Goodman TSTATG2152-2 Owner's Manual

Hide thumbs Also See for TSTATG2152-2:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual
Air Conditionin g & Heatin g
Heat Pump 5+2 Day Programmable
g
Di
ital Thermostat
Control up to 2-Heat & 1-Cool
Battery or System Powered
Backlit Digital Display
Auxiliary Heat Indicator
Fahrenheit or Celsius
Service Filter Indicator
Owner 's Manual
Thank goodness for Goodman.
Model TSTATG2152-2
TM

Advertisement

Table of Contents
loading

Related Manuals for Goodman TSTATG2152-2

Summary of Contents for Goodman TSTATG2152-2

  • Page 1 Air Conditionin g & Heatin g Heat Pump 5+2 Day Programmable ital Thermostat Control up to 2-Heat & 1-Cool Battery or System Powered Backlit Digital Display Auxiliary Heat Indicator Fahrenheit or Celsius Service Filter Indicator Owner ’s Manual Thank goodness for Goodman.
  • Page 2 OWNER'S MANUAL TSTATG2152-2 Contents Page # Safety Warnings Location of Controls Display Normal Operation Manual Operation Programmed Operation Aux Heat Clock Set Time Period Programming Overview Weekday Programming Weekend Programming Advanced Setup Advanced Features Factory Defaults Calibration Battery Replacement Warranty...

  • Page 3: Safety Warnings

    Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Copyright 2008 Goodman Manufacturing Company, LP Page 3...

  • Page 4: Location Of Controls

    OWNER'S MANUAL TSTATG2152-2 Location of Controls AUX HEAT PROGRAM SWITCH SWITCH RUN program Emergency Program OFF Normal SET program Lockout FAN SWITCH AUX HEAT On or Auto I2:00 AUTO NORM EMRGC’Y LOCKOUT PROGRAM HEAT NEXT BUTTON NEXT RUN OFF SET...
  • Page 5 OWNER'S MANUAL TSTATG2152-2 Display I2:00 Morning Evening MTuWThF SaSu FILTER Night HEAT COOL Day of the week. When programming, MTuWThF represent the five weekdays and SaSu represent the two weekend days. Heat and Cool indicators. In normal operation, Heat or Cool appears, depending on the Mode Switch position.

  • Page 6: Normal Operation

    OWNER'S MANUAL TSTATG2152-2 Normal Operation PROGRAM SWITCH RUN program Program OFF SET program AUX HEAT I2:00 FAN SWITCH AUTO NORM On or Auto EMRGC’Y LOCKOUT PROGRAM HEAT NEXT RUN OFF SET RESET FILTER COOL HEAT BATTERIES MODE SWITCH COOLER & WARMER...
  • Page 7 OWNER'S MANUAL TSTATG2152-2 Normal Operation PROGRAM SWITCH RUN program Program OFF SET program AUX HEAT I2:00 FAN SWITCH AUTO NORM On or Auto EMRGC’Y LOCKOUT PROGRAM HEAT NEXT RUN OFF SET RESET FILTER COOL HEAT BATTERIES MODE SWITCH COOLER & WARMER...
  • Page 8 OWNER'S MANUAL TSTATG2152-2 Aux Heat AUX HEAT I2:00 AUTO NORM EMRGC’Y LOCKOUT PROGRAM HEAT AUX HEAT NEXT RUN OFF SET SWITCH RESET FILTER COOL HEAT BATTERIES Emergency - Disables all compressor functions* and energizes only Aux Heat to satisfy the heat demand.

  • Page 9: Clock Set

    OWNER'S MANUAL TSTATG2152-2 Clock Set PROGRAM Slide the Program Switch to the SET position. RUN OFF SET Setting the time & day are the first two steps after sliding the Program Switch to SET. 6:00 Use these buttons to adjust the current time.
  • Page 10 OWNER'S MANUAL TSTATG2152-2 Time Period Programming Overview PROGRAM SWITCH Slide the Program Switch to the SET position. PROGRAM The blinking icon(s) on the display may be changed by pressing the COOLER or WARMER buttons. RUN OFF SET After the blinking icon is changed to the desired selection, press the NEXT button.

