INSTRUCTION MANUAL
Dream - Dream T
LSC 024- Rev. 00 - Ed. 11/2014

Advertisement

Table of Contents
loading

Related Manuals for Laspaziale S1 Dream

Summary of Contents for Laspaziale S1 Dream

  • Page 1 INSTRUCTION MANUAL Dream - Dream T LSC 024- Rev. 00 - Ed. 11/2014...
  • Page 2 Dream - Dream T espresso coffee machines WEEE Disposal of the equipment by the users within the European Community ( WEEE) in compliance with the article 13 of the legislative decree is- sued on 25 July 2005, nr151 ”Implementation of the directives 2002/95/CE,2002/96/CE e 2003/108/CE, concerning the decrease in the usage of dangerous substances in the electrical and electronic equipment and the disposal of waste”.

  • Page 3: Table Of Contents

    Dream - Dream T espresso coffee machines INDEX GENERAL DESCRIPTION OF THE MACHINE ......... 3 10 PROGRAMMING THE MACHINE ........... 21 1.1 DESCRIPTION OF THE MACHINE DREAM ......... 3 10.1 naVIgaTIon mEnu ..............21 1.2 DESCRIPTION OF THE MACHINE DREAM T ......4 10.2 calEnDar ................
  • Page 4 Dream - Dream T espresso coffee machines 10.20 grInDIng ................62 10.21 E.g.s. ElEcTronIc grounD sysTEm ........ 63 10.22 auTomaTIc sHouT DoWn ............ 64 10.23 grouP clEanIng ..............65 10.24 scrEEnsaVEr ................ 66 10.25 TImE uPDaTE ................68 10.26 conTrasT ................69 10.27 PrEssurE sEnsor ...............

  • Page 5: General Description Of The Machine

    Dream - Dream T espresso coffee machines 1 GENERAL DESCRIPTION OF THE MACHINE 1.1 DESCRIPTION OF THE MACHINE DREAM Fig. 1 7. group Head 1. steam Wand 8. Drip tray 2. Hot Water outlet 3. steam Knob 4. cup Warming Tray 5.

  • Page 6: Description Of The Machine Dream T

    Dream - Dream T espresso coffee machines 1.2 DESCRIPTION OF THE MACHINE DREAM T Fig. 2 7. Pressure gauge 1. steam Wand 8. Water reservoir 2. Hot Water outlet 9. grouphead 3. steam Knob 10. Drip Tray 4. cup Warming Tray 5.

  • Page 7: Description Of The Control Panel

    Dream - Dream T espresso coffee machines 1.3 DESCRIPTION OF THE CONTROL PANEL Fig. 3 g. manual button a. Power button b. Display h. one shot button c. menu/ok button i. boiler button d. up arrow button l. Hot Water Delivery button e.

  • Page 8: General Advice For The Installer Dream T

    Dream - Dream T espresso coffee machines 2. GENERAL ADVICE FOR THE INSTALLER DREAM T read carefully the instructions and warnings contained in this manual, since they provide important indications concerning the instal- lation of the appliance. Attention! The client must prepare the wiring system so that it is in an ideal position for the correct installation of the machine. The instal- lation engineer cannot change the existing system put in place by the customer.
  • Page 9 Dream - Dream T espresso coffee machines Danger! The electrical safety of the appliance is fully achieved only after it has been correctly connected to an earthing system as required by the laws in force. It is necessary to have the earthing connection checked by professionally qualified personnel. The manufacturer cannot be held liable for any damage caused by the lack or inefficiency of the system’s earthing connection.

  • Page 10: Installation

    Dream - Dream T espresso coffee machines • The noise emitted by the appliance during normal operation is less than 70 dB. • The appliance is supplied without water in the boiler to prevent that exposure to cold temperatures can cause irreparable damage. • The unit should be operated only with cold water intended for human consumption. Attention! Failure to comply with the above regulations could jeopardise the correct operation and safety of the appliance as well as its useful lifetime. 2.2 INSTALLATION • This appliance is not for built-in installation.

