SMC Networks SMC-EZ1026DT User Manual

Hide thumbs Also See for SMC-EZ1026DT:
Table of Contents

Advertisement

Quick Links

Download this manual
EZ Switch 10/100
24-Port Fast Ethernet Switch
24 MDI-X ports—connect to PCs or servers
One port with push-button MDI/MDI-X selection
Optional Gigabit modules for high-speed uplink
Auto-negotiation of speed and duplex mode
Half- and full-duplex flow control
Desktop and rack mountable
Broadcast storm control
Support for up to eight trunk ports
Configurable VLAN port groups

User Guide

SMC-EZ1026DT

Advertisement

Table of Contents
loading

Related Manuals for SMC Networks SMC-EZ1026DT

Summary of Contents for SMC Networks SMC-EZ1026DT

  • Page 1: User Guide

    One port with push-button MDI/MDI-X selection Optional Gigabit modules for high-speed uplink Auto-negotiation of speed and duplex mode Half- and full-duplex flow control Desktop and rack mountable Broadcast storm control Support for up to eight trunk ports Configurable VLAN port groups User Guide SMC-EZ1026DT...
  • Page 3 EZ Switch 10/100 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 6 Hughes Irvine, CA 92618 May 2001 Phone: (949) 707-2400 Pub. # 150525-301...
  • Page 4 6 Hughes, Irvine, CA. All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark; and EZ Switch is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.

  • Page 5: Limited Warranty

    IMITED ARRANTY Limited Warranty Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller.
  • Page 6 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 6 Hughes Irvine, CA 92618...

  • Page 7: Fcc Class A

    EC Conformance Declaration - Class A SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain.

  • Page 8: Safety Compliance

    OMPLIANCES Industry Canada - Class A This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matérial brouilleur: “Appareils Numériques,”...
  • Page 9 OMPLIANCES Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
  • Page 10 OMPLIANCES...

  • Page 11: Table Of Contents

    ABLE OF ONTENTS About the EZ Switch 10/100 1 Features and Benefits ....... . 2 Front Panel LEDs .
  • Page 12 ABLE OF ONTENTS Console Port to 9-Pin COM Port on PC ....37 Specifications ......38 EZ Switch 10/100 .

  • Page 13: About The Ez Switch 10/100

    BOUT THE EZ S 10/100 WITCH The EZ Switch 10/100 SMC-EZ1026DT is a 24-port Fast Ethernet switch. It has one slot on the front panel for optional slot-in 1000BASE-T, 1000BASE-SX (SC-type), 100BASE-FX (SC-Type), or 10BASE-T/100BASE-TX modules. The 10BASE-T/100BASE-TX ports deliver dedicated 10/100 Mbps links to each attached LAN segment.

  • Page 14: Features And Benefits

    EZ S 10/100 BOUT THE WITCH Features and Benefits N Push button selection for MDI/MDI-X cable connection on one port allows connections to hubs or switches to be made with straight-through cabling N Optional dual-port 1000BASE-SX, 1000BASE-T modules for high-speed uplink N Optional 8-Port 10BASE-T/100BASE-TX expansion module N Optional 2-Port 100BASE-FX expansion module gives remote 100 Mbps links up to a distance of 2 km...

  • Page 15: Front Panel Leds

    EZ S 10/100 BOUT THE WITCH Front Panel LEDs The front panel of the switch provides status LEDs for “at-a-glance” system monitoring. The following table details the functions of the various indicators: Port and System Status LEDs Condition Status Power The switch is receiving power.

  • Page 16: Rear Panel

    EZ S 10/100 BOUT THE WITCH Rear Panel The AC power receptacle and console port are located on the rear panel of the switch. Optional Modules There are four optional modules; a 2-port 1000BASE-T, a 2-port 1000BASE-SX, an 8-port 10BASE-T/100BASE-TX module and a 2-port 100BASE-FX module.
  • Page 17 EZ S 10/100 BOUT THE WITCH Module Port Status LEDs Condition Status SMC-EZ1026GT Module Ports The port has established a valid network connection and communications have been set to 10 Mbps. On Yellow The port has established a valid network connection and communications have been set to 100 Mbps.
  • Page 18 EZ S 10/100 BOUT THE WITCH Module Port Status LEDs Condition Status SMC-EZ1026FMSC LINK/ The port has not established any network connection. The port has established a valid 100 Mbps network connection. Flashing Traffic is passing through the port. SMC-EZ1026T Module Ports LINK/ The port has not established any network connection.

