL51A U.S.A, Canada, Europe, U.K, original Version Chassis No. KV7-XL51A00 Match the Chassis No. on the rating label of the projector with the Chassis No. in the Service Manual. If the Original Version Service Manual Chassis No. does not match the projector's, additional Service Literature is required.
Page 2: Table Of Contents
Contents SERVICE MANUAL ................. 1 Lamp control ..................71 Contents .................... Audio circuit ..................7 Safety Instructions ................3 Power supply & protection circuit ..........73 Safety Precautions ................3 Eco-Standby (Sub-CPU) ..............74 Product Safety Notice ..............3 Fan control circuit ................75 Service Personnel Warning ............
Page 3: Safety Instructions
Safety Instructions Safety Precautions WARNING: The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of the con- verter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is identified with the line ( ) in the schematic diagram.
Page 4: Specifications
technical Specifications Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 14.7” x 7.75” x 19.49” (374.0 mm x 196.8 mm x 495.0 mm) (Not including protrusions) Net Weight 16.5 lbs (7.5 kg) Feet Adjustment 0˚ to 1.0˚ Panel Resolution LCD Panel System 0.8”...
Page 5: Circuit Protections
■ Circuit Protections This projector provides the following circuit protections to operate in safety. If the abnormality occurs inside the projector, it will automatically turn off by operating one of the following protection circuits. Fuse A fuse is located inside of the projector. When the POWER indicator is not lightning, the fuse may be opened.
Page 6: Lamp Cover Switch
Circuit Protects Lamp cover switch Lamp cover switch (SW901) The lamp cover switch (SW901) cuts off the drive signal to the lamp circuit when the lamp cover is removed or not closed com- pletely. After opening the lamp cover for replacing the lamp ass’y, place the lamp cover correctly otherwise the projector can not turn on.
Page 7: Warning Temperature And Power Failure Protection
Circuit Protects Warning temperature and power failure protection The projector will be automatically turned off when the internal temperature of the projector is abnormally high, or the cool- ing fans stop spinning, or the power supplies in the projector are failed. - If the WARNING TEMP.
Page 8: Maintenance And Cleaning
■ Maintenance and Cleaning Cleaning the Air Filter The air filter prevents dust from accumulating on the surface of the optical elements inside the projector. Should the air filter become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in a buildup of internal heat and adversely affects the life of the projector.
Page 9: Cleaning The Projection Window
Maintenance and Cleaning Cleaning the Projection Window CAUtIoN This projector is equipped with a projection window. Do not rub the projection window with a hard fiber cloth or hit it with a something hard to prevent the projection window from scratching. Do not use a chemical cleaner (liquid and solid) to avoid deteriorating the projection window. Unplug the AC power cord before cleaning.
Page 10: Cleaning
Maintenance and Cleaning Cleaning After long periods of use, dust and other particles will accumulate on the LCD panel, prism, mirror, polarized glass, lens, etc., causing the picture to darken or color to blur. If this occurs, clean the inside of optical unit. Remove dust and other particles using air spray.
Page 11: Lamp Replacement
REPLACEMENt LAMP Replacement lamp can be ordered through your dealer. When ordering a projection lamp, give the following information to the dealer. Model No. of your projector : PLC-XL51A ● Replacement Lamp type No. : PoA-LMP121 ●...
Page 12: Lamp Replacement Counter Reset
Lamp Replacement Lamp Replacement Counter Reset Be sure to reset the Lamp replacement counter after the lamp is replaced. When the Lamp replacement counter is reset, the LAMP REPLACE indicator stops lighting. Turn the projector on and press the MENU button to display the On-Screen Menu.
Page 13: How To Check Lamp Used Time
Lamp Replacement How to check Lamp Used time The LAMP REPLACE indicator will light yellow when the total lamp used time (Corresponding value) reaches 3,000 hours. This is to indicate that lamp replacement is required. The total lamp used time is calculated by using the below expression, Total lamp used time (Corresponding value) = eco + ( normal x 1.5)
Page 14: Security Function Notice And Standby Mode Notice
■ Security Function Notice and Standby mode Notice Security Function disable This projector provides security functions such as "Key lock", "PIN code lock" and "Logo PIN code lock". When the projector has set these security function on, you are required to enter correct PIN code to use the projector. If you do not know the correct PIN code to the projector, the projector can no longer be operated or started.
Page 15: Network Easy Setup Function
■ Network Easy Setup Function Network Easy Setup function by using the Sd memory card 1. outline This projector provides a function to setup the network automatically by reading the network setting file (PJ_Network.ini) stored in the top directory of the SD memory card. By using the function, network setup can be done easily. Setting Procedure 1.
Page 16 Network Easy Setup Function 2-1-1 Used LAN No. Used LAN No. is specified. Setting Object LANNO Item type LAN No. 1 to 6 * If out of range value is specified, the setting is invalid. 2-1-2 Basic Network Setting Basic network setting is specified. LAN1 LAN LAN3...
Page 17 Network Easy Setup Function 2-1-4 Wireless LAN (WEP key) Setting WEP key of Wireless LAN are specified. WIRELESS4-WEP WIRELESS5-WEP Setting Object WEP64 / SHARED-WEP64 WEP18 / SHARED-WEP18 WEP key (1) WEP key () Item types 5 characters for ASCII 13 characters for ASCII (4 items) 10 characters for HEX 6 characters for HEX...
Page 18 Network Easy Setup Function description Describe "Example of setting file" as below; Used LAN No. Setting Object LAN No. LANNO LAN1 is specified for used LAN No. If the projector provides the SD memory card, LAN1 is selected forcibly. If this item is not specified, this function is disable.
Page 19: Mechanical Disassemblies
■ Mechanical disassemblies Disassemble should be made following procedures in numerical order. Following steps show the basic procedures, therefore unnecessary step may be ignored. Caution: The parts and screws should be placed exactly the same position as the original other- Screws Expression wise it may cause lose of performance and product safety.
Page 20 Mechanical disassemblies . Remove the DEC Legs. 3. Remove the screws-B (M3x35). 4. Remove the Stand Legs and Cap Stand Legs. DEC Leg DEC Leg Stand Leg Stand Plate Stand Leg Cap Stand Leg Cap Stand Leg - 0 -...
