CROSSTREK
2016

Quick Reference Guide

Love. It's what makes a Subaru, a Subaru.

Advertisement

Table of Contents
loading

Related Manuals for Subaru 2016 CROSSTREK

Summary of Contents for Subaru 2016 CROSSTREK

  • Page 1: Quick Reference Guide

    CROSSTREK 2016 Quick Reference Guide Love. It’s what makes a Subaru, a Subaru.
  • Page 2 Subaru of America, Inc. at the time of publication. This Quick Reference Guide © 2015 Subaru of America, Inc. applies to all Crosstrek models. Therefore, some explanations may be for equipment not installed on your vehicle. Subaru of America, Inc., reserves the right to change...

  • Page 3: Table Of Contents

    Table of Contents Getting Started Instrument Panel Gauges Personalize 10-11 12-19 Controls While Operating 20-21 Safety/In Case of Emergency 22-23 24-25 Additional Information...

  • Page 4: Remote Keyless Entry

    Remote Keyless Entry 1. Lock/Arm 3. Unlocking the Rear Gate • Press to lock all doors and the rear • Press the button to unlock gate and activate the security alarm. the rear gate. An electronic chirp will sound twice and the •...

  • Page 5: Heated Seats

    Seating Heated Seats Seat Controls (if equipped) 1. Forward/Backward Pull up on the lever below the front of Press the switch in the the driver’s seat to move the seat forward corresponding direction or backward. for the desired seat temperature. To turn off the 2.

  • Page 6: Instrument Panel

    Instrument Panel PAGE NUMBER...
  • Page 7 14-15 Clock Press the “+” button to advance the time or the “–” button to reverse the time. Vehicles with a navigation system, please refer to the separate “Operating Instructions for Navigation System.”...
  • Page 8 Gauges - Vehicles without EyeSight Trip meter A/B selection Trip meter and odometer and trip meter reset knob Immediate Attention Caution Informational Tachometer Brake system Seatbelt warning Hot coolant temperature / Front passenger Cold coolant temperature seatbelt warning High beam indicator light SRS airbag system AT OIL TEMP Security indicator light...
  • Page 9 Speedometer Information display selection knob Fuel gauge MPG gauge Vehicle Dynamics Control OFF Turn signals CHECK ENGINE / Front fog light indicator Malfunction indicator light (if equipped) Cruise control Tire pressure warning light indicator light Front passenger frontal Cruise control set airbag ON indicator light Front passenger frontal...
  • Page 10 Gauges - Vehicles with EyeSight Trip meter A/B selection Tachometer Fuel gauge and trip meter reset knob Immediate Attention Caution Informational Trip meter and odometer Brake system Seatbelt warning Hot coolant temperature / Front passenger Cold coolant temperature seatbelt warning High beam indicator light SRS airbag system AT OIL TEMP...
  • Page 11 Speedometer Information display selection knob MPG gauge Vehicle Dynamics Control OFF Turn signals CHECK ENGINE / Front fog light indicator Malfunction indicator light (if equipped) Cruise control Tire pressure warning light indicator light Front passenger frontal Cruise control set airbag ON indicator light Front passenger frontal airbag OFF...

  • Page 12: Personalize

    Personalize Tilt and Telescopic Steering Column Push the lever down firmly to adjust the height and lengthwise position of the column; firmly push the lever back up to lock the column in place. Do not adjust while driving.

  • Page 13: Power Exterior Mirrors

    Power Exterior Mirrors Turn the knob to the “L” side to adjust the left-hand mirror or to the “R” side to adjust the right-hand mirror. Move the knob in the direction you want to move the mirror. Then return the knob to the neutral/center position.

  • Page 14: Controls

    Controls Light Controls Push forward to change from low Push up Turns on headlights, instrument beam to high beam. Pull the lever for right panel illumination, parking lights, back to center to return to low beam. turn signal. tail lights and license plate lights. Push down for Turns on left turn signal.

  • Page 15: Windshield Wipers

    INT. HIGH Windshield Wipers To turn on the wipers, press the wiper control lever down one level for intermittent, two levels for low, or three levels for high speed. Return the lever to the “OFF” position to stop the wipers. For a single wipe, move the lever up. To spray washer fluid, pull and hold the lever toward you.