  • Page 19: Installing The Switch

    19-inch equipment rack. Equipment Checklist After unpacking the EZ Switch 10/100, check the contents of the box to be sure you have received the following components: • EZ Switch 10/100 SMC-EZ1026DT • Appropriate AC power cable • Rackmount kit •...
  • Page 20 NSTALLING THE WITCH • The status LEDs should be clearly visible. • There should be adequate space (approximately two inches) on all sides for proper air flow. Before rack mounting the switch, pay particular attention to the following factors: • Temperature: Since the temperature within a rack assembly may be higher than the ambient room temperature, check that the rack-environment temperature...

  • Page 21: Instructions

    NSTALLING THE WITCH Instructions 1. Positioning the Switch: For desktop or shelf mounting, attach the four adhesive feet to the bottom of the switch. For rack-mounting, attach the mounting brackets on both sides of the switch with the screws provided, and install the switch in the rack.
  • Page 22 NSTALLING THE WITCH 2. Applying Power: Plug one end of the power cable into the power receptacle at the back of the switch, and the other end into an appropriate electrical outlet. Check the Power LED to be sure power is on. Note: It is not necessary to power off the switch before connecting or disconnecting any UTP cables, as these...
  • Page 23 NSTALLING THE WITCH The maximum length for 100BASE-FX fiber is shown in the following table. Fiber Type Optical Maximum Cable Length Wavelength Multimode 1300 nm 2 km (1.24 miles) See “Cable Specifications” on page 30 for further information. Note: As a general rule, the length of fiber optic cable for a single switched link should not exceed 2 kilometers (1.24 miles) for multimode fiber.
  • Page 24 NSTALLING THE WITCH 6. Connecting to a 1000BASE-T Port: The 1000BASE-T module operates at 1000, 100 and 10 Mbps and supports IEEE 802.3x flow control. Auto-negotiation is used to select the optimal transmission speed and communication mode for each connection. Use Category 5 or 5e cable of maximum length 100m (328 feet).

  • Page 25: Sample Application

    NSTALLING THE WITCH Sample Application In the figure below, the EZ Switch 10/100 is operating as a collapsed backbone for a small LAN. It is providing dedicated 20 Mbps full-duplex connections to workstations and 200 Mbps full-duplex connections to power users and servers. An optional Gigabit fiber module installed in the front panel is used to provide a 2 Gbps full-duplex link to a switch up to 550 m away.

  • Page 26: Configuring The Switch From The Console Port

    ROM THE ONSOLE Configuration The SMC-EZ1026DT can be configured, via a console cable, from a PC using Windows 95, Windows 98 or Windows NT 4.0. First, connect a PC to the switch using an RS232 null-modem cable. Then install and run the utility program to configure the switch.

  • Page 27: Program Description

    ONFIGURING THE WITCH ROM THE ONSOLE Program Description Main Window From this window you can read the current configuration of the switch, set a new configuration and write this configuration into the device. The parts of the main window are summarized as follows: Device Type Select the device type that you wish to configure.
  • Page 28 ONFIGURING THE WITCH ROM THE ONSOLE RS232 COM Port Select the console port to connect to the switch. File: Open Browse for an existing configuration file and open it to configure the switch. File: Save Save the current configuration to a switch configuration file. Properties This opens up the three-page properties window from which new configuration settings may be entered.

  • Page 29: Properties Window

    ONFIGURING THE WITCH ROM THE ONSOLE Properties Window Port Page Use this page to configure the parameters of the ports. Click on a radio button in the “Port Selection” section to select the port to be configured and then select the properties from the configuration section.
  • Page 30 ONFIGURING THE WITCH ROM THE ONSOLE Full-Duplex Flow Control (802.3X) This eliminates frame loss by “blocking” traffic from end stations or segments connected directly to the switch. IEEE 802.3x Flow Control is used for full duplex. Auto-Negotiation Auto-negotiation for data rate and duplex mode may be enabled. If auto-negotiation is disabled, data rate and duplex mode must be specified.

