Summary of Contents for Intel PC Camera Pro Pack
- Page 1 Intel PC Camera Pro Pack ® ® with Intel Create and Share ™ Software Deluxe Getting Started Guide...
-
Page 2: Camera Mount
Camera Mount Notebook PC for your If you bought the Intel ® PC Camera Pro Pack to install on your notebook PC, we have the camera mount you need. It is designed specifically to attach the Intel ® PC Camera Pro to your notebook’s display. -
Page 3: What You Should Have
Congratulations! You can now start visiting with friends and family using your new Intel® Video Phone software as well as using the Intel® PC Camera Pro to capture video, audio, and still images that can be organized, stored, and incorporated into email postcards, movies, and home pages using Intel®... -
Page 4: Intel® ® Quick Tour
Create & Share Software Deluxe capabilities. Run the Quick Tour for tips and hints on what you can do with the Intel Create & Share Software Deluxe, from making video phone calls, creating and sending email postcards, making movies and web pages, to automatically taking snapshots and more. -
Page 5: Visit The Web Site
From the Windows Start menu click Intel Create & Share Software or double-click the desktop icon. To run the Configuration The first time you run the Intel Create & Share Wizard again, go Software Deluxe: Start>Programs The Configuration Wizard guides you through >Intel Create &... -
Page 6: Completing The Configuration Wizard
Create & Share new Intel® PC Camera Pro. Software> Register Online. The second time you run the Intel Create & Share Software Deluxe: Note • The Intel Registration Wizard appears so you Be sure to register can register your program. - Page 7 If you have more than one connection to the Internet and don’t care which connection is used, select ‘Use the default Internet connection’. Intel Video Phone will use the same kind of connection used the last time you connected to the Internet.
- Page 8 For help with pack/tsa.htm. problems that can 10 The Device Profile test profiles the camera and occur during the tunes the Intel Video Phone software for the best Configuration video quality. Click Test to test the video camera. Wizard see Appendix A...
- Page 9 Setting up the Intel® ® PC Camera Make sure the camera lens cover is open when you take pictures or create videos. Use the snapshot button to take snapshots, and the focus dial to focus the video picture. To adjust the quality (such as hue, saturation, or sharpness) of the video picture, follow the instructions in online Help under camera settings.
-
Page 10: Using The Camera's Video Input
Using the Camera’s Video Input The Intel PC Camera Pro has a connector to connect other video devices like camcorders or VCRs to your computer for use with the Intel Create & Share Software Deluxe. - Page 11 Video cable Audio cable From the Home Screen of the Intel Create & Share Software Deluxe, click Record Video. Click A/V Input on the Intel® Scene Recorder window. On the Video and Audio Input dialog, select “External video plugged into camera”. The Audio Source is automatically selected for you.
-
Page 12: What Are The Possibilities
Marketing at a later point in time. What is included? The Intel® PC Camera Pro Pack includes an Intel® PC Camera Pro and the Intel® Create & Share™ Software Deluxe that lets you use your PC to communicate in a variety of new ways. - Page 13 Features include: • Intel® Video Phone—Now you can talk to and see others at the same time using the Intel Video Phone software to make video phone calls over the Internet. For information about making Internet phone calls, see the section entitled “Preparing your first Internet phone...
- Page 14 • PC Camera Games—Use the Intel PC Camera Pro to put yourself into a virtual reality where you can pop the falling bubbles, shoot baskets, or hold the whole world in your hands. To put yourself in the action, click the PC Camera Games icon on the Home screen.
-
Page 15: Preparing For Your First Internet Phone Call
Preparing for your first Internet phone call One of the most popular uses of the Intel Create & Share Software is to make Internet video phone calls using an Intel Video Phone. You can make Internet video phone calls with anyone who has a standards compatible (H.323) video phone... - Page 16 To make an Internet video phone call: Start Intel Video Phone. Start the Intel Create & Share Software, and then click Make a Video phone call on the Home screen. Establish an Internet connection. Click the Internet button or the Internet On button.
-
Page 17: Helpful Hints For Making Internet Phone Calls
•Windows 98 and a Video-Ready modem. Create & Share Software> For information about making telephone video calls, Manual> User’s see Appendix B: Telephone Video Calls in the Intel® Manual. Create & Share™ Software Deluxe User’s Manual. Helpful Hints for making Internet phone calls To improve the sound quality: •... -
Page 18: To Improve The Video Quality
Other tips: • Remember, the person you are calling may have a different version of Intel Video Phone or a different video phone application. Be patient while making a call. • Place the camera on top of your computer and the microphone at least 6 inches from a computer speaker. - Page 19 For further instructions and solutions to common problems, consult the online Help. For customer support, check the Intel customer support Web site at: http://support.intel.com/support/createshare/ camerapack GETTING STARTED GUIDE...
-
Page 20: A Technical Specifications
Technical Specifications The following are the technical specifications for the Intel® PC Camera Characteristics Specification Image Sensor Progressive scan CCD, 640 x 480 Image Format YUV 4:2:0 Interface Universal Serial Bus (Rev. 1.00) Special Feature Flicker Free Operation (under 50 Hz/60 Hz fluorescent lighting) Maximum No. - Page 21 Characteristics Specification Lens F2.5 Tilt - Mechanical 22.5 deg down, 18 deg up Connector Series A type of USB receptacle Dimensions 71 mm x 45 mm x 109 mm Safety Standards UL, cUL EMC Standards FCC (B), CE, VCCI 1 For use only with UL listed PC. 2 Video capture and playback frame rate and resolution depend on many factors, including video source, system configuration, and software used.
- Page 22 Intel Camera Limited Warranty Limited Warranty Intel warrants that the Camera Hardware Product if properly used and installed, and the CD-ROM on which the accompanying software is provided, will be free from defects in material and workmanship for a period of one (1) year after the date of purchase.
- Page 23 If you return the Camera Hardware Product and/or CD-ROM to Intel, you must assume the risk of damage or loss during shipping. You must use the original packaging or the equivalent, and you must pay the postage. Intel may elect to replace or repair the Camera Hardware Product and/or CD-ROM with either a new or reconditioned product.
-
Page 24: Fcc Compliance Statement
TV. However, we do not guarantee the absence of interference. If you modify the board in any way, without getting approval from Intel Corporation, your board may violate FCC regulations. Violation of FCC regulations may cause the FCC to void your right to use the modified board. - Page 25 Intel World Wide Web Support You can reach Intel’s automated support services 24 hours a day, every day at no charge. The services contain the most up-to-date information about Intel products. You can access installation instructions, troubleshooting information, and general product information.
