Summary of Contents for Sharp LC-32LE340E

Page 1 COLOUR TELEVISION DVB-T / DVB-C (HDTV), PAL / SECAM SYSTEM COLOUR TELEVISION B/G, I B/G, D/K, L/L’ 31.5mm 17MB70 CHASSIS MODEL 25mm LC-32LE340E LC-40LE340E LC-32LE340EV 20mm LC-40LE340EV LC-32LE340RU LC-40LE340RU LC-32LE343E LC-40LE343E In the interests of user safety (required by safety...
Page 2: Table Of Contents
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 TABLE OF CONTENTS SPECIFICATIONS ........................4 IMPORTANT SERVICE SAFETY PRECAUTIONS ..............6 OPERATION MANUAL ......................9 DIMENSIONS ..........................18 INTRODUCTION ........................20 TUNER ............................22 AUDIO AMPLIFIER STAGES ..................... 24 A.. MAIN AMPLIFIER ......................24 B. LINE-OUT and HEAD-PHONE AMPLIFIER STAGE (CS3813N) ........27 C.
Page 3 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 20. SERVICE MENU SETTING ......................75 21. GENERAL BLOCK DIAGRAM ....................81 22. OVERALL WIRING DIAGRAM ....................82 23. SCHEMATIC DIAGRAMS ......................84 24. PRINTED WIRING BOARD ....................... 101 25. REPLACEMENT PARTS LISTING .................... 103 26. CABINET MECHANICAL PARTS LISTING ................135...
Page 4: Specifications
• As a part of our policy of continuous im- English - 53 - provement, SHARP reserves the right to • When the unit is used in a low temperature space (e.g. room, offi ce), the make design and specifi cation changes picture may leave trails or appear slightly delayed.
Page 5 • As a part of our policy of continuous im- English - 53 - provement, SHARP reserves the right to • When the unit is used in a low temperature space (e.g. room, offi ce), the make design and specifi cation changes picture may leave trails or appear slightly delayed.
Page 6: Important Service Safety Precaution
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING 1. For continued safety, no modification of any circuit should be attempted. 2.
Page 7 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRECAUTIONS FOR USING LEAD-FREE SOLDER 1 Using lead-free wire solder When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause damage or accident due to cracks. As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40°C, we recommend you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Page 8: End Of Life Disposal
If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.
Page 9: Operation Manual
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 OPERATION MANUAL Remote Control Buttons Acti vate Portal mode (*) Play (in Media Browser mode) Programme recording Fast rewind (in Media Browser mode) No function Mono/Stereo - Dual I-II / Current Language / Play preview (in Media Browser mode) Image size Teletext / Mix Electronic Programme Guide...
Page 10: Lcd Tv And Operating Buttons
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) LCD TV and Operating Buttons FRONT and REAR VIEW Control buttons VIEW Control Buttons 1. Standby/On button 2. TV/AV button 3. Programme Up/Down buttons 4. Volume Up/Down buttons N o t e : P r e s s “...
Page 11 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) RF Input connects to an aerial or cable antenna system. Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device to the television with an appropriate antenna cable, as shown in the illustration in the following pages.
Page 12: Antenna Connection
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) USB Disk Connection Antenna Connection • Plug your USB device to the USB input of the TV. Aerial/Cable Connection Note: Plug or unplug your USB disk while the TV is • Connect the aerial or cable TV plug to the AERIAL switched off.
Page 13: Side Hdmi Connection
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) • Recorded programmes are stored in the following Side HDMI Connection directory of the connected USB disk: \DVR\RECS. You can use side HDMI input to connect a device that All recordings are indicated with a number. A text has an HDMI connector to your TV.
Page 14: Connecting To A Dvd Player
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) Connecting to a DVD Player Using Side AV Connectors If you want to connect a DVD player to your LCD You can connect a range of optional equipment to your TV, you can use connectors of the TV set. DVD LCD TV using side connectors of the TV.
Page 15: Connecting To A Wired Network
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) Connecting to a Wired Network For connecting to a wired LAN network, you should perform the following steps: • Connect broadband ISP connection ethernet cable to the ETHERNET INPUT of your modem. • Ensure that Nero Media Home software is installed to your PC.(for DLNA function).
Page 16 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) Connecting to a Wireless Network (Optional) IMPORTANT: “Veezy 100” USB dongle(sold separately) is required to use wireless network feature. To use your TV with your wireless network, you need a “Veezy 100” Wireless USB dongle. To make your modem’...
Page 17: Remote Control Handset
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Operation Manual (Continued) Note: When the TV is switched to standby mode, Remote Control Handset standby LED can blink to indicate that features such Inserting Batteries as Standby Search, Over Air Download or Timer is active. The LED can also blink when you switch on •...
Page 18: Dimensions
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 DIMENSIONS LC-32LE340E/EV/RU LC32LE343E Models Dimensional Drawings • Speciﬁ cations TV BROADCASTING iii. A PAL/SECAM B/G D/K K’ I/I’ L/L’ • RECEIVING CHANNELS VHF (BAND I/III) • UHF (BAND U) HYPERBAND NUMBER OF PRESET CHANNELS Tran 10.000 CHANNEL INDICATOR i.
Page 19: Dimensional Drawings
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 LC-40LE340E/EV/RU LC40LE343E Models Dimensional Drawings • Speciﬁ cations TV BROADCASTING PAL/SECAM B/G D/K K’ I/I’ L/L’ • RECEIVING CHANNELS VHF (BAND I/III) • UHF (BAND U) HYPERBAND NUMBER OF PRESET CHANNELS 10.000 CHANNEL INDICATOR On Screen Display RF AERIAL INPUT 75 Ohm (unbalanced) OPERATING VOLTAGE...