  • Page 31: Trunk Assignment

    ONFIGURING THE WITCH ROM THE ONSOLE Trunk Assignment On this page you can configure port trunks. Ports can be combined into an aggregate link to increase the bandwidth of a network connection or ensure fault recovery. You can group ports into trunks that consist of two to eight ports.
  • Page 32 ONFIGURING THE WITCH ROM THE ONSOLE • All the ports in a trunk have to be treated as a whole when moved from/to, added or deleted from a VLAN. • Configure the trunk prior to connecting any cable between the switches to avoid creating a loop.
  • Page 33 ONFIGURING THE WITCH ROM THE ONSOLE Load Balancing Method: Port Based The port-based load-balancing method is an explicit port assignment scheme. Each port that does not belong to a particular trunk must be assigned to a port in that trunk. When the switch receives a packet with a DA that is associated with a trunk , it will automatically forward the packet to the trunk port that the receiving port has been assigned to.
  • Page 34 ONFIGURING THE WITCH ROM THE ONSOLE After selecting a trunk, click the “Port Based” button under “Load Balancing Mapping” to invoke the dialog box “Port Balanced Trunk Port Mapping for Trunk X.” Then click the radio buttons to configure the port-based load-balancing mapping, as shown below.
  • Page 35 ONFIGURING THE WITCH ROM THE ONSOLE VLAN On this page you can configure the membership of VLAN groups. A VLAN group is basically a broadcast domain, but ports and trunks may belong to more than one VLAN group. Any individual trunk or port can be a member of a VLAN group.
  • Page 36 ONFIGURING THE WITCH ROM THE ONSOLE Click on the “Add” button to invoke the dialog box “Add a new VLAN Group.” click on the “Trunk” and “Individual Port” checkboxes to configure the VLAN group, then click “OK.” Note: Once a VLAN group has been added, all other unselected ports will be gathered into one implicit VLAN group.

  • Page 37: Default Switch Configuration

    ONFIGURING THE WITCH ROM THE ONSOLE Default Switch Configuration If you experience problems in configuring the switch, you can return it to its default configuration by downloading default setting files. These files are provided on diskette 2/2 of the Setup Utility. The file that is used depends on the module installed, as shown in the table below.

  • Page 38: Default Settings

    ONFIGURING THE WITCH ROM THE ONSOLE Default Settings The following table shows the default configuration: Page Option Default Address Learning Enabled Port Broadcast Storm Control Disabled Full-Duplex Flow Control Enabled Auto-Negotiation Enabled Trunk Load Balancing Method Port-Based Assignment Trunk Selection None VLAN VLAN Group List...

  • Page 39: Troubleshooting

    ROUBLESHOOTING ROUBLESHOOTING 1. Symptom Power LED does not light after power on. Probable Causes Power outlet or power cord may be defective. Possible Solutions • Check for loose connections. • Check the power outlet by using it for another device. •...
  • Page 40 ROUBLESHOOTING 3. Symptom Computer A can connect to computer B, but cannot connect to computer C through the 24-port switch. Probable causes • Computers A and C may be in different VLAN groups. • Computer C’s network device may not be working. •...
  • Page 41 ROUBLESHOOTING • Verify that Category 5 cable is used for 100 Mbps RJ-45connections and that the length of any cable does not exceed 100 meters (328 feet). • Verify that cross-over cables are used for MDI-X to MDI-X connections and straight-through cables are used for MDI-X to MDI connections.

  • Page 42: Cables

    ABLES ABLES ABLE PECIFICATION Maximum 10BASE-T, 100BASE-TX, 1000BASE-T and 100BASE-FX Cable Length Cable Type Max. Length Connector 10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45 100BASE-TX Cat. 5 100-ohm UTP 100 m (328 ft) RJ-45 1000BASE-T Cat.

