Samsung 171N Service Manual

Hide thumbs Also See for 171N:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , User Manual
SERVICE
TFT-LCD MONITOR
GH17A*
GH17L***J/***
TFT-LCD MONITOR
Chassis
Model
GH17A*
171N
GH17L*
171s
(GH17L***J/***)
Manual
1. Precautions
3. Disassembly & Reassembly
4. Alignments & Adjustments
6. Exploded View & Parts List
11. Panel Description
CONFIDENTIAL
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung 171N

Summary of Contents for Samsung 171N

  • Page 1: Service Manual

    CONFIDENTIAL TFT-LCD MONITOR Chassis Model GH17A* 171N GH17L* 171s (GH17L***J/***) SERVICE Manual TFT-LCD MONITOR CONTENTS 1. Precautions 2. Product Specifications 3. Disassembly & Reassembly 4. Alignments & Adjustments 5. Troubleshooting 6. Exploded View & Parts List GH17A* 7. Electrical Parts List 8.

  • Page 2: Precautions

    CONFIDENTIAL 1 Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1 Safety Precautions 1-1-1 Warnings For continued safety, do not attempt to modify the (READING SHOULD circuit board. NOT BE ABOVE 0.5mA) Disconnect the AC power and DC power jack before servicing.

  • Page 3: Servicing Precautions

    CONFIDENTIAL 1 Precautions 1-2 Servicing Precautions WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 4: Product Specifications

    CONFIDENTIAL 2 Product Specifications 2-1 Specifications Item Description LCD Panel TFT-LCD panel, RGB vertical stripe, normally black transmissive, 17-Inch viewable, 0.264 mm pixel pitch Scanning Frequency Horizontal : 30 KHz ~ 81 KHz (Automatic) Vertical : 56 Hz ~ 75 Hz (~XGA) Display Colors 16,2 Million colors Maximum Resolution...

  • Page 5: Pin Assignments

    CONFIDENTIAL 2 Product Specifications 2-2 Pin Assignments Sync 15-Pin D-Sub Signal Cable Connector Type Separate Composite Sync-on-green Pin No. Green Green Green + H/V Sync. Blue Blue Blue DDC Return (GND) DDC Return (GND) DDC Return (GND) GND-R GND-R GND-R GND-G GND-G GND-G...

  • Page 6: Timing Chart

    CONFIDENTIAL 2 Product Specifications 2-3 Timing Chart This section of the service manual describes the timing that the computer industry recognizes as standard for computer-generated video signals. Table 2-1 Timing Chart Mode VESA VGA2/70 Hz VGA3/60 Hz 640/75 Hz 640/85 Hz 800/75 Hz 800/85 Hz 1024/60Hz...
  • Page 7 CONFIDENTIAL 2 Product Specifications Memo GH17A*/GH17L***J...

  • Page 8: Disassembly & Reassembly

    CONFIDENTIAL 3 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the GH17A*/GH17L***J TFT-LCD monitors. WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components. 3-1 Disassembly (GH17A*) Cautions:1. Disconnect the monitor from the power source before disassembly. 2.
  • Page 9 CONFIDENTIAL 3 Disassembly and Reassembly 3-1-3 Disassembly (GH17A*) Reassembly procedures are in the reverse order of Disassembly procedures. 1. Push the jig deep in the opening hole 4. Rear cover until it opens. 2. Push down the jig and pull up the rear cover till it opens.
  • Page 10 CONFIDENTIAL 3 Disassembly and Reassembly 3-2 Disassembly (GH17L***J) Cautions:1. Disconnect the monitor from the power source before disassembly. 2. Follow these directions carefully; never use metal instruments to pry apart the cabinet. 3-2-1 Removing the Stand 1. With a pad beneath it, stand the monitor on its front with the screen facing downward and the base close to you.
  • Page 11 CONFIDENTIAL 3 Disassembly and Reassembly Memo GH17A*/GH17L***J...

  • Page 12: Alignments & Adjustments

    CONFIDENTIAL 4 Alignments and Adjustments This section of the service manual explains how to use the Interfaceboard (DDC Control JIG) and how to input the EDID data of GH17A*/GH17L***J with DDC control JIG when you replace the AD Board. 4-1 Required Equipment The following equipment is necessary for adjusting the monitor: •...
  • Page 13 CONFIDENTIAL 4 Alignments and Adjustments 3. Input DDC data file and the product data. 4. After loading the EDID data, you can see the GH17A*/GH17L***J. 5. Click F3 and then input the serial number twice. 6. If you input the wrong serial number, you can see the on the left picture.
  • Page 14 CONFIDENTIAL 4 Alignments and Adjustments 4-2-2 How to adjust Auto color. 1. Before auto color adjustment, set up the PC`s display as below. • Resolution : 720*400 70 Hz • H - Freguency : 31.47 KHz • V - Freguency : 70 Hz •...
  • Page 15 CONFIDENTIAL 4 Alignments and Adjustments Memo GH17A*/GH17L***J...