  • Page 11: General Advice For The Installer Dream

    Dream - Dream T espresso coffee machines 3. GENERAL ADVICE FOR THE INSTALLER DREAM Attention! This appliance may only be used for its intended purpose. any other use is therefore considered as improper and unreasonable. The manufacturer cannot be held liable for any damage caused by improper, incorrect or unreasonableuse. Attention! make sure that the power rating of the system arranged by the customer corresponds to the highest rating indicated on the rating plate of the equipment.
  • Page 12 Dream - Dream T espresso coffee machines Attention! Installation must be carried out by qualified personnel according to current laws and to the manufacturer’s instructions. Incorrect installation may cause damage to people, animals or property for which the manufacturer cannot be held liable. Attention! The appliance must be installed on a flat bearing surface, the stability of which needs to be checked.

  • Page 13: Installation

    Dream - Dream T espresso coffee machines 4 INSTALLATION Legend: 1 main switch (prear- 4.1 ELECTRIC INSTALLATION SCHEME ranged by the cus- tomer). When carrying out the electric connections, please take into consid- eration all warnings and indications provided so far in this manual. Furthermore, in order to avoid dangerous overheating, unwind com- pletely the feeding cable.

  • Page 14: Water Mains Installation Scheme

    Dream - Dream T espresso coffee machines 4.2 WATER MAINS INSTALLATION SCHEME Legend: 1 Water (prear- Attention! ranged by the cus- The equipment is supplied without water in the boiler so as tomer); 2 Water softener (op- to prevent the boiler from being badly damaged, should the tional);...

  • Page 15: Warning/Technical Data Labels And Nameplates Applied To The Machine

    Dream - Dream T espresso coffee machines 4.3 WARNING/TECHNICAL DATA LABELS AND NAMEPLATES APPLIED TO THE MACHINE In the figure below are shown the warning/technical data labels and nameplates positioned on the machine. Warning! Dedicate the time necessary to familiarise yourself with these labels. Ensure that they are readable and keep them clean or replace those that have deteriorated or illegible (both the text and the graphics).

  • Page 16: Removing The Packaging

    Dream - Dream T espresso coffee machines 5. REMOVING THE PACKAGING after unpacking the machine, please check its integrity; in case of doubt, do not use it and consult the manufacturer. Packaging materials must not be left within children’s reach since they are potentially dangerous. Attention! The appliance weight is more than 30 kg and therefore, it cannot be moved by a single person alone.

  • Page 17: Dream T First Time Set Up

    Dream - Dream T espresso coffee machines 6. DREAM T FIRST TIME SET UP 6.1 FILLING THE WATER TANK A. remove the drip tray (7). B. Then take out the container (10) and fill it with cold drinking water. C. refit the water container (10), pushing it all the way down to the bottom and then refit the tray (7). 6.2 FIRST-TIME APPLIANCE INSTALLATION Attention! When the appliance is installed for the first time, carry out the steps listed below.

  • Page 18: Turning The Machine On For The First Time

    Failure to do so will damage the machine and will not be covered under war- ranty. Press and hold the button for 3 seconds, the display shows lasPaZIalE logo for some seconds and then the HomE scrEEn. Fig. 8 Whichever portafilter you intend to use then lock it into the grouphead so it will warm up with the machine.

  • Page 19: Dream First Set Up

    Dream - Dream T espresso coffee machines 7. DREAM FIRST SET UP 1. Press and hold the PoWEr buTTon button for 3 seconds, until the display lights up. 2. Whichever portafilter you intend to use then lock it into the grouphead so it will warm up with the machine. 3.

  • Page 20: Making Coffee

    Dream - Dream T espresso coffee machines 8 MAKING COFFEE There are a few ways you can pull a shot with the s1 Dream-T. you can use one of the two programmable shot buttons, single or double These buttons can be individually programmed for volume.

  • Page 21: Dispensing Steam

    Dream - Dream T espresso coffee machines 9 DISPENSING STEAM Warning! This is only possible with the boiler switched on. 1. Insert the steam wand (1) into a jug containing the drink to be heated. 2. Turn the steam knob (3) anticlockwise. 3.
  • Page 22 Dream - Dream T espresso coffee machines If the hot water delivery is set in automatic way, the display shows the following sym- bol. Fig. 13 auTomaTIc sysTEm To DElIVEry HoT WaTEr For InFusIons A. Place the pitcher underneath the hot water faucet (2). B.