Page 21 Mechanical disassemblies Lamp Unit and Alarm Battery removal. 1. Remove the screw-A(M3x8) and remove the Lamp cover. . Loosen the screws-B and remove the Lamp uint. 3. Remove the Air Filter upward. Lamp Cover Lamp Unit Air Filter - 1 -...
Page 22 Mechanical disassemblies Cabinet top ass'y removal. 1. Remove the 9 screws-A(M3x8) and remove the Cabinet top ass'y. . Remove the screw-B(T3x8), remove the R/C board, R/C pipe and remove the Decoration R/C. 3. Remove the Control board and Control Button. 4.
Page 23 Mechanical disassemblies Main Board ass'y removal. 1. Remove the screws-A(M.5x6) and remove the Antenna board, Shield antenna. . Remove the 4 screws-B(M.5x6), screw-C(M4x6), screws-D(T3x10) and remove the Main board ass'y. Antenna board Shield antenna Main board ass'y Hook Press this part - 3 -...
Page 24 Mechanical disassemblies 3. Remove the 3 screws-E(T3x6) and AV panel. 4. Remove the 4 nuts-F and Holder AV. 5. Remove the screw-G(M3x4), remove the LED board and remove the Decoration LED. Main Board Ass'y LED board Decoration LED Holder AV AV Panel - 4 -...
Page 25 Mechanical disassemblies 6. Remove the screws-H(M.5x6) and remove thenetwork board ass'y. Main board AV board Network board ass'y - 5 -...
Page 26 Mechanical disassemblies 7. Remove the 3 screws(T3x8) and disassembly the network board ass'y. Network board ass'y (T3x8) x3 Module board Shield MCI - B Shield MCI - A Network board - 6 -...
Page 27 Mechanical disassemblies Exhaust Fan ass'y removal. 1. Remove the exhaust Fan ass'y(FN903, FN904) upward. . Remove the screws-A(T3x8), remove the stopper exhaust Fan and remove the FN903, FN904. Exhaust Fan ass'y Mounting exhaust duct FN904 Exhaust Fan ass'y Stopper exhaust fan FN903 - 7 -...
Page 28 Mechanical disassemblies Power supply ass'y removal. 1. Remove the screw-A(M3x8) and remove the Lamp connector. . Remove the screw-B(M.5x6) ,remove the Ballast trigger holder and shield plate. 3. Remove the screws-C(T3x8), remove the screw-D(T3x8) and remove the Power Supply ass'y. Ballast trigger holder Power supply ass'y Shield plate...
Page 29 Mechanical disassemblies Power supply ass'y disassemble. Insulation sheet -A Insulation sheet -B M.5x6 T3x6 Power supply ass'y Power board T3x6 T3x6 Ballast unit Holder - 9 -...
Page 30: Optical Unit Removal
Mechanical disassemblies optical unit removal. 1. Remove the 5 screws-A(T3x8) and remove the Optical unit. Optical unit Caution ; Do not lose these parts. (4 pieces) (damper and Washer). - 30 -...
Page 31: Line Filter Board Removal
Mechanical disassemblies Line filter board removal. 1. Remove the 3 screws-A(T3x8) and remove the Line filter board ass'y. . Remove the Shield plate. Shield plate Line filter board ass'y Holder Line filter board M3x6 M3x6 Line filter board ass'y InsulatIion sheet AC-A InsulatIion sheet AC-B...
Page 32 Mechanical disassemblies Lamp Cover Switch removal. 1. Remove the 2 screws-A(T3x8), remove the Spacer sheets, remove the Holder-SW and remove the Thermal Switch (SW902) 2. Remove the screw-B(T3x8) and remove the Lamp cover switch (SW901). Spacer sheet A Spacer sheet B Holder -SW Thermal SW(SW902) Lamp cover SW(SW901)
Page 33 Mechanical disassemblies duct ass'y removal. 1. Remove the 6 screws-A(T3x30), remove the screw-B(T3x8) and remove the Duct ass'y. . Remove the screws-C(T3x8) and remove the Duct top-A, Duct top-B. 3. Remove the Fans(FN901, FN90, FN905) and Temp board. Duct ass'y Duct top-A Duct top-B Duct ass'y...
Page 34 Mechanical disassemblies Speaker unit removal. 1. Remove the screws-A (T3x1) and remove the speaker unit. Speaker unit M3x4 M3x4 Speaker Damper Damper Holder Spacer - 34 -...
Page 35: Optical Parts Disassembly
■ optical disassemblies optical unit Projection lens removal. 1. Remove the 4 screws (M4x1), remove the shield plate remove the 4 spacer and remove the projection lens. Shield plate Projection lens Spacer Spacer Caution ; Do not lose these parts (damper). - 35 -...
Page 36 Optical disassemblies LCd panel/prism ass'y removal. 1. Remove the 4 screws-A (M.5x8) and remove the LCD panel/prism unit. . Remove the screws-B (M.5x4), remove the screw-C (M3x10) and remove the LCD panel/prism ass'y. LCD panel/prism unit LCD panel/prism ass'y Damper Mounting prism Damper...
Page 37 Optical disassemblies R-type LCd Panel/Prism Ass'y L-type LCd Panel/Prism Ass'y There are types of LCD Panel/Prism Ass'y for this model. Either L-Type or R-Type LCD Panel/Prism Ass'y is used on the projec- tor. Check which type of LCD Panel/Prism Ass'y is used with the figure. The optical-characteristics is different between L-Type and R-Type LCD Panel/Prism Ass'y.
Page 38 Optical disassemblies Integrator Lens ass'y and Relay Lens ass'y removal. 1. Remove the screws-A (M.5x5) and remove the Integrator Lens ass'y. . Remove the screws-B (M.5x5), remove the Relay Lens ass'y. Relay lens ass'y Integrator lens ass'y INtEGRAtoE LENS (IN) 凸...
Page 39 Optical disassemblies Polarized glass ass'y removal. 1. Remove the screw-A (M.5x5) and remove the Polarized glass ass'y (R, G, B). Polarized glass ass'y Green Blue Green, Blue Polarized glass ass'y Red Polarized glass ass'y Holder Film side Do not touch this surface and back surface.
