Table of contents 1. IMPORTANT SAFETY INSTRUCTIONS ....1 5. PHONEBOOK ............17 Store a phonebook entry ..........17 2. SETTING UP THE TELEPHONE ........2 Review the phonebook ..........18 Package contents ............2 Alphabetical search ............. 18 Location ................. 2 Dial a phonebook entry..........19 Connecting the telephone..........
Page 3
Table of contents 8. PERSONAL SETTINGS..........26 Set date and time............26 8.1.1 Set the time format ........27 8.1.2 Set the date format ........27 Setup Handset ............. 27 8.2.1 Ringer volume..........27 8.2.2 Ringer tone ..........28 8.2.3 Alert tones............ 28 8.2.4 Set the dial mode.........
13. Please note the correct polarity while inserting the battery pack. 14. Do not immerse battery pack in water, do not place in fire. If you have questions about this product, or having difficulty with setup or operation, call our VTech Electronics (HK) Ltd. Customer Service Centre Tel: 852-2776 3223...
SETTING UP THE TELEPHONE Package contents The package contains the following items: ・ ・ 1 Handset 1 Rechargeable battery pack ・ ・ 1 Base station 1 English operation manual ・ ・ 1 AC power adapter 1 Chinese operation manual ・ 2 Telephone line cords Location For maximum coverage and reduce the interference, here are some guidelines you should consider when you place the base unit,...
4. Always use the cables provided in the box. Telephone Telephone base line cord power adapter Telephone Wall outlet not controlled wall jack by a wall switch Installing and charging the battery pack 1. Slide out the battery compartment cover. 2.
Page 7
NOTES: • Use only the supplied NiMH rechargeable battery pack. • If the handset will not be used for a long time, disconnect and remove the battery pack to prevent possible leakage.
GETTING TO KNOW YOUR PHONE Overview of your handset 1. Earpiece In phonebook entry name editing mode: press to 2. Mute / Remove toggle between uppercase and lower case. During a call: press to mute / unmute the In phonebook entry view mode: press to view the microphone.
Handset LCD display On when speaker phone is in use. Full battery power level. Off when speaker is off. 2/3 battery power level. On when ringers are volume off. Off when ringers are not volume off. 1/3 battery power level. Indicates when new call is received.
Overview of the base PAGE CHARGING LED Touch to page all registered handsets. Steadily On: when the handset is put into base cradle for charging. IN USE LED Flashes when there is an incoming call. Steadily on when the handset is in use. Paging Paging is useful if you misplace your handset(s).
Menu map Navigating the menus 1. Press < > 2. Press to scroll through the menu. 3. Press to open a sub-menu or validate an option. 4. Press to go back to previous menu level or cancel an action.
Page 12
Menu map PHONEBOOK REVIEW STORE ENTER NUMBER ENTER NAME CALL LOG REVIEW DEL ALL CALLS DELETE ALL CALLS? RINGER VOLUME Level 0 to Level 6 RINGER TONE Ringer 1 to Ringer 10 TONES KEY TONE BATTERY LOW OUT OF RANGE REGISTER HS SYSTEM PIN: DE-REGISTER HS...
Keystroke Table The following tables show you where each letter and punctuation character can be found. This will be helpful when storing a name in the phonebook. In editing mode, a cursor is displayed to indicate the current text entry position. It is positioned at the right of the last character entered. Writing Tips: 1.
Page 14
Lower case [Space] 1 @ _ # = < > ( ) & £ $ ¥ € [ ] { } ¤ a b c 2 d e f 3 g h i 4 j k l 5 m n o 6 p q r s 7 t u v 8 w x y z 9...
USING THE PHONE Calls 4.1.1 Make a call Press , and then enter the telephone number. 4.1.2 Predial a call 1. Enter the telephone number. Press to make corrections when entering the phone number. Press and hold to insert a dialing pause (a P appears). 2.
4.1.7 Call from the phonebook < < > Press to access the phonebook from idle mode. Press to select a displayed number from the phonebook, and then press to dial. 4.1.8 Call from the call list > < > Press to access the call list from idle mode.
4.1.12 Temporary ringer silencing Press to silence the ringer temporarily when the telephone is ringing. This will silence the ringer without disconnecting the call. The next incoming call will ring normally at the preset volume. NOTE: Each handset will ring when there is an incoming call unless the ringer volume is turned off. Pressing on one handset will only silence the ringer of that particular handset.
Last number redial (redial list) Press to display and dial the most recently dialed number. If you press again within two seconds, the number will not be dialed. NOTES: • You cannot edit a phonebook entry while you are on a call. •...
Page 19
Share an outside call You can call another system handset to join an outside call. That call continues even if you hang up. 1. During a call, press . The other handset rings. The outside call is put on hold. •...
