- Page 1 10143.3TpDVQaXSp INSTRUCTION MANUAL BUILT-IN ELECTRIC OVEN IOAK-2427 /8054089 (05.2013./1)
-
Page 2: Dear Customer
DEAR CUSTOMER, The oven is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the oven will be easy. Before being packaged and leaving the manufacturer, the oven was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully. -
Page 3: Table Of Contents
TABLE Of CONTENTS Safety instructions ......................4 Description of the appliance ..................... 8 Installation ......................... 10 Operation ........................... 12 Baking in the oven – practical hints ................33 Cleaning and maintenance ....................34 Technical data ........................40... -
Page 4: Safety Instructions
SAfETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or... - Page 5 SAfETY INSTRUCTIONS Warning: Ensure that the appliance is switched off before replacing the lamp to avoid the possibillity of electric shock. Use only original temperature probe supplied with the appliance. You should not use steam cleaning devices to clean the appliance. ● Ensure that small items of household equipment, including connection leads, do not touch the hot oven as the insulation material of this equipment is usually not resistant to high temperatures. ● Do not leave the oven unattended when frying. Oils and fats may catch fire due to overheating or boiling over.
-
Page 6: How To Save Energy
HOW TO SAVE ENERGY Using energy in a respon- sible way not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: Do not uncover the pan too often (a watched pot never boils!). - Page 7 DISPOSAL Of THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...
-
Page 8: Description Of The Appliance
DESCRIPTION Of THE APPLIANCE Electronic Water container programmer drawer Oven door handle Time setting sensor field Setting selection sensor field Temperature selection sensor field Confirmation sensor filed Setting selection sensor field Stand by / menu sensor field... - Page 9 SPECIfICATIONS Of THE APPLIANCE Cooker fittings:: Grill grate (drying rack) Baking tray Perforated bowl Roasting tray Solid bowl Temperature probe Shelf supports Steam generator...
-
Page 10: Installation
INSTALLATION Installing the oven The kitchen area should be dry and aired and equipped with efficient ventillation. When installing the oven, easy access to all control elements should be ensured. This is a Y–type design built–in oven, which means that its back wall and one side wall can be placed next to a high piece of furniture or a wall. - Page 11 INSTALLATION Electrical connection 230V 1N~ Warning: This appliance must be earthed. The appliance must be installed by a com- Neutral (Black or Blue) petent electrician using a double pole control unit of 16 ampere minimum capacity with Earth 3mm minimum contact separation at all (Green/Yellow poles.
-
Page 12: Operation
OPERATION Before using the appliance for Important! the first time Oven is equipped with a programmer with display controlled by six sensor ● Remove packaging, clean the interior of fields located symmetrically on both sides of the display. To activate each the oven, sensor field, touch the glass above the ● Take out and wash the oven fittings with sensor (indicated by a pictogram). An warm water and a little washing-up liquid, acoustic signal will be heard, which ●... -
Page 13: Oven Control
OPERATION Electronic programmer operation and oven control function symbols Sensor field functions - power cut-off - time setting sensor - temperature adjustment - field - end time - temperature - cook time - selection sensor field - Child Lock - stand by / menu sensor field - setting selection sensor field... -
Page 14: Set Current Time
OPERATION Switching on the appliance and selecting Set current time. language. Once language is selected, confirm the time After connecting the appliance to the mains, displayed on the display using the sen- electronic programmer starts in menu: setup sor field or change it using the sensor / language. fields. Using the sensor fields search the Time can be set in the range from 0:00 to contents of the language menu. -
Page 15: Menu
OPERATION Menu . sensor fields to navigate the menu. Touch . to activate the appliance from Touch to select the chosen item. standby. Use sensor fields to navigate To exit from the setup menu, select exit and the menu. touch to confirm.To immediately exit from The following main menu items are avail- the setup menu and switch the appliance to able: standby mode simultaneously touch - setup,... -
Page 16: Setting Cook Time
OPERATION For details on how to select language, please Setting cook time (for a heating func- refer to section Switching on the appliance tion) and selecting language. Once heating function is selected, touch To exit from the language menu to setup sensor field. When , starts to flash on the menu, select exit using the... - Page 17 OPERATION COOK TIME changes to END TIME in box If no change in setting is made within 5 sec- 2. Entered cook time, for example 0:30, onds, the appliance will return to previous changes to the actual end time, while the settings of cook time and the selected heating remaining time is displayed on the red bar function.
- Page 18 OPERATION Once cook time has elapsed, an acoustic Menu \ Setup \ Time \ Clock type signal is sounded (4 beeps / pause / 4 beeps). The sequence is repeated every 3 seconds Select clock type menu and touch for about a minute symbol is flashing. following items will be available: Touch to acknowledge and mute the - Standard...
- Page 19 OPERATION Menu \ Setup \ Lighting Menu \ Setup \ Sound Select Lighting menu and touch , The fol- Select Sound menu and touch , The fol- lowing items will be available: lowing items will be available: - continuous, - Tone_1 - intermittent.
- Page 20 OPERATION Menu \ Setup \ factory Settings Menu \ Setup \ Brightness Select Factory Settings menu and touch Select Brightness menu and touch , The The following screen will be displayed: following screen will be displayed: Touch navigation sensor fields to adjust Touch navigation sensor fields to select display brightness within 0-100% range in 1% whether to restore the factory settings or steps.
- Page 21 OPERATION Menu \ Heating functions Select the Heating Functions menu using the sensor fields and confirm selection by touching The following heating functions are avail- able: - conventional, - cake, - turnspit *, - grill, - turbo grill, - super grill, - fan cooking, - pizza, - browning, - roasting, - defrosting,...
