Panasonic CQ-C1405W Operating Instructions

Specifications
General FM Stereo Radio
Power supply : DC 12 V (11 – 16 V), test voltage Frequency range : 87.50 MHz – 108.00 MHz
14.4 V, negative ground Usable sensitivity : 6 dB/µV (S/N 30 dB)
Current consumption : Less than 2.2 A (CD mode; 0.5 W x
Frequency response : 30 Hz – 15 kHz (±3 dB)
4 channels)
Alternate channel selectivity : 75 dB
Maximum power output : 50 W x 4 channels (at 1 kHz), vol-
Stereo separation : 35 dB (1 kHz)
ume control maximum
Image rejection ratio : 75 dB
: 18 W x 4 channels (1 kHz, 1 %, 4 Ω)
Power output
IF rejection ratio : 100 dB
Tone adjustment range : Bass: ±12 dB at 100 Hz, Treble: ±12
Signal to noise ratio : 62 dB
dB at 10 kHz
Speaker impedance : 4 – 8 Ω AM Radio
Pre-amp output voltage : 2.5 V (CD mode, 1 kHz, 0 dB)
: 200 Ω
Pre-amp output impedance Frequency range : 531 kHz – 1 602 kHz
Dimensions (W x H x D) : 178 x 50 x 155 mm
Usable sensitivity : 28 dB/µV (S/N 20 dB)
Weight : 1.3 kg
Front AUX input
Input impedance : 10 kΩ
Notes:
Allowable external input : 2.0 V
¡ Specifications and design are subject to modification without
Connector : 3.5 mm ø stereo mini-pin
notice due to improvements.
Disc Player
¡
Some figures and illustrations in this manual may be different
Sampling frequency : 8 times oversampling
from your product.
DA converter : 1 bit DAC System
Pick-up type : Astigma 3-beam
Light source : Semiconductor laser
Wave length : 790 nm
Frequency response : 20 Hz – 20 kHz (±1 dB)
Signal to noise ratio : 96 dB
Total harmonic distortion : 0.01 % (1 kHz)
Wow and flutter : Below measurable limits
Channel separation : 75 dB
Accessories
Operating Instructions Installation kit (ZZBISC1101U-J) Mounting Collar
(English : YFM284C618CA) (FX0214C384ZB)
Lock Cancel Plate
(êÛÒÒÍËÈ : YFM284C619CA)
(FX0214C385ZA)
( : YFM284C620CA)
Trim Plate
Q'ty: 2
(Arabic : YFM284C498CA)
(YFC054C081ZA)
Mounting Bolt
Q'ty: 1 set
(YEJV014C002N)
Installation Instructions
Q'ty: 1 Power Connector
(YFM294C075CA)
(YGAJ021009)
Rubber Bushing
Q'ty: 1
(YFS014C095ZA)
Q'ty: 1 Removable Face Plate
Case
(YFC054C061ZB)
Notes:
¡ The number in parentheses underneath each accessory part
name is the part number for maintenance and service.
¡ Accessories and their part numbers are subject to modifica-
tion without prior notice due to improvements.
¡
Mounting Collar and Trim Plate are mounted on the main unit
at shipment.
Matsushita Electric Industrial Co., Ltd.
Web Site: http://panasonic.net
YFM284C618CA PTW1206-1106
Before Reading These Instructions
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components,
and assembled by people who are proud of the reputation their work has built for our company. We know this product will bring you many hours
of enjoyment, and after you discover the quality, value and reliability we have built into it, you too will be proud to be a member of our family.
Preparation
1
Set your car's ignition switch to the ACC or
ON position.
AC C
ON
2
Press [SRC] (PWR: Power).
The 24-hour system is used for the clock.
Clock Display at Power Off
1
Press [DISP] (CLOCK).
Press [DISP] to change the display.
(clock display)
Display off
2
Hold down [DISP] (CLOCK) for more than
2 seconds.
Hours blinks
3
Adjust the hour.
Hours set
[[]: sets the hour ahead.
[]]: sets the hour back.
4
Press [DISP] (CLOCK).
Minutes blinks
5
Adjust the minute.
Minutes set
[[]: sets the minute ahead.
[]]: sets the minute back.
6
Press [DISP] (CLOCK).
Complete
Notes:
¡ "ADJUST" is displayed before adjusting the clock.