Page 40 Optical disassemblies optical base top removal. 1. Remove the Optical base top-B. . Remove the screws (T3x8) and remove the Optical base top-A. Optical base top-A Optical base top-B Hook - 40 -...
Page 41: Optical Parts Location And Direction
■ optical Parts Location and direction Parts Name INtEGRAtoR LENS (oUt) CoNdENSER LENS (oUt) NC CoNdENSER LENS (G) CoNdENSER LENS (B) CoNdENSER LENS (R) RELAY LENS (IN) MIRRoR (B) MIRRoR (R) PRISM (PBS) dICHRoIC MIRRoR (B) dICHRoIC MIRRoR (G) Rugged surface Print marker this top side.
Page 42: Adjustments
■ Adjustments Adjustments after Parts Replacement : Adjustment necessary : Check necessary ● ❍ disassembly / Replaced Parts Polarized Glass LCd/ Integrator Relay Projection Power Main Prism Ass’y Lens (IN) Lens (oUt) lens Board Board Contrast Adjustment R-Contrast adjustment ❍ ● G-Contrast adjustment ❍...
Page 43: Optical Adjustments
■ Optical Adjustments Before taking optical adjustments below, remove the Cabinet Top following to the “Mechanical Disassembly”. Adjustments require a .0mm hex wrench and a slot screwdriver. When you adjust Integrator lens or Relay lens adjustment, you need to disconnect FPC cables of LCD panels on the main board. Optical adjustment requires a .0mm hex wrench and a slot screwdriver.
Page 44: Integrator Lens Adjustment
Optical Adjustments Integrator lens adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of integrator lens assy to make color unifor- mity in white. 1) If the shading appears on the left or right of the screen as shown in White Fig.2-1 , loosen 1 screw...
Page 45: Relay Lens-Out Adjustment
Optical Adjustments Relay lens-out adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of relay lens assy to make color uniformity in white. Fig.3 If the shading appears on the left or right of the screen as shown in loosen 1 screw , and adjust the slot to make color uniformity in white...
Page 46: Projection Lens Focus Adjustment
Optical Adjustments Projection lens focus adjustment Projection lens [ Before Adjustment ] The projector is set from the screen to 8 cm. The hole of the focus ring is set to the position of figure by operating the focus lever. (Screen size 78") Input a cross pattern.
Page 47 Optical Adjustments Loosen the 4 screws-A (A1, A2, A3, A4). Right and left focus under the screen is adjusted by using slot B. (Pre-adjustment) The screws-A1, A2 are lightly tightened and temporary is fixed. Focus on the entire screen is adjusted. Tighten the 4 screws-A (A1, A2, A3, A4).
Page 48: Electrical Adjustments
Refer to the “Service Adjustment Data Table” for further description of adjustment group no., item no. and data value. to exit the service mode oN/StANd-BY button To exit the service mode, press the oN / StANd-BY button MENU button Service Mode SANYO Input Video Data Group COMPUTER NETWORK COMPONENT Ver.
Page 49: Circuit Adjustments
Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the following adjust- ments except requiring the readjustments in servicing otherwise it may cause loss of performance and product safety. Note: Before adjustment, turn on the projector more than 10 minutes.
Page 50: Common Center Adjustment
Service Adjustment 1. Fan minimum voltage adjustment 4. Auto Calibration adjustment [Video] Equipment Digital voltmeter 1. Enter the service mode. . Receive the 16-step grey scale composite video signal Video [Video] 1. Enter the service mode. with mode. . Change data values of each test points to adjust the fan Lamp control Normal mode.
Page 51: Gamma Correction Adjustment
Service Adjustment 7. Gamma Correction adjustment This adjustment must use the service tool. Adjust the gamma curve correction by using the proper computer and "PROJECTOR SERVICE TOOL CD-ROM" soft- ware supplied separately. 8. Read/Write of LCd panel gamma data when Main Board replacing The gamma adjustment data of each LCD panel has been adjusted preciously to much each LCD panel characteristics...
Page 52: Test Points And Locations
Service Adjustment test Points and Locations MAIN BoARd TE501 TP563 TP561 TP501 TP531 K35G TP503 IC5201 IC5301 IC1802 IC5001 K201 - 5 -...
Page 53: Service Adjustment Data Table
Service Adjustment Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjustment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
Page 54 Service Adjustment Item Name Function Initial Range Note Group/Item 162 PreCoast YCbCr 1080i 60Hz 0 - 63 163 PostCoast YCbCr 1080i 60Hz 0 - 63 164 PreCoast YCbCr 1080i 50Hz 0 - 63 165 PostCoast YCbCr 1080i 50Hz 0 - 63 166 PreCoast YCbCr 1035i 0 - 63 167 PostCoast YCbCr 1035i...
Page 55 Service Adjustment Item Name Function Initial Range Note Group/Item 2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 0 - 1023 3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 0 - 1023 4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 - 255 Group 47 Noise Reduction (Time) Effective only for N.R L1 0 Noise Pixel Range...
Page 56 Service Adjustment Item Name Function Initial Range Note Group/Item Group 60 Image 0 Center Contrast 534/578/534/534/492/492 0 - 1023 1 Center Brightness 512/496/512/500/512/512 0 - 1023 2 Center Color 512/512/512/512/512/512 0 - 1023 3 Center Tint 90/90/90/90/90/90 0-180 Video(S-Video) / Component / SCART 4 Center Sharpness 16/16/16/16/16/16 /ANALOG / DIGITAL / HDCP...
Page 57 Service Adjustment Item Name Function Initial Range Note Group/Item 51 TG CLR_U 0-1023 52 TG CLR_D 0-1023 53 TG VCKP 0-2047 54 TG VCKPD 1344 0-2047 55 TG VVSTP 0-255 56 TG DFT_ON 57 TG HPC_R_DAT00 0-8191 58 TG HPC_R_DAT01 0-8191 59 TG HPC_G_DAT00 0-8191...
