- Page 1 MX3Plus Hand-Held Computer Microsoft® Windows® CE 5 Operating System Cradle Reference Guide...
-
Page 2: Limited Warranty
Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII. - Page 3 Lithium Battery Safety Statement Caution: Lithium battery inside. Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by battery manufacturer. (US) Attention: Contient une pile de lithium. Risque d’explosion dans le cas où la pile ne serait pas correctement remplacée. Remplacer uniquement avec une pile semblable ou equivalente au type de pile recommandé...
- Page 4 Legend: Chinese – CN; Danish – DK; Dutch – NL; English – US; Finnish – FI; French – FR; German – DE; Greek – GR; Italian – IT; Japanese – JP; Korean – KR; Norwegian – NO; Portuguese – PT; Spanish – ES; Swedish – SE; Turkish – TR.
-
Page 5: Vehicle Power Supply Connection Safety Statement
Vehicle Power Supply Connection Safety Statement Vehicle Power Supply Connection: If the supply connection is made directly to the battery, a five A slow-blow fuse should be installed in the positive lead within 5 inches (12.7 cm.) of the battery positive (+) terminal. (US) Raccordement de l’alimentation du véhicule Si l’alimentation est raccordée directement à... -
Page 7: Table Of Contents
Connect Cables RS232 Connector Status LED Docking and Undocking the MX3Plus Maintenance Cleaning MX3Plus Desk Top Cradle/MX3Plus Power Supply, External, AC US AC to DC Adapter Specifications Worldwide AC to DC Adapter Specifications 2-10 Chapter 3: Powered Vehicle Mount Cradle Overview... - Page 8 Components and Mounting Diagram 3-22 Typical Installation 3-22 Remote Antenna Mounting Instruction 3-23 Maintenance - Vehicle Mounted Devices 3-24 Cleaning 3-24 Vehicle Cradle Port Pinout 3-25 MX3Plus Vehicle Cradle RS232 Serial / IR Port Pinout 3-25 Chapter 4: Technical Assistance...
-
Page 9: Chapter 1: Introduction
Chapter 1: Introduction The MX3Plus is a rugged, portable, hand-held computer with a Microsoft® Windows® CE 5 operating system. There are two optional cradles available for the MX3Plus: desktop cradle that secures the MX3Plus, recharges batteries and enables communications between the MX3Plus and another device. -
Page 11: Chapter 2: Desktop Cradle
MX3Plus Main Battery. The MX3Plus can be either on or off while in the cradle. Cables are available from Honeywell for connecting the cradle to a printer, a personal computer or a bar code printer. Tethered scanners (for RS232 serial port connection) are also available from Honeywell. -
Page 12: Preparing The Cradle For Use
The MX3Plus must have a main battery installed when it is docked in a cradle. The main battery in the MX3Plus is recharged when the MX3Plus is docked in a powered desktop cradle and when it is docked in a powered vehicle cradle. -
Page 13: Desk Top Cradle Footprint
Table Mounting The cradle can be mounted to a flat, stable surface using the two holes in the desktop cradle bracket (mounting hardware is not supplied by Honeywell). Periodically check the cradle connection and table connection for stability. Re-tighten as necessary. -
Page 14: Attach Desktop Bracket
Note: This cradle cannot secure the VX3X or VX3Plus mobile devices. You will need a torque wrench capable of torquing at 6±1 IN/LB when assembling the cradle bracket. Honeywell does not supply the tools (torque wrench, screwdrivers) required for assembly. -
Page 15: Assemble/Attach The Ac Power Adapter
The Power connector is located on the back of the cradle. When powered, the cradle transfers power to the internal charging circuitry of the MX3Plus allowing it to recharge the Main Battery. A powered cradle supports RS232 and IR communications. -
Page 16: Connect Cables
When the MX3Plus is properly docked, the bi-directional half-duplex transceivers in the mobile device and cradle are aligned through their IR windows. The half-duplex IR signals from the MX3Plus are converted to RS232 signals in the cradle and available at this connector. The cradle supports only the Transmit, Receive and Ground signals on this port. -
Page 17: Status Led
Status LED An indicator on the cradle shows the status of the docked MX3Plus. When the indicator is not illuminated, there is no external power source connected to the cradle. Cradle Power Orange Power applied to the cradle. -
Page 18: Docking And Undocking The Mx3Plus
Do not use paper towels or harsh-chemical-based cleaning fluids since they may result in damage to the surfaces and/or battery charging terminals (pins). Use a clean soft cloth to wipe any dirt, moisture or grease from the MX3Plus, spare battery packs, charging contacts (pins) or the cradle. -