  • Page 16: Troubleshooting

    CONFIDENTIAL 5 Troubleshooting Notes: 1. Before troubleshooting, setup the PC’s display as below. • Resolution: 1280 x 1024 • H-frequency: 64 kHz • V-frequency: 60 Hz 2. If no picture appears, make sure the power cord is correctly connected. 3. If you push and hold the EXIT button for more than 5 seconds, the monitor automatically turns back to the factory preset.
  • Page 17 CONFIDENTIAL 5 Troubleshooting 5-1-2 No Power When Pin 6 of CN102 is around 2V, does proper DC 8V, Change power Adaptor. 3V appear at Pin 1 and 7 of CN102 seperately? Does proper DC 5 V appear at Check IC102 and related circuit. Pin 3 of IC102? Push Power button.
  • Page 18 CONFIDENTIAL 5 Troubleshooting 5-2 No Video Check signal cable connection and power. Replace that or Does the X201 and X202 oscillate properly? check related circuit. There R, G, B input are at R103, R104 and R105? Check input part. There sync. and data output are Please check the power related R212, R213, R214, R215, and RA201 ~ RA212? IC201 and output part.
  • Page 19 CONFIDENTIAL 5 Troubleshooting WAVEFORMS GH17A*/GH17L***J...

  • Page 20: Exploded View & Parts List

    CONFIDENTIAL 6 Exploded View and Parts List 6-1 GH17A* GH17A*/GH17L***J...
  • Page 21 CONFIDENTIAL 6 Exploded View & Parts List 6-2 GH17L***J GH17A*/GH17L***J...

