Morphy Richards 29006 Operating Instructions

Stereo cd alarm
clock radio
29006

OPERATING INSTRUCTIONS

Electrical requirements
Check the voltage on the rating plate of your clock radio corresponds with
your house electricity supply which must be A.C. (alternating current).
If the socket outlets in your home are not suitable for the plug supplied with
this appliance the plug should be removed and the appropriate one fitted.
IMPORTANT : THE PLUG REMOVED FROM THE MAINS LEAD, IF SEVERED, MUST
BE DESTROYED AS A PLUG WITH A BARED FLEXIBLE CORD IS
HAZARDOUS IF ENGAGED INTO A LIVE SOCKET OUTLET.
Should the fuse in the 13 amp plug require changing a 3 amp BS1362 fuse
must be fitted.
Battery back-up facility
(unit will work without a battery being fitted)
Your cd alarm clock radio is equipped with a battery back-up facility.
1 Remove the battery compartment cover (underneath the unit) by
pushing in the clip and lifting off.
2 Insert a battery size 9 volts PP3/6LR61 (Ensure battery is inserted correctly).
3 Replace the battery compartment cover.
Should a power interruption occur the clock will continue to run, however, time
keeping will not be accurate. The display will be extinguished to conserve battery
life but the memory will retain details of the clock time and alarm settings.
If the optional battery is not installed in case of the AC power failure the clock will
reset to 12:00 when power is restored. You will need to reset the clock and
alarm settings.
Battery back-up is designed to operate for a short period only.
If the unit is not to be used for a prolonged period, remove the battery to
avoid battery leakage.
In the interests of environmental safety : dispose of batteries safely.
P.3
Illustration
1
2
4
3
5
6
7
19
8
20
24
21
16
17
31

Location of controls

1 Alarm 1 and 2 selector switch
2 Alarm function selector switch
3 Play/pause button
4 Play mode/program button
5 REPEAT button: For continuous cd playback
6 MIN Skip/fast search/selection (
-to skip cd tracks and for reverse within a track
-for quick and normal setting of time and alarm clock
functions. Quick selection: press and hold
normal selection: press repeatedly
7 HOUR Skip/fast search/selection (
-to skip cd tracks and for fast search within a track
-for quick and normal setting of time and alarm clock
functions. Quick selection: press and hold,
normal selection : press repeatedly
8 Stop button: to stop cd playback
9 Snooze button: Stops alarm and repeats
10 PTS button: to select your favourite cd track to wake up to
1 1 Alarm 1 button: to set alarm 1
12 Alarm 2 button: to set alarm 2

Setting the clock time

1 While holding down the TIME button, press the
desired time. The pm indicator will light up when midday has been reached.
2 Release the button to save time setting.

Radio operation

FM wire aerial
To obtain the maximum FM reception fully extend the wire FM aerial (which is
located at the rear of the unit) and alter the direction of the wire for best results.
The aerial for the MW waveband is located inside the unit. To obtain the
maximum MW reception rotate the clock radio.
1 Slide the FUNCTION SELECTOR switch to select MW or FM.
2 Press the POWER on/off button.
3 Adjust the VOLUME control to a suitable level.
4 Slowly adjust the TUNING control to select your desired station. The
FM stereo indicator will light up when FM stereo signal is received.
5 To switch off the radio, press the POWER on/off button.
To play compact disc
1 Press the POWER/ON OFF button, the power indicator will light up.
2 Open the cd door using cd open tab, load a disc in the cd compartment.
Close the cd door by pushing down until it locks into place.
3 Select the cd mode by switching the function selector to cd.
4 Press the play/pause button. The display will show the track number when
you begin to play a cd. After a few seconds, the display reverts to the
current time.
Note : The same button can be used to momentarily interrupt playback. The
track number will flash until the
5 Adjust the volume control until the desired level is reached.
6 Press the stop button to stop playback.
7 To switch off the cd press the power on/off button.
30
12
1 1
15
22
9 10 13 14
23
18
13 Sleep button: to select sleep function
and set countdown time
14 Time button: to set time
15 Power on/off button: to turn radio,
cd and alarm on and off
16 PM indicator
backward):
17 Alarm 1 on indicator
18 Alarm 2 on indicator
19 Power indicator
20 Program indicator
21 Random indicator
forward):
22 Repeat indicator
23 FM stereo indicator
24 Speakers
25 Tuning indicator
26 Function selector switch
27 Volume control
28 Cd open tab
29 Earphone socket
30 FM wire aerial
31 Dial scale with pointer
32 Battery compartment
P.2
or to set the
button is pressed again.
P.4
29
28
27
26
25
32
24