Page 58 Service Adjustment Item Name Function Initial Range Note Group/Item 121 CSC_G_GP3 0-511 122 CSC_G_GP4 0-511 123 CSC_G_GP5 0-511 124 CSC_G_GP6 0-511 125 CSC_G_GP7 0-511 126 CSC_G_GP8 0-511 127 CSC_B_GP1 0-511 128 CSC_B_GP2 0-511 129 CSC_B_GP3 0-511 130 CSC_B_GP4 0-511 131 CSC_B_GP5 0-511 132 CSC_B_GP6 0-511...
Page 59 Service Adjustment Item Name Function Initial Range Note Group/Item 207 C0lshd Level R max 0-511 208 C0lshd Level G min 0-511 209 C0lshd Level G 0-511 210 C0lshd Level G 0-511 211 C0lshd Level G max 0-511 212 C0lshd Level B min 0-511 213 C0lshd Level B 0-511...
Page 60 Service Adjustment Item Name Function Initial Range Note Group/Item 0:Disable (Service Adjustment 4 Sub Image Enable 0 - 1 Dsiable, Used all the Center Values 1:Enable (Service Adjustment Enable) 0:Zoom Accelerator OFF, 6 Zoom Accelerator Enable 0 - 1 1:Zoom Accelerator ON No last memory 0:Enable (Normal), 1:Disable (Dzoo is not cancelled even if Keystone is...
Page 61 Service Adjustment Item Name Function Initial Range Note Group/Item Luminance Data Avarage Point for 15 DIMMER_AVERAGE_POINT 0 - 16 Mimmer Luminance Data Avarage Value for 16 DIMMER_AVERAGE_DATA * Read only Dimmer 17 DIMMER_LEVEL_AUTO Current Dimmer Leverl * Read only 18 DIMMER_LEVEL_NORMAL High Dimmer Level 0 - 15 19 DIMMER_LEVEL_ECO...
Page 62 Service Adjustment Item Name Function Initial Range Note Group/Item Group 254 Fan Control Range Setting (Temp./Voltage) Normal Ceiling Down 0 Not used 1 Not used Down 2 Not used 3 Not used 4 Not used 5 Not used Normal Celling 6 Not used 7 Not used 8 Not used...
Page 63 Service Adjustment Item Name Function Initial Range Note Group/Item With Onstart on. At the time of Power on after Cooling imperfect. 11 OnStart Cooling Start Threshold 0-100 Cooling The temperature set point for existence judgement 12 After shutdown cooling Cooling after shutdown (0: No, 1: Yes) Group 256 Fan Lamp Voltage Down Setting Current Lamp Voltage (0.1V)(Read...
Page 64 Service Adjustment Item Name Function Initial Range Note Group/Item CR - Offset Acquiring Area H-Start 4 CR - OFFSET AREA H START 0 - 1000 If not used: use Y's value Position CR - Offset Acquiring Area V-Start 5 CR - OFFSET AREA V START 0 - 1000 If not used: use Y's value Position 6 Y - GAIN AREA H START...
Page 65 Service Adjustment Item Name Function Initial Range Note Group/Item 2 H Back Porch 0 ~ 4095 3 V Back Porch 0 ~ 4095 4 Disp Line 0 ~ 4095 7 Overscan Not used 0 - 255 8 VSBEG Not used 0 - 15 Group 511 SCART (575i)
Page 66 Service Adjustment Item Name Function Initial Range Note Group/Item Group 526 YCbCr (1080i - 60) 0 Total Dots 2200 0 ~ 4095 * Read only 1 Disp Dots 1872 0 ~ 4095 2 H Back Porch 0 ~ 4095 3 V Back Porch 0 ~ 4095 4 Disp Line 1052...
Page 67 Service Adjustment Item Name Function Initial Range Note Group/Item 8 VSBEG Not used 0 - 15 Group 545 RGB Video (720P - 50 ) 0 Total Dots 1980 0 ~ 4095 1 Disp Dots 1246 0 ~ 4095 2 H Back Porch 0 ~ 4095 3 V Back Porch 0 ~ 4095...
Page 68 Service Adjustment Item Name Function Initial Range Note Group/Item 4 Disp Line 1064 0 ~ 4095 7 Overscan Not used 0 - 255 8 VSBEG Not used 0 - 15 Group 553 RGB Video (1080P - 24) 0 Total Dots 2750 0 ~ 4095 1 Disp Dots...
Page 69: Chassis Block Diagram
Chassis Block Diagrams Chassis over view POWER_SW_MCU MCU_STAT PW_EX_UART EX_PW_UART 124,368 IRRCVR0 331,161 IC5301 SYNC SEP. <BA7078> IC5041 AUDIO OUTPIT IC5201 <TDA7056at> PC1/PC2-SW <AN5870> IC5001 AUDIO CONTROL <NJW1141> IC4001 IC4011 AUDIO - 69 -...
Page 70: System Control
Chassis Block Diagrams System control IC891 INVERTER <MH74LVC> IC3501 <M62334> IC301 IC1802 SCALER <PW190> I/O EXPANDER - 70 -...
Page 71: Lamp Control
Chassis Block Diagrams Lamp control - 71 -...
Page 72: Audio Circuit
Chassis Block Diagrams Audio circuit - 72 -...
Page 73: Power Supply & Protection Circuit
Chassis Block Diagrams Power supply & protection circuit IC631 BLAST_AC FAN_ERR IC301 SCALER <PW190> - 73 -...
Page 74: Eco-Standby (Sub-Cpu)
Chassis Block Diagrams Eco-Standby (Sub -CPU) POWER BOARD POWER_SW_MCU_A IC301 MCU_STAT MCU_FILTER_LED IC301 MCU_POWER_LED PW190 IC4501 PW_MASTER_SD0 MCU_READY_LED SUB-CPU MCU_LAMP_LED MCU_TEMP._LED Control Port MASTER_SDI IC6942 MCU_EX_UART CPU_EX_UART MASTER_SCK IC3801 IC6961 EX_MCU_UART EX_CPU_UART IC891 RC_MCU ON_DC MAIN S16V Q683 S16V ES16V Q3611 POWER POWER_SW_MCU...