Page 20: Introduction
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 INTRODUCTION 1. INTRODUCTION 17MB70-2 mainboard is based on Broadcom concept IC. This IC combines DVB-T COFDM terrestrial and PAL/SECAM demodulators, HDMI receivers, a transport processor, a digital audio processor, graphics processing, Ethernet MAC and PHY, digital processing of analog video and audio, analog video digitizer and DAC functions, stereo high-fidelity audio DACs, a 400-MHz dual-threaded MIP processor, and a peripheral control unit providing a variety of television control functions.
Page 21: Tuner
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Sound system output is supplying 2x8W (10%THD) for stereo 8 speakers Supported peripherals are: 1 RF input VHF I, VHF III, UHF @ 75Ohm(Common) 1 Side AV (CVBS, R/L_Audio) 2 SCART socket(Common) 1 YPbPr (Common) 1 Side S-Video(Common) 1 PC input(Common) 4 HDMI 1.3 input(Common) 1 Common interface(Common)
Page 22: Circuit Descriptions
2 USB(Common) 1 Bluray/DVD(Optional) LC-32LE340/343 LC-32LE340/343 1 Ethernet-RJ45 (Common) LC-40LE340/343 LC-40LE340/343 1 External Touchpad(Common) CIRCUIT DESCRIPTIONS 2. TUNER 2. TUNER FT 2112/3/8/9 are newly developed Half-NIM modules designed for both digital (DVB-T / T2 and DTMB for terrestrial China) and analog TV reception in compliance with the European ATV standards for analogue, as well as with the terrestrial standard ETS 300 744 for DVB-T and the new terrestrial standard ETS 302 755 for DVB-T2.
Page 23: Audio Amplifier Stages
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Active Antenna Circuit 2.1 Features of FT 2112 1.1. Features of FT2112 • Digital DVB-T T2, DTMB & analogue (48.25MHz to 863.25MHz) reception • Single 5V supply voltage only • Built-in 5-33V DC-DC converter • Single power supply to the RF tuner & IF VGA amplifier section •...
Page 24: Main Amplifier
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 3. AUDIO AMPLIFIER STAGES A. MAIN AMPLIFIER (TPA3110) a. General Description 17MB70 uses TPA 3110 15-W filter-free stereo Class-D audio power amplifier for main audio output. The TPA3110D2 is a 15-W (per channel) efficient, Class-D audio power amplifier for driving bridged-tied stereo speakers.
Page 25 • SpeakerGuard™ Speaker Protection Includes Adjustable Power Limiter plus DC Protection LC-32LE340/343 • Flow Through Pin Out Facilitates Easy Board Layout LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 • Robust Pin-to-Pin Short Circuit Protection and Thermal Protection with Auto Recovery Option • Excellent THD+N / Pop-Free Performance •...
Page 26 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 e. Pin Functions I/O/P DESCRIPTION Number NAME Shutdown logic input for audio amp (LOW = outputs Hi-Z, HIGH = outputs enabled). TTL logic levels with compliance to AVCC. Open drain output used to display short circuit or dc detect fault status. Voltage compliant to AVCC.
Page 27 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 B. LINE-OUT and HEAD-PHONE AMPLIFIER STAGE (CXA3813N) a. Functional Block Diagram b. Absolute Ratings c. Recommended Operating Conditions...
Page 28: Subwoofer Amplifier Stage (Tpa3112)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 d. Pin Functions C. SUBWOOFER AMPLIFIER STAGE (TPA3112) a. General Description The TPA3112D1 is a 25-W efficient, Class-D audio power amplifier for driving a bridge tied speaker. Advanced EMI Suppression Technology enables the use of inexpensive ferrite bead filters at the outputs while meeting EMC requirements.
Page 29 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 c. Absolute Ratings d. Recommended Operating Conditions e. Pin Functions...
Page 30: Power Stage
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 4. POWER STAGE 17MB70 general power managment block diagram is shown below. 17PW26 power board is used in 32” 17MB70 TV sets. 3,3V stby, 5V stby, 3,3V, 5V, 12V, 24V and 33V can be generated by PW26.
Page 31 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Power Blocks on MB70: Below blocks are generated by step-downs and regulators on MB70 board.
Page 32 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 FAIRCHILD FAN2110 (U19-U20) a) General Description...
Page 33: Pin Configuration
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Pin Configuration Figure 3. MLP 5x6mm Pin Configuration (Bottom View) Pin Definitions Pin # Name Description Switching Node. Junction of high-side and low-side MOSFETs. P1, 6-12 Power Input Voltage. Connect to the main input power source. P2, 2-5 Power Ground.
Page 34 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Absolute Maximum Ratings Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability.
Page 35 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown. An adjustable soft-start reduces the stress on the input source at startup. In shutdown mode the regulator draws 20µA of supply current. The MP1583 requires a minimum number of external components, providing a compact solution.
Page 36 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 cycle for low dropout applications. With peak current mode control and internal compensation, the MP2012 is stable with ceramic capacitors and small inductors. Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown. MP2012 is available in the small 6-pin 3mmx3mm QFN package. 2.7-6V Input Operation Range Output Adjustable from 0.8V to VIN Up to 95% Efficiency...
Page 37: Microcontroller(Broadcom)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 5. MICROCONTROLLER(Broadcom) BCM3556 a) General Description The BCM3556 is the next generation of System-on-a-Chip (SoC) Digital Television (DTV) products from Broadcom® with 1080p60 input and output capability targetedfor the EU Market. It combines a high level of integration with best-of-class picture quality, enabling TV manufacturers to reduce overall system cost (BOM) and improve picture quality, all with a single SoC.