Page 19: Mx3Plus Desk Top Cradle/Mx3Plus Power Supply, External, Ac
1. Insert the barrel connector into the desk top cradle power jack (located on the back of the cradle) and push in firmly. 2. When a docked MX3Plus is receiving power from a cradle, the cradle Status LED is green and the CHGR LED on the mobile device are illuminated. -
Page 20: Worldwide Ac To Dc Adapter Specifications
Worldwide AC to DC Adapter Specifications Feature Specification Operating Temperature 32°F to 104°F (-0°C to 40°C) Storage Temperature -13°F to 158°F (-25°C to 70°C) Operating Humidity Up to 90% non-condensing at 104°F (40°C) Input Power Switch None Power "ON" Indicator None Input Voltage 108VAC min - 264VAC max... -
Page 21: Chapter 3: Powered Vehicle Mount Cradle
Overhead, dash and roof support pillar mounting is via a RAM Mount accessory which includes all the hardware and squeeze plates required for vehicle mounting. In most cases, disconnect any power and peripheral cables from the MX3Plus before it is secured in the vehicle mounted assembly. -
Page 22: Preparing The Powered Vehicle Mounted Cradle For Use
Can be easily accessed by a user seated in the driver's seat while the vehicle is not in operation. Quick Start The following list outlines, in a general way, the process to follow when preparing the MX3Plus powered vehicle mounted cradle for use. Refer to the following sections in this document for more details. -
Page 23: Components
Components Several types of vehicle mounting assemblies are provided for the MX3Plus: U-Bracket Cradle Assembly Remote mount for external antenna Before installation begins, verify you have the applicable vehicle mounting bracket assembly components necessary for your mount type. MX3Plus Vehicle Mount Components Front of Cradle: 1. -
Page 24: Vehicle Cradle Rs232 / Ir Port Connector
Vehicle Cradle RS232 / IR Port Connector The connectors are on the back of the cradle. -
Page 25: Attach Mounting Bracket To Vehicle
There must be at least 2” clearance at the back of the bracket for the cables. Position the bracket to allow access to the ports on the back of the Vehicle Mount Cradle. Using the mounting dimensions on the following diagram, mount the bottom mounting bracket to the vehicle, using ¼” bolts (not supplied by Honeywell). Note: Mount to the most rigid surface available. - Page 26 Care must be taken to avoid bending or warping the bottom “U” shaped bracket when attaching the cradle to a lift truck or other vehicle. A bent “U” bracket can over-compress or over-extend the rubber iso- lators leading to failure of the isolators.
-
Page 27: Assemble Vehicle Cradle
Assemble Vehicle Cradle Prerequisite: Bottom Mounting Bracket is secured to the vehicle. Before installation begins, make sure you have the following Vehicle Mount Cradle assembly components: Cradle Adjusting Knobs Procedure Attach the Bottom Mounting Bracket (currently secured to the vehicle) to the Vehicle Mount Cradle with the Adjusting Knobs. Insert one Adjusting Knob in each side of the mounting assembly. -
Page 28: Assembled Vehicle Mount Cradle
Assembled Vehicle Mount Cradle Periodically test the connection of the vehicle mounted bolts and the Adjusting Knobs and retighten if necessary. -
Page 29: Power Supplies
LPS or Class 2 outputs rated 12V, minimum 1Amp. The MX3Plus must have a main battery installed before inserting the MX3Plus in a cradle. When powered, the cradle transfers power to the internal charging circuitry of the MX3Plus allowing it to recharge the main battery. -
Page 30: Input Power Specifications
Input Power Specifications Honeywell Part Number: 1300A053CBL12ML3 Feature Specification DC Input Voltage 10.8 - 16 VDC Input Current 1.25 Amps Input Fuse 5A Time Delay 3-10... -
Page 31: Vehicle Cradle 24/72 Maximum Vdc Input Cable Connection
Recommended for vehicle electrical systems that use between 2 and 5 twelve volt batteries in series. Vehicle Power Supply, 24 - 72 Maximum VDC (Fuse Not Shown) 1. Power Switch 2. Power On Indicator 3. Output to Vehicle Cradle 4. Input from Vehicle Battery Honeywell Part Number: 9000A316PS24V72MX13 (Replaces 1300A301PS24WW). 3-11... - Page 32 1. If the MX3Plus is in the cradle, it can be either On or Off during this process. 2. Turn the Power Supply toggle switch to the Off position. 3. While observing the fuse requirements specified above, connect the power cable as close as possible to the actual battery terminals of the vehicle.