Page 75: Fan Control Circuit
Chassis Block Diagrams Fan control circuit TPFANA FN901 S16V FAN_1 D3622 D3621 FN902 IC7801 D3624 Q7801 TPFANB FN903 FAN_2 D3627 FN904 D3626 IC7841 D3629 Q7841 Q3601 P_FAIL P_FAIL P_Fail: H FAN_ERR Power Error: On TPFANC FN905 FAN_3 D3632 D3631 IC7871 Q7871 LAMP IC4891...
Page 76: Iic Bus Control Circuit
Chassis Block Diagrams IIC bus control circuit - 76 -...
Page 77: Network (Mci) Circuit
Chassis Block Diagrams Network (MCI) circuit - 77 -...
Page 78: Troubleshooting
■ Troubleshooting Indicators and Projector Condition Check the indicators for projector condition. Indicators WARNING WARNING LAMP Projector Condition POWER TEMP. FILTER REPLACE red/green orange yellow The projector is off. (The AC power cord is unplugged.) The projector is preparing for stand-by or the projection lamp is being cooled down.
Page 79: No Power
Troubleshooting No Power This projector provides a function which can be specified a defective area simply by indicating the LEDs. Connect the AC cord and press the Power button once and then check the LED indication. - When all of LED indicators are not lighting, the symptom indicates that the primary power supply circuit does not operate properly.
Page 80: No Picture
Troubleshooting No Picture Check following steps. No picture with all of Check signal processing stage and LCD driving stage; input sources Check power supply circuit 15.5V_PNL, 3.3V_DI and peripheral circuit. Check ICs IC501, IC531, IC561, IC401, IC301 and peripheral circuits. Check PC1/PC2-switching stage;...
Page 81: No Sound
Troubleshooting No Sound Check following steps. Check if the audio signal Check IC5001 and peripheral circuit. is observed at pins 10 and Check 9V_AUDIO, 16V power supply. 21 of IC5001. Check if the audio signal Check IC5041, 9V_AUDIO and peripheral circuit. is observed at pins 5 and Check the Mute signal at pin 7 of IC5041.
Page 82: Control Port Functions
Control Port Functions Scaler I/O Port Functions (PW190) Pin No. Name Function Name Function Switch DDC-SW2 DDC mode switch OFF:L Switch DDC-SW1 DDC mode switch OFF:L Switch COMP_SW Component switch DE_MCI MCI data enable CK_MCI MCI clock VS_MCI MCI H-sync HS_MCI MCI V-sync Switch...
Page 83 Scaler I/O Port Functions (PW190) Continue Function Pin No. Name Function Name COMPONENT Component Video signal ANALOG RGB Analog RBG ANALOG RGB Analog RBG ANALOG RGB Analog RBG VIDEO VIDEO GSYNC YSYNC ANALOG RGB SCART_CV H1-IN S-VIDEO S-VIDEO S_CHROMA ON_15.5V_PW 15.5V Power drive Power ON : H LAMP BLAST_AC...
Page 84: Ic Block Diagrams
IC Block Diagrams ● AN5870 <Signal Switch, IC5201> ● BA7078 <Sync Separator, IC5301> - 84 -...
Page 85 IC Block disgrams ● FA5502 <P.F. Control, IC601> ● HIN202EIB <RS-232C Driver, IC3801> - 85 -...
Page 86 IC Block disgrams ● M62334 <DAC (For Fan Control), IC3501> ● PW190 <Scaler, IC301> - 86 -...
Page 87 IC Block disgrams ● NJW1141 <Audio Control, IC5001> - 87 -...
Page 88: Electrical Parts List
Electrical Parts List Product safety should be considered when a component replacement is made in any area of a projector. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety. It is particularly recommended that only parts specified on the following parts list be used for components replacement pointed out by the mark.
Page 89: Electrical Parts Location
Elecrical Parts Location ● Assemblied Board A601 A2901 POWER BOARD R/C BOARD A6801 KEY SW BOARD A901 BALLAST UNIT A2001 AV BOARD A690 LAMP COVER SW BOARD A602 LINE FILTER BOARD A2000 NETWORK BOARD A1001 MAIN BOARD A2100 MODULE BOARD A2200 ANTENNA BOARD A4831...
Page 90: Electrical Parts List
KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description A2200 610 340 2123 ASSY,PWB,ANTENNA.KV7A ASSEMBLED BOARDS CAPACITOR A2100 610 340 2147 ASSY,PWB,MODULE.KV7A C9901 403 466 7416 CERAMIC 0.9P B A2200 610 340 2123 ASSY,PWB,ANTENNA.KV7A C9902 645 073 5554 INDUCTOR,0.0091U J A2000 610 348 0909 ASSY,PWB,NETWORK.KV7AE MISCELLANEOUS...
Page 91 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C8633 303 409 3426 CERAMIC 0.1U K C5111 303 391 5511 ELECT 10U M C5112 303 391 5511 ELECT 10U M C8634 303 409 3426 CERAMIC 0.1U K C8636 303 409 3426...
Page 92 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C8871 303 409 3426 CERAMIC 0.1U K R5107 301 275 1819 MT-GLAZE 1.1K JA 1/16W C8872 303 409 3426 CERAMIC 0.1U K R5108 301 263 6928 MT-GLAZE 2K JA 1/16W C8873...
Page 93 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R8662 301 224 9019 MT-GLAZE 10K JA 1/16W R8477 301 224 8913 MT-GLAZE 100K JA 1/16W R8478 301 224 9019 MT-GLAZE 10K JA 1/16W R8663 301 226 1516 MT-GLAZE 0.000 ZA 1/16W R8664...
Page 94 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description RB8325 945 034 5051 R-NETWORK 22X4 1/32W R8931 945 086 5368 IMPEDANCE,220 OHM P R8932 301 294 3115 MT-GLAZE 1K FA 1/16W 945 037 0824 R-NETWORK 22X4 1/16W RB8326 945 034 5051 R-NETWORK 22X4 1/32W...
Page 95 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description L8932 945 062 2824 INDUCTOR,3.3U M 305 014 4611 TR 2SC2412K T146 S L8933 945 062 2824 INDUCTOR,3.3U M 305 015 8727 TR 2SC2812-L6-TB L8934 945 062 2824 INDUCTOR,3.3U M 305 015 8925 TR 2SC2812-L7-TB...