- Page 22 OPERATION Menu \ Heating functions \ fan cooking Select the Fan Cooking menu using the The Eco function involves disconnecting the sensor fields and confirm selection by touch- heater 5 minutes before cook time elapses. . The following screen is displayed showing the default temperature of 170°C and level three. symbol flashes for 5 seconds when the screen is displayed.
-
Page 23: Using Meat Temperature Probe
OPERATION Once the food reaches the set temperature, Using meat (food) temperature probe all functions except cooling fan are turned off (see: Cooling fan operation) and an After selecting the chosen heating function, acoustic signal is sounded (4 beeps / pause set the desired cooking temperature, or ac- / 4 beeps). -
Page 24: Child Lock
OPERATION Important! Special functions Use only original temperature probe supplied with the appliance. Child Lock Simultaneously touch for approxi- Recommended probe temperature set- mately 3 seconds to active child lock. Activa- tings tion of child lock is indicated on the display by , symbol and a short beep. - Page 25 OPERATION Automatic power cut out Menu / preset programmes If the oven operates any heating function for Select Preset Programme menu and touch a long (excessive) period of time, heating The following items will be available elements are disconnected. a) meat, b) poultry, If all the heating elements are disconnected, c) pizza,...
- Page 26 OPERATION Touch to start the programme. Example: using a preset program with no oven preheating You can modify temperature settings for chamber oven and meat probe at any time, Select poultry menu and confirm by touching however, making any changes will modify the , The following types of poultry are avail- preset program.
- Page 27 OPERATION Example: using a preset program with The appliance display shows the following oven preheating information when a program is in progress: Select Pastries menu and confirm by touch- , The following types of pastries are available: crumble cake, fruit cake, Swiss roll, sponge cake, muffins, cookies, bread Select Swiss roll and a confirm selection by touching .
- Page 28 OPERATION Appliance display will show the following Preset programmes information 1. Meat - pork - beef - veal - lamb 2. Poultry - chicken - duck Desired temperature is maintained in the - goose oven. COOK TIME in box 2 is replaced with - turkey END TIME (programme end time is displayed and the remaining time of 10 minutes on the 3.
- Page 29 OPERATION Menu / user programs Touch ,to acknowledge and mute the acoustic signal. After this, the appliance Select user programmes menu and touch switches to standby mode. . 10 fully customisable user programmes are available. Editing user programme settings Operating user programmes To modify the heating function and COOK TIME, touch and hold sensor field and then Using...
- Page 30 OPERATION Menu / steam programmes Touch navigation sensor fields to change the temperature. Temperature range and Using button select Steam Programme default temperature are described in section menu and touch The following items will Menu \ Heating functions. Select the desired be available: temperature and touch . sensor field to a) sliced vegetables confirm. After touching the...
- Page 31 OPERATION Starting a steam programme You can modify end time at any time, how- ever, making any changes will modify the Select the appropriate steam program using preset program. To modify and store time buttons. symbol stops flashing) or stop (end) the process press .
- Page 32 OPERATION Menu / Cleaning Cooling fan operation Touch navigation sensor fields to select Cooling fan is started whenever oven cham- cleaning from main menu and touch ber temperature exceeds 50°C regardless following screen will be displayed: of any heating function operating or not. In order for the cooling fan to be started both protection relay and cooling fan delay must be on.
-
Page 33: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking we recommend using the baking trays which were provided with your cooker; it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;... -
Page 34: Cleaning And Maintenance
CLEANING AND MAINTENANCE Important! After three uses of a steam Proper routine maintenance and cleaning of oven, you must descale water-steam the oven can significantly extend its trouble- system as follows: free operation. - mix 0.5 l of water with the descaling agent, Turn off the oven before cleaning. Do - pour into the container tray and leave not begin cleaning until the oven has for 10-15 minutes,... - Page 35 CLEANING AND MAINTENANCE ● Ovens marked with the letter D are equ- ipped with easily removable wire shelf supports. To remove them for washing, undo the catch on the front (Z1), then pull the support and remove from the rear catch (Z2). After cleaning the supports, place them in the catch (T2) and fasten catch (Z1).
- Page 36 CLEANING AND MAINTENANCE Replacing halogen lighting in the oven 1.Disconnect power from oven 2.Remove shelves and trays from the oven. 3.Using a cross-head screwdriver remove Before replacing the halogen bulb, make the four screws holding the lamp cover, re- sure the appliance is disconnected from move the cover and the seal, wash clean electric mains to avoid possible electric mindful of wiping the cover dry.
-
Page 37: Door Removal
CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Using a flat screwdriver unhook the up- per door slat, prying it gently on the sides In order to obtain easier access to the oven (fig. B). chamber for cleaning, it is possible to remove 2. Pull the upper door slat loose. (fig. B, C) the door. - Page 38 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat Regular inspections (in the lower section of the door). Re- move the inner panel (fig. D). Besides keeping the oven clean, you 4. Clean the panel with warm water with should: some cleaning agent added. ● carry out periodic inspections of the con- Carry out the same in reverse order to trol elements and cooking units of the...
- Page 39 OPERATION IN CASE Of EMERGENCY In the event of an emergency, you should: switch off all working units of the oven disconnect the mains plug call the service centre some minor faults can be fixed by referring to the instructions given in the table below. Before calling the customer support centre or the service centre check the following points that are presented in the table.
-
Page 40: Technical Data
TECHNICAL DATA Electrical supply 220-240V ~50Hz Maximum load 3,1 kW Oven: bottom heater 1,1 kW top heater 0,9 kW grill 2,0 kW ultra-fan 2,0 kW Usable capacity of the oven* 65-72 litres Energy rating on the energy label Cooker dimensions H/W/D 59,5 / 59,5 / 57,5 cm Weight approx. - Page 44 Service Help Line 0844 815 8880 For the UK: please call 0818 46 46 46 For Ireland: please call...