Page 38 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 The BCM3556 supports direct PC inputs up to UXGA 1600x1200 formats with autophase and automode detection and supports dual LVDS outputs to support 1080p60 panels. The BCM3556 integrates a 400-MHz 32-bit MIPS dual CPU with two 32-KB instructioncaches and a combined 64-KB data cache with a 128-KB L2 cache, and a 32-bit 800/1066-MHz DDR2.
Page 39 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 c) BCM3556 - Block Diagram...
Page 40: Video Back-End Processor (Trident)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 6. VIDEO BACK-END PROCESSOR (Trident) PNX5120EH a) General Description The PNX5120EH is an advanced video picture improvement IC and the world's first solution, NXP’s Motion Accurate Picture Processing (MAPP), to combine movie judder cancellation, motion sharpness and vivid color management in a single device. Aimed primarily at digital and hybrid flat panel televisions in the mid-end and high-end European,Asian and U.S.
Page 41: Fpga (Spartan-3E)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 7. FPGA (Spartan-3E) XC3S1200E 7. FPGA (Spartan-3E) a) General Description The Spartan™-3E family of Field-Programmable Gate Arrays (FPGAs) is specifically XC3S1200E designed to meet the needs of high volume, cost-sensitive consumer electronic applications. The five-member family offers densities ranging from 100,000 to 1.6 million system gates, a) General Description The Spartan-3E family builds on the success of the earlier Spartan-3 family by increasing the amount of logic per I/O, significantly reducing the cost per logic cell.
Page 42 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 The Spartan-3E family builds on the success of the earlier Spartan-3 family by increasing the amount of logic per I/O, significantly reducing the cost per logic cell. New features improve system performance and reduce the cost of configuration. These Spartan-3E enhancements, combined with advanced 90 nm process technology, deliver more functionality and bandwidth per dollar than was previously possible, setting new standards in the programmable logic industry.
Page 43: Gb F-Die Ddr2-1066 Sdram (U41-U42-U8-U9)
• Low-cost QFP and BGA packaging options - Common footprints support easy density migration LC-32LE340/343 LC-32LE340/343 - Pb-free packaging options LC-40LE340/343 LC-40LE340/343 8. 1Gb F-die DDR2-1066 SDRAM (U41-U42-U8-U9) Samsung K4T1G084QF a) Key Features • JEDEC standard VDD = 1.8V ± 0.1V Power Supply •VDDQ = 1.8V ±...
Page 44: M X 16 Bit Ddrii Synchronous Dram (U28-U29)
bus is used to convey row, column, and bank address information in a RAS/CAS LC-32LE340/343 LC-32LE340/343 multiplexing style. For example, 1Gb(x8) device receive 14/10/3 addressing. LC-40LE340/343 LC-40LE340/343 The 1Gb DDR2 device operates with a single 1.8V ± 0.1V power supply and 1.8V ± 0.1V VDDQ.
Page 45 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 9. 32M x 16 bit DDRII Synchronous DRAM (U28-U29) 9. 32M x 16bit DDRII Synchronous DRAM (U28-U29) EtronTech EM68B16CWPA a) Key Features • JEDEC Standard Compliant • JEDEC standard 1.8V I/O (SSTL_18-compatible) • Power supplies: VDD & VDDQ = +1.8V ± 0.1V •...
Page 46 dynamic random-access memory (SDRAM) containing 512 Mbits in a 16-bit wide data I/Os. LC-32LE340/343 LC-32LE340/343 It is internally configured as a quad bank DRAM, 4 banks x 8Mb addresses x 16 I/Os The The EM68B16C is a high-speed CMOS Double-Data-Rate-Two (DDR2), synchronous LC-40LE340/343 LC-40LE340/343 device is designed to comply with DDR2 DRAM key features such as posted CAS# with...
Page 47: Gbit Nand Flash Memory (U35)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 4Gbit NAND Flash Memory (U35) ST NAND04G-B2D a) Key Features – Up to 8 Gbit memory array – Up to 8 Gbit memory array – Cost-effective solution for mass storage – Cost-effective solution for mass storage applications applications face...
Page 48 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 b) Pinning...
Page 49: Mbit Nand Flas Memory (U17)
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 128Mbit NAND Flash Memory (U17) ST NAND128-A a) Key Features MEMORIES – Block erase time: 2ms (Typ) – Up to 1 Gbit memory array – Up to 32 Mbit spare area – Cost effective solutions for mass storage applications OPTION –...
Page 50 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 V SS I/O15 I/O7 I/O14 I/O7 I/O6 I/O6 I/O13 I/O5 I/O5 I/O4 I/O12 I/O4 NAND Flash NAND Flash V DD V DD V DD V DD (x8) (x16) V SS V SS V SS I/O11 I/O3 I/O3 I/O2 I/O10...
Page 51: Usb Interface
I/O0 LC-32LE340/343 LC-32LE340/343 V SS LC-40LE340/343 LC-40LE340/343 AI07585B AI07559B USB Interface USB ports are directly connected concept IC, BCM 3556. USB ciecuit has 2 main parts: Protection IC (U4) Over Curent Protection IC (U108-U109) CI Interface 17MB70 Digital CI ve Smart Card Interface Block diagram: DVB-C/T2 Demodulator Sony CXD2820R a) Key Features...
Page 52 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 DVB-C/T2 Demodulator Sony CXD2820R a) Key Features DESCRIPTION The Sony CXD2820R is a combined DVB-T2, DVB-T and DVB-C demodulator that conforms to the ETSI EN 302-755 (second generation Terrestrial) ETSI EN 300-744 (Terrestrial) and ETSI EN 300-429 (Cable) standards. The CXD2820R is a DVB-T2 demodulator offering class-leading performance, optimised BOM requiring no external memory and low processor overhead.
Page 53 • Wide symbol range, 0.7 to 7.2Msym/s • Integrated matched filter 0.15 roll-off factor LC-32LE340/343 LC-32LE340/343 • Auto Acquisition controller with fast re-acquisition mode, 15ms typ. LC-40LE340/343 LC-40LE340/343 • Programmable acquisition range ±500kHz • 2.8us echo cancellation at 7.2Msym/s • Low impl. loss 0.4dB @ 64QAM and <1.0dB @ 256QAM typ. •...
Page 54 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 c) Pinning...
Page 55 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CXD2820R Name Function Equivalent Circuit Note supply MVSS Digital Ground 5V tolerant GPIO0 General purpose I/O PVSS Analog Ground Controllable pull-up 1.2V analog power PVDD Supplies PLL power supply 2.5V analog power Supplies crystal oscillator XVDD TS error flag 5V tolerant supply...
