Sony Trinitron KV-27HSR10 Service Manual

SERVICE MANUAL

Note: The service manual for RM-763 has
been issued separately.
Television system American TV standards
Channel coverage VHF: 2- 13
UHF: 14-69
Cable
Picture tube Microblack Trinitron !ube
29-inch picture tube measured
diagonally
Antenna 75-ohm external antenna term~nal
for VHFlUHF
Input VIDEO 1, 2 and 3 IN
S VIDEO IN (4-pin mini DIN)
Y: 1 Vp-p, 75-ohms
unbalanced, sync negative
C: 0.286 Vp-p (Burst signal),
75-ohms
Video (phono jacks): 1 Vp-p.
75-ohms unbalanced, sync
negative
Audio (phono jacks):
(100% modulation)
Impedance: 47 kilohms
output
MONITOR OUTPUT
S VIDEO OUTPUT (4-pin mini
DIN)
Y: 1 Vp-p, 75-ohms
unbalanced, sync negative
C: 0.286 Vp-p (Burst signal)
75-ohms
Video (phono jacks): 1 Vpp,
75-ohms unbalanced, sync
negative
Audio (phono jacks):
(100% modulation)
Impedance: 10 kilohms
-
1 125
Canadian Model
MODELS OF THE S A M E SERIES
KV-32XBR50
AUDIO OUTPUT (VARIABLE) (phono
jacks)
More than
maximum volume setting
(variable)
Impedance: 5 kiiohms
Power requirements 120V AC, 60Hz
Power consumptiin 225W (max.)
Accessories supplied
Remote Commander RM-763
with 4 size AA
Antenna connector (1)
U N mixer EAG66
Connecting cable
Video rack
SU-251 (black)
Design and specifications are subject to change without
notice.
US Model
Chassis N . SCC-C59C-A
O
Chassis No. SCC-C6OC-A
408
bateries (1)