  • Page 23: Programming The Machine

    Dream - Dream T espresso coffee machines 10 PROGRAMMING THE MACHINE Press and hold the to enter in the maIn mEnu, the display shows a series of icons, each icons corresponding to a function. Fig. 14 10.1 NAVIGATION MENU Press the up/down arrow button to move through the menu, each time the buttons are pressed, next icon get bigger and the name of the function appears on the top of the display.

  • Page 24: Backlight Lcd

    Dream - Dream T espresso coffee machines Each icon sHoWs on THE DIsPlay, corresponds to a function: This enables the user to change the date format of the machine calEnDar This enables the user to set the time on the machine. TImE This enables the beep tone to be turned on or off when the buttons are pressed.
  • Page 25 Dream - Dream T espresso coffee machines allow the user to set the m.a.T. system (not available, yet) m.a.T. allow the user to personalize the name of the user. ProFIlE namE This feature when enabled will give an alarm message on the display to indicate sErVIcE the machine is Due for service.
  • Page 26 T The s1 Dream can be set up to work in full power mode or in Economy mode. Full PoWEr alow the user to set the off-set from the the temperature detects by the coffee oFF sET temperature probe and the temperature which came out from the coffee group.

  • Page 27: Calendar

    Dream - Dream T espresso coffee machines 10.2 CALENDAR Press the down arrow once to highlight the calendar icon. note the calendar icon change. The top display line also changes to “calendar” as a further indication. Press the ok button once to enter the calendar set function. Initially, the month is highlighted.

  • Page 28: Time

    Dream - Dream T espresso coffee machines 10.3 TIME use the arrow keys to get there and then highlight the Time icon. The top title line also display the word “Time”. next press the menu button in order to enter the Time set function use the up or Down arrow to cycle through the hours.

  • Page 29: Beep

    Dream - Dream T espresso coffee machines 10.4 BEEP Press the down arrow once to highlight the bEEP icon. note the calendar icon change. The top display line also changes to “bEEP” as a further indication. Press the ok button once to enter the bEEP set function. Fig.

  • Page 30: Language

    Dream - Dream T espresso coffee machines 10.5 LANGUAGE Press the uP/down arrow once to highlight the languagE icon. Press the ok button once to enter the languagE set function. Fig. 25 Press the up/down button to choose the desired language. The following languages are available: ITalIan, gErman, sPanIsH, amErIcan EnglIsH and brITIsH EnglIsH.

  • Page 31: Backlight Lcd

    Dream - Dream T espresso coffee machines 10.6 BACKLIGHT LCD Press the uP/down arrow once to highlight the bacKlIgHT lcD icon. Press the ok button once to enter the menu. Fig. 27 This setting adjusts the amount of time the display stays backlit after that last front panel button press.

  • Page 32: Timer

    Dream - Dream T espresso coffee machines 10.7 TIMER Press the uP/down arrow once to highlight the TImEr icon. Press the ok button once to enter the menu. Fig. 29 if you want to use on/off timers move the dot next to on and press the menu button. note that if you have already set up programmable on/off times and change this set- ting to off, the programmed values are not lost and will become active again when this switch is later turned back on.
  • Page 33 Dream - Dream T espresso coffee machines you can set from 1-3 different on/oFF times per day. note the encircled 1, this indicates you are on the 1st time setting screen for monday. using this screen is just like setting the Time. scroll to select the on Hour, press the menu button to move to the on minutes, scroll to select minutes, press the menu button to select off Hour, scroll to select the de- sired hour, press menu again to select off minutes, then press the menu button again.
  • Page 34 Dream - Dream T espresso coffee machines after programming monday, the display will show the right screen. Pressing the menu button with copy highlighted, will copy all the monday settings to the other six days of the week. alternatively, it is possible to chose Tuesday by pressing the down arrow and then confirm with the ok button.