  • Page 11: Time Period Programming

    OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekday Programming Setting the time & day are the first two steps after PROGRAM sliding the Program Switch to SET (page 9). RUN OFF SET 6:00 Press NEXT Morning to advance Use these buttons to...
  • Page 12 OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekday Programming Press NEXT 8:00 to advance Use these buttons to MTuWThF NEXT adjust the cool setpoint for the day time period. COOL Press NEXT 8:00 to advance Use these buttons to MTuWThF NEXT adjust the heat setpoint for the day time period.
  • Page 13 OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekday Programming 6:00 Evening Press NEXT Use these buttons to MTuWThF to advance adjust the heat setpoint for NEXT the evening time period. HEAT I0:00 Press NEXT Use these buttons to MTuWThF to advance...

  • Page 14: Weekend Programming

    OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekend Programming 6:00 Morning Press NEXT Use these buttons to to advance SaSu adjust the start time for NEXT the morning time period. 6:00 Morning Press NEXT Use these buttons to to advance SaSu...
  • Page 15 OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekend Programming 8:00 Press NEXT Use these buttons to to advance SaSu adjust the cool setpoint for NEXT the day time period. COOL 8:00 8 00 Press NEXT Use these buttons to SaSu to advance...
  • Page 16 OWNER'S MANUAL TSTATG2152-2 Time Period Programming Weekend Programming 6:00 Evening Press NEXT Use these buttons to to advance SaSu adjust the heat setpoint for NEXT the evening time period. HEAT I0:00 Press NEXT Use these buttons to to advance SaSu...
  • Page 17 OWNER'S MANUAL TSTATG2152-2 Time Period Programming PROGRAM After you have completed setting the time period programming, you have two options: 1) Run the time period program by sliding the Program Switch to the RUN position. RUN OFF SET PROGRAM 2) Do not run the time period program. The thermostat will operate as a manual heat or cool thermostat.

  • Page 18: Advanced Setup

    OWNER'S MANUAL TSTATG2152-2 Advanced Setup This is normally done by the installer at initial installation. Enter advanced setup by sliding the Program Switch to SET. When the clock is flashing, press the NEXT button for 5 seconds. Do not release the button until this screen appears.

  • Page 19: About Advanced Features & Operation

    OWNER'S MANUAL TSTATG2152-2 Actual hours of fan operation Press NEXT Press RESET Press and hold the RESET to advance FILTER FILTER button to reset RESET FILTER NEXT FILTER the filter counter to 0 and remove the icon FILTER from the display.

  • Page 20: Factory Defaults

    OWNER'S MANUAL TSTATG2152-2 CAUTION Factory Defaults If, for any reason, you desire to return all the stored settings If, for any reason, you desire to return all the stored settings back to the factory default settings, follow the instructions below.

  • Page 21: Adjust The Temperature

    OWNER'S MANUAL TSTATG2152-2 CAUTION Calibration Under normal circumstances it will not be necessary to adjust the calibration of the temperature sensor. If calibration is required, please contact a trained HVAC technician to correctly perform the following procedure. Enter advanced setup by sliding the Program Switch to SET.

  • Page 22: Battery Replacement

    OWNER'S MANUAL TSTATG2152-2 Battery Replacement The batteries are easily accessible from the battery door located on the bottom front of the thermostat (fig. 1). To open the battery slot, pull out on the battery door (fig. 1) and swing down (fig. 2).
  • Page 23 No warranty applies to, and no warranty is offered by Goodman on, Goodman is not responsible for: any thermostat ordered over the Internet.
  • Page 24 Sunday Evening Night Air Conditionin g & Heatin g Goodman Manufacturing Company, L.P ., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. Copyright © 2009 • Goodman Manufacturing Company, L.P . • Houston, Texas Printed on recycled paper.