  • Page 43: Connector Pin Assignments

    ABLES RJ-45 Connector Pin Assignments Caution: DO NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. 10BASE-T/100BASE-TX Pin Assignments An Ethernet or Fast Ethernet twisted-pair link segment requires two pairs of wires.
  • Page 44 ABLES Straight-Through Wiring If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires must be straight-through. Straight-Through RJ-45 Pin Assignments End 1 End 2 1 (RD+) 1 (TD+) 2 (RD-) 2 (TD-)

  • Page 45: 1000Base-T Pin Assignments

    ABLES 1000BASE-T Pin Assignments The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected. Note that for 1000BASE-T operation, all four pairs of wires are used for both transmit and receive. Use 100-ohm Category 5 or 5e unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for 1000BASE-T connections.

  • Page 46: 1000Base-T Cable Requirements

    ABLES 1000BASE-T Cable Requirements All Category 5 UTP cables that are used for 100BASE-TX connections should also work for 1000BASE-T, providing that all four wire pairs are connected. However, it is recommended that for all critical connections, or any new cable installations, Category 5e (enhanced Category 5) cable should be used.

  • Page 47: Adjusting Existing Category 5 Cabling To Run 1000Base-T

    ABLES Adjusting Existing Category 5 Cabling to Run 1000BASE-T If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: 1.

  • Page 48: Console Port Pin Assignments

    ABLES Console Port Pin Assignments The DB-9 serial port on the switch’s rear panel is used to connect to the switch for out-of-band console configuration. The switch can be configured from a PC running the Setup utility program. The pin assignments used to connect to the serial port are provided in the following tables.

  • Page 49: Db-9 Port Pin Assignments

    ABLES DB-9 Port Pin Assignments CCITT Description Switch’s PC DB9 Modem Signal Circuit Signal DB9 DTE DB25 Direction Pin # Pin # DCE Pin # DTE-DCE DCD (Data Carrier Detected) 1 <------ RxD (Received Data) <------ TxD (Transmitted Data) ------> 108.2 DTR (Data Terminal Ready) ------>...

  • Page 50: Specifications

    PECIFICATIONS PECIFICATIONS EZ S 10/100 WITCH Model SMC-EZ1026DT Access Method CSMA/CD Ports 24 10BASE-T/100BASE-TX, with auto-negotiation Network Interface RJ-45: 100 ohm, UTP cable 10BASE-T - Categories 3, 4, or 5 100BASE-TX - Category 5 LEDs System: Power Ports: LINK/ACT, FDX/COL...
  • Page 51 PECIFICATIONS Size 440 x 240 x 43 mm (17.3 x 9.5 x 1.69 in.) Weight 3 kg (6.6 lbs) Temperature Operating: 0 to 55 °C (32 to 131 °F) Storage: -40 to 85 °C (-40 to 185 °F) Humidity 5% to 95% non-condensing +Power Requirements 100 to 240 VAC (±10%) 50 to 60 Hz (±3 Hz) Power Consumption...

  • Page 52: Optional Modules

    PECIFICATIONS Optional Modules 100BASE-TX Module Model SMC-EZ1026T Access Method CSMA/CD Ports 8 10BASE-T/100BASE-TX, with auto-negotiation Communication Mode Full and half duplex with auto-negotiation Network Interface RJ-45: 100 ohm, UTP cable 10BASE-T - Categories 3, 4, or 5 100BASE-TX - Category 5 LEDs LINK/ACT, FDX/COL Standards...

  • Page 53: 100Base-Fx Module

    PECIFICATIONS Communication Mode Full and half duplex with auto-negotiation Network Interface RJ-45: 100 ohm, UTP cable 10BASE-T - Categories 3, 4, or 5 100BASE-TX - Category 5 1000BASE-T - Category 5 or 5e LEDs SPD, LINK, ACT, FDX/Col Standards IEEE 802.3 IEEE 802.3u IEEE 802.3ab 100BASE-FX Module...

  • Page 54: 1000Base-Sx Module

    PECIFICATIONS 1000BASE-SX Module Model SMC-EZ1026GSSC, Access Method CSMA/CD Ports 2 1000BASE-SX Communication Mode Full duplex Network Interface SC connector: 50/125 or 62.5/125 micron multimode fiber cable. LEDs LNK, ACT Standards 802.3z...