  • Page 35: Counters

    Dream - Dream T espresso coffee machines 10.8 COUNTERS Press the uP/down arrow once to highlight the counTErs icon. Press the ok button once to enter the menu. Fig. 35 With the word counTErs in reverse video on the top of the display, as shown, you can view the current counter, then press the menu button to return to the main menu.

  • Page 36: Program

    Dream - Dream T espresso coffee machines 10.9 PROGRAM Press the uP/down arrow once to highlight the Program icon. Press the ok button once to enter the menu. Fig. 37 Press the uP/down arrow to chose: usEr 1, nEW usEr and bacK to exit from the program menu.

  • Page 37: User 1

    Dream - Dream T espresso coffee machines 10.10 USER 1 10.10.1 COFFEE TEMPERATURE once in the menu usEr 1, press the up/down arrow button to highlight the coFFEE TEmPEraTurE Icon. Press the oK button to enter in the menu. Fig. 39 use the up or down arrows to increase or decrease the indicated temperature until the desired espresso temperature is showing.

  • Page 38: Boiler Temperature

    Dream - Dream T espresso coffee machines 10.10.2 BOILER TEMPERATURE Press the up/down arrow button to highlight the boiler TEmPEraTurE Icon. Press the oK button to enter in the menu. Fig. 41 use the up or down arrows to increase or decrease the indicated temperature until the desired boiler temperature is showing.

  • Page 39: Coffee Doses

    Dream - Dream T espresso coffee machines 10.10.3 COFFEE DOSES Press the up/down arrow button to highlight the coffee Doses Icon. Press the oK button to enter in the menu. Fig. 43 remove a filter holder from the delivery group. Fill with ground coffee, taking care not to leave any coffee powder residues on the top edge of the filter holder, then press it using the special coffee press supplied.

  • Page 40: Hot Water

    Dream - Dream T espresso coffee machines 10.10.4 HOT WATER Press the up/down arrow button to highlight the Hot Water Icon. Press the oK button to enter in the menu. Fig. 45 This screen will display the current setting. use the up or down arrows to select the manual or auTomaTIc setting, then press the oK button.

  • Page 41: Pre Infusion (Only For Dream Version)

    Dream - Dream T espresso coffee machines 10.10.5 PRE INFUSION (ONLY FOR DREAM VERSION) Press the up/down arrow button to highlight the PrE InFusIon Icon. Press the oK button to enter in the menu. Fig. 48 use the Down arrow to activate the pre-infusion, then press the ok button to show the next screen.

  • Page 42: Name Profile

    Dream - Dream T espresso coffee machines 10.10.6 M.A.T. The m.a.T. function is not available yet. Fig. 51 10.10.7 NAME PROFILE Press the up/down arrow button to highlight the namE ProFIlE Icon. Press the oK button to enter in the menu. Fig.
  • Page 43 Dream - Dream T espresso coffee machines When you press the menu button after the eighth character the string is locked in and you return to the main Profile menu. any periods you entered are converted to spaces. Fig. 54 The name you gave this profile is now shown at the top of the Profile screen and in the Home menu.

  • Page 44: New User

    Dream - Dream T espresso coffee machines 10.11 NEW USER This function allow to add a new profile, it is possible to add 4 users. Press the ok button, the display shows: Fig. 56 It is possible to set the parameters: coffee temperature, boiler temperature coffee doses, preinfusion (only DrEam version), m.a.T.

  • Page 45: Multiprofiles

    Dream - Dream T espresso coffee machines 10.12 MULTIPROFILES once stored a new profile, it is possible to shift from one to another. When the display shows the HomE menu, press and hold press the down arrow button for 3 second, the display will show the user menu: Fig.
  • Page 46 Dream - Dream T espresso coffee machines Fig. 61 now the HomE mEnu shows the new usEr selected. Fig. 62 LSC 024 - Rev. 00 - Ed. 11/2014...

  • Page 47: Delete User

    Dream - Dream T espresso coffee machines 10.13 DELETE USER It is possible to delete the usEr 2. Press the up/down arrow button to highlight the DElETE ProFIlE Icon. Press the oK button to enter in the menu, the display shows: Fig.

