EZ Switch 10/100
24/16-Port Fast Ethernet Switch
24/16 auto-MDI/X ports—connect to PCs or other
switches or hubs
Optional fiber uplink for easy network expansion
Plug and play—nothing to configure, no crossover
cables required
Auto-negotiation of speed and duplex mode
Full-duplex support on all ports
Half and full-duplex flow control
Desktop and rack mountable
User Guide
SMC-EZ1024FDT
SMC-EZ1016FDT
Advertisement
Table of Contents
Related Manuals for SMC Networks 24/16
Summary of Contents for SMC Networks 24/16
-
Page 1: User Guide
EZ Switch 10/100 24/16-Port Fast Ethernet Switch 24/16 auto-MDI/X ports—connect to PCs or other switches or hubs Optional fiber uplink for easy network expansion Plug and play—nothing to configure, no crossover cables required Auto-negotiation of speed and duplex mode Full-duplex support on all ports... - Page 2 EZ Switch 10/100 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 6 Hughes Irvine, CA 92618 Phone: (949) 707-2400 March 2001 Pub. # 150506-301 R01...
- Page 3 6 Hughes, Irvine, CA. All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark; and EZ Switch is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
-
Page 4: Limited Warranty
IMITED ARRANTY Limited Warranty Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. - Page 5 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 6 Hughes Irvine, CA 92618...
- Page 6 EC Conformance Declaration - Class A SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain.
-
Page 7: Safety Compliance
OMPLIANCES Industry Canada - Class A This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus”, ICES-003 of Industry Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matérial brouilleur: “Appareils Numériques”, NMB-003 édictée par l’Industrie. - Page 8 Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
- Page 9 OMPLIANCES...
-
Page 10: Table Of Contents
Specifications ......15 EZ Switch 10/100 ........15... - Page 11 ABLE OF ONTENTS...
-
Page 12: About The Ez Switch 10/100
WITCH The EZ Switch 10/100 SMC-EZ1024FDT and SMC-EZ1016FDT are 24/16-port Fast Ethernet switches. They have one slot on the rear panel for a fiber optic uplink module with one 100BASE-FX (SC, ST, MTRJ or VF-45) type port. The 10BASE-T/100BASE-TX ports deliver dedicated 10/100 Mbps links to each attached LAN segment. -
Page 13: Features And Benefits
EZ S 10/100 WITCH Features and Benefits N Auto configuration for MDI/MDI-X cable connection allows connections to servers, workstations, hubs or switches to be made with straight-through cabling N Optional multimode and single-mode fiber uplink modules N Auto-negotiation of half or full duplex on all ports N IEEE 802.3 and 802.3u compliance ensures compatibility with standards-based hubs, switches and cards from any vendor N Half and full-duplex flow control prevents packets from being... -
Page 14: Front Panel Leds
Front Panel LEDs The front panel of the switch provides status LEDs for “at-a-glance” system monitoring. The following table details the functions of the various indicators: Condition Power RJ-45 Ports Link/ Flashing 100M Port and System Status LEDs Status The switch is receiving power. -
Page 15: Rear Panel
Link/ Flashing Note: All optional modules operate in full-duplex mode only. Rear Panel The AC power receptacle is located on the rear panel of the switch. Port and System Status LEDs Status The module has established a valid network connection. -
Page 16: Connecting To A Fiber Optic Port
The fiber modules are shown in the figure below. When you connect fiber cable to a 100 Mbps module on the switch, be sure you use an SC, ST, MTRJ or VF-45 type connector, depending on the module. When inserting the cable, be sure the tab on the plug clicks into position to ensure that it is properly seated. - Page 17 EZ S 10/100 WITCH The fiber module operates at 100 Mbps, full duplex, and supports 1EEE 802.3x flow control. The maximum length for 100BASE-FX fiber is as shown in the following table. Fiber transceiver Multimode Single-mode Optical Maximum Cable Length Wavelength 1300 nm 2 km (1.24 miles)
-
Page 18: Installing The Switch
NSTALLING THE The EZ Switch 10/100 can be placed on a desktop or shelf, or installed in a standard 19-inch equipment rack. Equipment Checklist After unpacking the EZ Switch 10/100, check the contents of the box to be sure you have received the following components: •... - Page 19 Make sure that a properly grounded power outlet is within 8 feet (2.44 meters) of the switch and is powered from an independent circuit breaker. As with any equipment, using a filter or surge...
