AIR CONDITIONER

Wall Mounted type

DESIGN & TECHNICAL MANUAL
INDOOR
OUTDOOR
AOU9RLFW
ASU9RLF
ASU12RLF
ASU15RLS
AOU12RLFW
AOU15RLS

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu ASU9RLF

Summary of Contents for Fujitsu ASU9RLF

  • Page 1: Wall Mounted Type

    AIR CONDITIONER Wall Mounted type DESIGN & TECHNICAL MANUAL INDOOR ASU9RLF ASU12RLF ASU15RLS OUTDOOR AOU9RLFW AOU12RLFW AOU15RLS...

  • Page 2: Indoor Unit

    1. INDOOR UNIT WALL MOUNTED TYPE : ASU9RLF ASU12RLF ASU15RLS DTR_AS044E_01 2010.08.09...

  • Page 3: Table Of Contents

    CONTENTS 1. INDOOR UNIT 1. FEATURE ........................01 - 01 2. WIRELESS REMOTE CONTROLLER ..........01 - 03 3. SPECIFICATIONS ....................01 - 05 4. DIMENSIONS ......................01 - 06 5. WIRING DIAGRAMS ..................01 - 08 6. CAPACITY TABLE ....................

  • Page 4: Feature

    FEATURE MODEL ASU9RLF / AOU9RLFW ASU12RLF / AOU12RLFW ASU15RLS / AOU15RLS FEATURES High density heat transfer tube arrangement Ø5 Making the tube Thin: Volume reduction of heat exchanger: Even temperature Improved the heat exchanger effectiveness Filter features Ammonia Trimethylamine Hydrogen sulfate...
  • Page 5 Auto swing louvre Wired control compatible START/STOP SET TEMP. - (01 - 02) -...

  • Page 6: Wireless Remote Controller

    WIRELESS REMOTE CONTROLLER FEATURES Simple function setting Built-in timers Program timer Sleep timer 2 °F 4 °F Timer setting 6 °F 8 °F 60min. 30min. 60min. 4 °F 90min. 2 °F Timer setting Switching remote controller signal code After code change Mixed-up I.U.
  • Page 7 FUNCTIONS MODE button MIN.HEAT button SET TEMP. button ( ECONOMY button SLEEP button FAN button START/STOP button SET button SWING button TIMER MODE button TIMER SET ( ) button CLOCK ADJUST button RESET button TEST RUN button Signal transmitter Remote controller display Temperature set display Operating mode display SLEEP display...

  • Page 8: Specifications

    SPECIFICATIONS 2.637 3.516 4.249 9000 12000 14500 0.50-3.20 0.90-3.90 1.10-4.60 1700-10900 3100-13300 3800-16000 3.516 4.689 5.275 12000 16000 18000 0.50-4.40 0.90-5.60 0.90-6.00 1700-15000 3100-19100 3100-21000 0.65 0.96 1.16 1.27 1.40 1.90 0.89 1.28 1.46 1.60 1.99 2.40 10.5 4.05 3.66 3.66 13.8 12.5...

  • Page 9: Dimensions

    DIMENSIONS MODEL : ASU9RLF, ASU12RLF, ASU15RLS 8-1/16 (205) : Installed state 31-3/32 (790) 8 (203) 5-1/2 (140) *1 5-23/32 (145) *1 *1: Vertical flap is downward Outline of unit 3-11/16 (94) 17-23/32 (450) 23/32 (18) 2-1/16 (52) 8-7/32 (209) 9-11/32 (237)
  • Page 10 INSTALLATION PLACE Outline of unit 1-7/8 (48) or more 2-1/16 (52) or more 3-15/16 (100) or more 2-3/4 (70) or more 59-1/16 (1500) or more - (01 - 07) -...

  • Page 11: Wiring Diagrams

    WIRING DIAGRAMS MODEL : ASU9RLF, ASU12RLF, ASU15RLS - (01 - 08) -...