  • Page 48: Service

    Dream - Dream T espresso coffee machines 10.14 SERVICE This function allows the programming of the maintenance intervals. The machine can store a number of delivered (500-1000-2000). once the delivered programmed is reached, the display shows a warning to remem- ber to the user to do the service.
  • Page 49 Dream - Dream T espresso coffee machines If you choose bacK and then press the ok button the display will show the maIn mEnu without activate the function. Each time one of the buttons to delivery coffee is pressed, the programmed cycle decrease of one unit.

  • Page 50: Change The Parametres

    Dream - Dream T espresso coffee machines 10.14.1 CHANGE THE PARAMETRES When the service function has already been activated, press the up/down arrow but- ton to highlight the sErVIcE Icon. Press the oK button to enter in the menu. Fig. 69 The display shows the cycle remaining (935) before shows the alarm sErVIcE.

  • Page 51: Reset Counters

    Dream - Dream T espresso coffee machines 10.14.2 RESET COUNTERS after doing the maintenance (replace gasket, double shower etc), the counters can be reset. When the display shows the sErVIcE counTErs mEnu, press and hold press the oK button, the display will show: Fig.

  • Page 52: Filter

    Dream - Dream T espresso coffee machines 10.15 FILTER This function allows the programming of the water softener cartridge replacement. you can set the number of litres of water to be consumed before the replacement of the water softener filter. once this level is reached the display will show a warning. Press the up/down arrow button to highlight the FIlTEr Icon.

  • Page 53: Change The Parametres

    Dream - Dream T espresso coffee machines The numbers of litres (gallons) is decremented in the following way: • 0,55 ml at each coffee delivery (DrEam). • 1750 ml for one minute of automatic refilling function (DrEam). When the numbers of the programmed litres are reached, the display shows the alarm “FIlTEr”.

  • Page 54: Reset Counters

    Dream - Dream T espresso coffee machines 10.15.2 RESET COUNTERS after replacing the water softener cartridge, the counter can be reset. When the display shows the FIlTEr counTEr mEnu, press and hold press the oK button, the display will show: Fig.

  • Page 55: Alarms

    Dream - Dream T espresso coffee machines 10.16 ALARMS gives the status of any active alarms in the machine. Press the uP/down arrow once to highlight the alarms icon. Then press the oK button to enter in the menu. Fig. 81 The display shows the last alarm detected by the appliance, stored by date and time.

  • Page 56: Read

    Dream - Dream T espresso coffee machines 10.17 READ The rEaD function allows to copy all parameters of the machine in a sD carD. Press the uP/down arrow once to highlight the rEaD icon, then press the oK button the display shows: Fig.
  • Page 57 Dream - Dream T espresso coffee machines The file DrEam_r.cvs can be opened by the programs notePad (for Windows) and TextEdit (apple), it is also possible to open the file DrEam_r.cvs, by other program, for example EXcEl. below an example of file DrEam_r.cvs with some explanations. USER PARAMETERS USER ACTIVE SET T GROUP °C SET T GROUP °F SET T BOILER °C SET T BOILER °F...
  • Page 58 Dream - Dream T espresso coffee machines ER AUTO HOT WATER sec hot water omatic time anual delivering ECK sec CALIB T BOILER °C x10 CALIB T BOILER °F x10 OFFSET T GROUP °C OFFSET T GROUP °F PID PAR P PID PAR I PID PAR D TIMER ON...