Page 56 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CXD2820R Name Function Equivalent Circuit Note supply MVSS Digital Ground PVSS Analog Ground 1.2V analog power PVDD Supplies PLL power supply 2.5V analog power Supplies crystal oscillator XVDD supply power Leave open when external XTALO Crystal oscillator output clock input to XTALI XTALI Crystal oscillator input...
Page 57 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CXD2820R Name Function Equivalent Circuit Note Controllable pull-up TSDATA4 TS data output Selectable output current Controllable pull-up TSDATA5 TS data output Selectable output current Controllable pull-up TSDATA6 TS data output Selectable output current Controllable pull-up TSDATA7 TS data output Selectable output current Digital Ground...
Page 58 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 MSB1222( DVB-C/T Demodulator) The MSB1222 contains a superior COFDM demodulator that is Nordig Unified 1.0.3/2.0, D-Book5.0, E-Book, DVB-T compliant. It can be used in all 2K, 4K and 8K modes with 5, 6, 7 and 8 MHz channels and is capable of receiving all modes of transmission.
Page 59: Low Power&Cec Microcontroller
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 LOW POWER&CEC MICROCONTROLLER NEC uPD78F0503 Pinning...
Page 60: Hdmi Switch
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CEC Circuit Design for CEC option: CEC Circuit Design for CEC option: 3V3_STBY 3V3_STBY R1008 R1008 3V3_STBY 3V3_STBY R1001 R1001 C924 U115 C924 LM358D U115 1 OUT1 LM358D 3V3_STBY UC_CEC IN1- OUT2 1 OUT1 3V3_STBY IN1+ IN2- UC_CEC IN1-...
Page 61 Block Diagram LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 b) Block Diagram...
Page 62 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Figure 8. Pin Diagram...
Page 63 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Pin Name Description R0X0P TMDS Input TMDS input Port 0 data pair for HDMI and MHL. R0X0N R0X1P TMDS Input TMDS input Port 0 data pairs for HDMI. R0X1N R0X2P R0X2N R0XCP TMDS Input TMDS input Port 0 clock pair for HDMI and MHL. R0XCN R1X0P TMDS...
Page 64 Signal Name Type Description TX0P TMDS Output HDMI Output Port Data. LC-32LE340/343 LC-32LE340/343 TMDS Low Voltage Differential Signal output data pairs. TX0N LC-40LE340/343 LC-40LE340/343 TX1P TX1N TX2P TX2N TXCP TMDS Output HDMI Output Port Clock. TMDS Low Voltage Differential Signal output clock pair. TXCN Pin Name Type...
Page 65 from the asserted state to the de-asserted state. After completion of POR, this pin is used as the TPWR output, indicating that the selected HDMI input LC-32LE340/343 LC-32LE340/343 port is receiving an active TMDS clock. This pin has an internal pull-up to LC-40LE340/343 LC-40LE340/343 the MICOMVCC33 power supply.
Page 66: Lnb Supply Ans Control Ic
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 LNB supply and control IC ST LNBH23L a) Key Features -in DC-DC converter for single 12 V supply operation and high efficiency (typ. 93% @0.5 A) pecification -in 22 kHz tone generator suits widely accepted standards -drop post regulator and high efficiency step-up PWM with integrated power NMOS allow low power losses -temperature internal protections with I²C diagnostic bits...
Page 67: Main Sw Update
5. Please choose “USB Operations” tab to update standby-micro sw file by using remote controler. 6. Please wait approximately for 30 seconds To reach the latest sw files please use; https://www.vestelservice.com/100359/New_Projects/Sharp/Sharp_2011/9_Customer _support/SW/ Troubleshooting A. No Backlight Problem Problem: If TV is working, led is normal and there is no picture and backlight on the panel.
Page 68: Troubleshooting
_support/SW/ LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 TROUBLESHOOTING Troubleshooting Troubleshooting A. No Backlight Problem Problem: If TV is working, led is normal and there is no picture and backlight on the panel Problem: If TV is working, led is normal and there is no picture and backlight on the panel. Possible causes: Backlight pin, dimming pin, backlight supply, stby on/ off pin.
Page 69 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Dimming pin sholud be high or square wave in open position. If it is low, please check S32 fo BRCM side and pnael or power cables, connectors. STBY_ON/OFF_NOT should be high for standby condition, please check R203. B.
Page 70: B. Ci Module Problem
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 B. CI Module Problem CI supply should be 5V when CI module inserted. If it is not 5V please check Problem: CI is not Working when CI module inserted CI_PWR_CTRL, this pin should be low. Problem: CI is not working when CI module inserted. Possible causes: Supply, supply control pin, detect pins, mechanical position of pins ●...
Page 71: Staying In Stand-By Mode
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 C. Staying in Stand-by Mode Problem: Staying in stand-by mode, no other operation This problem indicates a short on Vcc voltages. Protect pin should be logic high while normal operation. When there is a short circuit protect pin will be logic low. If you detect logic low on protect pin, unplug the TV set and control voltage points with a multimeter to find the shorted voltage to ground.
Page 72: Ir Problem
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 D. IR Problem Problem: LED OR IR not working Problem: LED or IR not working Check LED card supply on MB70 chasis Check LED card supply on MB70 chasis. E. Keypad Touchpad Problems E. Keypad Touchpad Problems Problem: Keypad or Touchpad is not working Problem: Keypad or Touchpad is not working Check keypad supply on MB70.
Page 73: Usb Problems
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 F. USB Problems Problem: USB is not working or no USB Detection. Check USB Supply, It should be nearly 5V. Also USB Enable should be logic high. G. No Sound Problem Problem: No audio at main TV speaker outputs. Check supply voltages of VDD_AUDIO, 8V_VCC and 12V_VCC with a voltage-meter.
Page 74: No Signal Problem
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 to check SW printouts via Teraterm. These printouts may give a clue about the problem. You can use Scart-1 for terraterm connection. I. No Signal Problem Problem: No signal in TV mode. Check tuner supply voltage; 5V_TUN. Check tuner options are correctly set in Service menu. Check AGC voltage at RF_AGC pin of tuner.