  • Page 12: Capacity Table

    CAPACITY TABLE 6-1. COOLING CAPACITY MODEL : ASU9RLF 6.41 4.83 0.22 7.14 4.86 0.23 7.87 5.30 0.23 8.11 5.72 0.23 8.60 5.70 0.23 9.08 6.07 0.24 8.53 5.30 0.44 9.51 5.33 0.45 10.48 5.81 0.46 10.80 6.28 0.46 11.45 6.25 0.46...
  • Page 13 MODEL : ASU15RLS 10.0 7.66 0.49 11.2 7.71 0.49 12.3 8.40 0.50 12.7 9.08 0.50 13.5 9.04 0.51 14.2 9.63 0.51 13.8 9.03 0.79 15.4 9.08 0.80 17.0 9.91 0.81 17.5 10.70 0.82 18.5 10.66 0.83 19.6 11.35 0.83 13.1 8.63 0.90 14.5...

  • Page 14: Heating Capacity

    6-2. HEATING CAPACITY MODEL : ASU9RLF 7.18 0.68 7.01 0.69 6.84 0.71 6.66 0.72 8.13 0.73 7.94 0.75 7.74 0.76 7.55 0.78 9.10 0.76 8.88 0.78 8.66 0.79 8.45 0.81 10.48 0.81 10.23 0.83 9.98 0.84 9.73 0.86 11.91 0.86 11.63...
  • Page 15 MODEL : ASU15RLS 12.05 1.25 11.77 1.27 11.48 1.30 11.19 1.32 13.55 1.29 13.23 1.32 12.90 1.34 12.58 1.37 15.02 1.35 14.66 1.37 14.30 1.40 13.95 1.43 17.06 1.44 16.66 1.47 16.25 1.50 15.84 1.53 18.15 1.40 17.72 1.43 17.29 1.46 16.85 1.49...

  • Page 16: Fan Performance

    FAN PERFORMANCE 7-1. AIR VELOCITY DISTRIBUTION MODEL : ASU9RLF, ASU12RLF 7(2) 3(1 ) 2 (0 .5 ) 2 (0 .5 ) 7 (2) 3 (1) 3(1) 2 (0 .5 ) 7(2) 3(1) 2 (0 .5 ) 7(2) 3(1 ) 2(0.5 )
  • Page 17 MODEL : ASU15RLS 7(2) 3 (1) 2 (0 .5 ) 2(0.5) 7(2) 3(1) 2 (0 .5 ) 3 (1) 7(2) 3 (1 ) 2 (0 .5 ) 7(2) 3(1) 2(0.5) - (01 - 14) -...

  • Page 18: Air Flow

    7-2. AIR FLOW MODEL : ASU9RLF, ASU12RLF Cooling 1330 1160 Heating 1330 1160 - (01 - 15) -...
  • Page 19 MODEL : ASU15RLS Cooling 1440 1230 1000 Heating 1500 1230 1050 - (01 - 16) -...

  • Page 20: Operation Noise

    OPERATION NOISE 8-1. NOISE LEVEL CURVE MODEL : ASU9RLF Cooling Heating High High Quiet Quiet MODEL : ASU12RLF Cooling Heating High High Quiet Quiet - (01 - 17) -...
  • Page 21 MODEL : ASU15RLS Cooling Heating High High Quiet Quiet - (01 - 18) -...

  • Page 22: Sound Level Check Point

    8-2. SOUND LEVEL CHECK POINT 39-3/8 in. (1m) - (01 - 19) -...

  • Page 23: Electric Characteristics

    ELECTRIC CHARACTERISTICS AS15RLS - (01 - 20) -...

  • Page 24: Safety Devices

    SAFETY DEVICES AS15RLS - (01 - 21) -...

  • Page 25: External Input & Output

    EXTERNAL INPUT & OUTPUT 11-1. EXTERNAL INPUT CONTROL INPUT (Operation/Stop or Forced stop) Initial starting after power turned on Starting other than at the left Circuit diagram example Indoor control PC board Connected unit Ex.) Switch Connector *10 m Signal Field supply Input signal Operation...
  • Page 26 Input signal Forced stop Command Normal Operation Indoor unit Stop Remote controller Remote control operation invalidity Parts (Optional) - (01 - 23) -...

  • Page 27: External Output

    11-2. EXTERNAL OUTPUT OPERATION STATUS OUTPUT Circuit diagram example Indoor Connected unit control PC board Connector Ex.)Relay unit Ex.)Display 24V DC Relay power supply *10 m Signal Field supply Operation Indoor unit Stop Output signal Parts (Optional) - (01 - 24) -...