PHONEBOOK The phonebook can store up to 50 entries with up to 30 digits for each phone number and 15 characters for each name. • Phonebook entries are shared by all system handsets. Any additions, deletions or edits made on one handset affect the phonebook on all handsets.
6. Use the dialing keys to enter the name. • Press to backspace and erase a character. • Press and hold to erase the entire entry. < > • Press to move the cursor to the left or to the right. 7.
Dial a phonebook entry < 1. Press when the handset is not in use. Press when the handset is not in use. < > Press to select >PHONEBOOK and then press twice. < > 2. Press , or use the alphabetical search to browse. 3.
6. Use the dialing keys to edit the name. • Press to backspace and erase a character. • Press and hold to erase the entire entry. < > • Press to move the cursor to the left or to the right. 7.
CALLER ID This product supports caller ID services provided by most local telephone service companies. Depending on your service subscription, you may see the caller's number, or the caller's name and number that are sent by the telephone company after the first or second ring. Caller ID allows you to see the name, number, date and time of calls.
Missed calls indicator When there are unreviewed calls in the call log, the handset shows XX MISSED CALL(S). Each time you review a call log entry marked with icon, the number of missed calls decreases by one. When you have reviewed all the missed calls, the missed calls indicator no longer shows. Review the call log >...
3. Use the dialing keys to edit the number. • Press to backspace and erase a digit. • Press and hold to erase the entire entry. > < • Press to move the cursor to the left or to the right. •...
Call log display screen messages PRIVATE NAME The caller is blocking the name. PRIVATE NUMBER The caller is blocking the telephone number. PRIVATE CALLER The caller is blocking the name and number. UNKNOWN NAME This caller's name is unavailable. UNKNOWN NUMBER This caller's number is unavailable.
REDIAL LIST The telephone stores the 5 most recently dialed numbers. • When there are already five entries, the oldest entry is deleted to make room for the new entry. • Entries are shown in reverse chronological order. • Press to browse the redial list.
PERSONAL SETTINGS Using the feature menu, you can customize many of the telephone's settings. 1. Press when in idle mode (when the phone is not in use) to enter the feature menu. < > 2. Use to scroll to the feature to be changed. When scrolling through the menu, the top menu item is always highlighted with a > symbol.
8.1.1 Set the time format 1. Press when in idle mode to enter the feature menu. < > 2. Press to scroll to >TIME FORMAT. < > 3. Press to select 12-HR or 24-HR. 4. Press to save. 8.1.2 Set the date format 1.
8.2.2 Ringer tone You can select different ringer tones. 1. Press when in idle mode to enter the feature menu. < > 2. Press to select >RINGER TONE. < > 3. Press to select the desired ringer tone. A sample of each ringer tone plays as you scroll through the choices. 4.
8.2.5 Set the flash time The default flash time is suitable for your country and network operator. It is unlikely that you should need to change this setting unless advised to do so. 1. Press when in idle mode to enter the feature menu. <...
NOTES: • Telephone company voicemail may alert you to new messages with stutter (broken) dial tone. Contact your telephone company for more details. • For information about using your voicemail service, contact your telephone company for assistance. 8.2.7 Change system PIN 1.
REGISTRATION Your new telephone system can accommodate up to 12 handsets. You can add new handsets to your telephone system, but each device must be registered with the telephone base before use. Register a handset 1. Press when in idle mode to enter the feature menu. <...
Page 35
5. Press , and display will show DE-REGISTER? 6. Press to confirm. Display will show DE-REGISTERED if it is successful. NOTE: You cannot de-register a handset if any other system handset is in use.
10. DEFAULT SETTINGS Items Default Values Ringer tone Melody 2 Ringer volume Volume 3 Key beep Low battery tone Out of range tone Dial mode TONE Flash time LONG Time format 24-HR Date format DD/MM/YY System PIN 0000...
11 HELP My telephone does not work at all. • Make sure the battery pack is installed and charged correctly. For optimum daily performance, return the handset to the telephone base or charger after use. • Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch. •...
Page 38
Please contact the technical support of the network provider for further information. This telephone is not equipped with a grounding function! Therefore some of the functions may be limited when used in PBX systems. For technical support, please call VTech Technical Inquiry Hotline Tel: 852-2667 7433.
12. TECHNICAL SPECIFICATIONS Basic Information Dimensions Handset: 168.2 x 45.0 x 27.3mm Base: 153.6 x 101.3 x 102.8mm Weight Handset: 108.5g Base: 169.8g Power consumption Base: 23dBm Valid range Indoor: 50m Outdoor: 300m Handset Operating Time Standby time: 100 hours Talk time: 8 hours RF Parameter Transmission Power...
Page 40
Customer Service Centre Suite 1601, Lever Tech Centre, 69-71 King Yip Street, Kwun Tong, Kowloon, Hong Kong. Customer Service Hotline: (852) 2666 5558 Technical Inquiry Hotline: (852) 2667 7433...
