Onkyo CR-305FX Service Manual

MODEL
STANDBY/ON MEMORY FM MODE
PHONES
Silver, Black and Titanium models
S CDT 120V AC, 60Hz
S CGQ 220-230V AC, 50/60Hz
S CGR 220-230V AC, 50/60Hz
S CPP 230-240V AC, 50Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
SERVICE MANUAL SERVICE MANUAL
CD RECEIVER
CR-305FX
