Caiman RVC 40540 Operating Instructions Manual

Rechargeable robot vacuum cleaner
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Fax +1 305 430 9692
Rechargeable Robot Vacuum
Aspiradora Robótica Recargable
14.4V DC - Ni-Mh batteries (Adapter 19V DC – 600 mA)
Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must be reproduced and
folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don't change the page numbering. Keep the
language integrity.
Print only what is inside the frame.
USA
Cleaner
SP
Front cover page (first page)
Assembly page 1/32
RVC 40540

Advertisement

Table of Contents
loading

Related Manuals for Caiman RVC 40540

Summary of Contents for Caiman RVC 40540

  • Page 1 Print only what is inside the frame. Fax +1 305 430 9692 Rechargeable Robot Vacuum Cleaner Aspiradora Robótica Recargable RVC 40540 14.4V DC - Ni-Mh batteries (Adapter 19V DC – 600 mA) Front cover page (first page) Assembly page 1/32...
