Page 1: User Manual
Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register _... - Page 2 Safety Information SAFETY INFORMATION Before using your new Samsung French Door Refrigerator, please read this manual thoroughly to ensure that you know how to safely and efficiently operate the features and functions that your new appliance offers. Because the following instruction covers various models, the characteristics of your Refrigerator may differ slightly from the Refrigerator described in this manual.What the icons and signs in this user...
- Page 3 Safety Information Do not spray water directly into or on the outside of the Refrigerator/Freezer drawer. • Water could get into the interior machine parts and cause electric shock. Do not use aerosols near the Refrigerator. • Aerosols used near the Refrigerator may cause an explosion or fire. Do not put undue stress on the power cord or place heavy articles on it.
- Page 4 • Do not allow children to climb into the freezer basket. If you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator immediately and contact your Samsung Electronics Call Center. After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer compartment.
- Page 5 Service Warranty and Modification • Any changes or modifications performed by a 3rd party on this finished appliance is not covered under Samsung warranty service, nor can Samsung be responsible for safety issues that result from 3rd party modifications. Children can get trapped inside Refrigerators.
- Page 6 Safety Information ADDITIONAl TIPS FOR PROPER USAGE a) Allow the appliance to stand for 2hours after installation. b) To get Best performance of product, 1) Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the freezer compartment.
-
Page 7: Table Of Contents
Making minor adjustments between doors Adjusting the freezer drawer level Checking the water dispenser line Installing the water dispenser line Setting up the refrigerator OPERATING THE SAMSUNG Using the digital display Controlling the temperature FRENCH DOOR REFRIGERATOR Using the ice and cold water dispenser... -
Page 8: Setting Up Your French Door Refrigerator
Setting up your French Door Refrigerator GETTING READY TO INSTAll ThE REFRIGERATOR Congratulations on your purchase of the Samsung French Door Refrigerator. We hope you enjoy the state-of-art features and efficiencies that this new appliance offers. SelectingthebestlocationfortheRefrigerator • A Location with easy access to the water supply. - Page 9 DISASSEMblEThEREFRIGERATORDOORS 1. With the door opened, remove the Top Table cap ( ) with a Flat head screwdriver, and close the door. Remove the 3 screws holding down the Top Table and remove the Top Table( 2. Disconnect the electrical connector ) above the upper right door hinge and the 3 electrical connectors ( ) above the...
- Page 10 Setting up your French Door Refrigerator REMOVINGThEREFRIGERATORDOORS • To reattach the Refrigerator doors, assemble parts in reverse order. Be careful not to missplace the parts of refrigerator. CAUTION DISASSEMblEThEFREEzERDRAWER 1. Push the upper drawer until it reaches to the cabinet rear wall. 2.
-
Page 11: Adjusting The Doors
ASSEMblEThEFREEzERDRAWER 1. Pull out the rails to the full length on each side of the cabinet evenly. Slot Slot 2. Hang the freezer door front onto open slots on the sides. Slot Slot Slot Slot 3. Tighten four 10mm hex-head screws completely. 4. -
Page 12: Making Minor Adjustments Between Doors
Setting up your French Door Refrigerator WhentheleftdoorislowerthantheRightdoor. Insert a flat-blade screwdriver into a slot on the left control lever, turn it clockwise or ounterclockwise to level the left door. Control Lever Screwdriver Control Lever Screwdriver WhentheleftdoorishigherthantheRightdoor. Insert a flat-blade screwdriver into a slot on the right control lever, turn it clockwise or counterclockwise to level the right door. -
Page 13: Adjusting The Freezer Drawer Level
1. If you open the drawer ( ), you can see the lower hinge ( 2. Insert the supplied hex wrench ( ) into the shaft ( ) of the lower hinge. 3. Please adjust the height turning the hex wrench ( ) clockwise( ) or counter-clockwise (... -
Page 14: Checking The Water Dispenser Line
) in reverse order. ChECKING ThE WATER DISPENSER lINE A water dispenser is one of the helpful features on your new Samsung Refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. - Page 15 Before being used, the leakage in these places should be examined CAUTION • Samsung Warranty does not cover WATER LINE INSTALLATION. • It will be done at customer’s charge unless the retail price includes installation cost.
- Page 16 Setting up your French Door Refrigerator Installingthewaterfilter 1. Remove the water filter cover( 2. Remove the fixed cap by turning it counter clockwise. Keep the cap in a safe place for later use if you don’t use a filter. 3. Remove the water filter from the box and put a replacement indicator sticker on the filter as shown.
-
Page 17: Setting Up The Refrigerator
If you have any further questions, contact your Samsung Electronics call center. 1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and the Refrigerator. - Page 18 Setting up your French Door Refrigerator SETTING UP ThE REFRIGERATOR • TYPE A Press the Ice off button if you want to turn the ice-maker off. ) Ice Off Button Speeds up the time needed to freeze products in the Freezer. It can be helpful ) Power Freeze if you need to quickly freeze easily spoiled items or if the temperature in the Button...