  • Page 59: Write

    Dream - Dream T espresso coffee machines 10.18 WRITE The WrITE function allows to change some parameters of the appliance, through the sD carD. copy a file DrEam_r.cvs and rename the file: DrEam_W.cvs. To change the stored parameters, delete the existing ones in the field and write a new parameters. The separation between the fields is carried out using the symbol “;”...
  • Page 60 Dream - Dream T espresso coffee machines sErVIcE sET: “0” = 500 delivery. “1” = 1000 delivery. “2” = 2000 delivery. “3” = 5000 delivery. FIlTEr: write “0” for oFF and “1” for on. FIlTEr sET lt: range 00010-5000 FIlTEr sET us gal: range 0001-5000 conTrasT: range 1-5.
  • Page 61 Dream - Dream T espresso coffee machines TImEr: For each day, write the time to switch on and oFF the machine, 0.00 0.00 0.00 0.00 0.00 0.00 In the example below, on Tuesday, the machine switch on at 07:00 and switch oFF at 09:00, switch on again at 12:00 and switch oFF again at 14:00 then switch on at 19:00 and switch oFF at 21:30.
  • Page 62 Dream - Dream T espresso coffee machines connect the sD carD rEaDEr in the sD carD InTErFacE and press the ok but- ton. Fig. 90 The display shows copying for few seconds, while the parameters stored in the sD are being written in the appliance. Fig.

  • Page 63: Led

    Dream - Dream T espresso coffee machines 10.19 Press the uP/down arrow once to highlight the lED icon, then press the oK button the display shows: Fig. 92 use the up and Down arrows to select oFF, on, or auTo, then press the menu but- ton to store the selection and return to maIn menu oFF = The two lights next to the group are always oFF...

  • Page 64: Grinding

    Dream - Dream T espresso coffee machines 10.20 GRINDING This feature, when enabled, will give the user a notice while brewing if the grind is too fine or coarse. Press the uP/down arrow once to highlight the grInDIng icon, then press the oK button the display shows: Fig.

  • Page 65: Electronic Ground System

    Dream - Dream T espresso coffee machines 10.21 E.G.S. ELECTRONIC GROUND SYSTEM When enabled, the system will release a small amount of water from the grouphead after 20 minutes of inactivity, to keep wet the coffee pack. Press the uP/down arrow once to highlight the Egs icon, then press the oK button the display shows: Fig.

  • Page 66: Automatic Shout Down

    Dream - Dream T espresso coffee machines 10.22 AUTOMATIC SHOUT DOWN When enabled the machine will automatically turn itself off after a pre-set period of inactivity. Press the uP/down arrow once to highlight the auTomaTc sHouT DoWn icon, then press the oK button the display shows: Fig.

  • Page 67: Group Cleaning

    Dream - Dream T espresso coffee machines 10.23 GROUP CLEANING allows the user to backflush or wash the double shower without being stored in the counter menu. Press the uP/down arrow once to highlight the grouP clEanIng icon, then press the oK button, the display shows: Fig.

  • Page 68: Screensaver

    Press the down button to enable the function, the display will show: Fig. 106 Press the uP/down button to cHosE Form THE FolloWIng PIcTurE: • COLOSSEUM • STATUE OF LIBERTY • FORBIDDEN CITY • VIENNA • BRANDEBURG DOOR • • LASPAZIALE Fig. 107 LSC 024 - Rev. 00 - Ed. 11/2014...
  • Page 69 Dream - Dream T espresso coffee machines When this function is enable, after 2 minutes of inactivity, the display shows the se- lected picture instead of the HomE mEnu. If mIX is selected, the display scroll all picture every 30 seconds. LSC 024 - Rev.

  • Page 70: Time Update

    Dream - Dream T espresso coffee machines 10.25 TIME UPDATE Press the uP/down arrow once to highlight the TImE uPDaTE icon, then press the oK button, the display shows: Fig. 108 Press the down button to enable the function, the display will show: Fig.

  • Page 71: Contrast

    Dream - Dream T espresso coffee machines 10.26 CONTRAST This function, allows to change the contrast setting of the display. Press the uP/down arrow once to highlight the conTrasT icon, then press the oK button, the display shows: Fig. 111 use the up or Down arrows to change the display contrast and then, press the oK button to return to the main menu.

  • Page 72: Pressure Sensor

    Dream - Dream T espresso coffee machines 10.27 PRESSURE SENSOR allows the user to deactivate the pressure sensor for the pump and water mains pres- sure. This function is available only for DrEam models. Press the uP/down arrow once to highlight the DEacT. PrEssurE sEnsorE icon, then press the oK button, the display shows: Fig.