  • Page 28: Function Setting

    FUNCTION SETTING 12-1. INDOOR UNIT (Setting by remote controller) FUNCTION SETTING METHOD (for Wireless remote controller) Entering the Function Setting Mode STEP 1 Setting the Remote controller Signal Code STEP 2 Selecting the Function Number and Setting Value Function number Setting value CAUTION - (01 - 25) -...

  • Page 29: Function Details

    FUNCTION DETAILS 1) Filter sign 2) Cooler room temperature correction 3) Heater room temperature correction - (01 - 26) -...
  • Page 30 4) Auto restart 5) Indoor room temperature sensor switching function 6) Remote controller signal code 7) External input control - (01 - 27) -...
  • Page 31 REMOTE CONTROLLER SIGNAL CODE SETTING - (01 - 28) -...

  • Page 32: Optional Parts

    OPTIONAL PARTS Exterior Parts name Model No. Summary - (01 - 29) -...

  • Page 33: Outdoor Unit

    2. OUTDOOR UNIT SINGLE TYPE : AOU9RLFW AOU12RLFW AOU15RLS DTR_AO066E_01 2010.08.09...
  • Page 34 CONTENTS 2. OUTDOOR UNIT 1. SPECIFICATIONS ....................02 - 01 2. DIMENSIONS ......................02 - 02 3. REFRIGERANT CIRCUIT ................02 - 05 4. WIRING DIAGRAMS ..................02 - 08 5. CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DIFFERENCE ...................02 - 11 6.

  • Page 35: Specifications

    SPECIFICATIONS Type INVERTER HEAT PUMP Model name AOU9RLFW AOU12RLFW AOU15RLS Power sourse 208/230V~60HZ Available voltage range 187-253V~60HZ Starting current Cooling 995(1690) 1036(1760) 1413(2400) Heating 906(1540) 889(1510) 1177(2000) Type×Q'ty Propeller fan×1 Motor output Cooling Sound pressure level dB(A) Heating Dimensions 19-27/32×25-9/32×1-7/16 19-27/32×35-9/32×1-7/16 23-5/32×34-11/16×1-7/16 (H×W×D) 504×642×36.4 504×896×36.4...

  • Page 36: Dimensions

    DIMENSIONS MODEL : AOU9RLFW Unit : in.(mm) INSTALLATION PLACE When there are obstacles at the When there are obstacles at the When there are obstacles at the back or front sides. back, side(s), and top. back, side with the installation of more than one unit.
  • Page 37 MODEL : AOU12RLFW Unit : in.(mm) INSTALLATION PLACE When there are obstacles at the When there are obstacles at the When there are obstacles at the back or front sides. back, side(s), and top. back, side with the installation of more than one unit.
  • Page 38 MODEL : AOU15RLS Unit : in.(mm) INSTALLATION PLACE When there are obstacles at the When there are obstacles at the When there are obstacles at the back or front sides. back, side(s), and top. back, side with the installation of more than one unit.

  • Page 39: Refrigerant Circuit

    REFRIGERANT CIRCUIT MODEL : AOU9RLFW Heat exchanger (INDOOR) 3-Way valve Muffler 2-Way valve 4-Way valve Compressor Strainer Heat exchanger Expansion valve (OUTDOOR) Strainer Cooling Heating Refrigerant pipe diameter Liquid:1/4"(6.35mm) Gas:3/8"(9.52mm) - (02 - 05) -...
  • Page 40 MODEL : AOU12RLFW Heat exchanger (INDOOR) 3-Way valve Muffler Muffler 2-Way valve 4-Way valve Compressor Strainer Heat exchanger Expansion valve (OUTDOOR) Strainer Cooling Heating Refrigerant pipe diameter Liquid:1/4"(6.35mm) Gas:3/8"(9.52mm) - (02 - 06) -...
  • Page 41 MODEL : AOU15RLS Heat exchanger (INDOOR) 3-Way valve Muffler Muffler 2-Way valve 4-Way valve Compressor Strainer Heat exchanger Expansion valve (OUTDOOR) Strainer Cooling Heating Refrigerant pipe diameter Liquid:1/4"(6.35mm) Gas:3/8"(9.52mm) - (02 - 07) -...