Page 96 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C673 303 410 7113 ELECT 100U M L631 910 078 5954 PIPE CORE C674 403 478 9019 MT-POLYEST 0.01U J 630V L661 910 244 3975 CORE L662 910 244 3975 CORE...
Page 97 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 305 173 9816 TR 2SC3928A1R 405 220 3115 TR ISA1235AC1E 405 220 3016 TR ISA1235AC1F 305 173 9915 TR 2SC3928A1S Q202 305 014 4512 TR 2SC2412K T146 R Q1061 305 134 5928 TR 2SA1037AK-T146-R...
Page 98 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description Q4547 305 014 4512 TR 2SC2412K T146 R 305 015 8727 TR 2SC2812-L6-TB 305 015 8925 TR 2SC2812-L7-TB 305 014 4611 TR 2SC2412K T146 S 305 015 8727 TR 2SC2812-L6-TB 305 163 1615 TR 2SC2812N-L6-TB0...
Page 99 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description Q5701 305 217 5019 TR RN1117 TE85L 305 015 8727 TR 2SC2812-L6-TB 305 015 8925 TR 2SC2812-L7-TB Q5702 305 217 5019 TR RN1117 TE85L Q5751 305 217 8515 TR RSQ025P03-TR 305 163 1615 TR 2SC2812N-L6-TB0...
Page 100 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 305 173 9816 TR 2SC3928A1R IC1361 409 699 6516 IC TA48S00AF 305 173 9915 TR 2SC3928A1S IC1371 309 531 6229 IC FA7701V-TE1 Q6907 305 014 4512 TR 2SC2412K T146 R IC1381 309 553 4712...
Page 101 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 303 433 1112 CERAMIC 1U K C1301 303 438 0219 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K C1447 403 455 1012 CERAMIC 1U K 303 433 1112 CERAMIC 1U K...
Page 102 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C2586 303 367 0410 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K C1831 303 438 0219 CERAMIC 0.1U K C2587 303 396 9613 CERAMIC 1U K 303 397 7618 CERAMIC 1U K...
Page 103 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 303 368 7319 CERAMIC 10U K 6.3V 303 409 3426 CERAMIC 0.1U K C331 303 438 0219 CERAMIC 0.1U K C362 403 455 1012 CERAMIC 1U K 303 433 1112 CERAMIC 1U K...
Page 104 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 303 433 1112 CERAMIC 1U K C4003 303 382 7814 CERAMIC 2.2U K C4004 303 438 0219 CERAMIC 0.1U K C436 403 455 1012 CERAMIC 1U K 303 433 1112 CERAMIC 1U K...
Page 105 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 303 409 3426 CERAMIC 0.1U K C4592 303 358 3215 CERAMIC 10U K 6.3V 303 368 7319 CERAMIC 10U K 6.3V C5018 303 401 5715 CERAMIC 0.33U K C5019 403 455 1012...
Page 106 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 303 433 1112 CERAMIC 1U K C5214 303 438 0219 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K C5601 303 397 5713 ELECT 100U M 303 387 5617 ELECT 100U M...
Page 107 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C7209 303 438 0219 CERAMIC 0.1U K 303 387 7314 ELECT 47U M C5703 303 342 3313 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K C7211 303 438 0219 CERAMIC...
Page 108 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description C8821 303 276 3113 CERAMIC 33P J C7803 303 438 0219 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K C8822 303 276 3113 CERAMIC 33P J C8823 303 438 0219 CERAMIC...
Page 109 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R1819 301 224 9019 MT-GLAZE 10K JA 1/16W R1373 301 224 9019 MT-GLAZE 10K JA 1/16W R1374 301 225 0213 MT-GLAZE 3.3K JA 1/16W R1821 301 225 0213 MT-GLAZE 3.3K JA 1/16W R1823...
Page 110 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R2890 301 224 9712 MT-GLAZE 22 JA 1/16W R2074 301 224 9910 MT-GLAZE 22K JA 1/16W R2075 301 225 3818 MT-GLAZE 1.5K JA 1/16W R2891 301 224 9712 MT-GLAZE 22 JA 1/16W R2892...
Page 111 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R424 301 224 9712 MT-GLAZE 22 JA 1/16W R3615 301 230 8013 MT-GLAZE 1K JA 1/3W R3616 301 224 8913 MT-GLAZE 100K JA 1/16W R425 301 224 9712 MT-GLAZE 22 JA 1/16W R426...
Page 112 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R5165 301 265 1614 MT-GLAZE 470 FA 1/10W R4597 301 301 8119 MT-GLAZE 3.9K FA 1/16W R4599 301 294 2613 MT-GLAZE 4.7K FA 1/16W R5201 301 225 8110 MT-GLAZE 10 JA 1/16W R5202...
Page 113 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R6957 301 225 1210 MT-GLAZE 4.7K JA 1/16W R5644 301 237 2915 MT-GLAZE 51 JA 1/16W R5647 301 224 9019 MT-GLAZE 10K JA 1/16W R6958 301 225 1210 MT-GLAZE 4.7K JA 1/16W R6959...
Page 114 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description R8821 301 225 8110 MT-GLAZE 10 JA 1/16W R7309 301 226 1516 MT-GLAZE 0.000 ZA 1/16W R7311 301 225 8110 MT-GLAZE 10 JA 1/16W R8822 301 225 8110 MT-GLAZE 10 JA 1/16W R890...
Page 115 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description 945 037 0831 R-NETWORK 47X4 1/16W L1803 945 059 1748 INDUCTOR,2.2U J RB427 945 036 0986 R-NETWORK 47X4 1/32W L2071 945 086 7577 FILTER,EMI 400MHZ 945 037 0831 R-NETWORK 47X4 1/16W L2081 945 086 7577...
Page 116 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description D3629 307 163 0414 DIODE 1SS352-(TPH3) L563 945 080 6828 INDUCTOR,3.3U M L5651 945 062 2855 INDUCTOR,33U M 307 149 0810 DIODE 1SS355-TE-17 D3631 307 163 0414 DIODE 1SS352-(TPH3) L5701 945 041 1978...
