CONTROLS AND CONNECTORS

CABLE CONNECTIONS

Turn off your computer before performing the procedure below.
1 Plug the power cable of your monitor into a nearby outlet. Plug the other
end of the power cord into the PC port.
2. Connect one end of the 15-pin VGA cable to the back of the monitor and
connect the other end to the computer's D-Sub port.
3.
Turn on your monitor and computer.
1. Power Cable
2. Signal Cable
1
Figure 2 Connecting Cables
5
2
