- Page 1 Sierra Wireless ® AirCard QUICK START GUIDE...
-
Page 2: Package Contents
Package Contents Your package contains the following: ® AirCard 12V/2A power supply T 3G/4G dipole antennas Ethernet cable This Quick Start Guide <update this image> Wi-Fi SSID and Security Key: The default Wi-Fi Network Name (SSID) and Wi-Fi Security Key (WPA) are unique for your device and are accessible on ®... - Page 3 ® About Your AirCard 3G/4G antenna connectors Power connector Reset LAN1/WAN port USB ports LAN 2-4 ports INTERFACE INTERFACE FUNCTION FUNCTION INTERFACE INTERFACE FUNCTION FUNCTION 3G/4G antenna Attach external 3G/4G antennas connectors LAN or WAN port for wired Ethernet clients or LAN 1 / WAN bridged devices (for example, ADSL modem) LAN Port for wired Ethernet clients...
- Page 4 Plug the power adapter into the wall socket and connect the power adapter to the POWER socket on the back of the AirCard Hub. Wait approximately 30 seconds for the AirCard Hub to power up. <image power adaptor connection>...
-
Page 5: Connect To The Internet
Press the WPS button on your AirCard hotspot until WLAN LED Press starts flashing. 2. Within 2 minutes, press press the WPS button on the wireless device press press you want to connect. Additional Wi-Fi Connections You can connect up to 16 Wi-Fi devices to your AirCard Hub. - Page 6 Connecting via Ethernet Cable Connect the provided Ethernet cable to the port marked LAN1/WAN or LAN 2-4 at the back of the AirCard Hub. Connect the other end of the Ethernet cable to your computer. Wait approximately 30 seconds for the connection to establish.
- Page 7 Now That You Are Connected <Replace Image> LED INDICATOR DEFINITION Power status indicator: (1) Power Off = No Power On = Power Wi-Fi status indicator: Off = Wi-Fi Off (2) WLAN Solid = Wi-Fi On, no traffic Flash = Wi-Fi On, data traffic Internet WAN indicator: Off = No Internet connection (3) WWAN...
-
Page 8: Modes Of Operation
Modes of Operation The AirCard Hub supports 3 operating modes offering varying levels of function and configuration options. A. A. A. A. Easy (default) Easy (default) Easy (default) Easy (default) Easy mode is best for users who just want to extend the functionality of their hotspot. - Page 9 B. B. B. B. Small Office / Home Office (SOHO) Small Office / Home Office (SOHO) Small Office / Home Office Small Office / Home Office (SOHO) (SOHO) SOHO mode is best for users that want to both extend their hotspot capability and have a local network when the mobile hotspot is not present.
- Page 10 Power User Power User Power User Power User mode opens all advanced user options for the AirCard Hub and is meant for users who are comfortable with networking technology. Advanced configuration settings are accessible in this mode. AirCard hotspot docked...
-
Page 11: Firmware Upgrades
Do not interrupt the power supply during the upgrade Do not interrupt the power supply during the upgrade Do not interrupt the power supply during the upgrade process..Once completed, your AirCard Hub will reboot to the process process process Easy mode operation. - Page 12 Help icon to access the User Manual. Caution: Caution: Caution: Caution: The antennas of the Sierra Wireless AirCard Hub must be maintained at least 20 cm from users during operation. Use only the antennas available from Sierra Wireless. (See www.sierrawireless.com/en/productsandservices/ AirCard/Accessories.aspx#AirCard Accessories.) Notice: User restrictions for Wi-Fi operation apply in France.
