ORDERING REPLACEMENT PARTS
To order replacement parts, write or call:
Consumer Products Distribution
Greenwich House
223 North Street
Sheepscar
Leeds LS7 2AA
West Yorkshire
Tel: Country Code: 0345-089009
Fax: 0113-2411120
To help us assist you, please be prepared to give the following information:
• The MODEL NUMBER of the product (X2-1).
• The NAME of the product (WEIDER
®
POWERGUIDE X2 HOME GYM SYSTEM).
• The SERIAL NUMBER of the product (see the front cover of this manual).
• The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 18 of this user's manual).
Part No. 123331 R0497A
Weider is a registered trademark of ICON Health & Fitness, Inc. © 1997 Printed in the USA
home
home
Model No. X2-1
Serial No.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or find that there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through our Customer
Service Department.
Please CALL:
0345-089009
or WRITE:
ICON Lifestyle Ltd
Greenwich House
223 North Street
Sheepscar
Leeds LS7 2AA
West Yorkshire
CAUTION
Read all precautions and instruc-
tions in this user's manual
before using this equipment.
Save this user's manual for
future reference.
gym
s
gym
s
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for Weider powerguide x2
Summary of Contents for Weider powerguide x2
- Page 1 Read all precautions and instruc- tions in this user’s manual before using this equipment. Save this user’s manual for USER’S MANUAL future reference. Part No. 123331 R0497A Weider is a registered trademark of ICON Health & Fitness, Inc. © 1997 Printed in the USA...
- Page 2 TABLE OF CONTENTS EXPLODED DRAWING—Model No. X2-1 R0497A IMPORTANT PRECAUTIONS ............. .2 BEFORE YOU BEGIN .
-
Page 3: Before You Begin
1/4” Nylon Locknut Weight dramatic muscle size and strength, or improve your POWERGUIDE X2 (see the front cover of this user’s 3 1/2” Thin Pulley Nylon Wheel cardiovascular system, the POWERGUIDE X2 will manual). - Page 4 The following tools (not included) are required: • Place all parts of the POWERGUIDE X2 in a cleared area and remove the packing materials; LOW CABLE (70) HIGH CABLE (71) •...
- Page 5 3. Slide nine Weights (45) onto the Guide Tube (34). TROUBLE-SHOOTING AND MAINTENANCE Make sure that the Weights are turned so the pin grooves are on the slotted side of the Guide Tube. Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent.
- Page 6 6. Slide the Weight Selector (47) and the Weight ATTACHING THE LEG LEVER TO THE LOW (45) onto the Guide Tube (34). PULLEY STATION Slot To use the Leg Lever (20), the seat must be attached to the front upright (see ATTACHING AND REMOV- ING THE SEAT on page 14).
- Page 7 9. Press two 1 3/4” Inner Caps (24) and two 1” ADJUSTMENT Round Caps (9) into the Press Frame (33). Lubricate the top axle of the Press Frame (33). The instructions below describe how each part of the home gym system can be adjusted. Refer to the Place one Press Bushing (54) onto the plate on the EXERCISE CHART accompanying this user’s manual to see how the home gym system should be set up for Lubricate...
- Page 8 Locknut (1). 30. Remove the decals from the decal sheet (not shown), and apply them to the home gym system in the loca- tions shown in the drawing below. POWERGUIDE X2 BENCH PRESS/ 200 LBS MULTI-GYM 13. Wet the lower ends of the Press Arms (29) with soapy water.
- Page 9 25. Press a 1 1/2” Inner Cap (19) into the Leg Lever 15. Route the Low Cable (70) under the indicated (20). 3 1/2” Thin Pulley (4). Be sure that the rubber stop is on the indicated side of the Pulley. Lubricate a 5/16”...
- Page 10 18. Route the Low Cable (70) on the indicated side of 21. Wrap the Low Cable (70) around the 3 1/2” “V” the “V” Brace (42). Route the Low Cable into the Pulley (74). Attach the Pulley and a Large Cable groove in a 3 1/2”...
- Page 11 “J” Pin (56)–1 REMOVE THIS PART IDENTIFICATION 4” Weight Pin (50)–1 CHART FROM THE MANUAL! 4 1/2” “L” Pin (61)–2 This chart is provided to help you identify the small parts used in assembly. Note: Some parts may have been pre- assembled for shipping purposes;...
- Page 12 PART IDENTIFICATION CHART—Model No. X2-1 R0497A R0197A This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part 5/16” x 3 3/4” Bolt (49)–1 1 1/4” Tap Screw (39)–2 refers to the key number of the part. The second number refers to the quantity used in assembly. 5/16”...
