- Page 1 Intel® Storage Server SSR212MC2 Spares / Parts List & Configuration Guide A reference guide to assist customers in ordering the necessary components to configure the Intel® Storage Server SSR212MC2 & SSR212MC2R Revision 1.4 Subject to Change October 2007...
-
Page 2: Revision History
Intel may make changes to specifications and product descriptions at any time, without notice. *Other brands and names may be claimed as the property of others. Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation. -
Page 3: Table Of Contents
ONTENTS ......................3 ONTENTS ................. 4 RODUCTION ONFIGURATIONS Base Unit Description...................4 Production System Codes ................5 Supported Processors .................5 Production Hardware Accessories..............6 Production Spares (Field Replaceable Units)..........6... -
Page 4: Production Configurations
RODUCTION ONFIGURATIONS This section contains information needed to order and configure a production SSR212MC2 or SSR212MC2R. The unit is shipped as a an integrated hardware platform, including enclosure, backplane, server board fan cooling module and power supply. Drivers and enclosure management software is included, but no operating system or storage applications are included. -
Page 5: Production System Codes
Production SSR212MC2BR unit, with North American power cord. SSR212MC2BRNA 00735858199094 Supported Processors For a full list of CPUs that are supported on the SSR212MC2, SSR212MC2BR, SSR212MC2R and SSR212MC2RBR, please refer to the Supported Processor List on the SSR212MC2 Product Support website: http://support.intel.com/support/motherboards/server/ssr212mc2/index.htm... -
Page 6: Production Hardware Accessories
SSR212MC2 cable kit, including: BBU cable, boot drive SAS, front panel flex cable, front panel SSI 890454 00735858193900 FMCSAS4XCBL SSR212MC2 4 lane SAS fan out cable with four 7 pin SATA connectors (mini-SAS to 4x SATA) 890489 00735858193917 FMCSASCBL SSR212MC2R 4 lane SAS cable (mini-SAS to mini-SAS) - Page 7 Please choose devices, such as HDDs, adapters, boot drives and JBODs from the Tested Hardware and Operating systems List (THOL). These devices have been verified to be compatible with the Intel® Storage Server SSR212MC2. Also, compatible memory may be selected from the Tested Memory List for the Intel Storage Server SSR212MC2.