  • Page 16: Manual Climate Control System

    Controls Manual Climate Control System (if equipped) 1. Air Flow Control Dial 3. Fan Speed Control Dial The air flow control dial allows you to Rotate the fan speed control dial to select choose the direction of air flow. Rotate one of four fan speeds.

  • Page 17: Automatic Climate Control System

    Automatic Climate Control System (if equipped) 1. Air Flow Control Dial 4. Recirculated/Outside Air Button In the automatic setting, the system In the automatic mode, the system determines the air flow location to will determine if recirculated air achieve the desired temperature, or is needed to achieve a desired you can manually choose the direction temperature.
  • Page 18 Controls Power Moonroof (if equipped) With the moonroof in the fully closed position, press the switch to tilt the moonroof up. Press and hold the switch to lower the moonroof. Press and hold the switch to fully open the moonroof. Press and hold the switch to close the moonroof.

  • Page 19: Auxiliary Input Jack

    Auxiliary Input Jack The 3.5mm auxiliary input jack is located in the front of the center console. You can connect a portable music player to the auxiliary jack and hear the music stored on it through the vehicle speakers. Press the “SOURCE”...

  • Page 20: Steering Wheel Audio Controls

    Controls Steering Wheel Audio Controls Push the top (+) of the switch to With any of the radio modes increase or the bottom (–) of the selected, push the switch left or right switch to decrease volume. to skip through your presets. In CD mode, push the switch up or down to skip forward or back a track.

  • Page 21: Cruise Control

    Cruise Control To activate the cruise control, press To resume your speed the “ ” button. The indicator light after canceling, push the on the instrument panel will turn switch to the “RES” side. on. To deactivate cruise control, press the “ ”...

  • Page 22: While Operating

    While Operating Vehicle Dynamics Control OFF Switch Pressing the switch to deactivate the Vehicle Dynamics Control system can help in the following situations: • A standing start on a steeply sloping road with a snowy, gravel-covered, or otherwise slippery surface. •...
  • Page 23 Automatic Transmission Shift Mode The automatic transmission gives you ultimate control with two different driving modes: Normal Mode and Manual Mode. Normal Mode When the selector lever is in the “D” (Drive) position, the transmission is in Normal shift mode. The shift position indicator on the instrument panel shows “D”, and the transmission automatically shifts into a suitable forward gear.

  • Page 24: Safety/In Case Of Emergency

    Safety/In Case of Emergency Child Restraint System For maximum safety, first carefully read the LATCH system instructions from the device manufacturer, as well as the installation instructions in your Owner’s Manual, to properly install the LATCH compatible restraint system. Use the appropriate seatbelts or anchorages provided in your vehicle.
  • Page 25 AWD vehicle. If from: accidents, vandalism, acts of towing is necessary, it is best God, violation of any laws, misuse and done by your Subaru retailer or a abuse, or vehicle modifications not commercial towing service. recommended by the manufacturer.

  • Page 26: Additional Information

    Additional Information Fuel • Use regular unleaded gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s Manual for more detailed information. Fuel Capacity • 15.9 US gal (60 liters, 13.2 lmp gal) • When the low fuel indicator light is displayed on the instrument panel, approximately 2.6 US gal (10.0 liters, 2.2 Imp gal) of fuel remain.

  • Page 27: Engine Oil

    Engine Oil Use only the following oils: • ILSAC GF-5, which can be identified with the ILSAC certification mark (Starburst mark). • Or API classification SN with the words “ENERGY CONSERVING.” - Use 0W-20 synthetic, replacement interval 6,000 miles under normal driving conditions.
  • Page 28 Notes...
  • Page 30 Notes...
  • Page 31 Manuals & Warranties Review vehicle manuals & maintenance schedule Review warranty information (Basic, Powertrain, Tire, Wear Items & Adjustments) Review Subaru Roadside Assistance 1 (800) 261-2155 Retailer Orientation Parts & Service departments locations & hours Service Advisor introduction and/or business card Service appointment &...
  • Page 32 Parking Brake operation STARLINK Audio System & Bluetooth Bluetooth - Pair owner’s phone(s) & show operation (Download SUBARU STARLINK and MySubaru Apps*) STARLINK Audio* and Navigation* system controls (Sources, Presets, List & Back buttons) Safety, Comfort & Convenience...
  • Page 33 Subaru of America, Inc., Subaru Plaza, P.O. Box 6000, Cherry Hill, NJ 08034-6000 MSA5B1607A Issued December 2015 Printed in USA 12/15...