  • Page 25: Installation Instructions

    Air Conditionin g & Heatin g Heat Pump 5+2 Day Programmable ital Thermostat Control up to 2-Heat & 1-Cool Battery or System Powered Backlit Digital Display Auxiliary Heat Indicator Fahrenheit or Celsius Service Filter Indicator Installation Instructions Thank goodness for Goodman.

  • Page 26: Remove Old Thermostat

    INSTALLATION INSTRUCTIONS TSTATG2152-2 Contents Page # Safety Warnings Preparation Remove Old Thermostat Battery Replacement Wire Connections Test Operation Troubleshooting Warranty Page 2...
  • Page 27 INSTALLATION INSTRUCTIONS TSTATG2152-2 Safety Warnings P/N TSTATG2152-2 CAUTION Follow Installation Instructions carefully. DISCONNECT POWER TO THE HEATER - AIR CONDITIONER BEFORE REMOVING WARNING THE OLD THERMOSTAT AND INSTALLING THE NEW THERMOSTAT. CAUTION The two Alkaline “AA” batteries must be replaced at least once every 12 months to ensure proper operation.
  • Page 28 INSTALLATION INSTRUCTIONS TSTATG2152-2 Preparation Proper installation of the thermostat will be accomplished by following these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. These tools will be required: Flat Blade...

  • Page 29: Remove & Replace Old Thermostat

    INSTALLATION INSTRUCTIONS TSTATG2152-2 Remove & Replace Old Thermostat Remove the cover of the old thermostat. If it does not come off easily check for Loosen the screws holding the thermostat base or subbase to the wall, and lift away. Disconnect the wires from the old thermostat.
  • Page 30 INSTALLATION INSTRUCTIONS TSTATG2152-2 Battery Replacement The batteries are easily accessible from the battery door located on the bottom front of the thermostat (fig. 1). To open the battery slot, pull out on the battery door (fig. 1) and swing down (fig. 2).

  • Page 31: Wire Connections

    Rev. Valve (Energize to Heat) Rev. Valve (Energize to Cool) Thermal Insulating Sheet A label is provided on the backplate that prevents drafts MODEL: TSTATG2152-2 97061606 4Z95 originating inside the wall from USE SIZE “AA” MADE IN CHINA ALKALINE BATTERIES entering the thermostat.

  • Page 32: Sample Wiring Diagrams

    INSTALLATION INSTRUCTIONS TSTATG2152-2 Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional C R Y W G B O...
  • Page 33 INSTALLATION INSTRUCTIONS TSTATG2152-2 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional C R Y W G B O...
  • Page 34 INSTALLATION INSTRUCTIONS TSTATG2152-2 Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heat-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional C R Y W G B O...
  • Page 35 INSTALLATION INSTRUCTIONS TSTATG2152-2 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional C R Y W G B O...

  • Page 36: Test Operation

    INSTALLATION INSTRUCTIONS TSTATG2152-2 Test Operation Turn on the power to the Heat Pump. On the thermostat, slide the Mode Switch to HEAT. Press the COOLER or WARMER button until the set temperature is 10 degrees above room temperature. The HVAC unit should energize in the heating mode.
  • Page 37 INSTALLATION INSTRUCTIONS TSTATG2152-2 Test Operation On the thermostat, slide the Mode Switch to COOL. Press the COOLER or WARMER buttons until the set temperature is 10 degrees below room temperature. The HVAC unit should energize in the cooling mode (Page 6 of the Owner’s Manual)

  • Page 38: Troubleshooting

    INSTALLATION INSTRUCTIONS TSTATG2152-2 Trouble Shooting SYMPTOM: The slide switches on the thermostat are very difficult to move. CAUSE: The backplate of the thermostat is screwed too tightly into a wall that is not perfectly flat. REMEDY: Loosen the screws holding the thermostat into the wall.

  • Page 39: Replace The Batteries

    FOR HOME OR OFFICE USE 4Z95 Air Conditionin g & Heatin g Goodman Manufacturing Company, L.P ., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. Copyright © 2009 • Goodman Manufacturing Company, L.P .
  • Page 40 No warranty applies to, and no warranty is offered by Goodman on, Goodman is not responsible for: any thermostat ordered over the Internet.