Page 75: Service Menu Setting
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 SERVICE MENU SETTINGS Service Menu Settings In order to reach service menu, First Press “MENU” buton, then write “4725” by uisng remote controller. You can see the service menu main screen below. You can check SW releases by using this menu.
Page 76 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Video Settings Audio Settings...
Page 77 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Options-1 Menu Options-2 Menu...
Page 78 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Tuner Settings Menu Source Settings Menu...
Page 79: General Block Diagram
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Diagnostic Menu General Block Diagram...
Page 80 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 NOTES:...
Page 81 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 BLOCK DIAGRAM General Block Diagram TUNER_CVBS Sc1_CVBS_OUT QSS_SW Sc1_CVBS_IN 4 HDMI 5V_VCC 5V_VCC Sc1_R_IN ST2042 ST2042 Sc1_G_IN USB Power USB Power Sc1_B_IN Supply Switch Supply Switch Sc1_FB_IN SC1 Pin8 LC-32LE340/343 SCART1 Scart1 L/R In LM358D AZ099-4S AZ099-4S LC-40LE340/343 TPWR...
Page 82: Overall Wiring Diagram
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 OVERALL WIRING DIAGRAM MB70 / PW07 OVERALL WIRING DIAGRAM 22. LC32LE340E/EV/RU - LC32LE343E Overall Wiring Diagram LC 32LE 340E & LC 32LE 340E V MODE L LC 32LE 340R U & LC 32LE 341S LC 32LE 341E K & LC 32LE 343E MB 70 MAIN B O AR D P ANE L INV E R T E R B OAR D...
Page 83 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 MB70 / PW07 OVERALL WIRING DIAGRAM LC40LE340E/EV/RU - LC40LE343E Overall Wiring Diagram LC 40LE 340E & LC 40LE 340E V MODE L LC 40LE 340R U & LC 40LE 341S LC 40LE 341E K & LC 40LE 343E MAIN B O AR D MB 70 LC-32LE340/343...
Page 84: Schematic Diagrams
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 23. SCHEMATIC DIAGRAMS HDMI1- USB - ETHERNET & KEYBOARD Schematic Diagram HDMI (SIL9287) HDMI_TX2P HDMI_RX_0_DATA2_P TP253 PW_KEYBOARD HDMI_TX2N HDMI_RX_0_DATA2_N 3V3_STBY 12V_VCC 330R KEYBOARD HDMI_TX1P HDMI_RX_0_DATA1_P TOUCH_PAD_OPTION HDMI_TX1N HDMI_RX_0_DATA1_N 24V_VCC 330R 3V3_STBY HDMI_TX0P HDMI_RX_0_DATA0_P C579 HDMI_TX0N HDMI_RX_0_DATA0_N HDMI_TXCP HDMI_RX_0_CLK_P STBY_ON/OFF...
Page 85 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CI AND NAND FLASH & PANEL_SW & DIM Schematic Diagram NAND FLASH 330R NAND_3V3 3V3_VCC 3V3_VCC NAND_WPZ C137 C239 NC29 5V_VCC 100n 330p NC28 F139 5V_VCC CI_PWR 330R NC27 C290 C242 LC-32LE340/343 220u 100n NC26 R172 LC-40LE340/343 NAND_DATA_0 NAND_DATA_7...
Page 86 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 RAM Interface Schematic Diagram DDR_VTT R929 DDR_VTT R547 DDR01_A00 DDR01_A00 DDR01A12 DDR01_A01 DDR01_A01 DDR01A03 DDR01A12 DDR01_A03 DDR01_A02 DDR01_A02 DDR01A00 DDR0_DQ14 DDR01A07 DDR01_A03 DDR01_A03 DDR01BA2 DDR01A07 DDR01_BA2 DDR01A01 DDR0_DQ10 DDR01A00 DDR0_DQ07 DDR01A02 DDR0_DQ11 DDR01A09 DDR0_A04 DDR01BA0 DDR01A03 DDR0_A04 DDR01_BA0 DDR01A01...
Page 87 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 HDMI ( SIL 9287 ) & MAIN POWER Schematic Diagram R139 POWER SOCKET 3V3_VCC TP236 3V3_VCC HDMI_3V3 LM1117 C558 HDMISW_SDA 100n 100n 3V3_STBY A/D DIMMING SELECTION 4V2_STBY CN29 C117 C116 VOUT R186 S105 3V3_STBY C321 4V2_STBY LC-32LE340/343 C252 HDMISW_SCL...
Page 88 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 BCM POWER / GND Schematic Diagram 3V3_AGC U114 5V_TUN_RF_AGC AH27 AGC_VDDO LM1117 F191 AB11 A_2V5 AUDMX_AVSS0 3V3_AGC AA11 5V_TUN A_2V5 AUDMX_AVSS1 330R C914 C264 C251 VOUT AUDMX_AVDD2P5 AUDMX_AVSS2 AUDMX_LDO_CAP AUDMX_AVSS3 AA10 AUDMX_AVSS4 AF23 AB10 AUD_AVDD2P5_0 AUDMX_AVSS5 AE22 AB21 AUD_AVDD2P5_1...
Page 89 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 TUNER & AV & PERIPHERALS Schematic Diagram R333 R338 C302 100n 100n Near Tuner LM1117 100n VGA_G_IN SD_G SD_INCM_G R917 supply pin C303 100n 5V_TUN R339 SD_B SD_INCM_B 8V_VCC VGA_B_IN C512 100n AD10 AC10 330R C693 C320 R337 SD_R...
Page 90 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 AUDIO AMP Schematic Diagram S101 12V_VCC S172 HEADPHONE AMPLIFIER S104 24V_VCC VDD_AUDIO SK24 C521 C705 S108 18V_VCC 100u 100u F112 VDD_AUDIO PIN2 C655 C945 PIN2 F187 S138 HP_L_O S165 S140 F188 S139 L_AUDIO_P C665 HP_R_O C935 C934 C479 C478...
Page 91 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 LVDS & PIXELENCE Schematic Diagram R148 TP120 R367 TP121 R146 TX_B_0_N PIX_SDA 100R TP123 R103 CN24 R380 VDD33 R147 TX_B_0_P 100R PIX_SCL TX_B_0_N VDD33 TP122 LC-32LE340/343 TP34 TX_B_1_N TX_B_0_P LC-40LE340/343 TP42 VDD12 VCD1V2 TX_B_1_P 330R TX_B_1_N 2V5_VCC TP43 TX_B_2_N...
Page 92 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 FRC ( GPIO - PCI - VDI ) Schematic Diagram NAND_FRC_REN NAND_FRC_WEN R369 NAND_FRC_CLE PCI_AD0 PCI_CBE0 100R R370 NAND_FRC_ALE PCI_AD1 PCI_CBE1 100R 100R R371 100R PCI_AD2 PCI_CBE2 R372 3V3_VCC PCI_AD3 PCI_CBE3 R305 PCI_AD4 PCI_CLK 3V3_VCC FRC_CLK R160 PCI_AD5 PCI_DEVSEL...
Page 93 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 FRC ( DDR ) Schematic Diagram C1&C3 G1&G3 1V8_DDRFRC R485 C405 C222 C225 C223 C224 C215 C214 C217 1V8_DDRFRC 560R DDR_VREFFRC F143 330p 330p 330p 330p 330p 330p 330p 100n 100n 100n 100n 100n 100n 100n R484 1V8_VCC 1V8_DDRFRC...
Page 94 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 FRC ( VDD - VSS ) & FRC_LVDS_OUT Schematic Diagram 1V25_VCCFRC 1V25_UIP_PLL C440 C128 C109 R302 100n 100n C127 3D_SHUTTER F118 3V3_VCC 3V3_PERFRC 1V25_UIP_PLL 100n C156 100n TX_2_EN TX_B_4_N AF12 AD13 1V25_VCCFRC 1V25_XTAL TX_2_EP TX_B_4_P C428 C153 100n F119...
Page 95: Vga Input
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 AUDIO IN/OUT & PERIPHERALS _28_CLOCK_12C Schematic Diagram 30061217 CAP SMD 2.2UF 6.3V M X5R (0402) MXM ROHS C139 AUDMX_LEFT1 R615 AUDMX_LEFT1 C180 5V_VCC R599 AUDMX_INCM1 100R AUDMX_RIGHT1 SAV_AUD_L_IN AUDMX_LEFT4 AUDMX_RIGHT1 C894 C940 BAV99 LC-32LE340/343 C954 C138 100n AUDMX_LEFT2 R617...