  • Page 22: Electrical Parts List

    CONFIDENTIAL 7 Electrical Parts List 7-1-1 GH17A* Main PCB Parts Loc. No. Code No. Description Specification Remarks BN94-00326A ASSY PCB MAIN GH17AS 0201-001223 ADHESIVE-TS HT-130S,RED,700+/- 50,- 0202-001044 SOLDER-WIRE. S63S-W3.0,S63S,D3,63Sn/37Pb,- 0202-001046 SOLDER-WIRE FLUX CF-110VH-2A,-,-,-,- 0202-001222 SOLDER-WIRE FLUX RS-107,RS60-1.2AA,D1.2,SN60/PB40,- 0204-001095 THINNER #4520,-,-,- BN39-00162A CBF HARNESS GH17LS,UL/CSA,UL1061#28,12P/12P,240MM,WHT,UL1061#28,51021-1200,51021-1200,BK,300...
  • Page 23 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks C146 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C147 2402-000179 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 C148 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C149 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C150 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C160 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C170 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608 C171 2203-005065 C-CERAMIC,CHIP...
  • Page 24 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks C247 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C248 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C249 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C250 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C251 2203-000426 C-CERAMIC,CHIP 0.018nF,5%,50V,NP0,TP,1608 C253 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C254 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C255 2203-005005 C-CERAMIC,CHIP...
  • Page 25 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks FT107 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- FT109 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT110 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT111 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT301 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT302 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT303 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1...
  • Page 26 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks R207 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R208 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R210 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R212 2007-000071 R-CHIP 22ohm,5%,1/16W,DA,TP,1608 R213 2007-001167 R-CHIP 75ohm,5%,1/16W,DA,TP,1608 R214 2007-000071 R-CHIP 22ohm,5%,1/16W,DA,TP,1608 R215 2007-000071 R-CHIP 22ohm,5%,1/16W,DA,TP,1608 R217 2007-000071 R-CHIP...
  • Page 27 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks R301 2007-000090 R-CHIP 10KOHM,5%,1/16W,DA,TP,1608 R303 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R304 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R305 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R306 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R307 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R308 2007-000072 R-CHIP 47ohm,5%,1/16W,DA,TP,1608 R309 2007-000072 R-CHIP...
  • Page 28 GH17PS,ABS HB ,- BN90-00351A ASSY STAND GH17AS BN90-00333A ASSY STAND GH17PS,ABS HB BN90-00410N ASSY COVER FRONT GH17ASBS,ADC,ABS 5V,IV16(SILVER) BN90-00331B ASSY COVER FRONT GH17AS(S/M 171N),ABS 5V IV16,SILVER BN59-00229A BOARD -,FUNCTION ASSY,-,-,-,-,- BN61-00067A SUPPORT-FUNCTION GH19PS,ABS+PC 5V,-,-,-,IV16,- BN63-00300A COVER-FRONT GH17PS,ABS HB ,- BN64-00038A KNOB-FUNCTION...
  • Page 29 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks BH68-00261F CARD WARRANTY-03 SyncMaster14-1,ADC,MOJO180G,E/F,USA BH68-00261J MANUAL-01 SEAREGISTRATION CARD,SEA,E,USA,MOJO120G,-,173,234,-,-,-,- BH68-00261R MANUAL-00 3 MONTHS CRM CARD,SECA,E/F,CANADA,MOJO120G,173,234 BH68-00344C CARD WARRANTY-00 SECA W’TY & CRM CARD,SECA,MOJO100G,E/F,CANADA BH68-00376H MANUAL-00 WIN XP INSTALL GUIDE,SYNCMASTER,ENGLISH,W/W,MOJO100G,-,148,210,-,-,-,- BH69-30348D BAG-PE LDPE,T0.05,W240*L356,Y,-,CMG73...
  • Page 30 CONFIDENTIAL 7 Electrical Parts List 7-2-1 GH17L***J Main PCB Parts Loc. No. Code No. Description Specification Remarks BN94-00373A ASSY PCB MISC-RTA PCB GH17LSSNJ/EDC,NETHERLAND 0202-001044 SOLDER-WIRE. S63S-W3.0,S63S,D3,63Sn/37Pb,- 0202-001046 SOLDER-WIRE FLUX CF-110VH-2A,-,-,-,- 0202-001222 SOLDER-WIRE FLUX RS-107,RS60-1.2AA,D1.2,SN60/PB40,- 0204-001095 THINNER #4520,-,-,- BN39-00101A CBF HARNESS ML17NS,UL1571,UL/CSA,30P,130MM,BLU/WHT,AWG30,DF14-30S-1.25C,FI-X30H,-,-,-,-,-,-, BN39-00162A CBF HARNESS...
  • Page 31 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks C161 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C162 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C170 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608 C173 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608 C201 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C202 2203-000236 C-CERAMIC,CHIP 0.1nF,5%,50V,NP0,TP,1608 C203 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C204 2203-005005 C-CERAMIC,CHIP...
  • Page 32 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks C254 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C255 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C256 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C257 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 C259 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C260 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C263 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C264 2203-000257 C-CERAMIC,CHIP...
  • Page 33 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks FT110 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT111 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT301 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT302 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT303 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT304 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- IC102 1203-001488 IC-POSI.FIXED REG.
  • Page 34 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks R163 2007-000402 R-CHIP 150ohm,5%,1/16W,DA,TP,1608 R164 2007-000402 R-CHIP 150ohm,5%,1/16W,DA,TP,1608 R165 2007-000643 R-CHIP 270ohm,5%,1/16W,DA,TP,1608 R166 2007-000643 R-CHIP 270ohm,5%,1/16W,DA,TP,1608 R174 2007-001167 R-CHIP 75ohm,5%,1/16W,DA,TP,1608 R175 2007-001167 R-CHIP 75ohm,5%,1/16W,DA,TP,1608 R176 2007-001167 R-CHIP 75ohm,5%,1/16W,DA,TP,1608 R201 2007-000092 R-CHIP...
  • Page 35 CONFIDENTIAL 7 Electrical Parts List Loc. No. Code No. Description Specification Remarks R280 2007-000090 R-CHIP 10KOHM,5%,1/16W,DA,TP,1608 R281 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R283 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R284 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R285 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R290 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R291 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R292 2007-000070 R-CHIP...
  • Page 36 CONFIDENTIAL 7 Electrical Parts List 7-2-2 GH17L***J Others Loc. No. Code No. Description Specification Remarks BN90-00167A ASSY COVER REAR GH17LS BN75-00152A UNIT-COVER REAR -,-,ABS HB,-,IV16,-,- BN70-00183A BRACKET VESA RB17AS,SECC,1 BN72-00194A COVER REAR GH17LS,ABS,HB,IV16,GOGH 170S/170B BN90-00168A ASSY STAND GH17-SN,WW,ABS/HB,IV16,WW BN75-00169A UNIT-STAND GH17LS,-,ABS HB,-,IV16,-,- BN90-00410W ASSY COVER FRONT...
  • Page 37 ASSY ACCESSORY GH17LSSNJ/EDC,EDC,NETERLANDS BN96-00184B ASSY ACCESSORY GH17LSSNJ/EDC,EDC,NETHERLANDS 0203-000214 TAPE-OPP MASKING OPP/W50/CLR,T0.05,W50,L400000, BH39-10007A CBF POWER CORD DET,250V/6A,H05VV-F,LP-34A/KKP BH68-00374A CARD WARRANTY-01 ASC List,Samsung,ART100G,Russian,EDC,295,210 BH68-00376H MANUAL-00 WIN XP INSTALL GUIDE,SYNCMASTER,ENGLISH,W/W,MOJO100G,-,148,210,-,-,-,- BH68-00489A MANUAL-01 RUSSIAN W/CARD,SER,RUSSIAN,RUSSIA,MOJO100G BH68-70438A CARD-BLOC WARRANTY-08 TFT LCD,BASIC,EU,MOJO,100G,W21 BH68-70448A CARD-01 TFT LCD,SRC,RUSSIA,S/W,120,W210*L120,INSTALL CARD...

