Connecting the RF802USB to Your PC or Laptop
1.
Plug a USB cable into the RF802USB and your PC or laptop.
2.
A wizard will locate the new hardware (your RF802USB). Choose Display a list of
the known drivers for this device so that I can choose a specific driver. Then
click Next.
3.
Select Hardware Types, and then click Next.
4.
Click Wireless USB.
5.
Click Have Disk. Place the CD in your CD-ROM drive.
6.
Then enter the path name E:\ (where E is the CD-ROM drive of your laptop
computer or PC). The driver files will be copied to this location. Then click OK.
Setting Network Properties in Windows 98/Me
These steps provide a quick summary of the setting Network Properties process. For
detailed installation steps with screen shots, see the chapter entitled Network
Basics.
Note: See the steps for Windows 2000 Network Properties below.
1. Right-click Network Neighborhood from the desktop.
2. Select Properties from the context menu. The Network dialog box displays and
presents three main tabs: Configuration, Identification, and Access Control.
3. Click the Configuration tab.
4. Click the Add button.
5. The Select Network Component Type dialog box displays.
6. Click Protocol, and then click the Add button.
7. The Select Network Protocols dialog box displays.
7a.
From the list of manufactures, click on Microsoft.
7b.
From the Network Protocols list, select TCP/IP, and then click OK.
8. The TCP/IP protocol is now installed. Click OK, and you will be returned to
Network Component Type dialog box.
9. Click the TCP/IP option for setting the IP address for your computer.
10. You can select either the Static or DHCP setting.
If you use the Static IP setup, then enter the IP value, Subnet masking,
DNS, Domain/Workgroup name, and Gateway Address values.
11. After setting these parameters, click OK to return to Network Component
Type.
12. You can now select the File and Printer Sharing options as well as the Access
to your computer. Access can be set for other users connected to the network by
setting the computer sharing options. Click OK.
13. The screen message Do you want to restart your computer will pop up.
Select Yes. Your computer will shut down and restart.
Multi-Tech Systems, Inc. Wireless Network Adapter User Guide
Chapter 2 - Installation
13
