Page 1: Quick Installation Guide
Quick Installation Guide Hybrid Video Recorder HD-TVI, 1920x1080, 960H, SD, TVR-2008AM1.0 TVR-2016AM1.0... -
Page 2: About This Document
About This Document This document contains instructions for DVR configuration and operation. Package Contents The package contains the following: Digital Video Recorder Power Cord Quick User Guide (This Document) Software CD (User’s Manual included) Rack-mount Kit ... -
Page 3: Important Safeguards
Important Safeguards 1. Read Instructions All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions The safety and operating instructions should be retained for future reference. 3. Cleaning Unplug this equipment from the wall outlet before cleaning it. Do not use liquid aerosol cleaners. Use a damp soft cloth for cleaning. - Page 4 14. Replacement Parts When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 15.
-
Page 5: Specifications
Specifications Video Signal Format NTSC or PAL (Auto Detect) Video Input Composite or HD-TVI: 8 or 16 inputs, 1 Vp-p, auto-terminating, 75 Ohms Monitor Outputs HDMI: 1 HDMI VGA: 1 VGA SPOT*: 1 BNC, 1 Vp-p, 75 Ohms Video Resolution HDMI: 1920x1080, 1440x900, 1280x1024 VGA: 1920x1080, 1440x900, 1280x1024 Composite (SPOT): 720x480 (NTSC), 720x576 (PAL) - Page 6 General Dimensions 17" (W) x 3.5" (H) x 16.1" (D) (430mm x 88mm x 410mm) Unit Weight* 13.2 lbs. (6.0kg) Shipping Weight* 19.8 lbs. (9.0kg) Shipping Dimensions 21.1" (W) x 9.4" (H) x 21.1" (D) (535mm x 238mm x 535mm) Operating Temperature 32°F to 104°F (0°C to 40°C) Operating Humidity...
-
Page 7: Table Of Contents
Table of Contents Installation ..........................7 Video Input ..........................7 Alarm Input/Output ........................7 RS485 Port ..........................9 RS232 Port ..........................9 eSATA Port ..........................9 Factory Reset Switch ......................10 Video Out ..........................10 Network Port ........................... 10 Audio In/Out ..........................10 Power Cord Connector ...................... -
Page 8: Installation
Installation No special tools are required to install the DVR. Refer to the installation manuals for the other items that make up part of your system. Your DVR can be used with either NTSC or PAL equipment. NOTE: You cannot mix NTSC and PAL equipment. For example you cannot use a PAL camera and an NTSC monitor. -
Page 10: Rs485 Port
ARI (Alarm Reset In): An external signal to the Alarm Reset In can be used to reset both the Alarm Out signal and the DVR’s internal buzzer. Mechanical or electrical switches can be wired to the ARI (Alarm Reset In) and GND (Ground) connectors. -
Page 11: Factory Reset Switch
Factory Reset Switch The DVR has a Factory Reset switch to the left of the HDMI connector on the rear panel. This switch will only be used on the rare occasions that you want to return all the settings to the original factory settings. -
Page 12: Power Cord Connector
Power Cord Connector Connect the AC power cord to the DVR and then to a wall outlet. WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD. MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE. - Page 13 Camera Buttons Pressing the individual camera buttons will cause the selected camera to display full screen. Buttons are also used to enter passwords. In the PTZ mode, pressing the button 1 zooms in the screen and the button 2 zooms out the screen, pressing the button 3 focuses near and button 4 focuses far, and pressing the button 5 moves to the preset and button 6 saves the preset.
- Page 14 Arrow Buttons These buttons are used to navigate through menus and GUI. You can also use them to change numbers by highlighting a number in the menu and using the Up and Down arrow buttons to increase or decrease the number’s value. These buttons are also used to control Pan and Tilt when in the PTZ mode.
-
Page 15: Ir Remote Control
IR Remote Control ID Button Alarm Button Monitor Buttons Freeze Button Display Button Clip Copy Button Sequence Button Bookmark Button Camera Buttons Zoom In/Out Button Triplex Button Preset Set/View Button Audio Buttons PTZ Mode Button Focus Near/Far Button Arrow Buttons Menu Button Zoom Mode Button Enter Button... -
Page 16: Initial Unit Setup
Initial Unit Setup Before using your DVR for the first time, you will want to establish the initial settings. This includes items such as time and date, display language, camera, remote control, record mode, network and password. Your DVR can be set up using various screens and dialog boxes. Press the button or move the mouse pointer on the right edge of the screen and then select (Login) in... -
Page 17: Setup Wizard
Setup Wizard Select the System menu → General → Wizard and press the button. The Wizard setup screen appears. The Wizard setup guides you through configuring the system for basic operation. Select either Quick wizard or Network wizard and select the Next button to start the selected setup wizard. - Page 18 Record Method Setup Select the desired recording mode from: – Motion Event Record (Recommended) – Continuous & Motion Event Record – Continuous Record Record Video Quality Setup Select the desired video quality profile from: – Higher Video Quality Priority Profile –...
- Page 19 Internet Connection Select whether or not your DVR is connected to the Internet. LAN Setup Select between Auto Configuration and Manual Configuration for network configuration, and then select the Test button to test the network configuration you selected. FEN Setup ...
-
Page 20: Operation
Operation Live Monitoring While in the live monitoring mode, pressing the button displays the following Live Monitoring menu on MENU the right edge of the screen. Pressing the button again hides the menu. You can navigate through menus MENU and items by pressing the arrow buttons. Login/Logout Monitor Display... -
Page 21: Searching Video
Camera Menu Selecting displays the Camera Menu. PTZ: Selecting PTZ and choosing the camera number allows you to control the selected camera as long as it has Pan, Tilt and Zoom capabilities. Zoom: Selecting Zoom and choosing the camera number zooms the current image of the selected camera on the screen. - Page 22 Search Selecting displays the Search menu. Event Log Search: Selecting Event Log Search selects video from the event log. Record Table Search: Selecting Record Table Search selects using a recording table. Motion Search: Selecting Motion Search selects motion events. ...
-
Page 23: Remote Program
Remote Program WebGuard WebGuard allows you to access a remote DVR, monitor live video images and search recorded video using Internet Explorer web browser anytime from virtually anywhere. Start Internet Explorer on your local PC. You can run the WebGuard program by entering the following information in the address field. -
Page 24: Iras
iRAS iRAS program, which is designed to be used with remote digital video recorder, is an integrated software program that controls system management, video monitoring, video recording and image playback of multiple remote sites. CAUTION: If an older version of iRAS software is installed on your computer, a screen appears asking you to upgrade the software. - Page 25 To uninstall RAS Mobile, go to Settings → Applications → Manage applications. Select RAS Mobile NOTE: and press Uninstall. 4. Press the Menu button on your mobile device. The following start-up screen will appear. New site: Registers device. Delete site: Deletes device.
- Page 26 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