Page 96 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 DVB S2 Schematic Diagram F149 3V3_VCC S2_3V3 220R C778 C775 C951 RESET_IC R782 R784 3V3_VCC 1N4001 C382 C348 330u JTAG_TDO RESETB V_UP VO_TX EXTM F193 VDDO_3P3_8 VDDO_3P3_3 S2_3V3 S189 VO_RX LNB_OUT SCL_S2 330R S190 VCC_L JTAG_TMS HOST_SCL S188 SDA_LNBP...
Page 97 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 DVB C & DVB T2 Schematic Diagram U104 M74HC4052 1 2Y0 RFAGCMSB1222 5V_TUN R374 2V5_AVDD 2V5_VCC IF_AGC_TUNER 3V3_IF 3V3_MSB RF_AGC_TUNER 330R 5V_IF_SUP 100R 330R 100n C260 RF_AGC IF_AGC_T2 C296 C297 C295 C240 C746 R206 R587 IF_AGC 100n 100n 100n...
Page 98 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 GPIO & LOW_PWB & LED Schematic Diagram C181 R959 F196 3V3_VCC LOW POWER+CEC MICROCONTROLLER KEYBOARD R297 U103 GPIO_00 R1031 NVM_WP R320 C932 1N4148 3V3_STBY 24C32 100n S204 3V3_VCC AMBILIGHT_SENSOR 1 E0 GPIO_01 HDMI_INT R879 3V3_STBY R311 3V3_VCC 3V3_STBY GPIO_02...
Page 99 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 FPGA Schematic Diagram R842 R829 F185 F184 TX_A_0_N_PIX TX_B_0_N_PIX 100R TX_A_0_P_PIX 100R TX_B_0_P_PIX +1V2_FPGA 2V5_VCC +2V5_FPGA 1V2_VCC R843 R822 PNX_VSYNC FPGA_VSYNC TX_A_1_N_PIX TX_B_1_N_PIX C844 100R TX_A_1_P_PIX 100R TX_B_1_P_PIX C843 220u 100n R830 R831 220u 100n C794 TX_A_2_N_PIX TX_B_2_N_PIX 100R...
Page 100 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 POWER SUPPLY Schematic Diagram S101 S109 S115 1N4148_SOD123 Q201 S120 S116 S106 S105 S103 330R D213 +400V TH102 TH104 S111 S117 L104 R143 R204 F100 D105 R142 S110 FERRITE_BEAD_FTZ_AXIAL_8x17x7 GBU4M 330R TH103 TH105 FUSE_RADIAL 275V Q101 IC101 TR200 275V...
Page 101: Printed Wiring Board
LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 24. PRINTED WIRING BOARD Main Unit Top Side LC-32LE340/343 LC-40LE340/343...
Page 102 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 Main Unit Bottom Side...
Page 103 1. MODEL NUMBER 2. REF. NO. 3. PART NO. Q107 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS DELIVERY SECTION (G: EPC SHARP GmbH) MARK * : SPARE 4. DESCRIPTION 5. CODE 6. QUANTITY 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS...
Page 104 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION F138 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS F139 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS F140 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro...
Page 105 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO CAPACITORS 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO C100 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS...
Page 106 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C305 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS C198 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C306 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS C199 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C307...
Page 107 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C529 30022236 CAP SMD 22PF 50V J COG (0402) ROHS C396 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS C530 30069320 CAP SMD 22UF 6.3V M X7R (1206) RoHS C397 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS C531...
Page 108 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C791 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS C636 30069201 CAP ELCH 22UF 16V M 105C 30mA 4x5.4 ROHS C792 30066872 CAP ELCH 220UF 6.3V M 105C 6.3x7.7 ROHS C637 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS C847...
Page 109 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R1047 30021996 RES SMD 1/16W 10K J 0402 ROHS C928 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS R1048 30022042 RES SMD 1/16W 1K J 0402 RoHS C929 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS R1049...
Page 110 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R314 30022085 RES SMD 1/16W 33R J 0402 RoHS R209 30021987 RES SMD 1/16W 4.7K J 0402 RoHS R315 30022051 RES SMD 1/16W 2.7K J 0402 ROHS R214 30021987 RES SMD 1/16W 4.7K J 0402 RoHS R316...
Page 111 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R546 30045875 RES NET 1/16W 56R J 8P 0402 ROHS 30021996 RES SMD 1/16W 10K J 0402 ROHS R547 30045875 RES NET 1/16W 56R J 8P 0402 ROHS R410 30021960 RES SMD 1/16W 47R J 0402 ROHS R549...
Page 112 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R795 30021991 RES SMD 1/16W 100R J 0402 ROHS R928 30045875 RES NET 1/16W 56R J 8P 0402 ROHS R796 30021991 RES SMD 1/16W 100R J 0402 ROHS R929 30045875 RES NET 1/16W 56R J 8P 0402 ROHS 30021996 RES SMD 1/16W 10K J 0402 ROHS...
Page 113 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION PL10 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs 30022052 RES SMD 1/16W 200R J 0402 RoHS 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs 30022132 RES SMD 1/16W 0R 0402 ROHS 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs 30022132 RES SMD 1/16W 0R 0402 ROHS 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs...
Page 114 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION Q106 30069749 TR NMOS BSH105 1.05A/20V SOT23 ROHS 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS Q107 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS Q112...
Page 115 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION F187 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro F188 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro F189 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro...
Page 116 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C100 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C164 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C101 30022334 CAP SMD 2.2NF 50V J X7R (0402) ROHS C165 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C102...
Page 117 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C311 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS C230 30066872 CAP ELCH 220UF 6.3V M 105C 6.3x7.7 ROHS C320 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS C231...
Page 118 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C396 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS C480 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS C397 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C402 30067968 CAP SMD 10UF 10V M X7R (0805) ROHS...
