FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading

Summary of Contents for Biostar M7VID

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH ..................... 3 M7VID Features....................... 3 Package contents ......................4 Layout of M7VID ......................4 CPU Installation ......................5 DDR DIMM Modules: DIMM1-2-3 ..................6 Jumpers, Headers, Connectors & Slots ................ 7 SPANISH ....................11 Características del M7VID .................... 11 Contenido del Paquete....................
  • Page 3: English

    English M7VID Features Use VIA KT333 / VT8233A Chipset, Winbond W83697HF. Contains on board I/O facilities, which include two serial ports, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports a game port and a monitor port.
  • Page 4: Package Contents

    HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1 Flash Memory Writer for BIOS update X 1 USB Cable X 2 (Optional) Rear I/O Panel for ATX Case X 1 (Optional) Layout of M7VID CPU1 Socket A JKBV1...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Dimm1-2-3

    DDR DIMM Modules: DIMM1-2-3 DRAM Access Time: 2.5V Unbuffered/ Registered DDR 1600/ 2100/ 2700 Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Total Memory Location Size (MB) DIMM 1 64MB/128MB/256MB/512MB/1GB Max is DIMM 2 64MB/128MB/256MB/512MB/1GB DIMM3...
  • Page 7: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary).
  • Page 8 Wake On LAN Header: WOL1 Ground 5V_SB Wake up WOL1 Front USB Header: JUSB2 (Optional) Pin1,2 ==> +5V Pin3,4 ==> Data(-) Pin5,6 ==> Data(+) Pin7,8 ==> Ground Pin9 ==> KEY JUSB2 Pin10 ==> NA 5V/ 5VSB Selection for USB/KB: JUSBV1/2/5/ JKBV1 Pin 1-2 on ==>...
  • Page 9 CNR Codec Primary/Secondary Selection: JCODECSEL Pin 1-2 ==> On-board Primary Codec Pin 2-3 ==> CNR Primary Codec JCODECSEL Front Panel Connector: JPANEL1 PWR_LED ON/OFF HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==>...
  • Page 10: Back Panel Connectors

    Clear CMOS Jumper: JCMOS1 Pin 1-2 on ==> Normal Operation (default) Pin 2-3 on ==> Clear CMOS Data JCMOS1 Back Panel Connectors JGAME1_USB1 JKBMS1 Game Port/ USB Ports (optional) JPRNT1 PS/2 Mouse Parallel JUSB1 Speaker Line In Mic PS/2 COM1 COM1 COM1 COM1...
  • Page 11: Spanish

    Spanish Características del M7VID Usa Chipset VIA KT333 / VT8233A, Winbond W83697HF. Contiene facilidades I/O integrados en la placa madre en el que incluye un puerto en serie paralelo, un puerto paralelo, un puerto para el ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB, puerto LAN (opcional), un puerto para juegos y un puerto para el monitor.
  • Page 12: Contenido Del Paquete

    Cable HDD X 1, Cable FDD X 1, Configuración completa del Driver CD X 1 Memoria de Escritura Flash para actualización del BIOS X 1 Cable USB X 2 (Opcional) Panel trasero I/O para caja ATX X 1 (Opcional) Disposición del M7VID CPU1 Socket A JKBV1...
  • Page 13: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 14: Módulos Ddr Dimm: Dimm1-2-3

    Módulos DDR DIMM: DIMM1-2-3 DRAM Tiempo de Acceso: 2.5V Unbuffered/ Registered DDR 1600/ 2100/ 2700 Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184contactos) Localización Total del del Módulo Tamaño de Módulo DDR DIMM Memoria (MB) DIMM 1 64MB/128MB/256MB/512MB/1GB DIMM 2 64MB/128MB/256MB/512MB/1GB...
  • Page 15: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 16 Cabezal frontal USB: JUSB2 (Opcional) Contacto1,2 ==> +5V Contacto3,4 ==> Dato(-) Contacto5,6 ==> Dato(+) Contacto7,8 ==> Tierra Contacto9 ==> KEY JUSB2 Contacto10 ==> NA 5V/ 5VSB Selección para USB/KB: JUSBV1/2/5/ JKBV1 Contacto 1-2 encendido ==> 5V Contacto 2-3 encendido ==> 5V_SB JUSBV1/2/5 JKBV1 USB 2.0 Dispositivo Wake-Up: J9/ J10...
  • Page 17 CNR Selección Codec Primario/Secundario: JCODECSEL Contacto 1-2 ==> Codec Primario Integrado Contacto 2-3 ==> CNR Codec Primario JCODECSEL Conector del Panel Frontal: JPANEL1 PWR_LED ON/OFF HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==>...
  • Page 18 Puente de Borrar CMOS: JCMOS1 Contacto 1-2 encendido ==> Operacion Normal (predeterminado) Contacto 2-3 encendido ==> Dato de Borrar CMOS JCMOS1 Conectores del Panel Trasero JGAME1_USB1 JKBMS1 Puerto de Juego/ JPRNT1 Puertos USB (opcional) Raton PS/2 Paralelo JUSB1 Salida Entrada Teclado Entrada COM1...
  • Page 19: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 20: System Requirement

    System Requirement OS Support: Windows 98 SE, Windows Me, Windows 2000, Windows XP DirectX: DirectX 8.1 or above. (The Windows XP operating system includes DirectX 8.1. If you use Windows XP, you do not need to install DirectX 8.1.) Installation Execute the setup execution file, and then the following dialog will pop up.
  • Page 21: Usage

    When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [WarpSpeeder™] utility will be automatically and immediately launched after you click “Finish”...
  • Page 22 Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [WarpSpeeder™] Utility. You can use the mouse by clicking the left button in order to invoke [WarpSpeeder™] directly from the little tray icon or you can right-click the little tray icon to pop up a popup menu as following figure.
  • Page 23 b. Contains About, Voltage, Overclock, and Hardware Monitor Buttons for invoking respective panels. With a user-friendly Status Animation, it can represent 3 overclock percentage stages: Duck walking => overclock percentage from 100% ~ 110 % Duck running => overclock percentage from 110% ~ 120% Duck burning =>...
  • Page 24 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 25 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. Overclock Panel contains these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 26 b. “Recovery Dialog button”: Pop up the following dialog. Let user select a restoring way if system need to do a fail-safe reboot. “Auto-overclock button”: User can click this button and [ WarpSpeeder™ ] will set the best and stable performance and frequency automatically. [ WarpSpeeder™...
  • Page 27 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 29 Note: Because the overclock, overvoltage, and hardware monitor features controlled several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions. This property can make [ WarpSpeeder™...
  • Page 30: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Page 31: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE SOLUCIÓN No hay corriente en el sistema. La luz de * Asegúrese que el cable de transmisión esté corriente no ilumina, ventilador dentro de la seguramente enchufado. fuente de alimentación apagada. Indicador de * Reemplace el cable. luz del teclado apagado.
  • Page 32 03/17/2002...
