- Page 1 2015 Quick Reference Guide...
-
Page 2: Basic Operation
For detailed operating and safety information, please refer to your Owner’s Manual. BASIC OPERATION Lock/ Unlock doors Remote keyless entry system All doors and the rear gate will be locked. The driver’s door will be unlocked. (To unlock all doors and the rear gate, briefly press the button a second time within 5 seconds.) Press and hold to open the rear gate. -
Page 3: Adjustable Components
Adjustable components Front seat Forward and backward adjustment Seat cushion height adjustment (Driver's seat only) Seatback reclining adjustment Tilt/ telescopic steering wheel Adjust the seat position and pull the tilt/ telescopic lock lever down. Move the steering wheel to the desired level. Pull the lever up to lock the steering wheel in place. -
Page 4: Start/ Stop Engine
Start/ Stop engine Push-button ignition switch (if equipped) To start engine: 1. Carry the access key, and sit in the driver’s seat. Operation 2. Apply the parking brake. indicator 3. Shift the select lever in the P position. 4. Depress the brake pedal until the indicator on the push-button ignition switch turns green. -
Page 5: Continuously Variable Transmission
Operate Select lever/ Shift lever Continuously variable transmission Select lever button With the brake pedal depressed, shift while pressing the button in Shift while pressing the button in Shift without pressing the button M = Manual mode: With the vehicle either moving or stationary, move the select lever from the D position to the M position to select the manual mode. -
Page 6: Driver's Area
DRIVER’S AREA Headlight switch/ Turn signal lever/ Front fog light switch Headlights Headlight flasher, High/Low beam change Turn signal Front fog lights (if equipped) To turn on the front fog lights, rotate dial to Front fog lights operate only when headlight switch is in... position. -
Page 7: Wiper And Washer Switch
Wiper and washer switch Windshield wiper To operate the wiper, rotate knob to; : Mist (for a single wipe) : Off : Intermittent : Low speed : High speed Wiper intermittent time control Windshield washer Rear window wiper and washer To operate the wiper, rotate knob to;... -
Page 8: Power Window Switches
Defroster button/ Rear window defogger button Defroster button: Press the button to defrost the windshield. Rear window defogger button: Press the button to turn on rear window defogger, outside mirror defogger or windshield wiper deicer. The function will automatically shut off after approximately *The illustration of the print is Type A. -
Page 9: Power Door Locking Switch
Power door locking switch To lock all doors and the rear gate To unlock all doors and the rear gate Seat heater HI : Rapid heating LO : Normal heating Fuel filler lid release lever Pull Right side This indicates that the fuel filler door (lid) is located on the right side of the vehicle. -
Page 10: Sunroof Switches
Sunroof switches Tilting Sliding Raise Open Lower Close Child safety locks Located on the edge of each rear door. When the lever is in the LOCK position, the rear door cannot be opened from the inside. Front seat shoulder belt anchor height To lower To raise Push the upper part... - Page 11 VEHICLE PERFORMANCE FUNCTIONS Vehicle Dynamics Control OFF switch Indicator lights on the combination meter Vehicle Dynamics Control mode Vehicle Dynamics Control OFF mode Deactivating the Vehicle Dynamics Control system facilitates the following operations. - a standing start on a steeply sloping road with a snowy, gravel-coverd, or otherwise slippery surface - extrication of the vehicle when its wheels are stuck in mud or deep snow Do not deactivate the system except when absolutely necessary.
-
Page 12: Cruise Control Buttons
Cruise control buttons Cruise control enables you to maintain a constant vehicle speed without holding your foot on the accelerator pedal and it is operative when the vehicle speed is 40 km/h or more. Cruise control main button: To activate and deactivate RES/ SET switch ▲RES/+ side: To increase the speed/ To resume... - Page 13 Energy flow screen: You can display the following information on the multi function display. - Status of the high voltage battery. - Energy flow between engine, motor, high voltage battery and wheels. Engine Motor High voltage battery The motor is assisting Driving only by the Driving only by the the engine motor power...
-
Page 14: Warning Lights
ON. Warning lights Refer to your Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized SUBARU dealer. Seatbelt warning Front passenger’s seatbelt warning Remind the driver to fasten... -
Page 15: Indicator Lights
Low fuel warning Access key warning (if equipped) Fuel tank is nearly empty. Refill The access key is not inside the fuel immediately. vehicle. For other situations, refer to your Owner’s Manual. Windshield washer fluid warning Hill start assist warning/ Hill start assist OFF indicator The fluid level in the windshield washer fluid tank decreases to Warning : Hill start assist... - Page 16 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