  • Page 73: Password

    Dream - Dream T espresso coffee machines 10.28 PASSWORD allows the user to create a password to block access to the main menu. Press the uP/down arrow once to highlight the PassWorD icon, then press the oK button, the display shows: Fig.
  • Page 74 Dream - Dream T espresso coffee machines Through the uP/Down arrows buttons, Insert the nEW password and press the oK button to store it and return to the main menu. When the password function is enable, the password must be insert to enter in the main menu.

  • Page 75: Software Update

    Dream - Dream T espresso coffee machines 10.29 SOFTWARE UPDATE This function allows the user to update the firmware in their machine. Press the uP/down arrow once to highlight the soFTWarE uPDaTE icon, then press the oK button, the display shows: Fig.
  • Page 76 Dream - Dream T espresso coffee machines Fig. 122 remove the sD carD rEaDEr, disconnect the plug and then riconnect the plug and switch on the appliance. Fig. 123 LSC 024 - Rev. 00 - Ed. 11/2014...

  • Page 77: Default Setting

    Dream - Dream T espresso coffee machines 10.30 DEFAULT SETTING This function, allows to restore the machine to its original factory settings. Press the uP/down arrow once to highlight the DEFaulT sETTIng icon, then press the oK button, the display shows: Fig.

  • Page 78: Set Calibration Boiler Temperature Probe

    Dream - Dream T espresso coffee machines 10.31 SET CALIBRATION BOILER TEMPERATURE PROBE This function, allows to calibrate the boIlEr temperature sensor. Press the uP/down arrow once to highlight the sET calIbraTIon boIlEr TEm- PEraTurE ProbE icon, then press the oK button, the display will show: Fig.

  • Page 79: Full Power

    10.32 FULL POWER The s1 Dream can be set up to work in full power mode or in Economy mode. Press the uP/down arrow once to highlight the Full PoWEr icon, then press the oK button, the display will show: Fig.

  • Page 80: Group Temperature Offset

    Dream - Dream T espresso coffee machines 10.33 GROUP TEMPERATURE OFFSET by default, the water temperature that comes out from the coffee group is 5°c more of the temperature detected by the coffee group temperature probe. It is possible to change this value by the oFFsET function: Press the uP/down arrow once to highlight the oFF sET icon, then press the oK but- ton, the display will show: Fig.

  • Page 81: P.i.d

    Dream - Dream T espresso coffee machines 10.34 P.I.D. Press the uP/down arrow once to highlight the PID icon, then press the oK button, the display will show: Fig. 132 use the up/down arrows button to set the P and press the ok button to store it and highlight the I.

  • Page 82: Economy Function

    Dream - Dream T espresso coffee machines 10.35 ECONOMY FUNCTION When the machine is set to Full PoWEr, it is possible to activate the Economy way by press and hold press for 5 seconds the boIlEr button, the display will show the symbol “E”...

  • Page 83: Information Center

    Dream - Dream T espresso coffee machines 10.36 INFORMATION CENTER This function allows to the final user to have a quick access to the following informa- tion. • serial number. • Firmware Version. • The activate functions. • The active alarms. To enter in the information center, press and hold press the up arrow button for three seconds, the display will show the serial number and the firmware version of the ap- pliance:...