¡ Hold down []] or [[] to change numbers rapidly.
Model:
Operating Instructions
CQ-C1405W
AUX
SQ 1 2 5 6
3 SRC / PWR 4
Q'ty: 1
Q'ty: 1
Q'ty: 1
Q'ty: 1
¡Please read these instructions carefully before using this product and keep this manual for future reference.
Printed in China
Maintenance
This unit is designed and manufactured to ensure the minimum of maintenance. Use a dry, soft cloth for routine exteri-
or cleaning. Never use benzine, thinner, or other solvents.
If the replaced fuse fails, contact your nearest authorized Panasonic Service Center.
Warning
¡ Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your nearest
authorized Panasonic Service Center.
Anti-Theft System
This unit is equipped with a removable face plate. Removing this face plate makes the unit totally inoperable.
Caution
¡ This face plate is not waterproof. Do not expose it to
¡ Do not touch the contacts on the face plate and the main
water or excessive moisture.
¡ Do not remove the face plate while driving your car.
¡ If dirt or other foreign substances get on the contacts,
¡ Do not place the face plate on the dashboard or nearby
areas where the temperature rises high.
Clock display
Removing Mounting
1 1
Turn off the power.
2
2
Press [ ]. The face plate will open.
3
Pull it out toward you.
4
Put the face plate in the case.
[ ]
Safety Information
■
Read the operating instructions for the unit and all other compo-
MP3 CD Player/Receiver
nents of your car audio system carefully before using the system.
They contain instructions about how to use the system in a safe and
CQ-C1405W
effective manner. Panasonic assumes no responsibility for any prob-
lems resulting from failure to observe the instructions given in this
manual.
This pictograph intends to alert you to the presence of
important operating instructions and installation
instructions. Failure to heed the instructions may
Warning
result in severe injury or death.
Warning
Observe the following warnings when using this
unit.
❑ The driver should neither watch the display nor operate
the system while driving.
Watching the display or operating the system will distract the driv-
er from looking ahead of the vehicle and can cause accidents.
Always stop the vehicle in a safe location and use the parking
brake before watching the display or operating the system.
❑ Use the proper power supply.
This product is designed for operation with a negative grounded
12 V DC battery system. Never operate this product with other bat-
tery systems, especially a 24 V DC battery system.
❑ Protect the Deck Mechanism.
Do not insert any foreign objects into the slot of this unit.
❑ Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the prod-
uct yourself. If the product needs to be repaired, consult your
dealer or an authorized Panasonic Servicenter.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an abnormal
state (has foreign objects in it, is exposed to water, is smoking, or
smells), turn it off immediately and consult your dealer.
❑ Refer fuse replacement to qualified service personnel.
When the fuse blows out, eliminate the cause and have it replaced
with the fuse prescribed for this unit by a qualified service engi-
neer. Incorrect replacement of the fuse may lead to smoke, fire,
and damage to the product.
Observe the following warnings when installing.
❑ Disconnect the lead from the negative (–) battery termi-
nal before installation.
Wiring and installation with the negative (–) battery terminal con-
nected may cause electrical shock and injury due to a short circuit.
Some cars equipped with the electrical safety system have specific
procedures of battery terminal disconnection.
TEXT
Notes on Discs
If you use commercial CDs, they must have
either of these labels shown at right.
Some copy-protected music CDs are not
playable.
How to hold the disc
¡ Do not touch the underside of the disc.
¡ Do not scratch on the disc.
¡ Do not bend the disc.
¡
When not in use, keep the disc in a case.
Do not leave discs in the following places:
¡ In direct sunlight
¡ Near car heaters
¡
Dirty, dusty and damp areas
¡
On seats and dashboards
Disc cleaning
Use a dry, soft cloth to wipe from the center outward.
<Correct> <Wrong>
Do not write on the disc label with a ballpoint
pen or other hard-point pens.
¡ You may have trouble playing back some CD-R/RW discs
recorded using CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints,
scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and
high humidity than ordinary music CDs. Leaving them
unit, since this may result in poor electrical contact.
inside a car for extended periods may damage them and
make playback impossible.
wipe them off with a clean and dry cloth.
¡ Some CD-R/RWs cannot be played back successfully due
to incompatibility among writing software, a CD recorder
(CD-R/RW drive) and the discs.
