Category
Software Features
(continued)

LED Indicators

Name Description
LNK
Link – Lit when data connection has been established.
ACT Activity – Lit when data is being transmitted or received.
SPD Speed – Lit when the speed is 100 Mbps. Off for 10 Mbps.
STS Status – Blinks to indicate that the unit is functioning.
PWR Power – Lit when the Adapter is turned on.
Multi-Tech Systems, Inc. MultiConnect Serial-to-Ethernet Adapter User Guide (S000344D)
Description
Functional Features
Command Line Configuration over Serial or Ethernet
Serial – TTY
Ethernet – Telnet – Web
Username and Password Authentication Using Local Database
The Username and Password can be created using commands.
The User database authenticates the Users before access to command mode
of the MultiConnect Adapter is enabled.
Remote Transparent Bridging
Ethernet-to-Serial Bridging
Point-to-Point Protocol (PPP)
Negotiations Bridging Control Protocol
802.3 MAC Type
CCP Compression
Discovery Support and IP Module Port Capture Using WinMCSI Port
Redirector
The Serial-to-Ethernet Adapter can be discovered by new WinMCSI Port
Redirector software on windows and the serial status can be viewed using
WinMCSI Client.
The Serial-to-Ethernet Adapter's serial port can be captured using any terminal
application after creating and mapping a virtual port.
Chapter 1 – Product Description & Specifications
8