  • Page 84: Alarms Control Dream

    Dream - Dream T espresso coffee machines 11 ALARMS CONTROL DREAM • COFFEE GROUP TEMPER PROBE FAILURE: the GROUP TEMPERATURE PROBE is damaged. It is a block alarm. • BOILER TEMPERATURE PROBE FAILURE: the BOILER TEMPERATURE PROBE is damaged. It is a no block alarm. • MAT TEMPERATURE PROBE FAILURE: the MAT TEMPERATURE PROBE (optional) is damaged. It is a no block alarm. • WATER PRESSURE SENSOR FAILURE: the WATER SENSOR PRESSURE (not available in the DREAM T) is damaged. It is a no block alarm. • BOILER REFILL SISTEM FAILURE: the automatic refill system for the boiler has been operating for more than 1 minute. It is a no block alarm. • FAILED BOILER TEMPERATURE: When, 12 minutes after switching on the boiler, the temperature detected by the probe is less than 60 °c. It is a no block alarm. • BOILER HIGH TEMPERATURE: the boiler temperature probe detects 130° C. It is a no block alarm. • FAILED COFFEE GROUP TEMPERATURE: When, 5 minutes after switching on the machine, the temperature detected by the probe is less than 60 °c.
  • Page 85 Dream - Dream T espresso coffee machines • SERVICE: the appliance requires an ordinary maintenance technical intervention. • FILTER: the appliance requires the replacement of the softener cartridge. • FINE GRIND: the extraction time is more than the value set in the GRINDIG CONTROL FUNCTION. • COARSE GRIND: the extraction time is less than the value set in the GRINDIG CONTROL FUNCTION. • REFILL THE WATER TANK: the water level in the tank, is below the level provided by the manufacturer. (Only for DREAM T). LSC 024 - Rev. 00 - Ed. 11/2014...

  • Page 86: Routine Appliance Maintenance To Be Performed By The User

    Dream - Dream T espresso coffee machines 12 ROUTINE APPLIANCE MAINTENANCE TO BE PERFORMED BY THE USER Take note! To grant the efficiency of the appliance and to maintain correct operation, it is necessary to follow the manufacturer’s instructions as to cleaning and regular maintenance. Attention! cleaning and routine maintenance operations must be carried out by the user according to the manufacturer’s instructions given here below.
  • Page 87 Dream - Dream T espresso coffee machines Every 3 days after turning off the machine, remove the shower heads using the wrench provided; brush them carefully, making sure that all the holes are clean. Then reassemble the parts following the sequence shown in the figure 138. A.

  • Page 88: Dream Water Supply Diagram

    Dream - Dream T espresso coffee machines DREAM WATER SUPPLY DIAGRAM Coffee Group EV coffee group BOILER EV LIV Fig. 139 = Water net supply tap = coffee group solenoid = motor pump = boiler pressure gauge = Pressor sensor = steam tap = no return valve EV H...

  • Page 89: Dream T Water Supply Diagram

    Dream - Dream T espresso coffee machines DREAM T WATER SUPPLY DIAGRAM BOILER EV LIV TANK Fig. 140 TANK = Tank = coffee group heating element = no return valve = coffee group solenoid = Expansion valve = boiler pressure gauge = Vibration pump = steam tap EV H...

  • Page 90: Wiring Diagram

    Dream - Dream T espresso coffee machines 15 WIRING DIAGRAM LD1 LD2 SL LT TOUCHPAD RS232 SD CARD MAIN POWER PLUG Fig. 141 LSC 024 - Rev. 00 - Ed. 11/2014...
  • Page 91 Dream - Dream T espresso coffee machines = main fuse = relays fuse = Flowmeter = Pressure sensor = coffee group static relay = boiler static relay = coffee group heating element = boiler heating element RS232 = serial rs232 = boiler water level probe = Tank water level control (not present in the DrEam machine) LD1/LD2...

  • Page 92: Technical Data

    Dream - Dream T espresso coffee machines 16 TECHNICAL DATA Fig. 142 DIMENSIONS AND WEIGHT POWER SUPPLY RATING AND ABSORPTION L (mm) P (mm) H (mm) VolT DREAM DREAM 230/110 50/60 2200 DREAM T DREAM T 230/110 50/60 2200 LSC 024 - Rev. 00 - Ed. 11/2014...
  • Page 93 Dream - Dream T espresso coffee machines LSC 024 - Rev. 00 - Ed. 11/2014...
  • Page 94 Dream - Dream T espresso coffee machines LSC 024 - Rev. 00 - Ed. 11/2014...
  • Page 96 Via E. Duse, 8 40033 Casalecchio di Reno Bologna - (Italy)  +39 051 611.10.11  +39 051 611.10.40  info@laspaziale.com  www.laspaziale.com LSC 024 - Rev. 00 - Ed. 11/2014 Type Engineering S.r.l.” for “LA SPAZIALE S.p.A.” Creation, layout and styling: “...