Page 117 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description FB606 945 041 1978 INDUCTOR,330 OHM R3022 301 224 8814 MT-GLAZE 100 JA 1/16W FB607 945 041 1978 INDUCTOR,330 OHM R3031 301 224 8913 MT-GLAZE 100K JA 1/16W FB609 945 041 1978 INDUCTOR,330 OHM R3032 301 224 8814...
Page 118 KV7-XL51A00 Electrical Parts List Key. No. Part No. Description Key. No. Part No. Description RESISTOR 307 209 1214 ZD UDZS-TE-176.2B R4831 301 225 8110 MT-GLAZE 10 JA 1/16W R4832 301 225 8110 MT-GLAZE 10 JA 1/16W R4833 301 224 9019 MT-GLAZE 10K JA 1/16W A6801 610 347 2157 ASSY,PWB,KEY SW.KV7AE CAPACITOR C6801...
Page 119: Mechanical Parts List
Mechanical Parts List Mechanical Parts Location Optical Unit - 119 -...
Page 120 Mechanical Parts Location STAND - 120 -...
Page 121: Optical Parts Location
Optical Parts Location Optical Parts Location L11-1 Optical Unit Polarized Glass -IN Polarized Glass (Red) Red: L02R GREEN BLUE Polarized Glass (Green, Blue) Green: L02G Blue : L02B The Polarized glass of Green and Blue include the holder. - 121 -...
Page 122 Optical Parts Location Relay Lens out Integrator Lens In - 122 -...
Page 123 Optical Parts Location Optical unit inside - 123 -...
Page 124: Mechanical Parts List
KV7-XL51A00 Mechanical Parts List Key. No. Part No. Description Key. No. Part No. Description CABINET & CHASSIS PARTS OPTICAL PARTS DIRECTORY 610 347 8326 CABINET TOP-KM3AB 610 341 3006 ASSY,PNL/PSM-KV7A 610 347 5318 CABINET BOTTOM-KM3AB L02R 645 097 6711 POLARIZED GLASS(IN/R) 610 336 2595 CAP FOCUS LEVER-KM3A L02G...
Page 125 - 125 -...
Page 126 SANYO Electric Co., Ltd. SM5111176-00 (PLC-XL51A) Dec. 2009 DC 200 Printed in Japan...
Page 127: Diagrams & Drawings
PLC-XL51A KV7-XL51A00 These schematic diagrams and printed wiring board drawings are part of the service manual original for chassis No. KV7-XL51A00 models PLC-XL51A. File with the service manual No. SM511176-00 Note: All the information of part numbers and values indicated on these diagrams are at the beginning of production.
Page 128: Parts Description And Reading In Schematic Diagram
KV7-XL51A00 Parts description and reading in schematic diagram 1. The parts specification of resistors, capacitors and coils Resistor Reading are expressed in designated code. Please check the parts Example 1/2 D J 10K B description by the following code table. 2.
Page 129 KV7-XL51A00 Pin description of diode, transistor and IC ● Diode ● Transistor/FET ● IC...
Page 130: Note On Soldering
Note on Soldering Do not use solder containing lead. Solder This product has been manufactured using lead-free solder Use solder with the metal content and composition ratio in order to help preserve the environment. by weight given in the table below. Do not use solders Because of this, be sure to use lead-free solder when which do not meet these conditions.
Page 131 POWER Schematic Diagrams MIRROR LENS POWER FACTOR CORRECTION NETWORK Q9501 C611 1000KK1000NH D611 L612 FMX-G26S L613 K6C_1B K6C_1A L611 L26B5410N F35B1470N Z20051--- R9502 1/16GJ47KA Q611 K6A_1B K6A_1A Q612 K6C_2B K6C_2A 2SK3934 2SK3934 C615_A L9501 C644 C612 C615 L26B 25KK4.7BB R9501 3470G 1000KK K6A_2B...
Page 132 R1001 R1013 SC1001 L1001 F34DG407G 1/10GF150C 1/10GF150C R1_IN R1002 1/16GJ100A L1011 SC1011 F34DG407G R1011 R1014 1/10GF150C 1/10GF150C G1_IN K30A R1012 1/16GJ J11B8382N 100A ;B4J11B0380N L1021 SC1021 F34DG407G R1021 R1016 1/10GF150C 1/10GF150C B1_IN K30A_1 R1022 K30A_2 1/16GJ 100A K30A_12 L1031 SC1031 R1031 F34DG207G K30A_3...
Page 133 IO_2.5V R358 R359 1/16GJ P_FAIL_MCI C389 R371 10KK1MN 1/16GJ ;10KK11B 100KA BATT R1824 S3.3V_PW 1/16GZ0A IC1381 S3.3V_PW S3.3V_PW PQ070XZ02ZPP S3.3V_PW Q1837 C1822 2SA1203Y SYS_SW_CPU R839 R1851 16KK0.1MN 1/16GJ1.5KA ;16KK0.11B PLLSTB TP_ICE S1.8V_PW A[17] ON_2.5VGA TEICE R1852 1/16GJ4.7KA R1379 S2.5V PW_ICE DAC_XCLR C1381 R1839...
Page 134 IC7201 EP2C5F256C8N 3.3V_FPGA IC7261 TA48S00AFP C7202 C7223 D3633 16KK 16KK 1SS352G 0.1MN 0.1MN ;1SS355 P_FAIL ;16KK0.11B R7201 ;16KK0.11B 1/16GJ C7224 10KA 16KK 0.1MN C7201 BAOUT[9] ;16KK0.11B BAOUT[0-9] R7262 3.3V_A 16KK R7261 3.3V_A RB7201 1/16GJ 0.1MN BAOUT[8] 1/10GZ0.0 10KA R7263 ;16KK0.11B R1JA4704G 1/16GF3.9KA BAOUT[7]...
Page 135 IC1491 TA48S00AFP C2561 15.5V_PNL L2561 25EM103T L2GA220JG ;25EM10WD C2562 D1452 TPPRGR1 TPCK12R1 1SS352G KK0.1GQ R2563 ;1SS355 P_FAIL 1/16GJ R2562 3.3KA L1451 1/16GZ0A L2GM 3R3MG C2582 3.3V_D1 C2563 25EM100LM D592 15.5V_PNL <TO: R572 L2581 3.3V_DI GAMMA> GCFB_R_OUT C2581 1/16GJ10KA ;25EM1001Z 1/8GZ000 R1491 C1491 R1493...