-
Page 33: Vehicle Power Supply Footprint
Vehicle Power Supply Footprint Power Supply Dimensions Length: 9.25” / 23.5 cm Height: 2.5” / 6 cm Width: 4.7” / 12 cm Mounting hole center Width: 3.5” / 9 cm Length: 8.75” / 22.2 cm 3-13... -
Page 34: Vehicle Cradle External Ac Power Supply
AC source provided with maximum 15 Amp over current protection (10 Amp for 230V circuits). How To If the MX3Plus is in the cradle, it can be either On or Off during this process. Connect the detachable cord set provided by Honeywell to the external AC supply (IEC 320 connector). -
Page 35: Dc To Dc Power Supply Installation
9000302PWRSPLY – Power Supply, 60-110VDC with cable Connecting Electrical Cables to Power Sources The DC to DC power supply is used to provide vehicle power to the MX3Plus when placed in a DC powered vehicle dock. Specifications for Electrical Supply Input Voltage Always observe input voltage range specified on the DC to DC power supply. -
Page 36: Wiring Schematic
How To Connect Vehicle Electrical Connection 1. The vehicle cradle must be empty. 2. Begin by connecting the power cable to the MX3Plus's vehicle cradle. Work from this connection with the last connection being to the vehicle’s power source. 3. Route the cable from the cradle to the DC to DC converter. - Page 37 13. While observing the fuse requirements specified here, connect the power cable as close as possible to the actual battery terminals of the vehicle. When available, always connect to unswitched terminals in the vehicle fuse panel, after providing proper fusing. Note: ATTENTION: For uninterrupted power, electrical supply connections should not be made at any point after the ignition switch of the vehicle.
-
Page 38: Vehicle Cradle Led
The cradle LED is located at the front center of the cradle. When Cradle LED is … It means …. No power applied to the cradle. IR communication active. Power applied to the cradle. Orange Power applied to the cradle and connection made with the MX3Plus. Green 3-18... -
Page 39: Dock Mx3Plus In Cradle
Do not put the MX3Plus into the vehicle cradle until the cradle is securely fastened to the vehicle. The MX3Plus is inserted into the cradle by placing the base of the MX3Plus in the charging pocket and then firmly pressing the MX3Plus backwards until the release mechanisms latch and secure the MX3Plus in the cradle. -
Page 40: Remove Mx3Plus From The Vehicle Cradle
Remove MX3Plus from the Vehicle Cradle The MX3Plus is removed from the vehicle cradle by releasing the catch mechanisms next to the Scan buttons and pulling the MX3Plus up and away from the vehicle cradle. 3-20... -
Page 41: Remote Antenna Installation Kit
Tools are not included. The remote antenna base is mounted on the top of a forklift, truck or other vehicle and cabled to the MX3Plus inside the vehicle. The cable is available in different lengths and with a straight or right angle adapter on the end. -
Page 42: Components And Mounting Diagram
Components and Mounting Diagram 1. Nut 2. Washer 3. Washer 4. Mounting Plate 5. To Antenna 6. To MX3Plus Antenna Connector 7. Antenna Typical Installation 1. Antenna 2. Mounting Plate 3. Vehicle Safety Cage 4. Coaxial Cable 5. Vehicle Mounted MX3Plus... -
Page 43: Remote Antenna Mounting Instruction
If the MX3Plus requires two antennas, they must be mounted at least 12 inches (304.8mm) apart. 2. Attach the female connector of the coaxial cable to the antenna connector on the vehicle mounted MX3Plus. 3. Insert the male connector on the coaxial cable though the hole in the mounting plate. -
Page 44: Maintenance - Vehicle Mounted Devices
Use a clean soft cloth to wipe any dirt, moisture or grease from the MX3Plus, charging contacts or the vehicle mounted cradle. Do not use any liquid to clean the cradle, battery pack, MX3Plus, or charging terminals (pins). Spray or dampen the cleaning cloth with a cleaning liquid. -
Page 45: Vehicle Cradle Port Pinout
Not Connected Not Connected +5VDC +5VDC at 200mA continuous (see note below) Note: Pin 9 of this port is connected to +5 VDC and only approved Honeywell cables are to be used for communication between the cradle and external devices. 3-25... - Page 46 3-26...
-
Page 47: Chapter 4: Technical Assistance
Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;... - Page 48 The duration of the limited warranty for the MX3Plus Battery Charger is 1 year. The duration of the limited warranty for the MX3Plus 1900 Ah Li-Ion Battery is 6 months. The duration of the limited warranty for the MX3Plus AC power supply and cables is 1 year.
- Page 50 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com E-EQ-MX3PLUSOGWW Rev E 10/12...
