- Page 1 OWNER’S MANUAL SoundPlate™ Please read this manual carefully before operating your set and retain it for future reference. LAP340 LAP345C LAP347C www.lg.com LAP340-NB_DUSALLK_ENG.indd 1 2013-12-19 10:49:24...
- Page 2 Getting Started Getting Started Safety Information WARNING: Do not install this equipment in a confined space such as a book case or similar unit. CAUTION: Do not block any ventilation openings. CAUTION Install in accordance with the manufacturer’s instructions. RISK OF ELECTRIC SHOCK Slots and openings in the cabinet are provided for DO NOT OPEN ventilation and to ensure reliable operation of the...
-
Page 3: Important Safety
Getting Started This device may be equipped with a portable 11. Only use attachments/accessories specified by battery or accumulator. the manufacturer. Follow these steps to insure the battery is 12. Use only with the cart, stand, tripod, bracket, or removed in a safe manner: Remove the old table specified by the manufacturer, or sold with battery or battery pack, follow the steps in reverse the apparatus. - Page 4 This equipment generates, uses, and can radiate radio Responsible Party : LG Electronics USA, Inc. 1000 Sylvan Avenue frequency energy and, if not installed and used in accordance with the instructions, may cause Englewood Cliffs, NJ 07632 harmful interference to radio communications.
-
Page 5: Table Of Contents
Front panel Rear panel Remote control Setting up the unit Operating Basic operations – Optical input operation – LG Sound Sync – AUTO POWER On/Off Using Bluetooth technology – Listening to music stored on the Bluetooth devices CINEMA SOUND Troubleshooting... - Page 6 Designs and specifications of the accessories are subject to change without prior notice. Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Sound Sync. Bluetooth Enjoys music from bluetooth device with simple connection.
-
Page 7: Getting Started
Power on or disconnected power cord Standby Blink CINEMA SOUND CINEMA SOUND (Twice rapidly) is off. is on. Blink LG sound sync Booting Bluetooth ready (Twice per second) (LG TV) ready Blink Mute (Once per second) On -> Off Optical function... -
Page 8: Remote Control
Reduce the sound volume. Increase the sound volume. Mutes or unmutes the sound. Select Optical function. Select LG TV function. Select Bluetooth function. Note y Once the unit is shut down to standby, please wait several seconds before trying to use remote again. -
Page 9: Battery Installation
Getting Started Battery installation !Warning > Caution y DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD. Avoid using your fingernail to open the battery cover. Failure to comply can result in an injury. y The battery used in this device may present a fire or chemical burn hazard if mistreated. -
Page 10: Setting Up The Unit
Getting Started > Caution Setting up the unit y Do not try to set up this unit alone. It may need at least 2 persons to lift your TV. This unit is designed to be positioned under your Otherwise it may result in a personal injury and/or property damages. - Page 11 Getting Started Note 2. Connect the optical cable and the power cord to the unit. You can arrange the cables of the unit. 1. Fix the cable holder with screws. 2. Arrange the cables as shown below. 3. Connect the other end of optical cable connecting the unit to your TV.
- Page 12 Getting Started > Caution How to Affix the Ferrite Core y Do not place your TV on the edge of this (Optional) unit. Otherwise it may result in a personal You may need to attach Ferrite core in order to injury and/or property damages.
-
Page 13: Operating
TV's remote control with LG Sound Sync. It Before operating this Unit it is advised to turn is compatible with the LG TV that is supported LG OFF TV speaker Sound as it may create sound Sound Sync. Make sure of the LG Sound Sync logo differences between the 2 products running on your TV. -
Page 14: Auto Power On/Off
Operating AUTO POWER On/Off With wired connection 1. Connect your LG TV to the unit by using an This function automatically turns on/off the unit optical cable. (Refer to the pages 10 - 11.) when you turn on/off the TV or the external device (DVD Player, Blu-ray Disc Player, etc.) connected to... -
Page 15: Using Bluetooth Technology
Bluetooth devices in the other rooms nearby. device. Your unit appears as “LG SOUND PLATE (XX:XX)”. Connecting individual devices under Bluetooth® wireless technology does not incur any charges. A Note mobile phone with Bluetooth®... -
Page 16: Cinema Sound
Operating Note CINEMA SOUND y When using Bluetooth® technology, you have to make a connection between the When watching movies, you can enjoy optimized unit and the bluetooth device as close as sound effect through the prominent bass and possible and keep the distance. cinematic surround effect. -
Page 17: Troubleshooting
Troubleshooting Troubleshooting PROBLEM CAUSE & CORRECTION y The power cord is unplugged. Plug in the power cord. No Power y Check the condition by operating other electronic devices. y Incorrect input source is selected. Check the input source and select the correct input source. No sound y The mute function is activated. -
Page 18: Appendix
Appendix Specifications General Power requirements AC 120 V, 60 Hz Power consumption 25 W Dimensions (W x H x D) 700 mm x 38.5 mm x 320 mm (27.6" x 1.5" x 12.6") (With foot) Net Weight (Approx.) 3.8 kg (8.4 lb) Operating temperature 5 °C to 35 °C (41 °F to 95 °F) Operating humidity... -
Page 19: Trademarks And Licenses
Bluetooth® wireless technology. The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners. LAP340-NB_DUSALLK_ENG.indd 19... - Page 20 LG Customer Information Center 1-800-243-0000 USA, Consumer 1-888-865-3026 USA, Commercial Register your product Online! www.lg.com Printed in China LAP340-NB_DUSALLK_ENG.indd 20 2013-12-19 10:49:41...