Page 119 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C559 30069320 CAP SMD 22UF 6.3V M X7R (1206) RoHS C653 30067969 CAP SMD 10UF 16V K X7R (0805) ROHS 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C654 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS C560...
Page 120 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C769 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS C838 30067968 CAP SMD 10UF 10V M X7R (0805) ROHS 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS C839 30067968 CAP SMD 10UF 10V M X7R (0805) ROHS C770...
Page 121 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS RESISTORS C900 30069137 CAP SMD 330NF 6.3V K X5R (0402) RoHS 30021996 RES SMD 1/16W 10K J 0402 ROHS C901 30069137 CAP SMD 330NF 6.3V K X5R (0402) RoHS 30021996 RES SMD 1/16W 10K J 0402 ROHS...
Page 122 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R136 30022051 RES SMD 1/16W 2.7K J 0402 ROHS R222 30022051 RES SMD 1/16W 2.7K J 0402 ROHS R137 30021996 RES SMD 1/16W 10K J 0402 ROHS R223 30021999 RES SMD 1/16W 10R J 0402 RoHS R138...
Page 123 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R294 30042505 RES SMD NET 1/32W 33R J 8P 0402 ROHS 30021989 RES SMD 1/16W 100K J 0402 ROHS R295 30042505 RES SMD NET 1/32W 33R J 8P 0402 ROHS R382 30022132 RES SMD 1/16W 0R 0402 ROHS R296...
Page 124 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R467 30021958 RES SMD 1/16W 47K J 0402 RoHS R567 30022049 RES SMD 1/16W 2.4K J 0402 RoHS R468 30021958 RES SMD 1/16W 47K J 0402 RoHS R568 30022024 RES SMD 1/16W 12K J 0402 ROHS R469...
Page 125 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION 30021996 RES SMD 1/16W 10K J 0402 ROHS R874 30021958 RES SMD 1/16W 47K J 0402 RoHS R800 30021987 RES SMD 1/16W 4.7K J 0402 RoHS R875 30021958 RES SMD 1/16W 47K J 0402 RoHS R802...
Page 126 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R942 30022051 RES SMD 1/16W 2.7K J 0402 ROHS S136 30022132 RES SMD 1/16W 0R 0402 ROHS R943 30050629 RES SMD 1/16W 200K F 0402 ROHS S138 30022132 RES SMD 1/16W 0R 0402 ROHS S139...
Page 127 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION IC300 30015087 IC SAFE OPTOCOUPLER TCET1102G D300 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO IC301 30063524 IC STAND-BY FSQ211 DIP8 ROHS D301 30008996 IC VREF TL431SAMF2 ADJ %1 SOT23 R IC302 30015087 IC SAFE OPTOCOUPLER TCET1102G D302...
Page 128 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C134 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS C422 30015459 CAP SMD 470NF 25V K X7R (0805) ROHS C151 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS C425 30000224 CAP SMD 220PF 50V J COG (0805) ROHS C154...
Page 129 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R227 30007021 RES SMD 1/10W 1K F 0805 ROHS R403 30000517 RES SMD 1/10W 15R J 0805 ROHS R228 30007021 RES SMD 1/10W 1K F 0805 ROHS R406 30000609 RES SMD 1/10W 2.2R J 0805 ROHS R229...
Page 130 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION J146 30002583 KISA DEVRE TELI 0.6MM TR100- 35000176 EYELET BR 2*3MM ROHS J147 30002583 KISA DEVRE TELI 0.6MM TR101 30068003 Choke Coil 150uH 3A K 20x20x10.5 RoHS J149 30002583 KISA DEVRE TELI 0.6MM TR200...
Page 131 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION D214 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS C118 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS D215 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS C120 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS C121...
Page 132 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION C407 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS R217 30012852 RES SMD 1/10W 3.9K F 0805 ROHS C408 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS R218 30058193 RES SMD 1/8W 30K F 0805 ROHS R219...
Page 133 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE PRICE CODE CODE REF No. PARTS DESCRIPTION REF No. PARTS DESCRIPTION R324 30025823 RES SMD 1/10W 15K F 0805 ROHS J134 30002583 KISA DEVRE TELI 0.6MM R325 30000668 RES SMD 1/10W 33K J 0805 ROHS J136 30002583 KISA DEVRE TELI 0.6MM J137...
Page 134 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 PRICE CODE REF No. PARTS DESCRIPTION S117 30002583 KISA DEVRE TELI 0.6MM S202 30001734 RES SMD 1/10W 0R 0805 ROHS S203 30002583 KISA DEVRE TELI 0.6MM S204 30002583 KISA DEVRE TELI 0.6MM S205 30001734 RES SMD 1/10W 0R 0805 ROHS S300 30001735 RES SMD 1/8W 0R 1206 ROHS S301...
Page 135: Cabinet Mechanical Parts Listing
30070136 PWR CORD SAFE EU 1800-70 W/GR+H 3P ROHS ( Power Cord EU) 23007323 R/C 5112 SHARP &5112 ( GRAY/S)BLACK/P)(X) ( Remote control ) 23004667 SHARP LC-32LE340E ( Owner Manual & Accesories (Batteries, YPBPr Cables,) 23006063 SHARP LC32LE340RU ( Owner Manual & Accesories (Batteries, YPBPr Cables, ) 23006053 SHARP LC32LE340EV ( Owner Manual &...
Page 136 23004293 SHARP LC-40LE340E ( Owner Manual & Accesories (Batteries, YPBPr Cables,) 23006111 SHARP LC40LE340RU (Owner Manual & Accesories (Batteries, YPBPr Cables) 23006093 SHARP LC-40LE340EV (Owner Manual & Accesories ( Batteries, YPBPr Cables, ) 23008462 SHARP LC-40LE343E (Owner Manual & Accesories ( Batteries,YPBPr Cables )
Page 137 LC-32LE340/343 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CABINET AND MECHANICAL PARTS LISTING LC-32LE340 / LC32LE343 LC-32LE340/343 LC-40LE340/343 FRONT 32942 LED(BS&SHARP/S) 20565061 LENS COSMETIC 32942 LED SILV.BRUS HST 40046849 LED IR LENS TFT XX856 (%3 MILKY) VER6. 40043424 MD.ASY.17TK124CY-XX850(V5.0 SW 20468754 SPK.AS.32930 LED(MB70(30X107X20(BL)SHARP 20565102...
Page 138 LC-32LE340/343 LC-40LE340/343 LC-40LE340/343 CABINET AND MECHANICAL PARTS LISTING LC-40LE340 / LC40LE343 Nº PARTS CODE QTY DESCRIPTION 20566988 FRONT 40942 LED(BS&SHARP/S) Front Cabinet) 40046850 LENS COSMETIC 40942 LED SILV.BRUS HST 40043424 LED IR LENS TFT XX856 (%3 MILKY) VER6. 20565404 MD.ASY.17LD98-7-37-42880(25/35(SH)RED/GR 20567124 SPK.AS.42930 LED(MB61(R/L(30X131(BL(SHA...
Page 139 Notes:...
Page 140: Sharp Corporation
LC-40LE340/343 LC-40LE340/343 125mm 100mm 80mm 63mm COPYRIGHT © 2011 BY SHARP CORPORATION 50mm ALL RIGHTS RESERVED No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical,...