- Page 19 • Type B For better energy efficiency, press the Energy Saver button. If condensation ) Energy Saver occurs on the doors, turn the Energy Saver function off. Button Press the Freezer / Power Freeze button to set the Freezer to your desired temperature.
-
Page 20: Operating The Samsung French Door Refrigerator
Operating the SAMSUNG French Door Refrigerator USING ThE DIGITAl DISPlAY • Type A • Type B When not in use the Display will turn o , this is normal. PowerFreeze This icon will light up when you activate the “Power freeze” feature. “Power freeze” helps your foods freeze faster. - Page 21 FilterIndicator When the filter indicator light is on, it is time to change the filter. Typically this happens about every 6 months. The Filter Indicator will be Blue when you initially insert the water filter. The Filter Indicator will be Light Pink when you have used your water filter for 5 months. The Filter Indicator will be Red when you have used your water filter for 6 months.
-
Page 22: Controlling The Temperature
Operating the SAMSUNG French Door Refrigerator CONTROllING ThE TEMPERATURE basicTemperatureofFreezerandRefrigeratorCompartments The basic temperature and/or recommended temperature of Freezer and Refrigerator Compartments are -19°C(-2°F)/3°C(38°F). If the temperature of Freezer and Refrigerator Compartments are too high or low, adjust the temperature manually. -
Page 23: Using The Ice And Cold Water Dispenser (Optional)
USING ThE ICE AND COlD WATER DISPENSER (OPTIONAl) PresstheIce/Waterbuttontoselectthetypeofyouwant No ICE Select this if you want to turn ice maker off. UsingtheIceDispenser Place a cup underneath the ice dispenser and push gently against the dispenser lever with your cup. Make sure the cup is in line with the dispenser to prevent the ice from bouncing out. If the Freezer door is left open for a long time, condensation may form or the ice inside the Ice-Maker may clump. -
Page 24: Storing Food
Operating the SAMSUNG French Door Refrigerator STORING FOOD LED Light Auto Door Closer ICE MAKER (OPTIONAL) Dairy Compartment Water Filter Foldable-Shelf Slide-Shelf Slide-Shelf Vertical Hinged Door Bins Section GLASS CONTAINER SHELVES Vegetable & Fruit Drawers Cool Select Pantry LED Light... -
Page 25: Storing Food In Refrigerator
STORING FOOD IN REFRIGERATOR The Samsung French Door Refrigerator has been designed to provide you with maximum space saving features and functions. Here are some of the customized compartments we have created to keep your food fresher longer. In order to further prevent odor from seeping into the ice compartment, stored food should be wrapped securely and as airtight as possible. -
Page 26: Using The Cool Select Pantry
Operating the SAMSUNG French Door Refrigerator USING ThE COOl SElECT PANTRY™ The Cool Select Pantry™ is a full-width drawer with adjustable temperature control. This pantry can be used for large party trays, deli items, pizza, beverages or miscellaneous items. There is a temperature control which can adjust the amount of cold air allowed into the pantry. -
Page 27: Using The Tilting Pocket
USING ThE TIlTING POCKET The Tilting Pocket can be used to store up to a 16”(406mm) pizza if you place it shown in the illustration. REMOVING ThE REFRIGERATOR ACCESSORIES 1.Doorbins&DairyCompartment To remove - Simply Lift the bin up and pull straight out. To relocate - Slide it in above the desired location and push down until it stops. -
Page 28: Removing The Freezer Accessories
Operating the SAMSUNG French Door Refrigerator 4.CoolSelectPantry To remove the pantry - Pull the pantry out to full extension. Tilt up the front side of pantry and pull straight out. To relocate the pantry - Push the rails to the back of the Refrigerator. -
Page 29: Cleaning The Refrigerator
To relocate the divider - Hook the top corners of divider over the hole of the bin. ClEANING ThE REFRIGERATOR Caring for your Samsung French Door Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. - Page 30 Do not remove the back cover. Doing so may cause an electric shock. CAUTION Do not disassemble or replace the LED type Lighting. To change the LED Type Lighting contact Samsung service center or your authorised Samsung CAUTION dealer. If Users randomly exchange the LED lamp by yourself, this may result in electric shock or personal CAUTION injury.
-
Page 31: Changing The Water Filter
Do NOT use the water or ice dispenser without a water filter cartridge because the water line may become blocked. Orderingreplacementfilters To order more water filter cartridges, contact your authorized Samsung dealer. Operating _... -
Page 32: Troubleshooting
Troubleshooting PROBLEM SOLUTION The Refrigerator does not • Check that the power plug is properly connected. work at all or it does not • Is the temperature control on the display panel set to the correct chill sufficiently. temperature? Try setting it to a lower temperature. •... -
Page 33: Circuit Diagram
circuit diagram RF26D* Circuit diagra m _33... -
Page 34: Rf26N
circuit diagram RF26N* 34_ Circiut diagram... - Page 35 Memo...
- Page 36 This product should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. AUSTRAILA 1300 362 603 www.samsung.com/au...