¡
This player cannot play the CD-R/RW discs if the session is
not closed.
Slide the left side of the face plate in place. ¡ This player cannot play the CD-R/RW discs which contain
other than CD-DA or MP3 data .
Press the right end of face plate until a
¡ Be sure to observe the instructions of the CD-R/RW disc
for handling it.
"click" is heard.
Recording MP3 files on a CD-media
¡ You are recommended to minimize the chances of mak-
ing a disc that contains both CD-DA files and MP3 files.
¡ If CD-DA files are on the same disc as MP3 files, the
songs may not play in the intended order, or some songs
may not play at all.
¡ Do not record files other than MP3 files and unnecessary
folder on a disc.
¡ The name of MP3 file should be added by rules as shown in
the following descriptions and also comply with the rules of
each file system.
■
This manual uses pictographs to show you how to use the product
safely and to alert you to potential dangers resulting from improper Caution
connections and operations. The meanings of the pictographs are
explained below. It is important that you fully understand the mean- Observe the following cautions when using this
ings of the pictographs in order to use this manual and the system
unit.
properly.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and traffic
This pictograph intends to alert you to the presence of
conditions while driving.
important operating instructions and installation instruc-
❑ This unit is designed for use exclusively in automo-
tions. Failure to heed the instructions may result in
Caution
biles.
injury or material damage.
❑ Do not operate the unit for a prolonged period with the
engine turned off.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
Operating the audio system for a long period of time with the
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM
engine turned off will drain the battery.
RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL
❑ Do not expose the unit to direct sunlight or excessive
INJURY OR DEATH.
❑ Never use safety-related components for installation, heat.
Otherwise these will raise the interior temperature of the unit,
grounding, and other such functions.
and it may lead to smoke, fire, or other damage to the unit.
Do not use safety-related vehicle components (fuel tank, brake,
❑ Do not use the product where it is exposed to water,
suspension, steering wheel, pedals, airbag, etc.) for wiring or fix-
moisture, or dust.
ing the product or its accessories.
❑ Installing the product on the air bag cover or in a location Exposure of the unit to water, moisture, or dust may lead to
where it interferes with airbag operation is prohibited. smoke, fire, or other damage to the unit. Make especially sure
❑ Check for piping, gasoline tank, electric wiring, and other that the unit does not get wet in car washes or on rainy days.
❑ Set the volume level to low enough before the AUX con-
items before installing the product.
nection is completed.
If you need to open a hole in the vehicle chassis to attach or wire
Failure to observe this, the loud noise may come out and dam-
the product, first check where the wire harness, gasoline tank, and
electric wiring are located. Then open the hole from outside if pos- age your speakers and your hearing. Direct connection of the
sible. speaker/headphone output of an external device without any
❑ Never install the product in a location where it interferes attenuator may distort sound or damage the connected external
device.
with your field of vision.
❑ Never have the power cord branched to supply other Observe the following cautions when installing.
equipment with power.
❑ Refer wiring and installation to qualified service per-
❑ After installation and wiring, you should check the nor-
sonnel.
mal operation of other electrical equipment.
Installation of this unit requires special skills and experience. For
The continuation of their using in abnormal conditions may cause
maximum safety, have it installed by your dealer. Panasonic is
fire, electrical shock or a traffic accident.
not liable for any problems resulting from your own installation
❑ In the case of installation to an airbag equipped car, con-
of the unit.
firm warnings and cautions of the vehicle manufacturer ❑ Follow the instructions to install and wire the product.
before installation.
Not following the instructions to properly install and wire the
❑ Make sure the leads do not interfere with driving or get-
product could cause an accident or fire.
❑ Take care not to damage the leads.
ting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
When wiring, take care not to damage the leads. Prevent them
from getting caught in the vehicle chassis, screws, and moving
parts such as seat rails. Do not scratch, pull, bend or twist the
leads. Do not run them near heat sources or place heavy objects
on them. If leads must be run over sharp metal edges, protect
the leads by winding them with vinyl tape or similar protection.
Notes on MP3
Note: MP3 encoding and writing software is not supplied
with this unit.
TEXT Points to remember when making MP3 files
MP3
¡
High bit rate and high sampling frequency are recom-
Printed side
mended for high quality sounds.