Page 136 S16V L5753 L26B3470G L5751 FROM MCI L26B3470G ES5V R5752 F5751 L5752 1/16GJ10KA 0.8A32VHK D6831 LAMP REPLACE(Y) L26B3470G R5755 R6863 D6832 TEMP WARNING(R) 1/10GJ1MC 1/16GZ0A Q5752 J11CY300G LAMP ON (GREEN ON) R6857 IC5751 Q5751 1/16GJ R6858 RSQ025P03G 390A FA7701VG C5754 C5799 1/16GJ R5756 L5702...
Page 137 3.3V_CPU C8151 K8151 16KK0.1MN J11B7080G SD_DAT2 SD_DAT3 SD_CMD R8151 C8152 1/16GJ100A SD CARD I/F SD_CLK R8152 3.3V_CPU C8153 1/16GJ100A R8154 3.3V_CPU SD_DAT0 1/16GJ4.7KA SD_DAT1 SD_CD R8157 R8153 1/16GZ0A 1/16GZ0A SD_WP R8158 3.3V_CPU 1/10GZ0C K8863 SC8151 D8151 Z30B0220G UDZS6.2BG :02DZ6.2YG N_ARMTRST ARMTDI ARMTMS ARMTCK...
Page 138 A[1-22] D[0-15] D[0-15] A[17] IC8501 3.3V_CPU S29GL032N90TFI-3- A[16] R8506 1/16GZ0A A[15] BYTE# A[14] A[13] DQ15/A-1 D[15] 3.3V_CPU 3.3V_CPU A[12] D[7] A[11] D[14] DQ14 RB8322 A[10] D[6] R1JA1034G R8503 R8504 ;R1EB1034G A[9] D[13] 1/16GJ 1/16GJ DQ13 10KA 10KA A[20] D[5] A[21] D[12] DQ12 N_RW...
Page 139 FPGA(FPGA I/F_2&SDRAM) 3.3V_FPGA XSDA1_[0-13] Q8601 3.3V_FPGA XSDA1_[0-13] IC8451 3.3V_FPGA XSDDQM1_[0-3] XSDDQM1_[0-3] X8852 IS42S34200D-6BL V10B7650G RB8863 RB8869 R1JA2204G XSDDATA1_[0-31] XSDDATA1_[0-31] R1JA2204G ;R1EB2204G 3.3V_FPGA ;R1EB2204G SDDA_CLK XSDDATA1_[24] XSDDATA1_[20] XSDDATA1_[25] XSDDATA1_[21] 16KK0.1MN XSDDATA1_[26] R8623 XSDDATA1_[22] C8898 1/16GJ330A XSDDATA1_[27] XSDDATA1_[23] RB8871 R1JA2204G XSDDATA1_[28] ;R1EB2204G XB[0-7] XSDDATA1_[16] XSDDATA1_[29]...
Page 140 NO DATA SCH_KV7AE...
Page 141 Printed Wiring Board Diagrams ■ ! CAUTION This projector is isolated from AC line by using the internal converter transformer. Please pay attention to the following notes in servicing 1. D o not touch the part on hot side (primary circuit) or both parts on hot and cold sides (secondary circuit) at the same time. 2. Do not shorten the circuit between hot and cold sides. 3. T he grounding lead must be connected to the ground of the same circuit when measuring of voltages and waveforms. KEY SW (SIDE : B) KEY SW (SIDE : A) KEYSTONE...
Page 142 LAMP BALLAST SPEAKER MAIN (SIDE : A) “CN2” KEY SW "K6801A" D6833 K29D L4814 R696 Q9604 R698 Q683 R4802 C5643 R5641 R5644 Q3613 Q3644 D5001 R8749 R8747 R8757 R8758 R3616 Q8701 Q8702 Q5651 Q9602 C4814 C3611 R3641 D5651 R3611 D2892 D6832 C5613 Q3582 L2891 C2891 R3583 D8704 L5651...
Page 143 BUZZER POWER MAIN (SIDE : B) “K2100” “K6R” C4808 FB603 R4867 Q9603 R9624 R4868 R9657 Q3642 R9661 R3697 Q3641 R9634 R9659 C5601 R5620 R9621 R9658 C5042 C5649 C8707 K20C Q2091 R2093 R2094 K8701 R2092 IC1441 Q5042 C1463 D8709 R1454 R1438 R1441 R1491 R5704 R5706 R8700 C8708...
Page 144 POWER (SIDE : A) POWER (SIDE : B) SCB6 C665 C661 C664 C665 L611 A30C5 C672 C672 C613 T651 T651 MAIN C613 “K8R” DB611 D665 DB611 D665 A30C5 DB611H PC671 Q611 PC661 D611 Q612 PC663 DB611H *** ??? Q612 Q611 D611 IC621 Q611H C611 C612 Q611H C651 C612 C611...
Page 145 R/C (SIDE : A) R/C (SIDE : B) MODULE (SIDE : A) MODULE (SIDE : B) ANTENNA A30C5 C2901 MAIN "K9901K" C9504 R9506 "K8D" R2901 K29D IC9501 Q9501 R9501 K9501 L9501 AV (SIDE : A) NETWORK "K9301K" SW8754 SW8753 SW8751 SW8752 K40A K20A K40B ANTENNA (SIDE : A) ANTENNA (SIDE : B) K20B A30C5 AV (SIDE : B) MODULE A30C5 A30C5 "K9502K" K9901 C9901 K40B K20A C3021...
Page 146 NETWORK (SIDE : A) MAIN MAIN "K8V" LAMP BALLAST (SIDE : A) "K8W" LAMP R8006 R8018 K9602 C8936 C8938 C8941 R8023 C8004 R8024 R8026 C5112 R8027 R8028 R8003 R8014 C8003 R8002 R8022 R8001 R8622 C8002 K8941 IC9746 R8019 R8612 R8619 K9601 R8016 C5106 TP5V_IN T1.2FPL R8629 R8611 R8637 L5101 C8001...