  • Page 38: Block Diagram

    CONFIDENTIAL 8 Block Diagram GH17A*/GH17L***J...
  • Page 39 CONFIDENTIAL 8 Block Diagrams Memo GH17A*/GH17L***J...

  • Page 40: Wiring Diagram

    CONFIDENTIAL 9 Wiring Diagram (GH17A*) CN101 (GH17L***J) GH17A*/GH17L***J...
  • Page 41 CONFIDENTIAL 9 Wiring Diagram Memo GH17A*/GH17L***J...

  • Page 42: Schematic Diagrams

    CONFIDENTIAL 10 Schematic Diagrams 10-1-1 GH17A* Part Schematic Diagram CPU+5V 1.5uH 1.5uH C135 ZD101 L110 L111 IC114 10000nF MC74F14D ZD102 +12V_MAIN CPU+5V C136 R101 100nF DDC_DATA IC102 C118 BA17805FP R102 DDC_CLK 10000nF IC101 C151 OUT 3 ZD103 100nF 24LC21AT-/SN C170 R109 C116 1.5uH...
  • Page 43 CONFIDENTIAL 10 Schematic Diagrams 10-1-2 GH17A* Part Schematic Diagram REFR REFCR REFPR R201 C201 R202 C266 C202 100nF 4.7K 100pF 1/16W 1/16W R217 DVDD_3.3 REFMR R218 R219 RESET REFG REFCG REFPG DVDD_1.8 R207 R203 C265 R204 C267 C203 R208 100nF 4.7K 100pF 1/16W...
  • Page 44 CONFIDENTIAL 10 Schematic Diagrams GH17A*/GH17L***J 10-3...
  • Page 45 CONFIDENTIAL 10 Schematic Diagrams 10-2-1 GH17L***J Part Schematic Diagram CPU+5V +12V_MAIN CPU+5V L101 CPU+5V FT104 IC102 1.5uH 1.5uH 1.5uH BLM41P600S BA17805FP C118 C137 BLM41P600S 10000nF L110 L111 IC114 10000nF ZD101 MC74F14D ZD102 C116 100uF C138 C115 R101 DDC_DATA 100nF 100nF C153 R102 100nF...
  • Page 46 CONFIDENTIAL 10 Schematic Diagrams 10-2-2 GH17L***J Part Schematic Diagram DOG(0:7) REFR REFCR REFPR REFMR R217 DVDD_3.3 R201 C201 R202 C266 C202 DOR(0:7) 100nF 4.7K 100pF R218 1/16W 1/16W R219 RESET DVDD_1.8 REFG REFCG REFPG REFMG R203 C265 R204 C267 C203 100nF 4.7K 100pF...
  • Page 47 CONFIDENTIAL 10 Schematic Diagrams 10-6 GH17A*/GH17L***J...
  • Page 48 CONFIDENTIAL 10 Schematic Diagrams 10-3 GH17A*/GH17L***J Part Schematic Diagram LVDS3.3V LVDS3.3V LVDS3.3V FT301 FT302 FT303 SGM32F1E104-2A SGM32F1E104-2A SGM32F1E104-2A C302 C303 C304 C305 C306 C307 100nF 100nF 100nF 100nF 100nF 100nF C311 C312 C301 C308 C309 C310 C313 100nF 100nF 10000nF 10000nF 10000nF 100nF...
  • Page 49 CONFIDENTIAL 10 Schematic Diagrams Memo 10-8 GH17A*/GH17L***J...
  • Page 50 Samsung Electronics Co.,Ltd. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea. Printed in Korea P/N : BN82-00073C-00 http://www.samsungmonitor.com (SyncMaster Worldwide) http://www.samsung-monitor.com (SyncMaster USA) http://www.sec.co.kr/monitor (Korea)