¡ Selecting VBR (Variable Bit Rate) is not recommended
because playing time is not displayed properly and sound
may be skipped.
¡ The playback sound quality differs depending on the
encoding circumstances. For details, refer to the user
manual of your own encoding software and writing soft-
ware.
Labels created by a printer, Irregularly shaped discs
¡ It is recommended to set the bit rate to "128 kbps or
Protective films or sheets
more" and "fixed".
Caution
Never assign the ".mp3", file name extension to
a file that is not in the MP3 format. This may
Disc with adhered Discs with cracks,
not only produce noise from the speaker dam-
stickers or tape scratches or parts missing
age, but also damage your hearing.
¡ You may encounter trouble in playing MP3 files or display-
ing the information of MP3 files recorded with certain writ-
ing software or CD recorders.
¡ The file extension ".mp3" should be assigned to each file
Display Information
depending on the file format.
¡ This unit does not have the play list function.
Displayed items
¡ Although Multi-session recording is supported, the use of
¡
CD-TEXT
Disc-at-Once is recommended.
Disc title
Supported file systems
Track title
ISO 9660 Level 1/Level 2, Apple Extension to ISO 9660, Joliet,
¡ MP3
Romeo
Folder name
Note: Apple HFS, UDF 1.50, MIX mode CD, CD Extra is not
File name
supported.
Displayable characters
Compression formats ¡ Displayable length of file name/folder name: within 32
characters. (Unicoded file and folder names are reduced
(Recommendation: "Points to remember when making
by half in the number of displayable characters.)
MP3 files" on the right.)
¡ Name files and folders in accordance with the standard of
¡
MPEG 1 audio layer 3 each file system. Refer to the instructions of writing soft-
Bit rate: 32 k – 320 kbps
ware for details.
VBR: Yes ¡
ASCII character set and special characters in each lan-
Sampling frequency: guage can be displayed.
32, 44.1, 48 kHz
Notes:
¡ MPEG 2 audio layer 3
¡ With some software in which MP3 format files have been
Bit rate: 8 k – 160 kbps
encoded, the character information may not be displayed
VBR: Yes
properly.
Sampling frequency:
¡ Undisplayable characters and symbols will be converted
16, 22.05, 24 kHz
into an asterisk (
❑ Use the designated parts and tools for installation.
Use the supplied or designated parts and appropriate tools to
install the product. The use of parts other than those supplied or
designated may result in internal damage to the unit. Faulty
installation may lead to an accident, a malfunction or fire.
❑ Do not block the air vent or the cooling plate of the unit.
Blocking these parts will cause the interior of the unit to over-
heat and will result in fire or other damage.
❑ Do not install the product where it is exposed to strong
vibrations or is unstable.
Avoid slanted or strongly curved surfaces for installation. If the
installation is not stable, the unit may fall down while driving and
this can lead to an accident or injury.
❑ Installation Angle
The product should be installed in a horizontal position with the
front end up at a convenient angle, but not more than 30˚.
The user should bear in mind that in some areas there may be
restrictions on how and where this unit must be installed.
Consult your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is com-
pleted before installation.
❑ To prevent damage to the unit, do not connect the
power connector until the whole wiring is completed.
❑ Do not connect more than one speaker to one set of
speaker leads. (except for connecting to a tweeter)
Caution
THIS PRODUCT IS A CLASS I LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Folder selection order/file playback order
Maximum number of files/folders
¡ Maximum number of files: 999
¡ Maximum number of files in one folder: 255
¡ Maximum depth of trees: 8
¡ Maximum number of folders: 255 (Root folder is includ-
ed.)
Notes:
¡
This unit counts the number of folders irrespective of the
presence or absence of an MP3 file.
¡ If the selected folder does not contain any MP3 files, the
nearest MP3 files in the order of playback will be played.
¡ Playback order may be different from other MP3 players
even if the same disc is used.
¡ "ROOT" appears when displaying the root folder name.
¡
MP3 (ID3 tag)
Album name
Title name/Artist name Copyright
It is prohibited by copyright laws to copy, distribute and
deliver copyrighted materials such as music without the
approval of copyright holder except enjoying yourself per-
sonally.
No warranty
Above description complies with our investigations as of
September 2006. It has no warranty for reproducibility and
displayability of MP3.
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
).