  • Page 42: Wiring Diagrams

    WIRING DIAGRAMS MODEL : AOU9RLFW - (02 - 08) -...
  • Page 43 MODEL : AOU12RLFW - (02 - 09) -...
  • Page 44 MODEL : AOU15RLS - (02 - 10) -...

  • Page 45: Capacity Compensation Rate For Pipe Length And Height Difference

    CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DIFFERENCE MODEL : AOU9RLFW Pipe length COOLING 7.5m 16ft. 25ft. 33ft. 49ft. 66ft. 49ft. 0.872 0.910 33ft. 0.961 0.886 0.925 Indoor unit is upper 7.5m 25ft. 0.979 0.965 0.890 0.929 than outdoor unit. 16ft.
  • Page 46 MODEL : AOU12RLFW Pipe length COOLING 7.5m 16ft. 25ft. 33ft. 49ft. 66ft. 49ft. 0.858 0.868 33ft. 0.929 0.872 0.882 Indoor unit is upper 7.5m 25ft. 0.960 0.933 0.876 0.885 than outdoor unit. 16ft. 0.992 0.964 0.937 0.879 0.889 Height 0ft. 1.000 0.972 0.944...
  • Page 47 MODEL : AOU15RLS Pipe length COOLING 7.5m 16ft. 25ft. 33ft. 49ft. 66ft. 49ft. 0.893 0.909 33ft. 0.955 0.908 0.924 Indoor unit is upper 7.5m 25ft. 0.975 0.959 0.912 0.928 than outdoor unit. 16ft. 0.992 0.979 0.963 0.916 0.931 Height 0ft. 1.000 0.987 0.970...

  • Page 48: Additional Charge Calculation

    ADDITIONAL CHARGE CALCULATION MODEL : AOU9RLFW Refrigerant type R410A lb. oz. 1lb.14oz. Refrigerant amount REFRIGERANT CHARGE Pipe length 0.22oz./ft. (20g/m) 0(chargeless) 3.5oz. Additional charge 0(chargeless) +100 MODEL : AOU12RLFW Refrigerant type R410A lb. oz. 2lb.5oz. Refrigerant amount 1050 REFRIGERANT CHARGE Pipe length 0.22oz./ft.

  • Page 49: Air Flow

    AIR FLOW MODEL : AOU9RLFW Cooling Number of rotations (r.p.m.) 1690 Heating Number of rotations (r.p.m.) 1540 MODEL : AOU12RLFW Cooling Number of rotations (r.p.m.) 1760 1036 Heating Number of rotations (r.p.m.) 1510 - (02 - 15) -...
  • Page 50 MODEL : AOU15RLS Cooling Number of rotations (r.p.m.) 2400 1010 1413 Heating Number of rotations (r.p.m.) 2000 1177 - (02 - 16) -...

  • Page 51: Operation Noise

    OPERATION NOISE 8-1. NOISE LEVEL CURVE MODEL : AOU9RLFW Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency,Hz Octave band center frequency,Hz...
  • Page 52 MODEL : AOU15RLS Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency,Hz Octave band center frequency,Hz - (02 - 18) -...

  • Page 53: Sound Level Check Point

    8-2. SOUND LEVEL CHECK POINT in. (1m) - (02 - 19) -...

  • Page 54: Electric Characteristics

    ELECTRIC CHARACTERISTICS Model Name AOU9RLFW AOU12RLFW AOU15RLS Voltage 208 / 230~ Power Supply Frequency *1) Max. Operating Current 12.5 Starting Current Main Fuse (Circuit breaker) Current *2) Wiring Spec. Power Cable *3) Limited wiring length *1) The maximum current is the total current of indoor unit and outdoor unit. *2) Wiring Spec.

  • Page 55: Safety Devices

    SAFETY DEVICES Model Protection form AOU9RLFW AOU12RLFW AOU15RLS Current fuse 20A/250V (IN THE INVERTER CASE) 5A/250V Circuit protection Current fuse 15A/250V (MAIN PRINTED 3.15A/250V CIRCUIT BOARD) OFF: 212 °F (100 °C) Fan motor protection Terminal protection program OFF: 203 °F (95 °C) Compressor Terminal protection program...
