1. BASIC OPERATION
1. QUICK REFERENCE
MAP SCREEN
To display this screen, press the "MENU" button on the Remote Touch, then select
"Nav" on the "Menu" screen.
No.
Name
2D north up, 2D
heading up or 3D
heading up sym-
bol
Options button
"GPS" mark
(Global
Positioning
System)
Traffic indicator
Scale indicator
84
Function
Indicates whether the map orientation is set to
north-up or heading-up. The letter(s) beside this
symbol indicate the vehicle's heading direction
(e.g. N for north). In 3D map, only a heading-up
view is available.
Select to display the "Navigation Options" screen.
Shows that the vehicle is receiving signals from
the GPS.
Shows that traffic information is received. Select
to start voice guidance for traffic information.
When traffic information is received via HD, HD
mark is displayed on the right.
This figure indicates the map scale.
ES350/300h_Navi_OM33B75U_(U)
15.04.23 21:15
Page
90
86
162
102
88