-
Page 20: Instructions
Instructions 1. Positioning the Switch: For desktop or shelf mounting, attach the four adhesive feet to the bottom of the switch. For rack-mounting, attach the mounting brackets on both sides of the switch with the screws provided, and install the switch... - Page 21 WITCH 2. Applying Power: Plug one end of the power cable into the power receptacle at the back of the switch, and the other end into an appropriate electrical outlet. Check the Power LED to be sure power is on.
-
Page 22: Sample Applications
NSTALLING THE WITCH Sample Applications In the figure below, the EZSwitch 10/100 is operating as a collapsed backbone for a small LAN. It is providing dedicated 20 Mbps full-duplex connections to workstations and 200 Mbps full-duplex connections to power users and servers. -
Page 23: Troubleshooting
Replace the power cord. 2. Symptom Link LED does not light after connection is made. Probable Causes Switch port, network card or cable may be defective. Possible Solutions • Check that the switch and attached device are both powered on. -
Page 24: Cables
ABLE PECIFICATION Cable 10BASE-T 100BASE-TX 100BASE-FX 100BASE-FX Note: If you need to connect from an SC connector to a device with 62.5/125 micron cable that has ST-type connectors, SMC provides an optional SC-ST Converter (Part Number: 99-012034-091). Cable Types and Specifications Type Cat. -
Page 25: Rj-45 Connector Pin Assignments
Each wire pair must be attached to the RJ-45 connector in a specific orientation detailed below. Because all ports on this switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. -
Page 26: Specifications
EZ S 10/100 WITCH Models SMC-EZ1024FDT SMC-EZ1016FDT Ports SMC-EZ1024FDT - 24 RJ-45 ports SMC-EZ1016FDT - 16 RJ-45 ports Network Interface RJ-45: 100 ohm, UTP cable 10BASE-T - Categories 3, 4, or 5 100BASE-TX - Category 5 LEDs Power - one Link/Act (activity) - one per port 100M - one per port FDX (full duplex) - one per port... - Page 27 PECIFICATIONS Size 17.32 x 6.81 x 1.69 in. (44.0 x 17.3 x 4.3 cm) Weight SMC-EZ1024FDT 5.3 lbs (2.3 kg) SMC-EZ1016FDT 4.8 lbs (2.2 kg) Temperature Operating: 32 to 122 °F (0 to 50 °C) Storage: -40 to 158 °F (-40 to 70 °C) Humidity, non-condensing 5% to 95% Power Requirements...
-
Page 28: Fiber Uplink Modules
TÜV/GS (EN60950) Warranty Limited Lifetime Fiber Uplink Modules Models SMC-EZ108FMSC, SMC-EZ108FSSC, SMC-EZ108FMST, SMC-EZ108FSST, SMC-EZ108FMMT, SMC-EZ108FMMT, SMC-EZ108FMVF Access Method CSMA/CD Communication Rate 100 Mbps Communication Mode Full and half duplex (via jumper setting) Network Interface SC, ST or MTRJ connector, 50/125 or 62.5/125 micron multimode fiber cable. - Page 29 PECIFICATIONS...
- Page 31 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (24 hours, 7 days a week) (800) SMC-4-YOU; (949) 707-2400; (949) 707-2460 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1188 748740; 44 (0) 1189 748741 (Fax) INTERNET E-mail address: techsupport@smc.com...
