Category
Intelligent Features
Software Features
Multi-Tech Systems, Inc. MultiConnect Serial-to-Ethernet Adapter User Guide (S000344D)
Description
High performance 10/100BaseT Ethernet bridge
Half duplex or full duplex support on the WAN interface
256 frame buffer
Stores 10,000 MAC addresses
Automatically learns MAC addresses
Serial interface supports DTE speeds to 230K bps
External and RS-232 power options
High performance processor runs the protocols
Command line interface
Flash memory to update firmware with the latest enhancements
Flexible IP protocol stack
Compact, rugged industrial chassis design with desktop or panel mounting
Two-year warranty
Internet Applications
DHCP Client:
Request IP address for Ethernet Interfaces
Telnet Server:
Command Line Configuration
Auto Dial-out Feature
Command line via custom port (other than standard port 23)
Telnet Client:
Connect to remote Telnet Server
Serial Auto Dial-in Feature
UDP Server:
Auto Dialout Feature with UDP Server support
UDP Client:
Serial Auto Dial-in Feature with UDP Client support
Terminal Server:
Network to Serial Connectivity
Serial to Network Connectivity
TFTP Server:
Flash Upgrade
SMTP Client:
The email client embedded in the MultiConnect sends email to the configured
recipients.
Daylight savings mode feature.
SNMP Agent:
The SNMP Agent is used to configure the MultiConnect module or view the
module's configuration or statistics using the SNMP manager compiled with
proprietary MIB.
RAW UDP/TCP Socket Support via Serial:
Commands to simulate the BSD system calls of UDP and TCP which can be
used to build a proprietary protocol on the serial device. Also to switch
between the sockets in a single session.
Supports to open, flush, send, receive, close, view statistics of TCP and UDP
sockets via Serial.
Supports both Client and Server modes for TCP and UDP.
POP3 Client:
The email client embedded in the MultiConnect receives email from the POP3
Server. This feature is useful for field upgrades. Firmware upgrades can be
sent as attachments.
HTTP Server:
To host Web pages on behalf of the serial device for monitoring and
configuration of the serial device.
Viewing configuration or statistics support.
FTP Client:
FTP Client embedded in the MultiConnect module lists the directory contents
or sends/receives text/binary files to/from a remote server respectively. This
feature is useful for field upgrades, etc. Firmware upgrades can be sent or
received via FTP transfer. It also supports passive mode connection.
Chapter 1 – Product Description & Specifications
7