This manual is also suitable for:

Lc-40le340ru Lc-40le340e Lc-32le340ev Lc-40le343e Lc-40le340ev Lc-32le343e ... Show all

Sharp LC-32LE340E Service Manual

1 Introduction

2 Tuner

3 Audio Amplifier Stages

4 Power Stage

5 Microcontroller(Broadcom)

6 VIDEO BACK-END PROCESSOR (Trident)

7 FPGA (Spartan-3E)

8 Gb F-Die DDR2-1066 SDRAM (U41-U42-U8-U9)

1000 M X 16 Bit DDRII Synchronous DRAM (U28-U29)

10 Gbit NAND Flash Memory (U35)

11 Mbit NAND Flas Memory (U17)

12 USB Interface

101 CI Interface

14 DVB-C/T2 Demodulator

15 Low Power&Cec Microcontroller

16 Hdmi Switch

17 LNB Supply Ans Control IC

18 Software Update

19 Troubleshooting

20 Service Menu Setting

21 General Block Diagram

22 Overall Wiring Diagram

23 Schematic Diagrams

24 Printed Wiring Board

25 Replacement Parts Listing

26 Cabinet Mechanical Parts Listing

Quick Links

Troubleshooting

Related Manuals for Sharp LC-32LE340E

Summary of Contents for Sharp LC-32LE340E

This manual is also suitable for:

Table of Contents
