- Page 1 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® SECTION 1 FLUSH INSET INSTALLATION SECTION 2 STANDARD INSTALLATION 1/4" FRAMED PANELS 3/4" OVERLAY PANELS Product Specification Created 1/15...
-
Page 2: Specifications
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® OVERALL DIMENSIONS FLUSH INSET INSTALLATION AFTER PANEL INSTALL 26" (66.0) 20 5/8" 44" (52.4) (111.8) 11 11/16" (29.7) 72 5/8" *83 1/2" (184.5) 212.1) 68 5/8" (174.3) SPECIFICATIONS Overall Width 44" (111.8 cm) †... -
Page 3: Anti-Tip Bracket
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® FLUSH INSET INSTALLATION 3/4" PANELS FLUSH INSET INSTALLATION TOP VIEW 24" 47 1/2" Case 3 1/4" (61.0) (120.7) 7/16" (8.3) (1.1) Finished cleats 5 1/4" 20" 1 1/2" NOTES (13.3) Trim overlap (50.8) (3.8) - Page 4 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® FLUSH INSET INSTALLATION 1/2" PANELS FLUSH INSET INSTALLATION TOP VIEW 24" 47 1/2" Case 3 1/4" (61.0) (120.7) 7/16" (8.3) (1.1) Finished cleats 5 3/8" 20" 1 1/2" NOTES (13.7) Trim overlap (50.8) (3.8)
-
Page 5: Panel Dimensions
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® FLUSH INSET 3/4" PANEL DIMENSIONS FLUSH INSET INSTALLATION NOTES Grille Panel PANEL DIMENSIONS Trimmed refrigerators are designed to be customized with decorative panels. Field-installed 1/2" or 3/4" custom door and grille panels are required. For 3/4"... - Page 6 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® 3/4" RAISED gRILLE PANEL ROUTINg FLUSH INSET INSTALLATION NOTE: Routed areas should be NOTES finished as they may be visible DETAIL TOP when assembled. Trimmed refrigerators are designed to be customized with decorative Front panels.
- Page 7 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® FLUSH INSET 1/2" PANEL DIMENSIONS FLUSH INSET INSTALLATION NOTES PANEL DIMENSIONS Grille Panel The 1/2" overlay panel must be secured to a .10" spacer panel and a 1/4" thick backer 1/4" Backer Panel 39 7/8"...
-
Page 8: Overall Dimensions
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® OVERALL DIMENSIONS STANDARD INSTALLATION 25 1/2" (64.8) 23 7/8" 25 1/2" 42" (60.7) (64.8) (106.7) 23 7/8" 42" (60.7) (106.7) 1 3/4" (4.4) 1 3/4" (4.4) *83 1/2" 212.1) *83 1/2" 212.1) *72 1/4"... - Page 9 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® STANDARD INSTALLATION STANDARD INSTALLATION TOP VIEW 24" 47 1/2" 3 1/4" (61.0) (120.7) NOTES 7/16" (8.3) (1.1) 20" 1 1/2" Trim overlap (50.8) (3.8) A Mounting the junction 6" 3 1/8" 24" (61) 41 1/2"...
-
Page 10: Custom Side Panels
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® CUSTOM SIDE PANELS STANDARD INSTALLATION 24" NOTES (61.0) 3/16" (.5) F Side panels must be used whenever the sides of the refrigerator will be 1 7/8" exposed. The 1/4" side panels will (4.8) slip into the side case trim. - Page 11 Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® 1/4" FRAMED PANEL DIMENSIONS STANDARD INSTALLATION NOTES PANEL ASSEMBLY CROSS SECTION Trim Trimmed refrigerators are designed to Grille Panel Door be customized with decorative panels. Field-installed custom door and grille panels are required.
-
Page 12: Features And Benefits
Monogram 42" Built-In Side-by-Side Refrigerator ZIS420NH ® FEATURES AND BENEFITS Halogen Light Columns - Located in the freezer and fresh food compartments, extend the full length of the interior compartments providing brilliant, all-level illumination LED Lighting - Located at the top of the fresh...
